Boneco therapure TP350 User manual

TP350
MANUAL
Read and save these instructions
Lisez et enregistrez ces instructions
Lea y guarde estas instrucciones

2
EN Always observe all safety notes (included separately in delivery).
FR Veuillez respecter impérativement l’ensemble des consignes de sécurité
(fournies séparéme nt dans le contenu de la livraison).
ES Tenga en cuenta siempre todas las indicaciones de seguridad
(se suministran aparte junto con el producto).

3

4
EN Instructions for use 5
FR Mode d’emploi 13
ES Instrucciones de uso 21

5
en
INSTRUCTIONS FOR USE

6
en
TABLE OF CONTENTS
Technical data 7
Introduction 8
Availability of accessories 8
Items included 8
Overview and part names 9
Indicators on the display 10
Button panel on the appliance 11
Starting up and switching o 12
Auto mode and manual control 13
Night mode 14
24-hour timer 15
Canceling the timer 15
Measuring the air quality 16
Switching the ionizer on and o 17
About the ionizer 17
Switching the ionizer on and o 17
Switching the UV lamp on and o 18
About the UV lamp 18
Switching the UV lamp on and o 18
Notes on care 19
Care instructions 19
Cleaning 20
Cleaning 20
Replacing the ATP350 filter 21
About the ATP350 filter 21
Replacing the ATP350 filter 21
Replacement filters 22
Replace the UV lamp 23
About the UV lamp 23
Removing a used UV lamp 23
Inserting a new UV lamp 24
Replacement for TPP6200 UV lamp 24
Disposing of a UV lamp 25

7
en
TECHNICAL DATA
* subject to change
** at 120 V ~ 60 Hz
Mains voltage 120 V ~ 60 Hz
Power consumption 77 W
Filter performance CADR (Dust, Smoke, Pollen) 120, 114, 111 cfm / 240, 193, 189 m3/h**
Dimensions L× W× H 8.9× 8.6 ×24.4 in (225 ×218 ×621 mm)
Weight (empty) 9.3 lbs (4.23 kg)
Operation noise level 60 dB(A)
TECHNICAL DATA*

8
en
INTRODUCTION
ITEMS INCLUDED
Therapure TP350 Quick Manual Safety instructions
HEALTHY AIR IS A BASIC NEED
There is little to which we react with greater sen-
sitivity than poor air. And yet many people do not
pay enough attention to air quality, which has
consequences for health and quality of life. This
makes us all the more pleased that you have cho-
sen a Therapure appliance to ensure that the basic
need for healthy room air is satisfied for you and the
people around you.
AVAILABILITY OF ACCESSORIES
You can obtain replacements for spent accessories
as well as additional accessories:
• At your Therapure specialist dealer,
• At www.envion.com

1
4
2
3
5
6 7 98
9
en
OVERVIEW AND PART NAMES
1Transport handle
2Display
3Function buttons
4Air quality indicator
5Air outlet
6UV lamp
7UV lamp cover
8ATP350 filter
9Air inlet / rear cover

10
en
INDICATORS ON THE DISPLAY
Symbol Meaning
Timer's remaining time indicator 15
Current performance level 13
UV lamp is activated 18
Ionizer is activated 17
Automatic mode is activated 13
Symbol Required action
Replace the filter 21
Replace the UV lamp 23

11
en
BUTTON PANEL ON THE APPLIANCE
Button Function
Set remaining time on timer 15
Switch on “AUTO” mode 13
Switch UV lamp on/o 18
Switch ionizer on/o 17
Button Function
Regulate the performance 13
Clear warning for filter /UV lamp 23
On /o switch 12
Night mode on /o 14

12
en
STARTING UP AND SWITCHING OFF
54
3
6
2
1
Attach the cable using the notch. Plug the Therapure TP350 in at a power outlet.
Switch on automatic mode if necessary.
Switch on the Therapure TP350.
Unroll as much cable as necessary.
Select the desired performance level.

13
en
3. To exit automatic mode and switch to manual
mode, tap the button for the performance level.
Each time you tap, you switch between the per-
formance levels: I› II › III › I
The last setting is saved when you switch o the ap-
pliance and restored the next time you switch it on.
On the other hand, if you disconnect the Therapure
TP350 from the power outlet, automatic mode will
be activated the next time you switch the appliance
on.
The Therapure TP350 has an Auto mode in which the
appliance controls its performance independently.
1. Switch on the Therapure TP350.
2. To switch the appliance to Auto mode, tap the
AUTO button. The AUTO indicator appears on the
display.
AUTO MODE AND MANUAL CONTROL

14
en
NIGHT MODE
Night mode deactivates the air quality indicator
when the appliance is used in a bedroom, but night
mode does not aect the function in any way.
1. Switch on the Therapure TP350.
2. To activate night mode, press the on/o switch
for five seconds.
3. To switch o night mode, press the on/o switch
again for five seconds.
The last setting is saved when you switch o the ap-
pliance and restored the next time you switch it on.
On the other hand, if you disconnect the Therapure
TP350 from the power outlet, night mode will be
deactivated the next time you switch the appliance
on.

15
en
The Therapure TP350 has a 24-hour timer, which is
controlled by the hour. After the desired time has
elapsed, the appliance is switched o automati-
cally.
1. Switch on the Therapure TP350.
2. Press the TIME button repeatedly until the de-
sired number of hours is set.
After the desired time has elapsed, the Therapure
TP350 is switched o automatically.
24-HOUR TIMER
CANCELING THE TIMER
To cancel the timer early, press the TIME button re-
peatedly until the hours indicator after the 24 indi-
cator goes out.

16
en
MEASURING THE AIR QUALITY
The Therapure TP350 has an integrated particle
sensor that measures the air quality. The result is
indicated by the color of the LED under the control
panel.
The air quality is good; no noteworthy
air pollution is measured.
The air is moderately polluted by
particles. Increase the performance of
the appliance.
The air is highly polluted by particles.
Thoroughly ventilate the room and set
the Therapure TP350 to the maximum
performance level.

17
en
SWITCHING THE IONIZER ON AND OFF
ABOUT THE IONIZER
The Therapure TP350 has a built-in ionizer that
can be switched on and o. It outputs negatively
charged ions into the air, which attach to the fine
dust. The negatively charged fine dust particles at-
tract other particles in the air, so they become too
heavy to stay in the air and fall to the floor, where
they get wiped up along with the household dust.
The ionizer generates a very low amount
of ozone. Do not use the ionizer if someone
around you is allergic to ozone.
SWITCHING THE IONIZER ON AND OFF
1. To switch the ionizer on, tap the ION button.
The ION indicator appears on the display:
2. To switch the ionizer o, press the ION button
again.

18
en
SWITCHING THE UV LAMP ON AND OFF
ABOUT THE UV LAMP
The Therapure TP350 has a built-in UV lamp that
can be switched on and o. The lamp's high-energy
properties help remove specific viruses and bacte-
ria. Thus the UV lamp contributes to the hygiene of
your living space.
The UV lamp generates a low amount of
ozone. Do not use the UV lamp if someone
around you is allergic to ozone.
SWITCHING THE UV LAMP ON AND OFF
1. To switch the UV lamp on, tap the UV button.
The UV indicator appears on the display:
2. To switch the UV lamp o, press the UV button
again.

19
en
CARE INSTRUCTIONS
The Therapure TP350 is a low-maintenance appli-
ance, which needs only a very small amount of at-
tention. Accordingly, it is easy to care for.
Always unplug the Therapure TP350 from the
power outlet before you start cleaning or
doing maintenance! Failure to do so can result in
electric shock and fatal injury! When liquid is used,
there is a danger of electric shock. Unplug the pow-
er plug every time before cleaning.
All parts inside and outside the Therapure
TP350 are designed for dry cleaning. Use a
damp cloth only for removing dirt on the outside.
Interval Task
Weekly Wipe o the appliance with a dry cloth
Every 2 weeks Clean the ventilation slots and the ATP350 filter with a vacuum cleaner
As needed Replace the UV lamp or the filter
NOTES ON CARE

20
en
CLEANING
1. Disconnect the Therapure TP350 from the power
outlet.
2. Wipe o the outside of the appliance with a dry
cloth.
3. Open the rear cover.
4. Remove coarse dirt and dust from the ATP350 fil-
ter using a vacuum cleaner.
5. Close the rear cover.
6. Plug the Therapure TP350 in at a power outlet.
CLEANING
