Bosch BCS 210 User manual

Robert Bosch GmbH
72757 Reutlingen
Germany
www.bosch-ebike.com
0 275 U07 XCX (2023.03) T / 43
en Original operating instructions
fr Notice d'utilisation d'origine
es Instrucciones de servicio originales
Ownerʼs Manual
Charger
BCS 210 | BCS230
This manual contains important safety,
performance and service information.
Read and understand it along with the
information provided to you by your
bicycle manufacturer before using the
product, and keep it for reference.
Cette notice contient d'importantes
informationes sur la sécurité, les
performances et l'entretien. Lisez-les et
comprenez-les ainsi que les informations
fournies par le fabricant de votre vélo
avant d'utiliser le produit, et conservez-
les pour référence ultérieure.
Este manual contiene información
importante de seguridad, rendimiento y
mantenimiento. Léalo y asegúrese de
entenderlo junto con la información que
le ha facilitado el fabricante de su
bicicleta antes de usar el producto;
guárdelo a modo de referencia.

0 275 U07 XCX | (15.03.2023) Bosch eBike Systems

English – 1
Table of Contents
Introduction ..................................................................................................................................... 2
About Warnings............................................................................................................................ 2
General Warnings ......................................................................................................................... 2
Using your Manual ........................................................................................................................ 3
On-product warning labels.................................................................................................................. 4
Operating the Charger ....................................................................................................................... 5
Safety Instructions........................................................................................................................ 5
Product Description and Specifications ........................................................................................... 7
Operation.................................................................................................................................... 9
Maintenance/cleaning ................................................................................................................. 11
Troubleshooting.............................................................................................................................. 12
Battery Recycling Program................................................................................................................ 13
Bosch eBike Systems 0 275 U07 XCX | (15.03.2023)

English – 2
Introduction
About Warnings
This manual contains many DANGER, WARNING,
and CAUTION indicators concerning the conse-
quences of failure to use, assemble, maintain, store,
inspect and dispose of a Bosch-equipped eBike in a
safe manner.
– The combination of the safety alert symbol and the
word DANGER indicates a hazardous situation
that, if not avoided, will result in death or serious
injury.
– The combination of the safety alert symbol and the
word WARNING indicates a hazardous situation
that, if not avoided, could result in death or serious
injury.
– The combination of the safety alert symbol and the
word CAUTION indicates a hazardous situation
that, if not avoided, could result in minor or moder-
ate injury.
General Warnings
Read all safety warnings and all in-
structions. Failure to follow the warn-
ings and instructions may result in
death or serious injury.
Save all safety warnings and instructions for fu-
ture reference.
The term eBike battery used in these operating in-
structions refers to all original Bosch eBike batteries.
uRead ALL accompanying manuals before riding
the bike for the first time. Your Bosch Drive Sys-
tem comes with additional manuals and documents
provided by the manufacturer of the bicycle and
other components. Failure to read and understand
safety information can result in death or serious in-
jury.
WARNING
uThis manual contains important safety, perfor-
mance and service information. Read it before
you take the first ride on your new bicycle, and
keep it for reference. The manual can also be found
online at www.bosch-ebike.com.
uThis manual is intended to be read together with
the separate user manual provided with your bi-
cycle. Be sure to read all provided documents in-
cluding labels on the product before your first ride.
uTake responsibility for your own SAFETY. If you
have any questions or do not understand some-
thing, consult with your dealer or the bicycle or
component manufacturer.
uSome eBike accessories may present a choking
hazard to small children. Keep these accessories
away from children.
CAUTION
uThe Bosch Drive System adds weight to your bi-
cycle which you may not be used to lift. Avoid in-
jury, use proper lifting techniques.
0 275 U07 XCX | (15.03.2023) Bosch eBike Systems

English – 3
Using your Manual
In addition to the functions outlined here, changes to
software relating to troubleshooting and functional
modifications may be introduced at any time.
Graphics
The bicycle shown in this manual may differ slightly
from your bicycle, but will be similar enough to help
you understand our instructions.
RIGHT-HAND and LEFT-HAND sides are determined
by facing in the direction the bicycle will travel when
going forward. When you see a broken line (------), the
item referred to is hidden from view.
Bosch eBike Systems 0 275 U07 XCX | (15.03.2023)

English – 4
On-product warning labels
A
B
AWide range charger
BCompact charger
A short version of important safety warnings in Eng-
lish, French and Spanish with the following content
can be found on the bottom side of the charger
(marked with number(4) in the representation on the
graphics page):
– For safe operation, see manual.
– Risk of electric shock
– Indoor use only
– Charge only batteries for the Bosch eBike Systems.
Other batteries may burst causing personal dam-
age.
– Do not replace the plug assembly as risk of fire or
electric shock may result.
0 275 U07 XCX | (15.03.2023) Bosch eBike Systems

English – 5
Operating the Charger
Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS SAVE THESE
INSTRUCTIONS –
This manual contains important safety and operat-
ing instructions for this battery charger.
uBefore using battery charger, read all instructions
and cautionary markings on battery charger, bat-
tery, and product using battery.
CAUTION
uTo reduce risk of injury, charge only batteries of
the Bosch eBike Systems. Other types of batter-
ies may burst causing personal injury and damage.
uRead and understand all safety warnings and in-
structions. Failure to follow the below warnings
could result in death or serious injury.
Save all safety warnings and instructions for fu-
ture reference.
The term eBike battery used in these operating in-
structions refers to all original Bosch eBike batteries.
DANGER
uOnly charge Bosch eBike lithium-ion battery
packs with approved Bosch eBike chargers. The
battery pack voltage must match the battery
pack charging voltage of the charger. Otherwise,
there is risk of fire and explosion.
Do not expose the charger to rain or
wet conditions. If water enters a charger,
there is a risk of electric shock.
uDo not charge or use your eBike in any area with
a potentially explosive atmosphere, such as at a
fueling area, or in areas where the air contains
chemicals or particles (such as grain, dust, or
metal powders). Obey all signs and instructions.
WARNING
uUse only the original Bosch battery charger sup-
plied with your eBike or one approved for your
eBike by the manufacturer and purchased from
a trusted source. Bypassing the battery charger or
the use of a non-approved or counterfeit battery
charger can lead to death or serious injury.
uKeep the battery charger clean. Contamination
can lead to the risk of an electric shock. Clean only
with the use of a damp cloth (mild soap/water).
uAlways check the charger, cable and plug before
use. Stop using the charger if you discover any
damage. Do not open the charger. Damaged
chargers, cables and plugs increase the risk of elec-
tric shock.
uDo not operate the charger on an easily ignited
surface (e.g. paper, textiles, etc.) or in a
flammable environment. There is a risk of fire due
to the charger heating up during operation.
uTake care if you touch the charger while it is
charging. Wear protective gloves. The charger
can get very hot, especially when the ambient tem-
perature is high.
uThe eBike battery may give off fumes if it be-
comes damaged or is used incorrectly. Ensure
the area is well ventilated and seek medical at-
tention should you experience any adverse ef-
fects. The fumes may irritate the respiratory sys-
tem.
uThe eBike battery must not be left unattended
while charging.
ueBike batteries must not be subjected to me-
chanical shock. There is a risk of the eBike battery
being damaged.
uKeep the battery charger away from children.
This will ensure that children do not play with the
charger.
Bosch eBike Systems 0 275 U07 XCX | (15.03.2023)

English – 6
uPersons who are not capable of safely operating
the charger because of their physical, sensory
or mental limitations, or because of their lack of
experience or knowledge, may only use this
charger under supervision or after having been
instructed by a responsible person. Otherwise,
there is a risk of operating errors and injuries.
uRead and observe the safety warnings and in-
structions in all operating instructions of the
eBike system and your eBike.
NOTICE: This device complies with part 15 of the
FCC Rules. Operation is subject to the following two
conditions:
1. This device must not cause harmful interference,
and
2. this device must accept any interference received,
including interference that may cause undesired
operation.
NOTICE: Changes or modifications made to this
equipment not expressly approved by the Robert
Bosch GmbH may void the FCC authorization to oper-
ate this equipment.
NOTE: This equipment has been tested and found to
comply with the limits for a Class B digital device, pur-
suant to Part 15 of the FCC Rules. These limits are de-
signed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses and can radiate radio fre-
quency energy and, if not installed and used in accor-
dance with the instructions, may cause harmful inter-
ference to radio communications. However, there is
no guarantee that interference will not occur in a par-
ticular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the
interference by one or more of the following mea-
sures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment
and receiver.
– Connect the equipment into an outlet on a circuit
different from that to which the receiver is con-
nected.
– Consult the dealer or an experienced radio/TV tech-
nician for help.
Responsible party:
Bosch eBike Systems Americas
Robert Bosch LLC
27211 Burbank, Foothill Ranch, CA 92610, USA,
www.bosch-ebike.com/us/
0 275 U07 XCX | (15.03.2023) Bosch eBike Systems

English – 7
Product Description and Specifications
(5)
(1)
(4)
(3)
(2)
(2)
Product Features
(1) Charger
(2) Device socket
(3) Device connector
(4) Charger safety instructions
(5) Charging connector
Bosch eBike Systems 0 275 U07 XCX | (15.03.2023)

English – 8
Technical data
Charger Wide Range Charger
(36–4/100-230) Compact Charger (36–2/100-240)
Product code BCS210 BCS230
Rated voltage V~ 90−264 90−264
Frequency Hz 47−63 47−63
Battery charging voltage V= 36 36
Charging current (max.) A 4 2
Charging time
– PowerPack 400, approx. hrs 3.5 6.5
– PowerPack 500, approx. hrs 4.5 7.5
Operating temperature °F +32to +104 +32to +104
Storage temperature °F +50to +104 +50to +104
Weight, approx. lb 1.8 1.3
Protection rating IP40 IP40
Power cable
Article number 1 270 020 343
Rated voltage – cables V~ 300
Rated voltage – connectors/plug-in connectors V~ 125
Rated current – connectors/plug-in connectors A 10
Material – cables PVC
Safety standard – cables UL 62
Safety standard – connectors/plug-in connectors UL 817
Length, approx. m 1.8
0 275 U07 XCX | (15.03.2023) Bosch eBike Systems

English – 9
Operation
Start-up
Connecting the charger to the mains
(2) (2)
(3)
uNote the household voltage! The voltage of the
power supply must correspond to the specifica-
tions given on the battery charger nameplate.
Plug the device connector (3) of the power cable into
the device socket (2) on the charger.
Connect the power cable (country-specific) to the
mains.
Use only the supplied input connection: standard AC
power cord ((3) in the diagram) when connecting to
the household electrical supply.
Charging the eBike battery when removed
(11)
(6)
(5) (9)
(10)
(8)
(6)
(5) Charging connector
(6) Socket for charging connector
(8) Rack-mounted battery
(9) Operation/state of charge indicator
(10) On/off button for eBike battery
(11) Standard battery
Switch the eBike battery off and remove it from its
holder on the eBike. When doing so, read and ob-
serve the operating instructions of the eBike battery.
uEnsure the eBike battery is placed on clean sur-
faces only. Avoid getting dirt, e.g. sand or soil, in
the charging socket and contacts in particular.
Plug the charging connector(5) of the charger into
the charging socket(6) on the eBike battery.
Charging the eBike battery when inserted in the
eBike
(11)
(6)
(7)
(5)
(5) Charging connector
(6) Socket for charging connector
(7) Charging socket cover
(11) Standard battery
Bosch eBike Systems 0 275 U07 XCX | (15.03.2023)

English – 10
(8) (6)
(7)
(5)
(5) Charging connector
(6) Socket for charging connector
(7) Charging socket cover
(8) Rack-mounted battery
(5)
(6) (7)
(5) Charging connector
(6) Socket for charging connector
(7) Charging socket cover
Switch the eBike battery off. Clean the cover of the
charging socket (7). Avoid getting dirt, e.g. sand or
soil, in the charging socket and contacts in particular.
Lift the cover of the charging socket (7) and plug the
charging connector (5) into the charging socket (6).
uThere is a risk of fire due to the charger heating
up during charging. Ensure the eBike battery on
the eBike is completely dry and placed on a fire-
proof surface before charging. If this is not possi-
ble, remove the eBike battery from the holder and
charge it in a more suitable location. When doing
so, read and observe the operating instructions of
the eBike battery.
Charging Process for Two eBike Batteries
If two eBike batteries are fitted to an eBike, both
eBike batteries can be charged using the uncovered
connection. To begin with, both eBike batteries are
charged one after the other until they reach ap-
prox.80–90% capacity, then they are both fully
charged at the same time (the LEDs flash on both
eBike batteries).
When the bike is in operation, power is drawn from
both eBike batteries on an alternating basis.
If you take the eBike batteries out of the holders, you
can charge each one individually.
Charging process
The charging process begins as soon as the charger is
connected to the eBike battery or charging socket on
the eBike and to the mains.
Note: The charging process is only possible when the
temperature of the eBike battery is within the permit-
ted charging temperature range.
Note: The drive unit is deactivated during the charg-
ing process.
The eBike battery can be charged with and without
the on-board computer. When charging without the
on-board computer, the charging procedure can be
observed on the eBike battery charge indicator.
When the on-board computer is connected, a charg-
ing notification appears on the display.
The state of charge is displayed by the battery charge
indicator(9) on the eBike battery and by the bars on
the on-board computer.
The LEDs on the eBike battery charge indicator(9)
flash during the charging process. Each solid illumi-
nated LED represents approximately 20% of the
charging capacity. The flashing LED indicates the next
20% currently charging.
Once the eBike battery is fully charged, the LEDs ex-
tinguish immediately and the on-board computer is
0 275 U07 XCX | (15.03.2023) Bosch eBike Systems

English – 11
switched off. The charging process is terminated. The
state of charge can be displayed for3 seconds by
pressing the on/off button(10) on the eBike battery.
Disconnect the charger from the mains and the eBike
battery from the charger.
When the battery is disconnected from the charger,
the eBike battery is automatically switched off.
Note: If you have charged the battery on the eBike,
carefully close the charging socket(6) with the
cover(7) after charging, so that no dirt or water can
get in.
If the charger is not disconnected from the eBike bat-
tery after charging, after a few hours the charger will
switch itself back on, check the state of charge of the
eBike battery and begin the charging procedure again
if necessary.
Maintenance/cleaning
WARNING
uDo not open any of the components. Service
should only be carried out at an authorized
Bosch eBike dealer. Failure to follow above warn-
ing can cause death or serious injury. Refer to your
bicycle manual or component manual for all non-
Bosch drive system components.
uDo not submerge your eBike components in wa-
ter, or wash with pressurized hose. Your Bosch
drive unit is designed to be water tight to rain water
or non-pressure hose washing.
uDo not paint any components of the Bosch drive
system as they may cause premature failure of
the component.
After-sales service and advice on using
products
If you have any questions about the eBike and its
components, contact an authorized bicycle retailer.
For contact details of authorized bike dealerships,
please visit www.bosch-ebike.com.
Please contact an authorized bicycle dealer if the
eBike battery is no longer working.
Bosch eBike Systems 0 275 U07 XCX | (15.03.2023)

English – 12
Troubleshooting
Cause Corrective measures
eBike battery defective
Two LEDs flash on the eBike battery.
Contact an authorized bike dealership.
eBike battery too warm or too cold
Three LEDs flash on the eBike battery.
Disconnect the eBike battery from the charger until
the charging temperature range has been reached.
Do not reconnect the eBike battery to the charger until
it has reached the correct charging temperature.
The charger is not charging.
No LEDs flashing (one or more LEDs will remain
permanently lit depending on the state of charge of
the eBike battery).
Contact an authorized bike dealership.
Charging not possible (no indicator on eBike bat-
tery)
Connector not attached properly Check all connections.
eBike battery contacts dirty Carefully clean the eBike battery contacts.
Socket outlet, cable or charger defective Check the mains voltage, have the charger checked
over by a bike dealership.
eBike battery defective Contact an authorized bike dealership.
0 275 U07 XCX | (15.03.2023) Bosch eBike Systems

English – 13
Battery Recycling Program
The drive unit, on-board computer incl.
operating unit, eBike battery, speed sen-
sor, accessories and packaging should be
disposed of in an environmentally correct
manner.
Do not dispose of eBikes and their components with
household waste.
You may recycle your Bosch battery
pack by calling 1.800.822.8837.
Bosch eBike Systems 0 275 U07 XCX | (15.03.2023)

English – 14
0 275 U07 XCX | (15.03.2023) Bosch eBike Systems

Français – 1
Table des matières
Introduction ..................................................................................................................................... 2
À propos des avertissements.......................................................................................................... 2
Avertissements généraux............................................................................................................... 2
Utilisez votre notice d’utilisation ..................................................................................................... 3
Étiquettes d’avertissement sur le produit.............................................................................................. 4
Utilisation du chargeur ....................................................................................................................... 5
Consignes de sécurité ................................................................................................................... 5
Description et caractéristiques techniques du produit........................................................................ 7
Fonctionnement........................................................................................................................... 9
Maintenance/nettoyage............................................................................................................... 11
Résolution des problèmes ................................................................................................................ 12
Programme de recyclage des accus.................................................................................................... 13
Bosch eBike Systems 0 275 U07 XCX | (15.03.2023)

Français – 2
Introduction
À propos des avertissements
Cette notice contient de nombreuses mentions de
danger de type DANGER, AVERTISSEMENT et AT-
TENTION destinées à attirer l’attention sur les consé-
quences d’erreurs, dans le but d’utiliser, d’assembler,
d’entretenir, de conserver et d’éliminer dans les
règles et en toute sécurité les vélos électriques dotés
d’un système eBike Bosch.
– Le symbole de sécurité et le mot DANGER si-
gnalent une situation à risque élevé, qui entraîne in-
évitablement des blessures graves, voire la mort, si
elle n’est pas évitée.
– Le symbole de sécurité et le mot AVERTISSEMENT
signalent une situation à risque élevé, pouvant en-
traîner des blessures graves, voire la mort, si elle
n’est pas évitée.
– Le symbole de sécurité et le mot ATTENTION si-
gnalent une situation à risque modéré pouvant en-
traîner des blessures légères ou modérées si elle
n’est pas évitée.
Avertissements généraux
Lisez tous les avertissements de sé-
curité et toutes les instructions. Le
fait de ne pas respecter les avertisse-
ments et les instructions peut entraîner
des blessures graves ou mortelles.
Conservez tous les avertissements et toutes les
instructions pour pouvoir s’y reporter ultérieure-
ment.
Le terme batterie de VAE utilisé dans cette notice
désigne toutes les batteries de VAE Bosch d’origine.
uLisez TOUS les manuels et TOUTES les notices
jointes avant d’utiliser votre vélo pour la pre-
mière fois. Votre système d’entraînement Bosch
est livré avec d’autres manuels et documents four-
nis par le fabricant du vélo et des autres éléments.
Ne pas lire ou ne pas comprendre les informations
de sécurité peut entraîner des blessures graves ou
mortelles.
AVERTISSEMENT
uCette notice contient d’importantes informa-
tions sur la sécurité, les performances et l’entre-
tien. Veuillez la lire avant d’utiliser votre vélo pour
la première fois, et la conserver pour référence ul-
térieure. Vous pouvez également retrouver cette
notice en ligne à l’adresse www.bosch-ebike.com.
uCette notice est destinée à être lue conjointe-
ment avec le manuel utilisateur séparé fourni
avec votre vélo. Assurez-vous de lire tous les do-
cuments fournis y compris les étiquettes apposées
sur le produit avant la première utilisation.
uAssumez la responsabilité de votre propre SÉ-
CURITÉ. En cas de question ou d’incompréhension,
contactez votre revendeur ou le fabricant du vélo
ou de l’élément.
uCertains accessoires de l’eBike peuvent présen-
ter un risque d’étouffement pour les petits en-
fants. Conservez ces accessoires hors de portée
des enfants.
ATTENTION
uLe système d’entraînement Bosch alourdit votre
vélo. Vous n’avez peut-être pas l’habitude de le
soulever. Évitez de vous blesser en utilisant des
techniques de levage appropriées.
0 275 U07 XCX | (15.03.2023) Bosch eBike Systems

Français – 3
Utilisez votre notice d’utilisation
Nous nous réservons le droit d’apporter à tout mo-
ment des modifications au logiciel pour corriger des
erreurs ou pour modifier les fonctionnalités décrites
dans la présente notice.
Graphiques
Le vélo illustré dans cette notice peut être légèrement
différent de votre vélo, mais il est suffisamment simi-
laire pour vous permettre de comprendre nos instruc-
tions.
Les côtés DROIT et GAUCHE sont déterminés en se
plaçant en situation, dans le sens de la marche du vé-
lo. Lorsqu’une ligne en pointillé (------) apparaît, l’élé-
ment auquel il est fait référence n’est pas visible.
Bosch eBike Systems 0 275 U07 XCX | (15.03.2023)

Français – 4
Étiquettes d’avertissement sur le produit
A
B
AWide range charger
BCompact charger
Vous trouverez sous le chargeur un résumé des
consignes de sécurité importantes en anglais, fran-
çais et espagnol avec le texte suivant (voir la posi-
tion(4) sur la page avec les graphiques) :
– Pour un fonctionnement sûr, reportez-vous au ma-
nuel.
– Risque de choc électrique
– Utiliser en lieu sec uniquement
– À utiliser uniquement avec les batteries des sys-
tèmes d’assistance électrique eBike de Bosch.
D’autres batteries risqueraient d’éclater et de cau-
ser des blessures corporelles et des dommages.
– Ne pas remplacer la connectique car un risque d’in-
cendie ou de choc électrique pourrait en résulter.
0 275 U07 XCX | (15.03.2023) Bosch eBike Systems
