Bosch F.01U.299.030 User manual

Digital Discussion System
CCS 1000 D
en Operation manual

Digital Discussion System Table of contents | en 3
Bosch Security B.V. Operation manual 2020.05 | V2.2 |
Table of contents
1Safety 5
2About this manual 6
2.1 Manual purpose 6
2.2 Digital document 6
2.3 Intended audience 6
2.4 Alerts and notice signs 6
2.5 Copyright and disclaimer 6
2.6 Document history 7
3System overview 8
3.1 CCSD-CU(RD) Control Unit 10
3.2 Control Unit with MP3 recording and DAFS 10
3.3 Discussion Device 11
3.4 CCSD-EXU Extension Unit 11
3.5 GUI languages 11
4Planning 12
4.1 Unpacking 12
4.2 Delivered with products 12
4.2.1 CCSD-CU Control Unit or CCSD-CURD Control Unit 12
4.2.2 CCSD-Dx Discussion Device 12
4.2.3 CCSD-EXU Extension Unit 12
4.3 Additional components 14
4.4 Making custom extension cables 16
4.5 Setup options and limits 17
4.5.1 Small/medium sized system (max. 80 Discussion Devices) 17
4.5.2 Large system (max. 245 Discussion Devices) 18
4.5.3 Extension cables 20
5Installation 23
5.1 Install Unit(s) 23
6Connections 24
6.1 Connect system components 24
6.2 Control Unit connections 26
6.3 Discussion Device connections 28
6.4 Extension Unit connections 29
7Configuration 30
7.1 Control Unit 30
7.1.1 Discussion modes 33
7.1.2 Key combinations 34
7.2 Extension Unit 35
7.3 Discussion Device 36
7.3.1 Configure Discussion Device 36
7.3.2 Initialize Discussion Device 36
7.3.3 Erase address 37
7.4 Web browser interface 38
7.4.1 First use configuration 38
7.4.2 Login 39
7.4.3 Manage discussion 43
7.4.4 Prepare discussion 44
7.4.5 Manage recorder 45

4en | Table of contents Digital Discussion System
2020.05 | V2.2 | Operation manual Bosch Security B.V.
7.4.6 System settings 46
7.4.7 Power 52
7.4.8 Logging 52
7.4.9 System info 52
7.4.10 Logout 52
7.5 RESTful Application Program Interface (API) 53
8Operation 54
8.1 Recording and playing back discussion 54
8.2 Using the microphone button 56
8.3 Using the priority button 57
8.4 Adjusting headphones volume 57
9Troubleshooting 58
9.1 Troubleshooting table 58
10 Maintenance 62
10.1 Cleaning 62
10.2 Inspect components 62
10.3 Storage 62
11 Technical data 63
11.1 Control Unit 63
11.2 Discussion Device 64
11.3 Extension Unit 66
11.4 Safety compliance 67
11.4.1 Control Units 67
11.4.2 Discussion Devices 67
11.4.3 Extension Unit 67

Digital Discussion System Safety | en 5
Bosch Security B.V. Operation manual 2020.05 | V2.2 |
1 Safety
Prior to installing or operating products, always read the Important Safety Instructions which
are available as a separate multilingual document: Important Safety Instructions (Safety_ML).
These instructions are supplied together with all equipment that can be connected to the
mains supply.
Old electrical and electronic appliances
Electrical or electronic devices that are no longer serviceable must be collected separately and
sent for environmentally compatible recycling (in accordance with the European Waste
Electrical and Electronic Equipment Directive).
To dispose of old electrical or electronic devices, you should use the return and collection
systems put in place in the country concerned.
Class A Notice for FCC and ICES 003
applies to U.S.A. and Canadian models only
Business Equipment
For commercial or professional use
This equipment has been tested and found to comply with the limits for a ClassA
digital device, pursuant to Part15 of the FCC and Canadian ICES‑003 requirements.
These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in residential area
is likely to cause harmful interference in which case the user will be required to
correct the interference at their own expense. Intentional or unintentional changes or
modifications not expressly approved by the party responsible for compliance shall not
be made. Any such changes or modifications may void the user’s authority to operate
the equipment.

6en | About this manual Digital Discussion System
2020.05 | V2.2 | Operation manual Bosch Security B.V.
2 About this manual
– Please read this manual carefully before installing and operating any of the products of
the CCS1000D Digital Discussion System.
– Retain all documentation supplied with the products for future reference.
2.1 Manual purpose
This manual provides information required for installing, configuring, operating and
maintaining the products of the CCS1000D Digital Discussion System. For documentation
updates, refer to the product related information at: www.boschsecurity.com
2.2 Digital document
This manual is available as a digital document in the Adobe Portable Document Format (PDF).
Refer to the product related information at: www.boschsecurity.com.
2.3 Intended audience
This manual is intended for installers, technicians and users of a CCS1000D Digital
Discussion System.
2.4 Alerts and notice signs
Four types of signs can be used in this manual. The type is closely related to the effect that
may be caused if it is not observed. These signs - from least severe effect to most severe
effect - are:
Notice!
Containing additional information. Usually, not observing a ‘notice’ does not result in damage
to the equipment or personal injuries.
!
Caution!
The equipment or the property can be damaged, or persons can be lightly injured if the alert
is not observed.
!
Warning!
The equipment or the property can be seriously damaged, or persons can be severely injured
if the alert is not observed.
Danger!
Not observing the alert can lead to severe injuries or death.
2.5 Copyright and disclaimer
All rights reserved. No part of this document may be reproduced or transmitted in any form by
any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior
written permission of the publisher. For information on getting permission for reprints and
excerpts, contact Bosch Security Systems B.V..
The content and illustrations are subject to change without prior notice.

Digital Discussion System About this manual | en 7
Bosch Security B.V. Operation manual 2020.05 | V2.2 |
2.6 Document history
Release date Documentation version Reason
2014.09 V1.0 1st edition.
2014.10 V1.1 Cover photo and sections: 2.6, 3, 4, 4.3, 4.5, 6, 6.1,
6.2, 7, 7.1, 7.3, 7.3.1 (incl. illustration), 7.3.3, 7.3.4,
7.3.5 (incl. illustration), 7.3.6, 7.3.8 adapted.
2016.05 V2.0 New sections added: 3.4, 4.2.1, 4.2.2, 4.2.3, 4.5.1,
4.5.2, 4.5.3, 6.4, 7.1.2, 7.2, 7.3.2, 7.3.3, 7.4.1, 7.5,
11.3
Sections updated: 2.6, 3, 6.1, 6.2, 7.4.2, 7.4.4, 7.4.6,
8.1, 9.1
2018.08 V2.1 Section updated: 7.4.6
2020.05 V2.2 Section added:
–GUI languages
Sections updated:
–Login: added information about first time login.
–System info: completed with additional
available information about OSS license terms.
–Troubleshooting table: updated table with
information about how to handle a large
amount of API calls

8en | System overview Digital Discussion System
2020.05 | V2.2 | Operation manual Bosch Security B.V.
3 System overview
HD-SDI
8
11
5
7
6
10
1
2
3
4 4
5
12
13
11
5
5
12
9
5
12
5
Figure3.1: Typical system setup

Digital Discussion System System overview | en 9
Bosch Security B.V. Operation manual 2020.05 | V2.2 |
The CCS1000D Digital Discussion System is a hot plug‑and‑play conferencing system that is
ideally suited for small to medium‑sized meeting areas, such as town halls, local business
centers, and courtrooms. The main components of the discussion system are:
1. Control Unit: there are two types of control unit: the CCSD‑CU and the CCSD‑CURD.
Their functions and differences are described in CCSD-CU(RD) Control Unit, page 10 .
2. Discussion Devices (CCSD‑Dx), which can be configured as participant devices (2) or a
chairperson’s device (3).
3. Chairperson’s device (CCSD‑Dx).
4. Discussion Device cable (and extension cables as required): connects the Discussion
Devices, Control Unit(s), and optional Extension Unit(s) in a daisy‑chain configuration.
5. Ethernet cable: the Ethernet port is used to connect the laptop or PC, IP camera’s, and
other equipment solely used to operate the CCS1000D Digital Discussion System.
6. PC/Laptop: can be used temporary to upgrade the system, or to manage discussions,
prepare discussions, and configure the system.
7. Ethernet switch: routes the system data via Ethernet.
8. Display: can be used to show the speaking participant.
9. Wireless access point/router: used in combination with a wireless tablet device.
10. Tablet device: can be used to manage discussions, prepare discussions, and configure
the system.
11. HD Conference Dome: captures the image of a speaking participant.
12. Coax cable: transports the video signal between the camera and the HD-SDI (13).
13. HD-SDI: is used to connect to the display (8) and to the Ethernet network switch (7). TV-
One CORIOmatrix mini and the Kramer MV-6 are supported.

10 en | System overview Digital Discussion System
2020.05 | V2.2 | Operation manual Bosch Security B.V.
3.1 CCSD-CU(RD) Control Unit
P
T
T
Figure3.2: CCSD‑CU
P
T
T
Figure3.3: CCSD‑CURD
The Control Unit is the central component of the CCS1000D Digital Discussion System. Its
main purpose is to:
– provide an interface for connecting Discussion Devices and peripheral equipment.
– supply DC power to Discussion Devices.
– monitor and control the CCS1000D Digital Discussion System.
Touch‑buttons and LED indicators on the front panel are used for configuring and operating.
The Control Unit has a built‑in web browser interface, which can be accessed with a tablet,
laptop, or PC. The web browser interface can be used to view and manage basic and
advanced system configuration, such as microphone management and digital recording
options. Configuration changes made at the Control Unit are automatically updated in the web
browser interface and vice‑versa.
3.2 Control Unit with MP3 recording and DAFS
P
T
T
Figure3.4: CCSD‑CURD
The CCSD‑CURD has the following additional features:
– Built‑in MP3 recorder with internal memory and USB recording.
– Built‑in Digital Acoustic Feedback Suppression (DAFS).
– Built‑in loudspeaker and headphone socket with volume control for listening to the ‘floor
language’ or recordings.
– Additional RCA outputs for individual microphone recording, e.g. for recording individual
speakers in a courtroom.

Digital Discussion System System overview | en 11
Bosch Security B.V. Operation manual 2020.05 | V2.2 |
3.3 Discussion Device
Figure3.5: CCSD‑Dx
The device allows a participant to take part in a discussion by speaking into the microphone
and listening to proceedings through the built‑in loudspeaker or (optional) headphones. It has
the following main features:
– Microphone button for activating and deactivating the microphone.
– LED indicator above the microphone button and a light‑ring indicator in head of the
microphone.
– Rotary thumbwheel on the side of the device for adjusting the volume of the headphones.
A device can be configured as either a ‘participant device’ or a ‘chairperson device’, which
enables a user to function as the chairperson at a meeting. See Configure Discussion Device,
page 36 .
3.4 CCSD-EXU Extension Unit
Figure3.6: CCSD‑EXU
The Extension Unit is used in combination with a Control Unit (CCSD‑CU or CCSD‑CURD) to
supply additional power to the CCS1000D Digital Discussion System.
One or more Extension Units can be used to expand the CCS1000D Digital Discussion
System up to 245 Discussion Devices. A single Extension Unit can provide power for up to 85
additional Discussion Devices (CCSD‑DS or CCSD‑DL).
The Extension Unit is switched on and off automatically with the Control Unit.
3.5 GUI languages
The CCS 1000D Digital Discussion System has the following GUI languages:
ar cs de en el es fi fr hu id it ja ko nl pl pt pt-
BR
ru th tr vi zh-
CN
zh-
TW
Web browser •••••••••••••••••••••••

12 en | Planning Digital Discussion System
2020.05 | V2.2 | Operation manual Bosch Security B.V.
4 Planning
Before using the CCS1000D Digital Discussion System, read this section to make sure you
have all components for connecting and operating the system. This section also includes
important information on the number of Discussion Devices that can be connected to the
system. See Setup options and limits, page 17 .
4.1 Unpacking
This equipment should be unpacked and handled with care. If an item appears to be damaged,
notify the shipper immediately. If any items are missing, notify your Bosch representative.
The original packaging is the safest container in which to transport products and can be used
to return products for service if necessary.
4.2 Delivered with products
Make sure the following items are delivered with your products:
4.2.1 CCSD-CU Control Unit or CCSD-CURD Control Unit
Quantity Component
1 CCSD‑CU or CCSD‑CURD
1 Mains power cord
1 24VDC power supply
1 Micro USB cable
2 Sets of chairperson’s buttons for a Discussion Device
1 Exchange tool for buttons
1 Set of feet for table top use
1 Set of 19” 1U mounting brackets
1 Safety instructions
1 Installation note
1 DVD with operation manual and supporting tools
4.2.2 CCSD-Dx Discussion Device
Quantity Component
1 CCSD‑DS or CCSD‑DL
1 Quick Installation Guide
4.2.3 CCSD-EXU Extension Unit
Quantity Component
1 CCSD‑EXU
1 Mains power cord
1 24VDC power supply
1 Set of feet for table top use

Digital Discussion System Planning | en 13
Bosch Security B.V. Operation manual 2020.05 | V2.2 |
1 Set of 19” 1U mounting brackets
1 Safety instructions
1 Quick Installation Guide

14 en | Planning Digital Discussion System
2020.05 | V2.2 | Operation manual Bosch Security B.V.
4.3 Additional components
The following additional components can be used with the CCS1000D Digital Discussion
System, as required:
LBB4116 Series Extension Cables – These standard length extension cables can be
connected to components in the daisy‑chain. If you want to add one or more extension cables
to the system cabling, make sure you follow the guidelines in Setup options and limits, page
17 .
Type number Cable length
LBB4116/02 2 m (6.6 ft)
LBB4116/05 5 m (16.0 ft)
LBB4116/10 10 m (33.0 ft)
LBB4116/15 15 m (49.2 ft)
LBB4116/20 20 m (66.0 ft)
LBB4116/25 25 m (82.0 ft)
LBB4116/00 Installation Cable 100m – This roll of cable and LBB4119 connectors can be
used to make custom length extension cables. See Making custom extension cables, page 16 .
LBB4119 Connectors (25 pairs) – Pairs of connectors for terminating extension cables made
from the LBB4116/00 roll of cable.
DCN‑DISCLM Cable Clamps (25pcs) – This cable clamp can be used to secure the connector
of a Discussion Device to the next Discussion Device in the daisy chain.

Digital Discussion System Planning | en 15
Bosch Security B.V. Operation manual 2020.05 | V2.2 |
LBB4117/00 Cable Locking Clamps (25pcs) – This cable locking clamp can be used to lock
the connectors of extension cables. One cabling locking clamp is required for each male/
female connector.
USB memory stick (CCSD‑CURD only) – A correctly formatted USB memory stick is required if
you want to record discussions directly to an external device. Refer to the following
information:
– Preferred type: Sandisk.
– Maximum size: 128GB.
– Formatting: The USB memory stick must be formatted to the FAT32 file system. If
required, the USB memory stick can be formatted using:
– the recommend formatting tool on the DVD supplied with the Control Unit. This tool
can also be downloaded from the relevant product page on: www.boschsecurity.com
– the Windows default formatting tool. This tool can only format USB memory sticks
up to 32GB to the FAT32 file system.
– Partition: Device with single FAT32 partition.
– Partitioning scheme: Must be MBR (GPT is not supported).
Note: The partitioning scheme can also be changed with the formatting tool.
USB cable with micro USB connector - A USB cable with a micro USB connector is required if
you want to transfer the internal memory (recordings) to a PC.
RJ45 Ethernet cable - An RJ45 Ethernet cable is required if you want to connect a laptop or
PC to the control unit for running the web browser interface and connecting system cameras.
RCA cables - RCA cables are required if you want to connect optional audio equipment to the
Control Unit, such as a sound reinforcement system.
XLR cable - An XLR cable is required if you want to connect an external microphone to the
Control Unit.
Wireless Access Point (WAP) - A commercially available wireless access point or router is
required if you want to connect equipment with a WiFi connection to the system.

16 en | Planning Digital Discussion System
2020.05 | V2.2 | Operation manual Bosch Security B.V.
4.4 Making custom extension cables
Custom extension cables can be made from the LBB4116/00 DCN‑NG installation cable 100m
and LBB4119/00 DCN‑NG connectors (25 pairs). Refer to the following figures and table:
Socket
Plug
Figure4.1: Extension cable plug and socket
Plug Socket
1
6
2
3
4
5 5
6
4
3
2
1
Figure4.2: Plug and socket pin numbers
1
5
2
4
3
6
GND
Figure4.3: Extension cable connections
Pin Signal Color
1 Downlink GND ---
2 Downlink data Green
3 +24 V(DC) Brown
4 Uplink data White
5 Uplink GND ---
6 +24 V(DC) Blue
Tab.4.1: Extension cable connections

Digital Discussion System Planning | en 17
Bosch Security B.V. Operation manual 2020.05 | V2.2 |
4.5 Setup options and limits
This section describes the setup options and limits for the CCS1000D Digital Discussion
System. The following example system setups are described:
– A small/medium sized system that has a Control Unit, and a maximum of 80 Discussion
Devices. See Small/medium sized system (max. 80 Discussion Devices), page 17 .
– A large system that has a Control Unit, one or more Extension Units, and a maximum of
245 Discussion Devices. See Large system (max. 245 Discussion Devices), page 18 .
– A system that has extension cables longer than 20m (66.0ft) connected to a trunk or
tap-off. See Extension cables, page 20 .
Note: Due to power loss, extension cables longer than 20m (66.0ft) have a direct effect
on the number of Discussion Devices that can be connected to a trunk/tap-off.
4.5.1 Small/medium sized system (max. 80 Discussion Devices)
A small/medium sized system has one Control Unit and a maximum of 80 Discussion Devices.
The following limits are applicable in this situation:
–Limit 1: A maximum of 40 Discussion Devices can be daisy‑chained to each trunk of the
Control Unit.
–Limit 2: If an extension cable longer than 20m (66.0ft) is added to a trunk, the number
of Discussion Devices that can be added to that trunk is reduced. Refer to the table in
Extension cables, page 20 .
–Limit 3: The maximum cable length for a trunk is 100m (328.0ft). This includes all
extension cables (including the first 20m (66.0ft) of extension cable) + the Discussion
Device cables of 2m (6.6ft) per device.
The following figure shows the maximum of 40 Discussion Devices connected to each trunk of
the Control Unit: 40 + 40 = 80 Discussion Devices.
1
40x
40x
2
2
Figure4.4: Example setup for a small/medium sized system (max. 80 discussion devices)
1. Control Unit
2. Extension cable 20m (66.0ft) long connected to each trunk of the Control Unit

18 en | Planning Digital Discussion System
2020.05 | V2.2 | Operation manual Bosch Security B.V.
4.5.2 Large system (max. 245 Discussion Devices)
A system can be extended (by more than 80 Discussion Devices) by adding one or more
Extension Units to a trunk of the Control Unit.
–Limit 1: A maximum of 40 components can be daisy‑chained to a trunk of the Control
Unit.
Note: A component can be a Discussion Device or an Extension Unit.
–Limit 2: A maximum of 40 Discussion Devices can be daisy‑chained to each tap-off of an
Extension Unit.
–Limit 3: A maximum of 85 Discussion Devices can be connected to each Extension Unit.
–Limit 4: A maximum of 245 Discussion Devices can be connected to the system.
–Limit 5: If an extension cable longer than 20m (66.0ft) is added to a trunk/tap-off, the
number of Discussion Devices that can be added to that trunk/tap-off is reduced. Refer to
the table in Extension cables, page 20 .
–Limit 6: The maximum cable length for a trunk/tap-off is 100 m (328.0ft). This includes
all extension cables (including the first 20m (66.0ft) of extension cable) + the
Discussion Device cables of 2m (6.6ft) per device. + the Extension Unit cables.

Digital Discussion System Planning | en 19
Bosch Security B.V. Operation manual 2020.05 | V2.2 |
The following figure shows:
– the maximum of 40 components connected to the trunk: 3 Extension Units + 37
Discussion Devices = 40 components.
– the maximum number of Discussion Devices (245) connected to the system.
1
3
3
40x
40x
40x
40x
40x
3
4x
4x
37x
2
2
2
2
2
2
2
2
Figure4.5: Example setup for a large system (max. 245 Discussion Devices)
1. Control Unit
2. Extension cable 20m (66.0ft) long
3. Extension Unit

20 en | Planning Digital Discussion System
2020.05 | V2.2 | Operation manual Bosch Security B.V.
4.5.3 Extension cables
Adding an extension cable longer than 20m (66.0ft) to a trunk/tap-off has a direct effect on
the available power for the components connected in the daisy chain. A component can be a
Discussion Device or an Extension Unit.
Use the following table to determine the total number of components that can be connected
to a trunk/tap-off when one or more extension cables are connected to that trunk/tap-off.
–Limit 1: The maximum cable length for a trunk/tap-off is 100m (328.0ft). This includes
all extension cables (including the first 20m (66.0ft) of extension cable) + the
Discussion Device cables of 2m (6.6ft) per device. + the Extension Unit cables.
Total length of extension cable(s) per trunk/
tap-off
Maximum number of components per trunk/
tap-off
0 m to 20 m 40
20 m to 22 m 39
22 m to 24 m 38
24 m to 26 m 37
26 m to 28 m 36
28 m to 30 m 35
30 m to 32 m 34
32 m to 34 m 33
34 m to 36 m 32
36 m to 38 m 31
38 m to 40 m 30
40 m to 42 m 29
42 m to 44 m 28
44 m to 46 m 27
46 m to 48 m 26
48 m to 50 m 25
50 m to 52 m 24
52 m to 54 m 23
54 m to 56 m 22
56 m to 58 m 21
58 m to 60 m 20
60 m to 62 m 19
62 m to 64 m 18
64 m to 66 m 17
66 m to 68 m 16
68 m to 70 m 15
