Bosch FW 120 User manual

Installation and operating instructions
Weather-compensated controller with solar control
FW 120
6 720 612 481-00.1R
for heating appliances with BUS-enabled Heatronic 3
6 720 800 844 (2012/02)

6 720 800 844 (2012/02)
2| Overview of controls and symbols
Overview of controls and symbols
Fig. 1 Standard display
6 720 617 763-01.1O
3
34
1
menu info
1
2
35
6
7
8
4
912 h15
18
21
24 h
3
6
advance advance

6 720 800 844 (2012/02)
Overview of controls and symbols | 3
Controls
1Turning the rotary selector in +direction:
Selects menu/information above or increases
setting value
Turning the rotary selector in – direction:
Selects menu/information below or decreases
setting value
Pushing the rotary selector : Opens menu or
confirms setting/value
2Operating mode selector for heating:
Automatic mode
Constant Comfort
Constant Economy
Constant Frost
3Key :
To bring the next switching time and the associated
operating mode
= Comfort
= Economy
= Frost1
for central heating forward to the current time.
4Key : To activate DHW heating immediately.
The DHW cylinder is heated to the required
temperature for 60 minutes or, with combi boilers,
comfort mode is activated for 30 minutes.
5Key : Open/close menu INSTALLER
SETTINGS open: hold down for approx. 3 seconds
6Key : Display values
7Key : Delete/reset value
8Key : Return to next menu level up
Tab. 1
To make the further description
easier
•controls and operating modes
are sometimes only depicted
with symbols, e.g. or .
•menu levels are separated by the
>symbol, e.g. Holiday > Start.
menu
info
Symbols
Current room temperature
(only with wall mounting)
Flashing segment:
Current time (13:45 to 14:00)
Solid segments:
Period for operating mode = Comfort
today (1 segment = 15 min)
Empty segments:
Period for operating mode = Economy
today (1 segment = 15 min)
No segments:
Period for operating mode = Frost
today (1 segment = 15 min)
Operating mode Comfort
Operating mode Economy
Operating mode Frost
Automatic mode
Holiday mode
Burner operation in the display
+Scroll menu/info text up or increase value
– Scroll menu/info text down or decrease
value
ok Open menu, confirm setting/value
Return to next menu up
Delete/reset value
Bring the next switching time and the
associated operating mode
= Comfort
= Economy
= Frost
for central heating forward to the current
time.
Activate DHW heating immediately.
The DHW cylinder is heated to the
required temperature for 60 minutes or,
with combi boilers, comfort mode is
activated for 30 minutes.
Tab. 2
12 h
15
9
3

6 720 800 844 (2012/02)
4| Contents
Contents
1 Key to symbols and safety instructions . 6
1.1 Explanation of symbols . . . . . . . . . . 6
1.2 Safety instructions . . . . . . . . . . . . . 7
2 Technical data for the accessory item . . . 8
2.1 Standard delivery . . . . . . . . . . . . . . 8
2.2 Specification . . . . . . . . . . . . . . . . . . 9
2.3 Cleaning . . . . . . . . . . . . . . . . . . . . . 9
2.4 Supplementary accessories . . . . . . . 9
2.5 Sample system . . . . . . . . . . . . . . . 10
3 Installation (for contractors only) . . . . . 11
3.1 Installation . . . . . . . . . . . . . . . . . . . 11
3.1.1 Installation in heating appliance . . 11
3.1.2 Wall mounting . . . . . . . . . . . . . . . . 13
3.1.3 Installation of outside temperature
sensor . . . . . . . . . . . . . . . . . . . . . . 14
3.1.4 Fitting other accessories . . . . . . . . 15
3.1.5 Disposal . . . . . . . . . . . . . . . . . . . . . 15
3.2 Electrical connections . . . . . . . . . . 15
3.2.1 Electrical connection in the heating
appliance . . . . . . . . . . . . . . . . . . . . 15
3.2.2 Electrical connection for wall
mounting . . . . . . . . . . . . . . . . . . . . 16
4 Commissioning (contractors only) . . . . 17
5 Operation . . . . . . . . . . . . . . . . . . . . . . . . 18
5.1 Changing the room temperature and
operating mode . . . . . . . . . . . . . . . 18
5.1.1 Changing the set room temperature
for a limited period . . . . . . . . . . . . 18
5.1.2 Advancing heating mode before the
programmed time (bringing forward
the next switching point) . . . . . . . 18
5.1.3 Changing DHW mode
(time-limited) . . . . . . . . . . . . . . . . 19
5.1.4 Changing heating mode
permanently . . . . . . . . . . . . . . . . . 19
5.2 Display views and menu
navigation . . . . . . . . . . . . . . . . . . . 20
5.3 Setting programs . . . . . . . . . . . . . . 21
5.3.1 Changing an individual switching
point . . . . . . . . . . . . . . . . . . . . . . . 21
5.3.2 Deleting an individual switching
point . . . . . . . . . . . . . . . . . . . . . . . 23
5.3.3 Resetting an entire program
(overwriting with factory
settings) . . . . . . . . . . . . . . . . . . . . 23
5.4 Resetting all settings (for heating
contractors only) . . . . . . . . . . . . . . 24
6 Adjusting the MAIN MENU . . . . . . . . . . . 25
6.1 Menu structure . . . . . . . . . . . . . . . 25
6.2 Heating program . . . . . . . . . . . . . . 28
6.2.1 Time/Temperature level program . 28
6.2.2 Temperature for the operating
modes (change temperature
permanently) . . . . . . . . . . . . . . . . . 28
6.2.3 Heat-up rate . . . . . . . . . . . . . . . . . . 28
6.3 DHW program . . . . . . . . . . . . . . . . 29
6.3.1 DHW program operating modes . . 29
6.3.2 Time/temperature level program for
DHW via cylinder . . . . . . . . . . . . . . 30
6.3.3 Time program for DHW with combi
boiler . . . . . . . . . . . . . . . . . . . . . . . 30
6.3.4 Time program for DHW circulation
pump (only with DHW cylinder) . . 31
6.3.5 Parameters for DHW . . . . . . . . . . . 31
6.3.6 Thermal disinfection of DHW . . . . . 32
6.4 Holiday program . . . . . . . . . . . . . . 33
6.5 General settings . . . . . . . . . . . . . . 34
6.5.1 Time and Date . . . . . . . . . . . . . . . . 34
6.5.2 Display formats . . . . . . . . . . . . . . . 34
6.5.3 Key lock . . . . . . . . . . . . . . . . . . . . . 34
6.5.4 Language . . . . . . . . . . . . . . . . . . . . 34
6.6 Solar settings . . . . . . . . . . . . . . . . 35
7 Viewing information . . . . . . . . . . . . . . . . 36
Chapters against a grey background
are intended for installers. The
pages concerned are identified by a
grey vertical bar at the side of the
page.

6 720 800 844 (2012/02)
Contents | 5
8 Menu settings INSTALLER SETTINGS
(contractors only) . . . . . . . . . . . . . . . . . 39
8.1 INSTALLER SETTINGS
menu summary and settings . . . . . 39
8.1.1 INSTALLER SETTINGS:
System configuration . . . . . . . . . . 39
8.1.2 INSTALLER SETTINGS:
Heating parameters . . . . . . . . . . . 40
8.1.3 INSTALLER SETTINGS:
Solar system config . . . . . . . . . . . 40
8.1.4 INSTALLER SETTINGS: Solar sys
parameters . . . . . . . . . . . . . . . . . . . 41
8.1.5 INSTALLER SETTINGS:
Fault history . . . . . . . . . . . . . . . . . 41
8.1.6 INSTALLER SETTINGS: Cust service
address . . . . . . . . . . . . . . . . . . . . . . 42
8.1.7 INSTALLER SETTINGS:
System info . . . . . . . . . . . . . . . . . . . 42
8.1.8 INSTALLER SETTINGS:
Floor drying . . . . . . . . . . . . . . . . . 42
8.2 Configuring the heating system. . . 43
8.3 Parameters for heating . . . . . . . . . 43
8.4 Configuring the solar thermal
system . . . . . . . . . . . . . . . . . . . . . 47
8.5 Parameters for solar thermal
system . . . . . . . . . . . . . . . . . . . . . 48
8.5.1 Parameters for the standard solar
thermal system . . . . . . . . . . . . . . . 48
8.5.2 Parameters for thermal
disinfection . . . . . . . . . . . . . . . . . . 49
8.5.3 Parameters for solar
optimisation . . . . . . . . . . . . . . . . . 49
8.5.4 Commissioning the solar thermal
system . . . . . . . . . . . . . . . . . . . . . 51
8.6 Fault history . . . . . . . . . . . . . . . . . 51
8.7 Viewing and entering the customer
service address . . . . . . . . . . . . . . . 51
8.8 Viewing system information . . . . . 51
8.9 Screed drying function . . . . . . . . . 52
9 Troubleshooting . . . . . . . . . . . . . . . . . . 53
9.1 Troubleshooting with display
(contractors only) . . . . . . . . . . . . . 53
9.2 Troubleshooting without display . 58
10 Energy saving tips . . . . . . . . . . . . . . . . . 60
11 Environmental protection . . . . . . . . . . . 61
12 Individual time program settings . . . . . 62
12.1 Heating program . . . . . . . . . . . . . . 62
12.2 DHW program . . . . . . . . . . . . . . . . 63
12.3 DHW circulation program . . . . . . . 64
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

6 720 800 844 (2012/02)
6| Key to symbols and safety instructions
1 Key to symbols and safety instructions
1.1 Explanation of symbols
Warnings
Keywords at the start of a warning indicate the
type and seriousness of the ensuing risk if
measures to prevent the risk are not taken.
•NOTE indicates that material losses may
occur.
•CAUTION indicates that minor to medium
injury may occur.
•WARNING indicates that severe injury may
occur.
•DANGER indicates a risk to life.
Important information
Additional symbols
Conventions used in these for representing the
menu structure:
•Individual menu levels are separated by the
> symbol, e.g. Holiday > Start
•Parameters that can be set/selected on a
menu are marked with a bullet point • .
•The operation of control elements is indicated
by the symbol for the control:
–means turn rotary selector
–means press rotary selector
–means press and release menu key
–means press and release info key
–means press and release delete/reset
key
–means press and release menu up key
–means press and release advance
switching time key
–means press and release immediate
DHW key
Warnings in this document are framed
and identified by a warning triangle
printed against a grey background.
If there is a danger due to
electricity, the exclamation mark in
the warning triangle is replaced by a
lightning symbol.
Important information where there is
no risk to people or property is
indicated with the adjacent symbol. It
is bordered by lines above and below
the text.
Symbol Explanation
BAction step
ÆCross-reference to other parts of this
document or to other documents
•List/list entry
–List/list entry (second level)
Tab. 3
menu
info

6 720 800 844 (2012/02)
Key to symbols and safety instructions | 7
1.2 Safety instructions
BThese instructions must be observed to
ensure correct operation.
BInstall and commission the heating appliance
and all accessories in accordance with the
instructions provided.
BThis accessory must only be installed by
suitably qualified installers.
BOnly use these accessories in conjunction
with the heating appliances listed. Follow the
connection diagram!
BDo not connect this accessory to the 230 V
mains electricity supply.
BPrior to the installation of this accessory:
Isolate the heating appliance and all other
BUS subscribers from the power supply
(220 to 240 V AC).
BFor wall mounting: never install this accessory
in wet areas.
BInstruct customers about the functions and
operation of the accessories.
BRisk of scalding during thermal disinfection:
Supervise short periods of operation with
water temperatures over 60 °C or fit a
thermostatic DHW mixer.
BWhen there is a risk of frost, leave the heating
appliance switched on and follow the frost
protection information.

6 720 800 844 (2012/02)
8| Technical data for the accessory item
2 Technical data for the accessory item
•This controller is used to display appliance
and system information and to change the
settings shown.
•The controller is a weather-compensated
controller for central heating and DHW
heating with time programs:
–Central heating : 3 seven-day heating
programs with 6 switching times per day
are available (one program is active).
–Domestic hot water : weekly DHW
program with 6 switching times per day.
•Options:
–Remote control FB 100 or FB 10.
–Module IPM 1 for controlling one mixed or
non-mixed heating circuit.
–ISM 1 module for solar DHW heating.
•The controller has a power reserve sufficient
for at least 6 hours of operation. If the
controller is without power for a period longer
than the power reserve then the time and date
will be deleted. All other settings are saved.
•Installation options:
–In heating appliance with BUS-enabled
Heatronic 3
–Wall-mounted with BUS connection to
heating appliance with BUS-enabled
Heatronic 3
2.1 Standard delivery
Fig. 2 Standard delivery
1Controller top section
2Base for wall mounting
3Slide cover
4Installation and operating instructions
5Outside temperature sensor with fixing
materials
The FW 120 can only be connected
to a heating appliance with BUS-
enabled Heatronic 3.
2x
2x
5
2
4
1
3
6 720 612 481-01.1R
8

6 720 800 844 (2012/02)
Technical data for the accessory item | 9
2.2 Specification 2.3 Cleaning
BIf required, use a damp cloth to wipe the
controller casing. Never use aggressive or
acidic cleaning agents for this.
2.4 Supplementary accessories
See also the pricelist.
•IPM 1: Module for controlling one mixed or
one non-mixed heating circuit.
•ISM 1: Module for controlling solar water
heating.
•IUM 1: Module for controlling external safety
equipment.
•FB 10: Remote control for the mixed or non-
mixed heating circuit.
•FB 100: Remote control with plain text display
for the mixed or non-mixed heating circuit.
•No. 1143: Cable set for fitting one module
(e.g. IPM 1) inside the heating appliance.
Dimensions Fig. 8, page 13
Rated voltage 10...24 V DC
Rated current
(excluding illumination)
6 mA
Controller output 2-wire BUS
Permiss. ambient temp. 0 ... +50 °C
IP rating III
Protection:
- Built into the Heatronic 3
- Wall mounting
IPX2D
IP20
Tab. 4 Specification
°C ΩAF °C ΩAF
– 20 2392 4984
– 16 2088 8842
– 12 1811 12 720
– 8 1562 16 616
– 4 1342 20 528
±0 1149 24 454
Tab. 5 Actual values, outside temperature
sensor

6 720 800 844 (2012/02)
10 | Technical data for the accessory item
2.5 Sample system
Fig. 3 Simplified system scheme (see technical guides for installation illustration and further options)
AF Outside temperature sensor
FB 10 Remote control
FB 100 Remote control
FK Flat-plate collector
FW 120 Weather-compensated controller with
solar control
HK Heating circuit
HP Heating circuit pump
HW Low loss header
IPM 1 Module for one heating circuit
ISM 1 Module for solar DHW heating
KW Cold water connection
MMixer servomotor
MF Flow temperature sensor, mixed
heating circuit
PCirculation pump for heating circuit
SP Solar circuit pump
S...solar Solar combi cylinder
SF Cylinder temperature sensor (NTC)
T1Collector temperature sensor
T2Cylinder temperature sensor on the
heating water side, bottom
TB Temperature limiter
TWM Thermostatic DHW mixer
VF Common flow sensor
WW DHW connection
1) The FW 120 can be mounted in the
heat source or on the wall.
2) Either FB 10 or FB 100
6 720 800 004-01.1O
WW
TWM
KW
S...solar
SP SF
HK
MF
TB
M
P
1)
FW 120 FB 10
VF
230V AC
T
2
AF
FK
230V AC
ISM1
2)
T
1
FB 100
2)
HP
1)
FW 120
HW
IPM1
230V AC

6 720 800 844 (2012/02)
Installation (for contractors only) | 11
3 Installation (for contractors only)
The detailed system scheme for installing the
hydraulic components and associated control
devices can be found in the technical guides or
tender documentation.
3.1 Installation
3.1.1 Installation in heating appliance
BDetailed description of heating appliance
components, see heating appliance
installation instructions.
BRemove outer casing.
Fig. 4
BRemove cover and dummy cover.
Fig. 5
BInsert top section into slots.
Fig. 6
DANGER: Risk of electric shock!
BPrior to the installation of this
accessory:
Isolate the heating appliance and
all other BUS subscribers from the
power supply (220 to 240 V AC).
6 720 645 342-03.1O
3.
6 720 641 933-33.1O
4.
1.
2.
6 720 641 933-31.1O

6 720 800 844 (2012/02)
12 | Installation (for contractors only)
BClick top section into place and mount cover.
Fig. 7
6 720 641 933-32.1O
2.
1.
3.
4.

6 720 800 844 (2012/02)
Installation (for contractors only) | 13
3.1.2 Wall mounting
The control quality of the controller is dependent
on where it is installed.
The installation location (= lead room) must be
suitable for controlling the heating.
BSelect the installation location.
Fig. 8
BRemove the top section and slide cover from
the base.
Fig. 9
BFit the base.
Fig. 10
BMake the electrical connections (ÆFig. 14 or
15 on page 16).
BRefit top section an slide cover on base.
Fig. 11
The mounting surface on the wall
should be level.
6 720 612 481-03.1R
0,3 m0,3 m
1,2 - 1,5 m
0,6 m
119 mm
134 mm
35 mm
1.
2.
3.
6 720 612 220-27.1J
6 720 645 340-07.1O
6 mm 3,5 mm6 mm
3.
2.
1.
6 720 612 220-06.1R

6 720 800 844 (2012/02)
14 | Installation (for contractors only)
3.1.3 Installation of outside temperature sensor
Control quality depends on installation location
of outside temperature sensor AF.
BSelect the installation location.
Fig. 12
1
/
2
H
(min 2m)
H
1
/
2
Y
Y
1
/
2
H
(min 2m)
H
N
S
WE
NW NE
SW SE
6 720 645 349-02.1O

6 720 800 844 (2012/02)
Installation (for contractors only) | 15
BRemove cover.
BFix sensor housing to external wall with two
screws.
Fig. 13
3.1.4 Fitting other accessories
BFit accessories according to the legal
requirements and the installation instructions
supplied with them.
3.1.5 Disposal
BDispose of packaging in an environmentally
responsible manner.
BWhen replacing components, dispose of the
used components in an environmentally
responsible manner.
3.2 Electrical connections
3.2.1 Electrical connection in the heating
appliance
BInstallation of the controller automatically
produces BUS connection via the three
contacts (ÆFig. 6 on page 11).
Fig. 14 Controller installed via BUS contacts in
BUS-enabled Heatronic 3.
1.
2.
6 720 610 967-10.2J
The controller recognises via the
third contact that it is installed
inside the heating appliance.
FW 120
124BB
6 720 800 004-02.1O
ST 19
Heatronic 3
AF
AF

6 720 800 844 (2012/02)
16 | Installation (for contractors only)
3.2.2 Electrical connection for wall mounting
BBUS connection from the controller to other
BUS subscribers:
Use electrical cable according to local codes
and requirements.
Permissible cable lengths from the BUS-enabled
Heatronic 3 to the controller:
BTo prevent inductive interference: Route all LV
leads separately from cables carrying 220 to
240 V or 380 to 415 V (minimum separation
100 mm).
BIn case of external inductive interference,
shield the cables.
This ensures that the cables are shielded from
external interference (e.g. heavy current
cables, overhead wires, transformer stations,
radio and television set, amateur radio
stations, microwave ovens etc).
Fig. 15 Controller connected to BUS-enabled
Heatronic 3.
Fig. 16 BUS links connected via branch box (A)
Permissible cable lengths to outside temperature
sensor:
Cable length Cross-section
≤80 m 0.40 mm2
≤100 m 0.50 mm2
≤150 m 0.75 mm2
≤200 m 1.00 mm2
≤300 m 1.50 mm2
Tab. 6
124BB
6 720 800 004-03.1O
ST 19
AF
B
B
AF
FW 120
Heatronic 3
If the BUS links feature different
cross-sections:
BConnect BUS links via a branch
box.
Cable length Cross-section
≤20 m 0.75 mm2... 1.50 mm2
≤30 m 1.00 mm2... 1.50 mm2
≥30 m 1.50 mm2
Tab. 7
B
2
BB
A
B
2
BB
B
2
BB
6 720 612 220-08.1J
100 mm 100 mm

6 720 800 844 (2012/02)
Commissioning (contractors only) | 17
4 Commissioning (contractors only)
BSet DIP switch at IPM 1 to 1.
BSwitch ON the system.
BSet FB 10 or FB 100 to 1.
During commissioning or after a global reset
(resetting all settings), the language selected for
the factory settings will be displayed.
BSelect the language with and confirm
with .
BSet the date and time if the reserve power
supply has run out.
–Select the hour with and confirm with
.
–Select the minutes with and confirm
with .
–Select the year with and confirm with
.
–Select the month with and confirm
with .
–Select the day with and confirm with
.
BThe automatic system configuration starts
during commissioning (wait for 60 seconds
and then follow the instructions displayed).
BSwitch off automatic Auto switch between
GMT - BST Æchapter 6.5.1 from page 34
BAdapting other settings to the current system,
Æchapter 6 from page 25 and chapter 8 from
page 39.
BFill and vent solar thermal system according to
its documentation and prepare it for
commissioning as described in chapter 8.4 on
page 47.
BAdapting other settings to the current solar
thermal system, Æchapter 8.5 from page 48.
BCommission the solar thermal system,
Æchapter 8.5.4 on page 51.
Description of the controls
Æpage 2.

6 720 800 844 (2012/02)
18 | Operation
5 Operation
5.1 Changing the room temperature
and operating mode
5.1.1 Changing the set room temperature for a
limited period
You can also permanently change the required
room temperature, Æchapter 6.2.2 on page 28.
This function is only available if the heating
system is not regulated via remote control
FB 100:
BSet the required room temperature with .
–If the operating mode selector is set to
:
The new temperature applies until the next
switching point. Afterwards, the set
temperature applies for the switching
period.
–If the operating mode selector is set to
/ / : The new temperature applies
until the selector position is changed.
Afterwards, the set temperature applies to
the selected operating mode.
5.1.2 Advancing heating mode before the
programmed time (bringing forward the
next switching point)
To permanently change the operating mode,
Æchapter 5.1.4 on page 19.
This function is only available if the heating system
is not regulated via remote control FB 100 and
automatic mode has been activated :
BPress briefly to bring forward the next
switching time and the associated operating
mode Comfort / Economy / Frost to
the current time.
The display shows the changed details.
BPress and hold and simultaneously turn
the rotary selector to change the next
switching point. As a maximum, the switching
time can be changed between the current
time and the switching time after next.
If the next switching time of the heating
program is exceeded, the function will be
reset, and automatic mode will be active
again.
Cancelling the function early:
BPress briefly again.
The controller provides the option
of setting the required room
temperature for the operating mode
concerned. The temperature given
is not the actual room temperature.
It is an orientation value that
influences the required flow
temperature.
The functions of the controls and the
meanings of the symbols on the
display are explained on pages 2
and 3.
The function can be used in
situations such as going to bed
earlier, being away from home
longer or returning early.

6 720 800 844 (2012/02)
Operation | 19
5.1.3 Changing DHW mode (time-limited)
BPress and release to activate DHW heating
immediately.
–The DHW cylinder is heated up to the
temperature set in the DHW program for
60 minutes.
–With a combi boiler, comfort mode is
activated for 30 minutes.
To undo the change to DHW mode:
BPress briefly again.
5.1.4 Changing heating mode permanently
Automatic mode
(factory setting)
Automatic change between Comfort /
Economy / Frost according to the active
heating program. The controller regulates to the
room temperatures selected in submenu Heating
levels (Æchapter 6.2.2 on page 28).
Constant heating
The controller constantly maintains the room
temperature set for Comfort in submenu
Heating levels (Æchapter 6.2.2 on page 28).
The heating program is ignored.
Constant economy
The controller constantly maintains the room
temperature set for Economy in
submenu Heating levels (Æchapter 6.2.2 on
page 28). The heating program is ignored.
Constant frost protection
The controller constantly maintains the room
temperature set for Heating levels in
submenu Heating levels (Æchapter 6.2.2 on
page 28). The heating program is ignored.
You can use this function if you need
hot water outside the programmed
switching times.
DHW is heated independently of the
position of the operating mode selector
in accordance with the DHW program
(
Æ chapter 6.3 from page 29 ).

6 720 800 844 (2012/02)
20 | Operation
5.2 Display views and menu
navigation
The user interface of the weather- compensation
controller FW 120 is implemented as a menu
system. Within that menu, the various functions
are arranged in a hierarchical structure. For
greater clarity, the menu is subdivided into three
sections (MAIN MENU, INFO, INSTALLER
SETTINGS). Each section can be accessed by its
own button. For the entire menu tree, see
chapters 6.1, 7 and 8.1.
To navigate through the menu:
•Press to open MAIN MENU. From any
point within the MAIN MENU, press to
go back to the standard display.
•Press to open the INFO menu. From any
point within the INFO menu, press to go
back to the standard display.
•Hold down for at least 3 seconds to open
the INSTALLER SETTINGS menu. From any
point within the INSTALLER SETTINGS menu,
press to go back to the standard display.
•The selected menu point/parameter is
displayed in colours, i.e. white on
black.
•Arrows in the left margin indicate that there is
more information than can be shown on the
display at once. It can be viewed with .
•opens the submenu associated with the
selected menu point/parameter or activates
editing mode for the parameter (the
parameter setting starts flashing).
•A flashing parameter setting (e.g. switching
time or operating mode)
–can be changed with .
–can be deleted (reset to the default) with
.
–is stored with .
–remains unchanged if any other key apart
from is pressed.
•To return to the next menu up from a
submenu:
–Highlight menu point and
confirm with , or
–press .
menu
menu
info
info
menu
menu
i
n
f
o
inverse
