Bosch GLM 10 Assembly instructions

IMPORTANT: IMPORTANT: IMPORTANTE:
Read Before Using Lire avant usage Leer antes de usar
Operating/Safety Instructions
Consignes d’utilisation/de sécurité
Instrucciones de funcionamiento y seguridad
1-877-BOSCH99 (1-877-267-2499) www.boschtools.com
For English Version Version française Versión en español
See page 4 Voir page 17 Ver la página 33
GLM 10
GLM 10
Call Toll Free for Consumer Information & Service Locations
Pour obtenir des informations et les adresses de nos centers de service
après-vente, appelez ce numéro gratuit
Llame gratis para obtener información para el consumidor y
ubicaciones de servicio

-2-
GLM 10
1
a
e
dc
f
b
g
2
4
5
6
7
8
3
9

-3-
1’ 6” (0.5m)
1’ 6” (0.5m)
8’ (2.45m)
1’ 6” (0.5m)

-4-
General Safety Rules
Read all instructions. Failure to follow all
instructions listed below may result in
hazardous radiation exposure, electric shock, fire and/or
serious injury. The term “tool” in the warnings listed below
refers to your mains-operated (corded) tool or battery-operated
(cordless) tool.
SAVE ALL WARNINGS AND INSTRUCTIONS
FOR FUTURE REFERENCE
The following label is on your laser
tool for your safety. ALWAYS BE
AWARE of their location when
using the tool.
DO NOT direct the
laser beam at persons
or animals and do not
stare into the laser beam yourself. This tool
produces class 2 laser radiation and complies
with 21 CFR 1040.10 and 1040.11 except for deviations
pursuant to Laser Notice No. 50, dated June 24, 2007. This
can lead to persons being blinded.
!
WARNING
Safety Symbols
The definitions below describe the level of severity for each signal
word. Please read the manual and pay attention to these symbols.
!
This is the safety alert symbol. It is used to alert you to potential
personal injury hazards. Obey all safety messages that follow
this symbol to avoid possible injury or death.
Read manual symbol - Alerts user to read manual.
WARNING indicates a hazardous situation which,
if not avoided, will result in death or serious injury.
!
WARNING

-5-
Working safely with the
measuring tool is possible
only when the operating and
safety information are read
completely and the instructions
contained therin are strictly
followed. Never make warning
labels on the Measuring tool
unrecognizable.
Never aim the beam at a
workpiece with a reflective
surface. Bright shiny reflective
sheet steel or similar reflective
surfaces are not recommended
for laser use. Reflective surfaces
could direct the beam back
towards the operator.
Take care to recognize the
accuracy and range of the
device. Measurement may not be
accurate if used beyond the rated
range of the device.
Use of controls or adjustments
or performance of procedures
other than those specified
herein may result in hazardous
radiation exposure.
The use of optical instruments
with this product will increase
eye hazards.
Have the measuring tool
repaired only through qualified
specialist using original spare
parts. This ensures that the
safety of the measuring tool is
maintained.
Do not allow children to use
the measuring tool without
supervision. They could
unintentionally blind other
persons.
Do not point the laser beam
at persons or animals and do
not look into the laser beam
yourself, not even from a large
distance.
Do not use the laser viewing
glasses as safety goggles. The
laser viewing glasses are used for
improved visualization of the laser
beam, but they do not protect
against laser radiation.
Do not use the laser viewing
glasses as sun glasses or
in traffic. The laser viewing
glasses do not afford complete
UV protection and reduce color
perception.
Safety Rules
Be sure to read and understand
all instructions in this manual
before using this product.
Failure to follow all instructions
may result in hazardous radiation
exposure, electric shock, fire,
and/or bodily injury.
Use of controls or adjustments
or performance of procedures
other than those specified
Safe Operating Procedures

-6-
in this manual, may result in
hazardous radiation exposure.
The use of optical instruments
with this product will increase
eye hazard.
ALWAYS: Make sure that any
bystanders in the vicinity of use
are made aware of the dangers
of looking directly into the
measuring tool.
DO NOT remove or deface
any warning or caution labels.
Removing labels increases
the risk of exposure to laser
radiation.
DO NOT stare directly at the
laser beam or project the laser
beam directly into the eyes of
others. Serious eye injury could
result.
DO NOT place the measuring
tool in a position that may
cause anyone to stare into
the laser beam intentionally
or unintentionally. Serious eye
injury could result.
DO NOT use any optical tools
such as, but not limited to,
telescopes or transits to view
the laser beam. Serious eye
injury could result.
ALWAYS remove the batteries
when cleaning the laser light
aperture to laser lens.
DO NOT operate the measuring
tool around children or
allow children to operate the
measuring tool. Serious eye
injury could result.
ALWAYS turn the measuring
tool “OFF” when not in use.
Leaving the measuring tool “ON”
increases the risk of someone
inadvertently staring into the laser
beam.
DO NOT operate the measuring
tool in combustible areas such
as in the presence of flammable
liquids, gases or dust.
ALWAYS position the
measuring tool securely.
Damage to the measuring tool
and/or serious injury to the user
could result if the measuring tool
falls.
ALWAYS use only the
accessories that are
recommended by the
manufacturer of your measuring
tool. Use of accessories that
have been designed for use with
other measuring tools could result
in serious injury.
DO NOT leave measuring tool
“on” unattended in any operation
mode.
Repair and servicing must
always be performed by a
qualified repair facility. Repairs
performed by unqualified
personnel could result in serious
injury.
DO NOT use this measuring
tool for any purpose other than
those outlined in this manual.
This could result in serious injury.
DO NOT disassemble the
measuring tool. There are no
user serviceable parts inside.

-7-
Disassembling the laser will
void all warranties on the
product. Do not modify the
product in any way. Modifying
the measuring tool may result
in hazardous laser radiation
exposure.
Electrical safety
Batteries can explode or leak,
cause injury or fire. To reduce
this risk, always follow all
instructions and warnings on
the battery label and package.
DO NOT short any battery
terminals.
DO NOT charge alkaline
batteries.
DO NOT mix old and new
batteries. Replace all of them
at the same time with new
batteries of the same brand
and type.
DO NOT mix battery
chemistries.
Dispose of or recycle batteries
per local code.
DO NOT dispose of batteries
in fire.
Keep batteries out of reach of
children.
Remove batteries if the device
will not be used for several
months.
The measuring tool is intended for measuring distances,
lengths, heights and clearances. The measuring tool is suitable
for measuring only indoors.
Intended Use
Features
The numbering of the product features shown refers to the
illustration of the measuring tool on the graphic page.
1On/Off (Hold button)
2 Display
3 Battery lid
4Latch of battery lid
5Serial number
6Laser warning label
7Reception lens
8Laser beam outlet
9Hand strap *
* Optional accessory
Display Elements
aBattery low indicator
bTemperature warning
cLaser switched on
dMeasurement hold
ePrevious measuring value
fUnit of measure
gCurrent measuring value

-8-
Digital Laser Measure GLM 10
Measuring range (typical) 6 in - 35 ft (0.15 –10 mA)
Measuring accuracy (typical) ±1/8 in (±3.0 mmB)
Lowest indication unit 1/16 in (1 mm)
Measuring duration
– typical 0.5 s
– maximal 4 s
Operating temperature +14° F to 104° F (-10° C to +40° C)
Storage temperature -4° F to 158° F (-20° C to +70° C)
Relative air humidity, max. 90 %
Laser class 2
Laser type 635 nm, <1mW
Laser beam diameter 77° F (at 25 °C)
at 35 ft (10 m) distance, approx. 3/8 in (9 mm)
Batteries 2 x 1.5V (AAA)
Battery service life in measuring operation, approx. 5 h
Weight 0.2 lb (0.1 kg)
Dimensions 4 x 1.4 x 0.9 in (100 x 36 x 23 mm)
A) The working range increases depending on how well the laser light is reflected
from the surface of the target (scattered, not reflective) and with increased brightness
of the laser point to the ambient light intensity (interior spaces, twilight). In unfavorable
conditions, e.g., with extreme interior illumination or a badly reflecting surface, the
measuring range may be limited.
B) In unfavorable conditions, e.g., with extreme interior illumination, badly reflecting
surface or the room temperature deviating heavily from 77°F (25°C), the maximum
deviation can be up to ±7 mm per 15 m. In favorable conditions, a deviation influence
of ±0.05 mm/m must be taken into account.
The measuring tool can be clearly identified with the serial number 5on the type
plate.
Technical Data

-9-
Preparation
Inserting/Replacing the Batteries
AAA Alkaline batteries are recommended for the measuring
tool.
To open the battery lid 3, press the latch 4in the direction
of the arrow and remove the battery lid. Insert the batteries.
When inserting, pay attention to the correct polarity
according to the representation on the inside of the battery
compartment.
When the battery symbol appears for the first time on
the display, measurements are still possible for approx. 15
minutes. When the battery symbol flashes, the batteries must
be replaced; measurements are no longer possible.
Always replace all batteries at the same time. Only use
batteries from one brand and with the identical capacity.
Remove the batteries from the tool when not using it for
extended periods. When storing for extended periods, the
batteries can corrode and discharge themselves.

-10-
Operation
Initial Operation
Protect the tool against moisture and
direct sun irradiation.
Do not subject the tool to extreme temperatures or
variations in temperature. As an example, do not leave it
in vehicles for longer periods. In case of large variations in
temperature, allow the tool to adjust to the ambient temperature
before putting it into operation. In case of extreme temperatures
or variations in temperature, the accuracy of the tool can be
impaired.
Avoid heavy impact or falling of the tool. After heavy exterior
impact on the tool, an accuracy check should always be
carried out before continuing to work (see “Accuracy Check
of the Distance Measurement”, page 13) each time before
continuing to work.
Do not point the laser beam at persons
or animals and do not look into the laser
beam yourself, not even from a large distance.
Do not leave the switched on measuring tool unattended
and switch the tool off after use. Other persons could be
blinded by the laser beam.
Switching On and Off
To switch on the measuring tool, push down the On/Off button
1. When switching on the measuring tool, the laser beam is
switched on. The laser indicator flashes on the display.
To switch off the measuring tool, push down the On/Off button 1
and hold for 3 seconds.
When no button on the measuring tool is pressed for approx. 5
minutes, the measuring tool automatically switches off to save
the batteries.
Measuring Procedure
Measurements are taken from the rear edge of the tool as
indicated by icon located on the tool’s rubber overmold.
!
WARNING
!
WARNING

-11-
After the measuring tool is switched on, continuous
measurement starts. Aim the laser beam at the target surface.
The current measuring value gis displayed in the bottom line
of the display (see figure A). During continuous measurement,
the measuring tool can be moved relative to the target, whereby
the current measuring value gis updated approx. every 0.5
seconds in the bottom line of the display (see figure B).
In this manner,as an example, you can move a certain distance
away from a wall, while the actual distance can always be read.
The laser indicator flashes on the display.
The rear edge of the measuring tool is preset as the reference
plane for the measurement.
For a wall to wall measurement, as an example, position the
measuring tool with its rear edge against the initial wall.
No Measurement Being Displayed
All dashes will display when the beam is
moved too fast or if the object is out of
range in continuous mode.
“HOLD” Function (see Figure B)
Press the “On/Off” button 1to stop the
measuring procedure. The laser beam
is switched off and the HOLD indication
appears on the display.
The current measuring value is still
displayed in the bottom line of the display,
but is no longer continuously updated.
Press the “HOLD” button 1once more
to switch the laser on again. The laser
indicator flashes on the display. The
previous measuring value is displayed in the
top line. The continuously updated/current
measuring value is displayed in the bottom
line.

-12-
Press the “HOLD” button 1once more to
stop the measuring procedure again. The
laser beam is switched off and the HOLD
indication appears on the display. The
previous measuring value is displayed in
the top line. The current measuring value
is displayed in the bottom line, but is no
longer continuously updated.
When no button on the measuring tool is pressed for approx. 5
minutes, the measuring tool automatically switches off to save
the batteries.
“Err” occurs when trying to hold a
measurement that is out of range or
measurement cannot be read correctly by tool.
Changing the Unit of Measure
The unit of measure can be changed any time for display of
the measured value, even for already measured or calculated
values.
Switch off the measuring tool. Press the measuring button 1
and hold it down. The display will alternately show both units
of measure. When the desired setting is displayed, release the
measuring button 1. The setting is saved.
Working Advice
General Information
The reception lens 7and the laser beam outlet 8must not be
covered when taking a measurement.
Measurement takes place at the center of the laser beam, even
when target surfaces are at a slope.

-13-
Influence Effects on the Measuring Range
The measuring range depends on the light conditions and the
reflection properties of the target surface.
Influence Effects on the Measuring Result
Due to physical effects, faulty measurements cannot be excluded
when measuring on different surfaces. Included here are:
– Transparent surfaces (e.g., glass, water),
– Reflecting surfaces (e.g., polished metal, glass),
– Porous surfaces (e.g. insulation materials),
– Structured surfaces (e.g., roughcast, natural stone).
Also, air layers with varying temperatures or indirectly received
reflections can affect the measured value.
Accuracy Check of the Distance Measurement
The accuracy of the distance measurement can be checked as
follows:
– Select a permanent measuring section with a length of
approx. 3 ft to 35 ft (1 m to 10 m); its length must be precisely
known (e.g. the width of a room or a door opening). The
measuring distance must be indoors; the target surface for the
measurement must be smooth and reflect well.
– Measure the distance 10 times after another.
The deviation of the individual measurements from the mean
value must not exceed ±1/8” (±3.0mm). Log the measurements,
so that you can compare their accuracy at a later point of time.
Troubleshooting
Cause Corrective Measure
Temperature warning indicator (b) flashing; measurement
not possible
Measuring tool not within the Wait until the measuring
operating temperature range tool has reached the
between +14°F and 104°F operating temperature
( –10°C and +40°C)

-14-
Maintenance and Service
Keep the measuring tool clean at all times.
Do not immerse the measuring tool into water or other
fluids.
Wipe off debris using a moist and soft cloth. Do not use any
cleaning agents or solvents.
Maintain the reception lens 7 in particular, with the same
care as required for eye glasses or the lens of a camera.
If the measuring tool should fail despite the care taken
in manufacturing and testing procedures, repair should
be carried out by an authorized after-sales service center
for Bosch power tools. Do not open the measuring tool
yourself.
In all correspondence and spare parts orders, please always
include the 10-digit article number given on the type plate of
the measuring tool.
ENVIRONMENT PROTECTION
Recycle raw materials & batteries instead of disposing
of waste. The unit, accessories, packaging & used
batteries should be sorted for environmentally friendly
recycling in accordance with the latest regulations.
!
WARNING
Battery low indicator (a) appears
Battery voltage decreasing Replace batteries
(measurement still possible).
Battery low indicator (a) flashing; measurement not possible
Cause Corrective Measure
Battery voltage too low Replace batteries
All indicators on the display flash
The measuring tool is defective. Contact the Customer
Service

-15-
Robert Bosch Tool Corporation (“Seller”) warrants to the
original purchaser only, that all Bosch lasers and measuring
tools will be free from defects in material or workmanship for
a period of one (1) year from date of purchase. Bosch will
extend warranty coverage to two (2) years when you register
your product within eight (8) weeks after date of purchase.
Product registration card must be complete and mailed to
Bosch (postmarked within eight weeks after date of purchase),
or you may register on-line at www.boschtools.com/Service/
ProductRegistration. If you choose not to register your product,
a one (1) year limited warranty will apply to your product.
30 Day Money Back Refund or Replacement -
If you are not completely satisfied with the performance of your
laser and measuring tools, for any reason, you can return it to
your Bosch dealer within 30 days of the date of purchase for
a full refund or replacement. To obtain this 30-Day Refund or
Replacement, your return must be accompanied by the original
receipt for purchase of the laser or optical instrument product.
A maximum of 2 returns per customer will be permitted.
SELLER’S SOLE OBLIGATION AND YOUR EXCLUSIVE
REMEDY under this Limited Warranty and, to the extent
permitted by law, any warranty or condition implied by
law, shall be the repair or replacement of parts, without
charge, which are defective in material or workmanship
and which have not been misused, carelessly handled,
or misrepaired by persons other than Seller or Authorized
Service Center. To make a claim under this Limited Warranty,
you must return the complete Bosch laser or measuring
tool, transportation prepaid, to any BOSCH Factory Service
Center or Authorized Service Center. Please include a dated
proof of purchase with your tool. For locations of nearby
service centers, please use our on-line service locator or call
1-877-267-2499.
LIMITED WARRANTY OF BOSCH LASER AND
MEASURING TOOL PRODUCTS

-16-
THIS WARRANTY PROGRAM DOES NOT APPLY TO TRIPODS
AND RODS. Robert Bosch Tool Corporation (“Seller”) warrants
tripods and leveling rods for a period of one (1) year from date
of purchase.
THIS LIMITED WARRANTY DOES NOT APPLY TO OTHER
ACCESSORY ITEMS AND RELATED ITEMS. THESE ITEMS
RECEIVE A 90 DAY LIMITED WARRANTY.
To make a claim under this Limited Warranty, you must return
the complete product, transportation prepaid. For details to
make a claim under this Limited Warranty please visit www.
boschtools.com or call 1-877-267-2499.
ANY IMPLIED WARRANTIES SHALL BE LIMITED IN DURATION
TO ONE YEAR FROM DATE OF PURCHASE. SOME STATES
IN THE U.S., AND SOME CANADIAN PROVINCES DO
NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED
WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT
APPLY TO YOU.
IN NO EVENT SHALL SELLER BE LIABLE FOR ANY
INCIDENTAL OR CONSEQUENTIAL DAMAGES (INCLUDING
BUT NOT LIMITED TO LIABILITY FOR LOSS OF PROFITS)
ARISING FROM THE SALE OR USE OF THIS PRODUCT. SOME
STATES IN THE U.S., AND SOME CANADIAN PROVINCES
DO NOT ALLOW THE EXCLUSION OR LIMITATION OF
INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE
ABOVE LIMITATION MAY NOT APPLY TO YOU.
THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL
RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH
VARY FROM STATE TO STATE IN THE U.S., OR PROVINCE TO
PROVINCE IN CANADA AND FROM COUNTRY TO COUNTRY.
THIS LIMITED WARRANTY APPLIES ONLY TO PRODUCTS
SOLD WITHIN THE UNITED STATES OF AMERICA, CANADA
AND THE COMMONWEALTH OF PUERTO RICO. FOR
WARRANTY COVERAGE WITHIN OTHER COUNTRIES,
CONTACT YOUR LOCAL BOSCH DEALER OR IMPORTER.

-17-
Symboles relatifs à la sécurité
Les définitions ci-dessous décrivent le niveau de gravité
pour chaque terme signalant un danger. Veuillez lire le mode
d’emploi et lire la signification de ces symboles.
!
C’est le symbole d’alerte relatif à la sécurité. Il est utilisé
pour vous avertir de l’existence possible d’un danger de
lésion corporelle. Obéissez à tous les messages relatifs à
la sécurité qui suivent ce symbole pour éviter tout risque
de blessure ou même de mort.
Symbole de lecture du mode d’emploi - Alerte
l’utilisateur pour lire le mode d’emploi.
AVERTISSEMENT indique une
situation dangereuse qui, si
elle n’est pas évitée, causera la mort d’une personne ou une
blessure grave.

-18-
Consignes générales de sécurité
Lisez toutes les instructions.
Le non-respect de toutes les
instructions figurant ci-dessous risquerait de causer
une exposition dangereuse aux rayonnements, un choc
électrique, un incendie et/ou des blessures graves. Dans
les avertissements, le terme « outil électroportatif » se rapporte
à votre outil branché sur le secteur (avec fil) ou à votre outil
alimenté par piles (sans fil).
L’étiquette suivante est
apposée sur votre outil laser
pour votre sécurité. IL FAUT
TOUJOURS CONNAÎTRE sa
position lors de l’utilisation
de l’instrument. Utilisez l’outil
correct pour votre application.
Ne dirigez pas le faisceau laser en direction de
personnes ou d’animaux, et ne regardez pas
directement le faisceau laser vous-même. Cet
instrument produit des rayonnements laser de
classe 2 et est conforme aux normes 21 CFR
1040.10 et 1040.11, à l’exception des déviations en vertu de
l’Avis relatif au laser N° 50 daté du 24 juin 2007.
Consignes de sécurité
Il ne sera possible de travailler
sans danger avec le télémètre
que si vous avez lu toutes
les informations relatives à
son utilisation et toutes les
consignes de sécurité, et si ces
instructions sont suivies à la
lettre.Ne rendez jamais illisibles
les étiquettes d’avertissement
figurant sur ce télémètre.
Ne dirigez jamais le faisceau
vers une pièce dont la surface
est réfléchissante. La tôle
d’acier brillante réflective ou les
surfaces réflectives similaires
ne sont pas recommandées
pour utilisation d’un laser. Les
surfaces réflectives risquent
de rediriger le faisceau vers
l’utilisateur.
!
AVERTISSEMENT

-19-
Procédures d’utilisation en toute sécurité
Familiarisez-vous avec le
degré de précision et la portée
maximum de cet appareil. Si cet
appareil est utilisé au-delà de sa
portée maximum, les mesures
risquent d’être erronées.
L’utilisation de commandes
ou la réalisation de réglages
ou de procédures autres que
celles spécifiées dans les
présentes pourrait résulter en
une exposition dangereuse aux
rayonnements.
L’utilisation d’instruments
optiques avec ce produit
augmentera les risques de
problèmes oculaires.
Ne faites réparer ce télémètre
que par des spécialistes
compétents utilisant seulement
des pièces de rechange du
fabricant de l’instrument.
Ceci assurera le maintien de la
sécurité du télémètre.
Ne laissez pas des enfants se
servir du télémètre à laser sans
supervision. Ils risqueraient
d’aveugler d’autres personnes
par accident.
Ne pointez pas le faisceau
laser sur des personnes ou des
animaux, et ne regardez pas
directement dans le faisceau
laser, m ê me à grande distance.
N’utilisez pas les lunettes de
visualisation pour laser en
guise de lunettes de protection.
Les lunettes de visualisation
pour laser servent à améliorer la
visualisation du faisceau laser,
mais ils ne protègent pas contre
les rayonnements laser.
N’utilisez pas les lunettes de
visualisation pour laser en
guise de lunettes de soleil
ou quand vous conduisez
un véhicule. Les lunettes
de visualisation pour laser
n’assurent pas une protection
complète contre les rayons UV,
et ils réduisent la perception des
couleurs.
Lisez toutes les instructions
contenues dans ce mode
d’emploi et assurez-vous
que vous les comprenez
avant de vous servir de ce
produit. Le non-respect de
quelconques instructions
risquerait de causer une
exposition dangereuse aux
rayonnements, un choc
électrique, un incendie et/ou
des blessures corporelles.
L’emploi de commandes ou
de réglages, ou l’exécution
de procédures autres que ce
qui est indiqué dans ce mode
d’emploi risquerait de causer
une exposition dangereuse
aux rayonnements.

-20-
L’emploi d’instruments
optiques avec ce produit
augmentera le danger pour
les yeux.
ASSUREZ-VOUS TOUJOURS
que toutes les personnes
pouvant être présentes
aux environs de l’endroit
où l’instrument est utilisé
sont au courant des
dangers pouvant résulter de
l’observation directe de la
source de la lumière laser.
NE RETIREZ PAS et ne rendez
pas illisibles de quelconques
étiquettes d’avertissement
ou de mise en garde. Le
retrait d’étiquettes augmente
le risque d’exposition aux
rayonnements laser.
NE FIXEZ PAS directement
du regard le faisceau laser et
ne le dirigez pas directement
dans les yeux de tiers. Ceci
risquerait de causer des
blessures graves.
NE PLACEZ PAS l’outil laser
dans une position telle que
cela risquerait d’inciter
quelqu’un à regarder
intentionnellement ou non le
faisceau laser. Cela risquerait
de causer de graves blessures
aux yeux.
N’UTILISEZ PAS
d’instruments optiques tels,
entre autres, des télescopes
ou des transits, pour regarder
le faisceau laser. Cela
risquerait de causer de graves
blessures aux yeux.
N’UTILISEZ PAS l’outil laser
à proximité d’enfants et ne
permettez pas à des enfants
de se servir de l’outil laser.
Cela risquerait de causer de
graves blessures aux yeux.
ÉTEIGNEZ TOUJOURS («
OFF ») l’outil laser lorsque
vous ne vous en servez pas.
Si vous laissiez l’outil laser
en marche (« ON ») alors,
ceci augmenterait le risque
que quelqu’un regarde par
inadvertance la source du
faisceau laser.
N’UTILISEZ PAS l’outil
laser dans des zones
combustibles, par exemple
en présence de liquides,
de gaz ou de poussières
inflammables.
POSITIONNEZ TOUJOURS
solidement l’outil laser. La
chute de l’outil laser risquerait
d’endommager l’outil laser et/
ou de causer une blessure
grave à l’utilisateur.
UTILISEZ TOUJOURS
exclusivement les
accessoires qui sont
recommandés par le
fabricant de votre outil
laser. L’emploi d’accessoires
qui ont été conçus pour une
utilisation avec d’autres outils
laser risquerait de causer des
blessures graves.
