Bosch GLM 30 User manual

Robert Bosch Power Tools GmbH
70538 Stuttgart
GERMANY
www.bosch-pt.com
1 609 92A 297 (2016.05) I / 114
GLM 30 Professional
en Original instructions
fr Notice originale
es Manual original
cn 正本使用说明书
tw 原始使用說明書
th หนังสือคู่มือการใช้งานฉบับต้นแบบ
id Petunjuk-Petunjuk untuk
Penggunaan Orisinal
vi Bản gốc hướng dẫn sửdụng
ar
fa
ςТЎϩХʉ ЌТϾϦφЍʉ ʌμВТЎϺυ
ΖЎϩʉ ˒μВЖЙʉʓ ИͳϞφЁʑ
OBJ_BUCH-2099-004.book Page 1 Monday, May 30, 2016 2:09 PM

1 609 92A 297 | (21.4.16) Bosch Power Tools
2|
English. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 6
Français . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 21
Español . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Página 31
中文 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .页42
中文 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .頁52
 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  61
Bahasa Indonesia . . . . . . . . . . . . . . . . . . . . . . . . . . . Halaman 72
Tiếng Việt . . . . . . . . . . . . . . . . . . . . . . . . . . .Trang 82
. . . . . . . . . . . . . . . . . . . . . . . . . . . 103
. . . . . . . . . . . . . . . . . . . . . . . . . . . 113
OBJ_BUCH-2099-004.book Page 2 Thursday, April 21, 2016 1:10 PM

1 609 92A 297 | (21.4.16) Bosch Power Tools
3|
2
6
5
4
3
1
87
GLM 30
c
b
a
d
e
f
gh
OBJ_BUCH-2099-004.book Page 3 Thursday, April 21, 2016 1:10 PM

1 609 92A 297 | (21.4.16) Bosch Power Tools
4|
1,95 m
0,5 m
1
1.
2.
B
A
OBJ_BUCH-2099-004.book Page 4 Thursday, April 21, 2016 1:10 PM

1 609 92A 297 | (21.4.16) Bosch Power Tools
5|
GLM250 VF
Professional
1 608 M00 05B
9
2 607 001 391
10
2 609 160 194
11
OBJ_BUCH-2099-004.book Page 5 Thursday, April 21, 2016 1:10 PM

6| English
1 609 92A 297 | (21.4.16) Bosch Power Tools
English
Safety Notes
All instructions must be read and observed in order to work safely
with the measuring tool. The integrated protections in the meas-
uring tool may be compromised if the measuring tool is not used
in accordance with the instructions provided. Never make warn-
ing signsonthe measuringtool unrecognisable. STORE THESEIN-
STRUCTIONS IN A SAFE PLACE AND INCLUDE THEM WITH THE MEASURING
TOOL WHEN GIVING IT TO A THIRD PARTY.
Caution – The use of other operating or adjusting equipment or the applica-
tion of other processing methods than those mentioned here can lead to dan-
gerous radiation exposure.
Themeasuring tool isprovided withawarning label(markedwithnumber 6 in
the representation of the measuring tool on the graphics page).
If the text of the warning label is not in your national language, stick the pro-
vided warning label in your national language over it before operating for the
first time.
Do not direct the laser beam at persons or animals and do not
stare into the direct or reflected laser beam yourself, not even
from a distance. You could blind somebody, cause accidents or
damage your eyes.
If laser radiation strikes your eye, you must deliberately close your eyes and
immediately turn your head away from the beam.
Do not use the laser viewing glasses as safety goggles. The laser viewing glass-
es are used for improved visualisation of the laser beam, but they do not protect
against laser radiation.
Do not use the laser viewing glasses as sun glasses or in traffic. The laser view-
ing glasses do not afford complete UV protection and reduce colour perception.
4
OBJ_BUCH-2099-004.book Page 6 Thursday, April 21, 2016 1:10 PM

English | 7
Bosch Power Tools 1 609 92A 297 | (21.4.16)
Have the measuring tool repaired only through qualified specialists using
original spare parts. This ensures that the safety of the measuring tool is main-
tained.
Do not allow children to use the laser measuring tool without supervision.
They could unintentionally blind other persons or themselves.
Do not operate the measuring tool in explosive environments, such as in the
presence of flammable liquids, gases or dusts. Sparks can be created in the
measuring tool which may ignite the dust or fumes.
Do not make any modifications to the laser equipment.
Product Description and Specifications
Please unfold the fold-out page with the representation of the measuring tool and
leave it unfolded while reading the operating instructions.
Intended Use
The measuring tool is intended for measuring distances, lengths, heights, and clear-
ances. The measuring tool is suitable for measuring indoors.
Technical Data
Digital Laser Measure GLM 30
Article number 3 601 K72 5.. 3 601 K72 57.
Measuring range (typical) 0.15–30 mA) 0.15–30 mA)
Measuring range (typical under un-
favourable conditions) 20 mB) 20 mB)
Measuring accuracy (typical) ±2.0mmA) ±2.0mmA)
Measuring accuracy (typical under
unfavourable conditions) ±3.0mmB) ±3.0mmB)
Lowest indication unit 1mm 1mm
Operating temperature –10 °C...+45°C –10 °C...+45°C
Storage temperature –20 °C...+70 °C –20 °C...+70 °C
Relative air humidity, max. 90 % 90 %
Laser class 22
Laser type 635 nm, <1 mW 635 nm, <1 mW
OBJ_BUCH-2099-004.book Page 7 Thursday, April 21, 2016 1:10 PM

8| English
1 609 92A 297 | (21.4.16) Bosch Power Tools
Product Features
The numbering of the product features shown refers to the illustration of the measur-
ing tool on the graphic page.
1Display
2Measuring button
3Battery lid
Laser beam diameter (at 25 °C)
approx.
–at10mdistance
–at30mdistance
9mm
C)
27 mmC)
9mm
C)
27 mmC)
Automatic switch-off after approx.
–Laser
– Measuring tool (without meas-
urement)
20 s
5min
20 s
5min
Weight according to EPTA-
Procedure 01:2014 0.09 kg 0.09 kg
Dimensions 105 x 41 x 24 mm 105 x 41 x 24 mm
Degree of protection IP 54 (dust and splash
proof) D)
IP 54 (dust and splash
proof) D)
Batteries
Rechargeable batteries
2x1.5VLR03(AAA)
2x1.2VHR03(AAA)
2x1.5VLR03(AAA)
2x1.2VHR03(AAA)
Individual measurement per bat-
tery set 5000 5000
Setting the unit of measure –
Setting the sound –
A) For measurements from the rear measuring tool edge, weak backlighting and 25 °C operating
temperature are applicable for high reflectivity of the target (e.g. a white-painted wall). In addition,
a deviation influence of ± 0.05 mm/m must be taken into account.
B) For measurements from the rear measuring tool edge, strong backlighting and – 10 °C to +45 °C
operating temperature are applicable for low reflectivity of the target (e.g. a black box). In addition,
a deviation influence of ±0.15 mm/m must be taken into account.
C) The width of the laser line depends on the surface characteristics and on the ambient conditions.
D) except battery compartment
The measuring tool can be clearly identified with the serial number 5on the type plate.
Digital Laser Measure GLM 30
OBJ_BUCH-2099-004.book Page 8 Thursday, April 21, 2016 1:10 PM

English | 9
Bosch Power Tools 1 609 92A 297 | (21.4.16)
4Latch of battery lid
5Serial number
6Laser warning label
7Reception lens
8Laser beam outlet
9Laser target plate*
10 Laser viewing glasses*
11 Protective pouch*
* The accessories illustrated or described are not included as standard delivery.
Display Elements
aAuto-sum
bPrevious measuring value
cCurrent measuring value
dLaser, switched on
eLength measurement
fBattery low indicator
gTemperature warning
hError message “Error”
Assembly
Inserting/Replacing the Batteries
Using alkali-manganese or rechargeable batteries is recommended for operation of
the measuring tool.
With 1.2-V-rechargeable batteries fewer measurements could be possible than with
1.5-V-batteries.
To open the battery lid 3, press the latch 4and remove the battery lid. Insert the bat-
teries/rechargeable batteries. When inserting, pay attention to the correct polarity
according to the representation on the inside of the battery compartment.
When the battery symbol appears for the first time on the display, at least 100 in-
dividual measurements are still possible.
When the battery symbol flashes, the batteries/rechargeable batteries must be re-
placed. Measurements are no longer possible.
Always replace all batteries/rechargeable batteries at the same time. Do not use dif-
ferent brands or types of batteries/rechargeable batteries together.
OBJ_BUCH-2099-004.book Page 9 Thursday, April 21, 2016 1:10 PM

10 | English
1 609 92A 297 | (21.4.16) Bosch Power Tools
Remove the batteries/rechargeable batteries from the measuring tool when
not using it for longer periods.When storing for longer periods, the batteries/re-
chargeable batteries can corrode and self-discharge.
Operation
Initial Operation
Do not leave the switched-on measuring tool unattended and switch the mea-
suring tool off after use. Other persons could be blinded by the laser beam.
Protect the measuring tool against moisture and direct sun light.
Do not subject the measuring tool to extreme temperatures or variations in
temperature. As an example, do not leave it in vehicles for a long time. In case of
large variations in temperature, allow the measuring tool to adjust to the ambient
temperature before putting it into operation. In case of extreme temperatures or
variations in temperature, the accuracy of the measuring tool can be impaired.
Avoid heavy impact to or falling down of the measuring tool. After severe exte-
rior effects to the measuring tool, it is recommended to carry out an accuracy
check (see “Accuracy Check of the Distance Measurement”, page 13) each time
before continuing to work.
Switching On and Off
To switchonthe measuring tool, briefly press the measuring button 2. Measuring tool
and laser are switched on.
Do not leave the switched-on measuring tool unattended and switch the mea-
suring tool off after use. Other persons could be blinded by the laser beam.
To switch off the measuring tool, press the measuring button 2and hold it down.
Measuring Procedure (see figure A)
Once switched on, the measuring tool is in the length measurement mode.
The rear edge of the measuring tool is always the reference level for the measure-
ment.
Place the measuring tool against the desired starting point of the measurement (e.g.
a wall).
Briefly press the measuring button 2to initiate the measurement. Then the laser
beam is switched off. To switch the laser beam on again, briefly press the measuring
button 2. To initiate a further measurement, briefly press the measuring button 2
again.
OBJ_BUCH-2099-004.book Page 10 Thursday, April 21, 2016 1:10 PM

English | 11
Bosch Power Tools 1 609 92A 297 | (21.4.16)
Do not point the laser beam at persons or animals and do not look into the la-
ser beam yourself, not even from a large distance.
Note: The measured value typically appears within 0.5 seconds and no later than
4 seconds. The duration of the measurement depends on the distance, the lighting
conditions and the reflective properties of the target surface. Upon completion of the
measurement the laser beam is automatically switched off.
Auto-Sum (see figure B)
The auto-sum automatically shows the sum of all individual measurements (e.g. use-
ful for the material calculation).
The auto-sum value is erased as soon as the device is switched off or if it automatically
switches off when no button is pressed after 5 minutes.
The auto-sum is not saved. A subsequent correction of the auto-sum is not possible.
Aim the laser beam at the target surface.
Briefly press the measuring button 2to initiate the measurement.
The current measured value cappears in the bottom line of the
display. The laser beam is switched off.
To switch on the laser beam, briefly press the measuring button 2.
To initiate another measurement, briefly press the measuring but-
ton 2again. The current measured value cis displayed in the bot-
tom line. The previous measured value bis displayed in the middle
line. In the top line, the auto-sum a(the sum of the current and
previous measured value) is displayed.
Switching the Sound On and Off (3 601 K72 5..)
Switch the measuring tool off.
Press and hold the measuring button 2. When the cur-
sor is on the desired setting, release the measuring
button 2. After releasing, the measuring tool switches
itself on with the selected setting.
Changing the Unit of Measure (3 601 K72 57.)
Switch the measuring tool off.
OBJ_BUCH-2099-004.book Page 11 Thursday, April 21, 2016 1:10 PM

12 | English
1 609 92A 297 | (21.4.16) Bosch Power Tools
Press and hold the measuring button 2. When the cur-
sor is on the desired setting, release the measuring
button 2. After releasing, the measuring tool switches
itself on with the selected setting.
Display Illumination
The display illumination is continuously switched on. When no button is pressed, the
display illumination is dimmed after approx. 10 seconds to preserve the batteries/re-
chargeable batteries. When no button is pressed for after approx. 30 seconds, the
display illumination goes out.
Working Advice
General Information
The reception lens 7and the laser beam outlet 8must not be covered when taking a
measurement.
The measuring tool must not be moved while taking a measurement. Therefore, place
the measuring tool, as far as this is possible, against or on a firm stop or supporting
surface.
Influence Effects on the Measuring Range
The measuring range depends on the lighting conditions and the reflective properties
of the target surface. For better visibility of the laser beam in extraneous light, use the
laser viewing glasses 10 (accessories) and the laser target plate 9(accessories) or
shade the target area.
Influence Effects on the Measuring Result
Due to physical effects, faulty measurements cannot be excluded when measuring on
different surfaces. Included here are:
– Transparent surfaces (e.g., glass, water),
– Reflecting surfaces (e.g., polished metal, glass),
– Porous surfaces (e.g. insulation materials),
– Structured surfaces (e.g., roughcast, natural stone).
If required, use the laser target plate 9(accessory) on these surfaces.
Furthermore, faulty measurements are also possible when sighting inclined target
surfaces.
Also, air layers with varying temperatures or indirectly received reflections can affect
the measured value.
OBJ_BUCH-2099-004.book Page 12 Thursday, April 21, 2016 1:10 PM

English | 13
Bosch Power Tools 1 609 92A 297 | (21.4.16)
Accuracy Check of the Distance Measurement
The accuracy of the measuring tool can be checked as follows:
– Select a permanently unchangeable measuring section with a length of approx. 3
to 10 metres; its length must be precisely known (e.g. the width of a room or a door
opening). The measurement should be carried out under favourable conditions,
meaning, the measuring distance must be indoors and the target surface for the
measurement must be smooth and reflect well.
–Measurethedistance10times in succession.
The deviation of the individual measurements from the average value must not exceed
±4 mm over the entire measuring section in favourable conditions. Record the meas-
urements in order to be able to compare the accuracy at a later date.
Troubleshooting – Causes and Corrective Measures
Cause Corrective Measure
Temperature warning indicator (g) flashing; measurement not possible
The measuring tool is outside the operat-
ing temperature range of –10 °C to
+45 °C.
Wait until the measuring tool has reached
the operating temperature
“Error” indication in the display
The target surface reflects too intensely
(e.g. a mirror) or insufficiently (e.g. black
fabric), or the ambient light is too bright.
Work with the laser target plate 9(acces-
sory)
The laser beam outlet 8or the reception
lens 7are misted up (e.g. due to a rapid
temperature change).
Wipe the laser beam outlet 8and/or the
reception lens 7dry using a soft cloth
The calculated auto-sum is greater than
99999 m.
Divide calculation into intermediate steps
Measuring result not plausible
The target surface does not reflect cor-
rectly (e.g. water, glass).
Cover off the target surface
The laser beam outlet 8or the reception
lens 7are covered.
Make sure that the laser beam outlet 8or
the reception lens 7are unobstructed
Obstruction in path of laser beam Laser point must be completely on target
surface.
OBJ_BUCH-2099-004.book Page 13 Thursday, April 21, 2016 1:10 PM

14 | English
1 609 92A 297 | (21.4.16) Bosch Power Tools
The measuring tool monitors the proper function for each measurement. When a de-
fect is detected, all indicators on the display flash. In this case, or when the corrective
measures listed above cannot correct the error, have your dealer forward the meas-
uring tool to an authorised Bosch after-sales service.
Maintenance and Service
Maintenance and Cleaning
Keep the measuring tool clean at all times.
Do not immerse the measuring tool in water or other fluids.
Wipe off debris using a moist and soft cloth. Do not use any cleaning agents or sol-
vents.
Maintain the reception lens 7in particular, with the same care as required for eye
glasses or the lens of a camera.
If the measuring tool should fail despite the care taken in manufacturing and testing
procedures, repair should be carried out by an authorised after-sales service centre
for Bosch power tools. Do not open the measuring tool yourself.
After-sales Service and Application Service
Our after-sales service responds to your questions concerning maintenance and re-
pair of your product as well as spare parts. Exploded views and information on spare
parts can also be found under:
www.bosch-pt.com
Bosch’s application service team will gladly answer questions concerning our prod-
ucts and their accessories.
In all correspondence and spare parts orders, please always include the 10-digit arti-
cle number given on the nameplate of the product.
The indication remains unchanged or the measuring tool reacts unexpectedly
after pressing a button
Software error Remove the batteries and start the meas-
uring tool again after reinserting them.
Cause Corrective Measure
OBJ_BUCH-2099-004.book Page 14 Thursday, April 21, 2016 1:10 PM

English | 15
Bosch Power Tools 1 609 92A 297 | (21.4.16)
People’s Republic of China
China Mainland
Bosch Power Tools (China) Co., Ltd.
567, Bin Kang Road
Bin Jiang District 310052
Hangzhou, P.R.China
Service Hotline: [phone]
Fax: [phone]
E-Mail: [email protected]
www.bosch-pt.com.cn
HK and Macau Special Administrative Regions
Robert Bosch Hong Kong Co. Ltd.
21st Floor, 625 King’s Road
North Point, Hong Kong
Customer Service Hotline: [phone]
Fax: [phone]
E-Mail: [email protected]
www.bosch-pt.com.hk
Indonesia
PT Robert Bosch
Palma Tower 10th Floor
Jl. RA Kartini II-S Kaveling 6 Sek II
Pondok Pinang, Kebayoran Lama
Jakarta Selatan 12310
Indonesia
Tel.: [phone]
Fax: [phone]
E-Mail: [email protected]osch.com
www.bosch-pt.co.id
OBJ_BUCH-2099-004.book Page 15 Thursday, April 21, 2016 1:10 PM

16 | English
1 609 92A 297 | (21.4.16) Bosch Power Tools
Philippines
Robert Bosch, Inc.
28th Floor Fort Legend Towers,
3rd Avenue corner 31st Street,
Fort Bonifacio Global City,
1634 Taguig City, Philippines
Tel.: [phone]
Fax: [phone]
[email protected]
www.bosch-pt.com.ph
Bosch Service Center:
9725-27 Kamagong Street
San Antonio Village
Makati City, Philippines
Tel.: [phone]
Fax: [phone]
E-Mail: rosalie[email protected]
Malaysia
Robert Bosch Sdn. Bhd.
No. 8A, Jalan 13/6
G.P.O. Box 10818
46200 Petaling Jaya
Selangor, Malaysia
Tel.: [phone]
Fax: [phone]
E-Mail: [email protected]
Toll-Free: 1800 880188
www.bosch-pt.com.my
OBJ_BUCH-2099-004.book Page 16 Thursday, April 21, 2016 1:10 PM

English | 17
Bosch Power Tools 1 609 92A 297 | (21.4.16)
Thailand
Robert Bosch Ltd.
Liberty Square Building
No. 287, 11 Floor
Silom Road, Bangrak
Bangkok 10500
Tel.: [phone]
Fax: [phone]
Robert Bosch Ltd., P. O. Box 2054
Bangkok 10501, Thailand
www.bosch.co.th
Bosch Service – Training Centre
La Salle Tower Ground Floor Unit No.2
10/11 La Salle Moo 16
Srinakharin Road
Bangkaew, Bang Plee
Samutprakarn 10540
Thailand
Tel.: [phone]
Fax: [phone]
Singapore
Powerwell Service Centre Ptd Ltd
65 Ubi Crescent, #06-03 Hola Centre
Singapore 408559
Tel.: [phone]
Fax: [phone]
E-Mail: [email protected]
Toll-Free: 1800 3338333
www.bosch-pt.com.sg
OBJ_BUCH-2099-004.book Page 17 Thursday, April 21, 2016 1:10 PM

18 | English
1 609 92A 297 | (21.4.16) Bosch Power Tools
Vietnam
Robert Bosch Vietnam Co. Ltd
13th Floor , 194 Golden Building
473 Dien Bien Phu Street
Ward 25, Binh Thanh District
84 Ho Chi Minh City
Vietnam
Tel.: [phone]
Fax: [phone]
Hotline: [phone]
E-Mail: [email protected]
www.bosch-pt.com.vn
www.baohanhbosch-pt.com.vn
Australia, New Zealand and Pacific Islands
Robert Bosch Australia Pty. Ltd.
Power Tools
Locked Bag 66
Clayton South VIC 3169
Customer Contact Center
Inside Australia:
Phone: [phone]
Fax: [phone]
Inside New Zealand:
Phone: [phone]
Fax: [phone]
Outside AU and NZ:
Phone: [phone]
www.bosch-pt.com.au
www.bosch-pt.co.nz
Egypt
Unimar
20 Markaz kadmat
El tagmoa EL Aoul – New Cairo
Tel: [phone] - 95 / + 2 02 224 78072 - 73
Fax:[phone]
E-Mail: [email protected]m
OBJ_BUCH-2099-004.book Page 18 Thursday, April 21, 2016 1:10 PM

English | 19
Bosch Power Tools 1 609 92A 297 | (21.4.16)
Ethiopia
Forever plc
Kebele 2,754, BP 4806,
Addis Ababa , Ethiopia
Tel: [phone]
E-Mail: [e-mail]
Nigeria
C. Woermann Ltd.
P.O. Box 318
6, Badejo Kalesanwo Street
Matori Industrial Estate
Lagos, Nigeria
Tel: [phone]
E-Mail: [e-mail]
Republic of South Africa
Customer service
Hotline: [phone]
Gauteng – BSC Service Centre
35 Roper Street, New Centre
Johannesburg
Tel.: [phone]
Fax: [phone]
E-Mail: [email protected]
KZN – BSC Service Centre
Unit E, Almar Centre
143 Crompton Street
Pinetown
Tel.: [phone]
Fax: [phone]
E-Mail: [email protected]
Western Cape – BSC Service Centre
Democracy Way, Prosperity Park
Milnerton
Tel.: [phone]
Fax: [phone]
E-Mail: [email protected]
OBJ_BUCH-2099-004.book Page 19 Thursday, April 21, 2016 1:10 PM

20 | English
1 609 92A 297 | (21.4.16) Bosch Power Tools
Bosch Headquarters
Midrand, Gauteng
Tel.: [phone]
Fax: [phone]
E-Mail: rbsa-hq.[email protected]
Disposal
Measuring tools, accessories and packaging should be sorted for environmental-
friendly recycling.
Do not dispose of measuring tools and batteries/rechargeable batteries into house-
hold waste!
Battery packs/batteries no longer suitable for use can be directly returned at:
Great Britain
Robert Bosch Ltd. (B.S.C.)
P.O. Box 98
Broadwater Park
North Orbital Road
Denham
Uxbridge
UB 9 5HJ
At www.bosch-pt.co.uk you can order spare parts or arrange the collection of a prod-
uct in need of servicing or repair.
Tel. Service: [phone]
E-Mail: [e-mail]
Subject to change without notice.
OBJ_BUCH-2099-004.book Page 20 Thursday, April 21, 2016 1:10 PM
