BOWMAN Signature BD111-0033 User manual

BOWMAN Dispensers
20325 71st Ave NE, Suite D, Arlington, WA 98223
800.962.4660 • www.BowmanDispensers.com
Product Videos:
BowmanDispensers.com/Product-Videos
BOWMAN Dispensers
20325 71
st
Ave NE, Suite D, Arlington, WA 98223
800.962.4660 • www.BowmanDispensers.com
^ĂŶŝƟnjĞƌĨĂĐĞ
ŵĂƐŬƐĂŶĚƟƐƐƵĞƐ
ŶŽƚŝŶĐůƵĚĞĚ
Product Description:
• Kit Includes:
-RS001-0233 Respiratory Hygiene Station
මHolds two boxes of face masks, one - two boxes of facial
tissues or one box of gloves, and one hand sanitizer
bottle or hand sanitizing wipe canister
මBOWMAN®Signature Series - Cherry Fauxwood ABS Plastic
-KS010-0420 Floor Stand
මBlack Powder-Coated Steel
-MP-070 Sign Holder - Vertical
මHolds 8.5" x 11" signage
මClear PETG Plastic
• Assembly hardware included
Primary Area for Product Usage:
• All ports of entry
• Anywhere respiratory hygiene products are needed
Dispenses:
• Left: Bottles no larger than 4.06"W x 4.06"D or 4.00" diameter
(10.5 cm x 10.5 cm)
• Middle: Box(es) no larger than 7.75"W x 9.00"H x 4.75"D
(19.7 cm x 22.9 cm x 12.1 cm)
• Right: Box(es) no larger than 5.50"W x 9.00"H x 4.75"D
(14.0 cm x 22.9 cm x 12.1 cm)
1SPEVDU4QFDJàDBUJPOT(overall assembled dimensions):
• 17.90"W x 58.36"H x 17.00"D (45.7 cm x 148.2 cm x 45.7 cm)
• 17.6 lbs (8.0 kg) - approximated
1BDLBHF4QFDJàDBUJPOT
• Package Quantity: 1 per case
• 36"L x 20"W x 6"H (91.4 cm x 50.8 cm x 15.2 cm)
• 24.0 lbs (10.9 kg) - approximated
BOWMAN®Signature Series
Cover Your Cough Compliance Kit
BD111-0033

%2:0$10DQXIDFWXULQJ&RPSDQ\,QF$OO5LJKWV5HVHUYHG3URGXFWVSHFLÀFDWLRQVVXEMHFWWRFKDQJHZLWKRXWQRWLÀFDWLRQ&RQVXPDEOHVQRWLQFOXGHG%D1110033TDSb
BD111-0033 - Installation
Information subject to change without notice. Dimensions are approximate. (Not to scale)
BOWMAN Dispensers
20325 71st Ave NE, Suite D, Arlington, WA 98223
800.962.4660 • www.BowmanDispensers.com
dŽƐĞĐƵƌĞďĂƐĞƚŽĐŽůƵŵŶƚƵƌŶĐŽůƵŵŶ
ƵƉƐŝĚĞĚŽǁŶ;ǁŝƚŚƚŽƉƉůĂƚĞĚŽǁŶͿ
ĂŶĚƉůĂĐĞďĂƐĞŝŶǀĞƌƚĞĚĂƐƐŚŽǁŶŽŶ
ĐŽůƵŵŶ
hƐĞWŚŝůůŝƉƐƐĐƌĞǁĚƌŝǀĞƌƚŽƐĞĐƵƌĞďĂƐĞ
ƚŽĐŽůƵŵŶǁŝƚŚ;ϰdžͿƐĐƌĞǁƐ;ϭϬͲϯϮdž
ϱϭϲ"Ϳ
dƵƌŶƐƚĂŶĚƌŝŐŚƚƐŝĚĞƵƉƐŽƚŚĞďĂƐĞŝƐ
ŽŶƚŚĞŇŽŽƌ
1 2 3
Assembly Instructions
BOWMAN®Signature Series - Cover Your Cough Compliance Kit
BD111-0033
ŽůƵŵŶƐƐĞŵďůLJ
ǁŝƚŚdŽƉWůĂƚĞ
ĂƐĞ
dŽƉŽĨ
ĐŽůƵŵŶ
ŽƩŽŵŽĨ
ĐŽůƵŵŶ
ĂƐĞ
6
ƩĂĐŚƚŚĞZ^ϬϬϭͲϬϮϯϯZĞƐƉŝƌĂƚŽƌLJ
,LJŐŝĞŶĞ^ƚĂƟŽŶƚŽƚŚĞĐŽůƵŵŶƵƐŝŶŐ;ϰdžͿ
ƐĐƌĞǁƐŝŶĐůƵĚĞĚǁŝƚŚƐƚĂŶĚdŝŐŚƚĞŶ
dŽŵŽƵŶƚƚŚĞDWͲϬϳϬ^ŝŐŶ,ŽůĚĞƌ
ĂůŝŐŶƚŚĞŚŽůĞƐŽĨƚŚĞŚŽůĚĞƌǁŝƚŚƚŚĞ
ŚŽůĞƐŽĨƚŚĞĚŝƐƉĞŶƐĞƌtŝƚŚĂŇĂƚŚĞĂĚ
ƐĐƌĞǁĚƌŝǀĞƌĂƩĂĐŚƵƐŝŶŐ;ϮdžͿďĂƌƌĞů
ƐĐƌĞǁƐŝŶĐůƵĚĞĚǁŝƚŚƐŝŐŶŚŽůĚĞƌ
dŚƵŵďĂĐĐĞƐƐƚŽƐŝŐŶĂŐĞŐŽĞƐƚŽǁĂƌĚ
ďĂĐŬŽĨĚŝƐƉĞŶƐĞƌ
45
dŽƉWůĂƚĞ
ŽĨĐŽůƵŵŶ
Parts included:
• Base
• Column
• Hygiene Station
• Sign Holder
• Hardware
ම(8x) 10-32 x 5/16" Phillips head screws
ම(2x) barrel screws
Tools Required:
• Phillips Screwdriver • Flathead Screwdriver
/ŶƐƚĂůůĂƟŽŶ
Always mount dispensers securely prior to loading with product.

Designed for Long-Term, Heavy-Duty
Applications
Designed for Long-Term Use Designed for Long-Term, Heavy-Duty
Applications
The combination of copolymers
(Acrylonitrile, Butadiene, and
Styrene) gives ABS an excellent
combination of strength, rigidity,
DQGWRXJKQHVV7KHIDX[ZRRGÀQLVK
is ARVINYL laminate created from a
VHPLULJLGÀOP
ABS is chemical and stress-crack
resistant. It is tough, dimensionally
stable, and will hold up to long-term
use. To ensure product longevity,
fauxwood products should not be
mounted in very hot or cold areas.
Our fauxwood material is
engineered to have a natural
grain appearance both in Cherry
DQG0DSOHÀQLVKHV7KHWZR
color choices provide a visually
appealing, upscale option to any
area.
Our steel dispensers and stands
are coated with polyester powders
which makes them highly resistant
to corrosion.
Powder-coated steel is ideal for
dispensers used in a healthcare or
an industrial setting because it is
impact resistant and is not effected
by extremes in temperature.
Dispensers and stands made
of powder-coated steel are both
attractive and functional, providing
years of service.
Copolyester resin is designed for
heavy-duty applications, and is
used by BOWMAN® Dispensers.
We never use acrylic in our
products.
Copolyester (PETG) is typically
15-20 times tougher than general
purpose acrylic. PETG is made to
withstand handling and reduce
losses due to breakage.
PETG resists a variety of chemicals
and commonly used cleaning
agents. It is tough and durable (not
brittle), providing years of trouble-
free functionality and long life.
Clear optical characteristics mean
the viewer can see the content,
read text, and see true colors
through the material. It complies
with FDA regulations for food
contact.
BOWMAN®Signature Series products
can be cleaned with standard
hospital cleaning products.
Petroleum-based oils, solvents, and
paints should not be used.
Standard hospital cleaning supplies
can be used.
For best results, clean by washing
the surface with a diluted solution
of a mild, non-abrasive detergent
in cold or warm water and a non-
abrasive cloth. Standard hospital
cleaning supplies can be used.
Dry with a soft cloth. Do not use
any solvent-based materials,
abrasives (e.g. Scotch-brite, steel
wool), or apply excessive force
during cleaning.
Most cleaning chemicals do not
weaken the surface or cause
damage to the material. Suggested
cleaning method is to use a soft
cloth, warm water, and mild soap.
Fauxwood ABS Plastic
RS001-0233
Powder-Coated Steel
KS010-0420
PETG Plastic
MP-070
Material Characteristics
Care and Cleaning
Characteristics & Care
BD111-0033
BOWMAN®Signature Series - Cover Your Cough Compliance Kit
BD111-0033 - Characteristics & Care
Information subject to change without notice. Dimensions are approximate. (Not to scale)
