Brähler Systems DIGIMIC DCen mini User manual

Operating Instructions
Rev 1.01
DIGIMIC®
DCen mini –Central Unit

DCen min DIGIMIC®
2Copyright by BRÄHLER ICS AG
DIGIMIC®is registered trademark of
Brähler ICS Konferenztechnik International Congress Service AG.
All other trademarks and trade names are the property of their respective owners.
Printed in Germany
Should you have any questions regarding this manual please contact:
Brähler ICS Konferenztechnik
International Congress Service AG
Auf der Alten Burg 6
53639 Königswinter, Germany
T [phone]
[email protected]
You will find further information about our products on the Internet:
www.braehler.com
© 2012
BRÄHLER ICS AG, Königswinter
All rights reserved, especially (also partly) the translation, reprint, reproduction through copying or other
similar methods.
BRÄHLER ICS reserves the right to make changes without notice.
Manual BGE-DCen-mini_(1.x).doc

DIGIMIC® DCen mini
Copyright by BRÄHLER ICS AG 3
Unsere Anlagen sind nach neuestem Stand der Technik konzipiert und getestet. Sie bedürfen im Normalfall
Our equipment and installations have been built and tested according to the latest state of the art.
Under normal conditions, they do not require any special maintenance.
However, please be aware of the following:
safe stand of the system
never operate equipment near heat sources such as heating radiators etc.
connecting cables - avoid trip-traps
liquids - avoid penetration of liquids into the housing
Warning: Never expose equipment to rain or humidity.
Please also be aware of the fact that rough handling of the equipment, such as strong bumps or
vibrations, may result in damages. Inappropriate handling and storage, i.e. handling and storage not
in conformity with the operating instructions, may as well lead to equipment damages.

DCen mini DIGIMIC®
4Copyright by BRÄHLER ICS AG

DIGIMIC® DCen mini
Copyright by BRÄHLER ICS AG 5
Inhalt
Disclaimer......................................................................................................................................6
About this manual.........................................................................................................................6
Important remarks.........................................................................................................................7
Introduction...................................................................................................................................8
Items delivered............................................................................................................................................8
System components....................................................................................................................................9
Accessories.................................................................................................................................................9
Connections (rear side) ..............................................................................................................10
1. 48VDC (Power Supply).........................................................................................................................10
2. LAN (RJ45)............................................................................................................................................10
3. CMic LINE (Displayport®).....................................................................................................................10
4. PA OUT (XLR).......................................................................................................................................10
5. Toggle switch ........................................................................................................................................10
6. LINE OUT (Cinch).................................................................................................................................10
7. LINE IN (Cinch).....................................................................................................................................10
Controls (front side)....................................................................................................................11
8. VOLUME...............................................................................................................................................11
9. BALANCE..............................................................................................................................................11
10. Operating modes VOX and FLOAT ....................................................................................................11
11. ON / OFF Switch.................................................................................................................................11
Setup............................................................................................................................................12
Switching on and setting............................................................................................................13
Operation.....................................................................................................................................14
Volume ......................................................................................................................................................14
Balance .....................................................................................................................................................14
Microphone Operation Mode.....................................................................................................................14
Switch for different sensitivities.................................................................................................................14
Shut off......................................................................................................................................................14
Factory setting...........................................................................................................................................14
Firmware Update.......................................................................................................................................15
Application examples..................................................................................................................17
Microphone units Classic: .........................................................................................................................17
Microphone units Classic CSV (voting).....................................................................................................17
Microphone units Pro Series.....................................................................................................................18
Appendix......................................................................................................................................19
Technical data...........................................................................................................................................19
Adapter cable............................................................................................................................................20
Trouble shooting........................................................................................................................................21
Warranty....................................................................................................................................................22
SERVICE FORM...........................................................................................................................23
Contact addresses......................................................................................................................25

DCen mini DIGIMIC®
6Copyright by BRÄHLER ICS AG
Disclaimer
All information, designs and specifications in this manual were correct at the time of publication. The product
will be continually improved and updated, so the product can differ in appearance and in functions.
Both the compliance of these instructions and the conditions and methods of installation, operation, use and
maintenance of the system cannot be monitored by the manufacturer. Improper installation can result in
property damage and endanger people.
Therefore, we assume no responsibility or liability for any loss, damage or expense resulting from improper
installation, improper operation, maintenance and use or associated with this. Also, we assume no
responsibility for patent infringements or violations of other rights of third parties arising from the use of this
system. The manufacturer reserves the right to make changes of the product, technical data or instructions
without a notice.
Warning: opening the device, manipulation and attempts to repair as well as improper
operation lead to lost of warranty.
About this manual
Symbols
The meanings of the symbols and fonts used in this manual are as follows:
Indicates an important note, if not minded, the functionality of the unit, the security of your data, or
your health are put at risk.
Supplementary information, remarks, and tips follow this symbol.
Text, which follows this symbol, describes activities that must be performed in the order shown.
Texts in bolded letters require your special attention.

DIGIMIC® DCen mini
Copyright by BRÄHLER ICS AG 7
Important remarks
Safety
Should any liquid or solid object fall into the housing, unplug the unit and have it checked by qualified
personnel before further operation.
Installation
Do not install the unit in a location near heat sources such as radiators or air ducts, or in a place exposed to
direct sunlight, excessive dust or humidity, mechanical vibration or shock.
To avoid moisture condensations do not install the unit where the temperature may rise rapidly.
Cleaning
To keep the housing in its original condition, periodically clean it with a soft cloth. Stubborn stains may be
removed with a cloth lightly dampened with a mild detergent solution. Never use organic solvents such as
thinners or abrasive cleaners since these will damage the housing.
Repacking
Save the original shipping carton and packing material; they will become handy if you ever have to ship the
unit.
For maximum protection, re-pack the unit as originally packed from the factory.
If not supplied with the equipment, a complete transportation and storage box system is available from
BRÄHLERICS. We recommend you to use this system for long-term protection and care.
General
Please keep this manual together with the equipment. If you pass on the unit to other parties, please include
this manual.
Please read the manual carefully, taking special care when you see this symbol as
indicates important information!
This product conforms to the rules of the following European regulations:
2004/108/EG
Council directive to the alignment of the rules, of rights of all member states about the electromagnetic
compatibility, adapted through RL 91/263/EWG, 92/31/EWG and 93/68/EWG of the council. Further
information is available on request.

DCen mini DIGIMIC®
8Copyright by BRÄHLER ICS AG
Introduction
Thank you for your confidence in the conference technology of Brähler!.
The Central Control Unit DCen mini controls all connected delegate units (CMic/CChair as well as
DMic/DChair) of the DIGIMIC discussion system, configures them automatically and routes the digital audio
signals. As a stand-alone unit the DCen mini includes 3 microphone modes:
AUT3 (push to talk up to 3 delegates)
VOX (VAL limited: voice activation up to 3 simultaneous activated microphone units)
FLOAT (AUTF3, the first of three speakers will be replaced by the last speaker.)
The DCen mini has one CMic outlet to connect up to 25 delegate units.
Once a unit is connected to the central control unit it is ready to use immediately without any further
adjustment. For additional functionalities the DCen mini is equipped with a network interface to ensure
remote control from various applications via PC, e.g. DMicControl software for microphone control on a
geographical virtual microphone mimic and name handling.
Voting functionality with up to 5 voting buttons can be achived with CMic CSV delegate units and DIGIVOTE
basic interactive PowerPoint voting software.
Please read this manual carefully, to get access to all features of the DCen mini central unit.

DIGIMIC® DCen mini
Copyright by BRÄHLER ICS AG 9
Items delivered
DCen mini (DIGIMIC® central unit)
PSU DCen power supply (input range 90 –250 V)
Mains cable 2.0 m
System components
CChair DIGIMIC® Classic Chairman Unit
CChair CSV DIGIMIC® Classic Chairman Unit with channel selector and voting
CMic DIGIMIC® Classic Delegate Unit
CMic CSV DIGIMIC® Classic Delegate Unit with channel selector and voting
DChair DIGIMIC® Chairman Unit pro (adapter cable 08.3502 necessary)
DMic DIGIMIC® Delegate Unit pro (adapter cable 08.3502 necessary)
DExt DIGIMIC® Extension power supply unit to expand the number of units in line
(adapter cable 08.3502 and/or 08.3500 necessary)
DMicControl PC Software for microphone management
DV basic interactive PC Software to conduct voting, opinion polls, and others
Accessories
TMD/01 Conference microphone, electret (01.0701)
TMD/01-S2 Conference microphone, electret, 2 goosenecks (01.0701.S2)
TM58/6 Conference microphone, electret, with luminant ring indicator, rigid tube with gooseneck (01.0560)
K45/16 Dynamic conference headphone, 1,5m cable (03.0290)
PMX60-2 Dynamic conference headphone, with neckband, 3.5 mm jack (03.5501)
CM9 Connection cable DIGIMIC „classic“, different length available
D9 Connection cable DIGIMIC „pro“, different length available
Adapter cable D9 DisplayPort CM9 “Classic”unit <--> S8G cable plug “Pro”Series (08.3500)
Adapter cable D9 DisplayPort plug “Classic”unit <--> S8G socket “Pro”Series (08.3502)

DCen mini DIGIMIC®
10 Copyright by BRÄHLER ICS AG
Connections (rear side)
The digital central unit DCen mini is designed for easy handling without complex settings.
The connections are shown below:
1. 48VDC (Power Supply)
Connection for the included AC adapter. Please use this certified power supply only.
2. LAN (RJ45)
LAN connection for integration into your network to operate by remote control via software (DHCP client)
3. CMic LINE (Displayport®)
Connection for up to 25 units of the type CMic, CChair, CMic CSV, CChair CSV or DMic, DChair via adapter
cable
4. PA OUT (XLR)
Controlled, balanced Output for an external PA system
5. Toggle switch
Switch for different level at PA OUT:
microphone level (-36 dBu)
line level (+4 dBu)
6. LINE OUT (Cinch)
Line Out asymmetric unregulated: Cinch connector for signal transfer to external devices such as mixers.
7. LINE IN (Cinch)
Line Input (-12 to +14 dBu): Cinch connector for input of signals from external devices
1. power
supply
2. network
3. delegate
units
4. PA Output
5. toggle switch,
Mic/Line level
6. Line Output
7. Line Input

DIGIMIC® DCen mini
Copyright by BRÄHLER ICS AG 11
Controls (front side)
The panel has seven backlit buttons, which are explained below.
8. VOLUME
With the buttons Volume –(down) und Volume + (up) the volume is adjusted or changed. This relates to the
LS of the units and the PA-OUT. To set the key equivalent to, if necessary pressed several times.
Button “-“decreases the volume level
Button “+” increases the volume level
While pressing the button the brightness changes corresponding to the selected volume.
9. BALANCE
With the two buttons LS and PA the ratio of the volume between the internal speakers of the units (LS) and
the externally supplied source (PA) is set.
The illumination of the buttons changes according to the duration of pressing.
10. Operating modes VOX and FLOAT
Select the conference mode with these two buttons. The corresponding button is lit for the selected mode.
If no button is pressed the automatic mode is set. Automatic mode is also set by pressing both buttons
simultaneously.
AUT3 push to talk up to 3 delegates. Further requests are rejected. Participants can switch off or on their
microphones at all times.
VOX limited: voice activation for up to 3 activated microphone units.
AUTFloat AUTF3, the first of three speakers will be replaced by the last speaker (FIFO = First In First Out).
Several participants can be active simultaneously up to a set limit. If another microphone is switched
on, the microphone was turned on first, is switched off.
11. ON / OFF Switch
Pressing this button about 3 sec the DCen mini is switched on and off. When switched on, the button is
illuminated.
8. VOLUME
9. Balance
LS / PA
10. Mode
VOX / FLOAT
11. ON/OFF
switch

DCen mini DIGIMIC®
12 Copyright by BRÄHLER ICS AG
Setup
The build-up is done according to the block diagrams in the next section.
Place the central unit to the designated location and distribute the microphone consoles in an appropriate
manner in the room. Observe the safety instructions.
First insert the small plug of the AC adapter into the socket marked with "48VDC ".
Connect the first microphone unit of the chain by plugging in the connector (DisplayPort ®) of the
unit into the socket marked with "CMic LINE" until it locks.
For use with units of the Pro Series
(DMic / DChair) the adapter cable is
inserted in the same way into the
socket marked with " CMic LINE”.

DIGIMIC® DCen mini
Copyright by BRÄHLER ICS AG 13
Connect the IEC power connector with the included AC power supply. The other end of the power
cable is plugged into the country-specified mains socket.
Switching on and setting
DCen mini is switched on by pressing the ON / OFF button for about 1 second.
During the boot sequence the ON / OFF button flashes in different levels of intensity:
In sequence the lights of the button VOLUME down (-), VOLUME up (+), BALANCE LS and BALANCE PA.
When the four left buttons are off (not illuminated), the startup is complete. The buttons are now set to
correct brightness on volume, balance and microphone mode. The ON / OFF button lights up permanently.
All connected microphone units are automatically identified.
You should now perform a test. Conveniently, this occurs in the operating mode AUT3, i.e. neither
button VOX nor button FLOAT light up. Otherwise you press the two buttons simultaneously to get
into this mode.
Press the microphone button on each unit to switch it on and press repeatedly to switch it off. When
switched on, the microphone button and microphone ring indicator must light up.
ON / OFF button

DCen mini DIGIMIC®
14 Copyright by BRÄHLER ICS AG
Operation
Volume
With the two buttons VOLUME (-) and VOLUME (+) the volume can be adjusted. The illumination of these
buttons depends on the set level.
dark: low or off
bright: loud
This setting affects the volume of the microphones loudspeakers as well as the level of the PA OUT
connector.
Balance
With the second pair of buttons, the balance between the microphone speakers and the output level at the
PA OUT connector is set.
If the balance is in the middle both buttons light up brightly and both outputs are at full capacity. Pressing the
button BALANCE LS the button BALANCE PA gets darker and the level at the output OUT PA gets lower.
Microphone Operation Mode
With the buttons VOX and FLOAT the microphone mode is selected. The default mode is the AUT3
Microphone (automatic).
Pressing the button VOX the mode voice activation limit is selected. Pressing the button FLOAT the
microphone mode AUTF (Automatic FLOAT) is selected. If an external control via network changes to the
mode MAN (manual), both buttons light up. If another mode is selected, the both buttons light up with half
brightness.
AUT3 push to talk up to 3 delegates. Further requests are rejected. Participants can switch off or on their
microphones at all times.
VOX limited: voice activation for up to 3 activated microphone units.
AUTFloat AUTF3, the first of three speakers will be replaced by the last speaker (FIFO = First In First Out).
Several participants can be active simultaneously up to a set limit. If another microphone is switched
on, the microphone was turned on first, is switched off.
Switch for different sensitivities
Often the microphone signal of the delegate units is send to an external amplifier or mixing console. For this
is the PA OUT connector. Usually this occurs setting the switch to +4 dBu (line level). For amplifier systems
(PA), which have only a microphone input, the switch position is -36 dBu. With this setting such a device is
feed in with a microphone instead of a line level.
Shut off
Pressing the ON / OFF button for two seconds will shut off the DCen mini.
Factory setting
In the initial phase, the current configuration of the system can be erased and reset to the factory settings.
This requires that the buttons FLOAT and VOX are pressed simultaneously and maintained while the system
is switched on with the ON / OFF button.
To confirm the procedure the four buttons located on the left are flashing cyclical (Volume -, Volume +, LS
balance, balance, PA).

DIGIMIC® DCen mini
Copyright by BRÄHLER ICS AG 15
Firmware Update
The central unit DCen mini can be updated via firmware update.
1. Requirement:
The central unit to be updated must be online in a network.
The update files you get are only valid for the central unit to be updated.
2. Unzip the files
The update files will be delivered as a zip archive. Unzip all files to your computer while keeping the
folder structure intact.
There are usually 4 files per DCen mini for the update and an executable file "DCenUpdate.exe". If more
than one central unit has to be updated, please unzip all the zip archives to the update directory.
3. Copying the data files to the DCen mini
Locate and start the file DCenUpdate.exe from within the unzipped directory tree. The software will start
with the following main window:
Select the SN (serial number) of the DCen mini
you intend to update. Remember that you will
see all DCen systems found on the network in
the list.
Click on the button “Refresh List” to refresh the
list of available DCen systems in your network.
You can leave the program without installing the
files by pressing the “Exit” button.
Click on button “Update” to start the file transfer for the update. The program will show a progress
indicator while copying the files necessary for the update to the DCen system.
In case of a network problem, the following requester will pop up:
Please check the network connections and
settings of your computer and the DCen mini to
be updated and click on “Retry”. Otherwise
contact your system administrator.
If the procedure was only partially successful
and cannot be continued at this time, it can be
restarted from the beginning without problems
later on. Incomplete or corrupted files will be
detected by the DCen mini and will not be
installed.
On successful completion, the following requester will pop up: „File transfer successful! “

DCen mini DIGIMIC®
16 Copyright by BRÄHLER ICS AG
4. Installation on the DCen mini
The final step of the updating process is done locally on the DCen mini.
Turn off the central unit. Wait at least 5 seconds before switching it on again. The DCen mini will verify
the integrity of the transferred files and will offer to upgrade the firmware from the old to the new release.
Should an update be offered, the two buttons BALANCE are flashes in the following way:
The button Balance LS flashes and indicates with increasing brightness “YES”.
Die button Balance PA flashes and indicates with decreasing brightness „NO”.
By pressing the corresponding button you can start or rejected the update process.
Note: Do not switch off the DCen mini during installation process!!
After the successful update the Central Unit DCen it will continue with the standard start-up procedure.

DIGIMIC® DCen mini
Copyright by BRÄHLER ICS AG 17
Application examples
The cabling is limited to connecting the external power supply, and the delegate units with each other. Here
are shown some of the many possibilities.
Microphone units Classic:
CChair
DCen mini
CMic CMic CMic CMic
100 –240 VAC
Power Supply
The chain consists of Chairpersons’ microphone CChair and delegate units CMic. The connections are done
via lockable DisplayPort® connectors. Appropriate extension cables are available in different lengths.
Microphone units Classic CSV (voting)
For operation in a LAN, you may use CMic CSV units for voting purpose. Using the PC software DIGIVOTE
basic interactive several opinion polls or voting are done.
CMic CSV
DCen mini
CMic CSV CMic CSV
CChair CSV
LAN
Switch /
Hub
PC Software
• DV basic interactive
• DMicControl 100 –240 VAC
Power Supply
With the PC software DMicControl the connected microphones can be controlled very easy. Using this
software more microphone modes such as MAN (manual control) are available.

DCen mini DIGIMIC®
18 Copyright by BRÄHLER ICS AG
Microphone units Pro Series
DCEN mini also works with the microphone units of the DIGIMIC Pro Series. With access to a LAN and the
PC software DMicControl, all connected microphones can be controlled. Using this software more
microphone modes such as MAN (manual control) are available.
DMicDMic
DChair
DCen mini
Switch /
Hub
PC Software
• DMicControl
DMic
100 –240 VAC
Power Supply
Adapter cable
08.3502 D9 cable
LAN cable
D9 cable
D9 cable
Expansion with additional power supply
With a DExt (additional power supply), a discussion system with classic units can be extended. To do so
adapter cables are required.
CMic CSV
DCen mini
CMic CSV CMic CSV
CChair CSV
CMic CSV CMic CSV CMic CSV
DExt
90 –240 VAC
50 –60 Hz
100 –240 VAC
Power Supply
Adapter cable
08.3500
Adapter cable
08.3502
In conjunction with microphone units of the Pro Series there is only the adapter cable for the direct
connection (08.3502) to DCEN mini necassary.
Up to 100 delegates units including 3
power supplies DExt are possible

DIGIMIC® DCen mini
Copyright by BRÄHLER ICS AG 19
Appendix
Technical data
This products complies with international standards IEC60914
Connectors
Socket for external power supply (48 VDC)
Socket for network connection LAN (10/100 Mbit / s)
Socket for delegate units (25 microphone units; DisplayPort®)
Connector for analog output, XLR, balanced (switchable mic / line level)
Connectors for Line Out / In (RCA jack)
Audio
Sampling rate 48 kHz
Frequency response 20 –20,000 Hz
Latency about 1ms
Low susceptibility to mobile phone interference, like Bluetooth, UMTS, WiFi and others
Features
Power switch with indicator light
Six illuminated keys for different operating modes
Protection against short circuit and overload at the output (CMic LINE)
Power supply
48VDC, external AC Power Supply
Housing
plastic, silver painted, top black
W x H x D: (200 x 65 x 200) mm
approx. (7.9 x 2.6 x 7.9) inch
Weight about 2 kg

DCen mini DIGIMIC®
20 Copyright by BRÄHLER ICS AG
Adapter cable
08.3500 DisplayPort®connector socket (Classic units) < -- > S8G plug (Pro Series DMic, DChair)
Application: DExt < -- > CMic/CChair
22.6380 22.3670.5
(KSS8G)
connector
08.3502 DisplayPort®plug (Classic units) < -- > S8G connector socket (Pro Series DMic, DChair)
Application: DCen mini < -- > DChair/DMic
Application: CMic/CChair < -- > DExt
22.3700.5
(KKS8G)
22.6370
(unlockable via
upper housing)
2,50 m
2,50 m
