Elvari™ Toilet Seat Cover
Dispenser, Surface‑Mounted
Model 5B1‑11
Table of Contents
Safety Information .............................................................2
Dimensions........................................................................2
Installing the Toilet Seat Cover Dispenser ........................3
Cleaning and Maintenance................................................3
Read the instructions in this manual before beginning installation.
Save these instructions and refer to them for operation and maintenance information.
For questions regarding the operation, installation, or maintenance of this product, visit bradleycorp.com or call 800.BRADLEY (800.272.3539).
Product warranties and parts information may also be found under “Resources” on our website at bradleycorp.com.
Scan or click code to view
Installation Guide (French)
Scan or click code to view
Installation Guide (English)
Scan or click code to view
Installation Guide (Spanish)

Elvari™ Toilet Seat Cover Dispenser, Surface‑Mounted – Model 5B1‑11 Installation
2 10/15/2023 Bradley • P20-257 Rev. A: ECO 22-15-012
Safety Information
WARNING
Toilet seat cover dispensers are no stronger than the anchors and walls to which they are attached, and therefore, must be
firmly secured in order to support the intended load requirements. To avoid potential injury, the building owner or maintenance
personnel should remove the dispenser from service if the mounting is not adequately secured to the wall or if there are any
observed product defects.
IMPORTANT
Read this entire installation manual to ensure proper installation. When installation is complete, file this manual with the owner or
maintenance department. Compliance and conformity to local codes and ordinances is the responsibility of the installer.
Separate parts from packaging and make sure all parts are accounted for before discarding any packaging material. If any parts
are missing, do not begin installation until you obtain the missing parts.
Dimensions
Medium Capacity
Large Capacity
(mm)
15-3/4" (400)
8-11/16" (221)3-9/16" (90)
2" (50)
11"
(279)
3-13/16"
(96)
Maximum ADA
Mounting Height
50-9/16" (1284)
Floor
15-3/4" (400) 11-5/8" (295)
2-7/16"
(62) 1-1/4"
(32)
2-1/16"
(52)
9-1/2"
(241)
Maximum ADA
Mounting Height
51-9/16" (1309)
Floor
ADA maximum dispense height is 48" (1219). See ADA mark for location.

Installation Elvari™ Toilet Seat Cover Dispenser, Surface‑Mounted – Model 5B1‑11
Bradley • P20-257 Rev. A: ECO 22-15-012 10/15/2023 3
Installing the Toilet Seat Cover Dispenser
Coordinate installation with architect and contractor to avoid protrusion from
opposite wall or pipes, vents, conduits, electrical wiring, etc., in wall.
Follow all applicable local building codes. If installing where unit projects above top
of wainscot, provide aluminum channel or other filler to prevent gap from finished
wall and flange of unit. For block walls, use metal expansion shields (not included).
Drill the mounting holes and set the anchors (not included)
per the mounting hole locations shown in the dimension
illustrations on the previous page.
A
Position the dispenser on the wall and use appropriate
fasteners (not included) to secure in place
(x2 for medium capacity, x4 for large capacity).
B
Cleaning and Maintenance
Scan or click the QR code below to view the Stainless Steel Washroom Accessories document.
Medium Capacity Dispenser Large Capacity Dispenser
