Bradley S19-220ABF User manual

P.O. Box 309, Menomonee Falls, WI USA 53052-0309
PHONE 1-800-BRADLEY FAX [phone]
http://www.bradleycorp.com
215-158ABF Rev. H; EN 06-532E
© 2007 Bradley Corporation
Page 1 of 6 6/19/07
S19-220ABF
Wall-Mounted Barrier Free
Eyewash with Plastic Bowl
S19-220BBF
Wall-Mounted Barrier Free
Eyewash with Stainless Steel
Bowl
Table of Contents
Pre-Installation Information . . . . . . . . . . . . . . 2
Installation Instructions . . . . . . . . . . . . . . . . . . 3
Dimensions and Rough-ins . . . . . . . . . . . . . . . 4
Plastic Bowl
Assembly of Components . . . . . . . . . . . . . . 5
Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Stainless Steel Bowl
Assembly of Components . . . . . . . . . . . . . . 6
Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Installation

2
S19-220ABF, S19-220BBF Installation
4/16/07 Bradley Corporation • 215-158ABF Rev. H; EN 06-532E
WARNING
Read this installation manual completely to ensure proper installation, then file it
with the owner or maintenance department. Compliance and conformity to drain
requirements and other local codes and ordinances is the responsibility of the
installer.
Separate parts from packaging and make sure all parts are accounted for before
discarding any packaging material. If any parts are missing, do not begin
installation until you obtain the missing parts.
Flush the water supply lines before beginning installation and after installation is
complete. Test the unit for leaks and adequate water flow. Main water supply to
the eyewash should be “ON” at all times. Provisions shall be made to prevent
unauthorized shutoff.
The ANSI Z358.1 standard requires an uninterruptible supply of flushing fluid at a
minimum 30 PSI (0.21 MPa) flowing pressure. Flushing fluid should be tepid per
ANSI Z358.1.
The inspection and testing results of this equipment should be recorded weekly
to verify proper operation. This equipment should be inspected annually to
ensure compliance with ANSI Z358.1.
Workers who may come in contact with potentially hazardous materials should be
trained regarding the placement and proper operation of emergency equipment
per ANSI Z358.1.
For questions regarding the operation or installation of this product, visit
www.bradleycorp.com or call 1-800-BRADLEY.
Product warranties may also be found under ”Product Information” on our web
site at www.bradleycorp.com.
Installation
THIS
SIDE
UP
Packing List
!
!
!
!
P.O.Box309, MenomoneeFalls, WI 53051
R
TESTTHISUNITEACHWEEK
Test-operatevalve(s) each week and sign below.
Reportany malfunctions immediately.
Ventil(e)wöchentlich im Testbetrieb prüfen, bestätigt
durchUnterschrift. Jegliche Störung sofort melden.
Date
Datum
Date
Signed
Unterschrift
Signe
Date
Date
Date Signed
Signed
Signed
DIESESGERÄT1STWÖCHENTLICHZUPRÜFEN.
ESSAIHEBDOMADAIRE
Testle fonctionnement des valves chaque semaine et
signeen bas. S'il y à quelque chose qui ne va pas fait
unrapport immédiatement.
P.O.BOX309, MENOMONEE FALLS,WI 53052-0309 USA
TEL:1-800-BRADLEY FAX:[phone])
http://www.bradleycorp.com
114-051

3
Installation S19-220ABF, S19-220BBF
Bradley Corporation • 215-158ABF Rev. H; EN 06-532E 4/16/07
Installation
NOTE: Refer to the dimensions and rough-ins shown on page 4.
Supplies Required:
• (4) 3/8" bolts and wall anchors for mounting wall bracket
• Pipe sealant
• Piping to 1/2" NPT water supply inlet on unit
• Piping to 1-1/4" NPT drain outlet for eyewash
• Sign-mounting hardware
Step 1: Install eyewash bracket
NOTE: The top of the eyewash heads should be 36" (914 mm) from the floor.
1. Position the inlet drain fitting over the 1-1/4" drain outlet pipe from wall. Using the eyewash
bracket as a template, mark the bolt hole locations on wall.
2. (optional) Install four suitable anchors (supplied by installer) for 3/8" bolts in the wall at the
marked hole locations.
3. Bolt the eyewash bracket to the wall or wall anchors using 3/8" bolts (supplied by installer).
Step 2: Assembly eyewash components
1. Assemble the remaining eyewash components as shown on page 5 (for eyewash with a plastic
bowl) or page 6 (for eyewash with a stainless steel bowl).
• Apply pipe sealant (supplied by installer) to all male-threaded pipe joints.
• Use a strap wrench around pipes when tightening to prevent pipe marring.
Step 3: Connect water supply
1. Connect the water supply piping (supplied by installer) to the 1/2" NPT inlet on the eyewash.
2. Connect the drain piping (supplied by installer) to the 1-1/4" NPT drain outlet on the eyewash.
3. Mount safety sign to wall using sign-mounting hardware (supplied by installer).
4. Open the water supply lines. Test for leaks and adequate water flow.

5-1/4"
(133mm)
19-1/4"
(489mm)
24-1/4"
(616mm)
Ø 10" (254mm)
15-1/2"
(394mm)
3-1/2" (89mm)
23-5/8"
(600mm)
To Floor
Ø P-Trap Outlet
15-1/2"
(394mm)
4-1/2"
(114mm)
36"
(914mm)
To Floor
30-3/4"
(781mm)
To Floor
3/8" (10mm)
S19-220ABF
4-1/2"
(114mm)
36"
(914mm)
To Floor
5-1/4"
(133mm)
19-1/4"
(489mm)
24-1/2"
(622mm)
Ø 10-3/4" (273mm)
15-7/8"
(403mm)
30-3/4"
(781mm)
To Floor
3-1/2" (89mm)
23-5/8"
(600mm)
To Floor
Ø P-Trap Outlet
15-1/2"
(394mm)
3/8" (10mm)
4
S19-220ABF, S19-220BBF Installation
4/16/07 Bradley Corporation • 215-158ABF Rev. H; EN 06-532E
S19-220BBF

5
Installation S19-220ABF, S19-220BBF
Bradley Corporation • 215-158ABF Rev. H; EN 06-532E 4/16/07
Assembly of Components - S19-220ABF (Plastic Bowl)
P.O. Box 309, Menomonee Falls, WI 53051
R
TEST THIS UNIT EACH WEEK
Test-operate valve(s) each week and sign below.
Report any malfunctions immediately.
Ventil(e) wöchentlich im Testbetrieb prüfen, bestätigt
durch Unterschrift. Jegliche Störung sofort melden.
Date
Datum
Date
Signed
Unterschrift
Signe
Date
Date
Date Signed
Signed
Signed
DIESES GERÄT 1ST WÖCHENTLICH ZU PRÜFEN.
ESSAI HEBDOMADAIRE
Test le fonctionnement des valves chaque semaine et
signe en bas. S'il y à quelque chose qui ne va pas fait
un rapport immédiatement.
P.O.BOX 309, MENOMONEE FALLS,WI 53052-0309 USA
TEL:1-800-BRADLEY FAX:[phone])
http://www.bradleycorp.com
114-051
1.5 Flow Control
This End
1.4
1.3
1.2
1.1
2
4
9
4.1
1/2" IPS
Supply Inlet
10
3
5
1-1/4" IPS
Drain Outlet
1.6
1.7
1.8
6
7
8
1
Figure 2a NOTE: Items 1.1-1.8 come preassembled as Item 1.
1 S90-353 1 Barrier Free Wall-Mt. Eyewash
1.1 S29-097 1 Eyewash Bracket
1.2 124-028 1 Gasket
1.3 154-058 1 Plastic Eyewash Bowl
1.4 173-025 1 Cup Strainer
1.5 S21-071 1 Supply Stem
1.6 113-1185 1 Spacer, Drain
1.7 S05-091 1 Eyewash Yoke Assembly
1.8 107-371 2 Dust Cover
2 113-965 1 Pipe, Stainless Steel 1/2" x 3-1/2"
3 269-241 1 Elbow
4 S27-282 1 1/2" Ball Valve with nut
4.1 110-215 1 Nut only
5 128-135 1 Handle Assembly
6 142-002DA 1 Lockwasher
7 269-1097 1 Tailpiece
8 269-1640 1 P-Trap
9 114-051 1 Safety Sign
10 204-421 1 Emergency Tag
Item Part No. Qty Description Item Part No. Qty Description
Prepack S45-1785 includes Items 1.2, 1.4, 1.5, 1.6
Prepack S45-123 includes Items 5, 6, 4.1
Prepack S45-122 includes Items 4, 5, 6, 4.1

6
S19-220ABF, S19-220BBF Installation
4/16/07 Bradley Corporation • 215-158ABF Rev. H; EN 06-632E
Assembly of Components - S19-220BBF (Stainless Steel Bowl)
P.O. Box 309, Menomonee Falls, WI 53051
R
TEST THIS UNIT EACH WEEK
Test-operate valve(s) each week and sign below.
Report any malfunctions immediately.
Ventil(e) wöchentlich im Testbetrieb prüfen, bestätigt
durch Unterschrift. Jegliche Störung sofort melden.
Date
Datum
Date
Signed
Unterschrift
Signe
Date
Date
Date Signed
Signed
Signed
DIESES GERÄT 1ST WÖCHENTLICH ZU PRÜFEN.
ESSAI HEBDOMADAIRE
Test le fonctionnement des valves chaque semaine et
signe en bas. S'il y à quelque chose qui ne va pas fait
un rapport immédiatement.
P.O.BOX 309, MENOMONEE FALLS,WI 53052-0309 USA
TEL:1-800-BRADLEY FAX:[phone])
http://www.bradleycorp.com
114-051
1.5 Flow Control
This End
1.4
1.3
1.2
1.1
2
4
9
1/2" IPS
Supply Inlet
10
3
5
1-1/4" IPS
Drain Outlet
1.6
1.7
1.8
6
7
8
1
4.1
Figure 2b NOTE: Items 1.1-1.8 come preassembled as Item 1.
1 S90-354 1 Barrier Free Wall-Mt. Eyewash
1.1 S29-097 1 Eyewash Bracket
1.2 124-028 1 Gasket
1.3 187-053 1 Stainless Steel Eyewash Bowl
1.4 173-009 1 Cup Strainer
1.5 S21-071 1 Supply Stem
1.6 113-1159 1 Spacer, Drain
1.7 S05-091 1 Eyewash Yoke Assembly
1.8 107-371 2 Dust Cover
2 113-965 1 Pipe, Stainless Steel 1/2" x 3-1/2"
3 269-241 1 Elbow
4 S27-282 1 1/2" Ball Valve with nut
4.1 110-215 1 Nut only
5 128-135 1 Handle Assembly
6 142-002DA 1 Lockwasher
7 269-1097 1 Tailpiece
8 269-1640 1 P-Trap
9 114-051 1 Safety Sign
10 204-421 1 Emergency Tag
Item Part No. Qty Description Item Part No. Qty Description
Prepack S45-123 includes Items 5, 6, 4.1
Prepack S45-122 includes Items 4, 4.1, 5, 6
Prepack S45-1782 includes Items 1.2, 1.4, 1.5, 1.6
