1 of 2 Bradley • 215-1369-19A Rev. G: ECN 17-03-015
Operation and Service Guide: Showers
P.O. Box 309 •Menomonee Falls, WI 53052-0309
1.800.BRADLEY •1.262.251.6000 •bradleycorp.com
154-139 Arm
269-1679WE15 Head
110-115 Nut
WS-1X Basic Showerhead S24-172WE15
Standard Institutional Showerhead S24-173 *
Standard Institutional Showerhead
with Lockable Ball Joint S24-174 *
S24-008 Head
153-117 Adaptor
153-117 Adaptor
S54-002 LBJ
S24-008 Head
110-115 Nut
110-115 Nut
154-139 Arm
154-139 Arm
WS-1X Showerheads
*Add suffix WE15 for 1.5 GPM Flow.
Add suffix WE20 for 2.0 GPM Flow
(Example: S24-173WE15 or S24-173WE20)

2 of 2 Bradley • 215-1369-19A Rev. G: ECN 17-03-015
Operation and Service Guide: Showers
P.O. Box 309 •Menomonee Falls, WI 53052-0309
1.800.BRADLEY •1.262.251.6000 •bradleycorp.com
Shower head Type Part No.
Max. Flow Rate @
80 ±2 psi
Min. Flow Rate @ 45 ±2 psi
Shower heads listed for use with automatic compensating
valves rated at (see values below) or less
Brass (BS) S24-172WE15 1.5 gpm (5.7 L/min) 1.4 gpm (5.3 L/min)
Standard Institutional (S)
S24-173* 2.5 gpm (9.5 L/min) 2 gpm (7.6 L/min)
S24-173WE15 1.5 gpm (5.7 L/min) 1.4 gpm (5.3 L/min)
S24-173WE20 2.0 gpm (7.6 L/min) 1.7 gpm (6.6 L/min)
Standard Institutional with
Lockable Ball Joint (S-LBJ)
S24-174* 2.5 gpm (9.5 L/min) 2.1 gpm (7.9 L/min)
S24-174WE15 1.5 gpm (5.7 L/min) 1.4 gpm (5.3 L/min)
S24-174WE20 2.0 gpm (7.6 L/min) 1.7 gpm (6.6 L/min)
* 2.5 GPM flow rate does not meet California Energy Commission 20 CCR T.20, Div. 2, 1601-1609.
