Bresser Meteo Temp HZ User manual

Weather Station · Wetterstation ·
Meteo Temp HZ
EN Instruction manual
DE Bedienungsanleitung

DE
Besuchen Sie unsere Website über den folgenden QR Code oder Weblink um weitere Informationen
zu diesem Produkt oder die verfügbaren Übersetzungen dieser Anleitung zu finden.
EN
Visit our website via the following QR Code or web link to find further information on this product or
the available translations of these instructions.
FR
Si vous souhaitez obtenir plus d’informations concernant ce produit ou rechercher ce mode d’emploi en
d’autres langues, rendez-vous sur notre site Internet en utilisant le code QR ou le lien correspondant.
NL
Bezoek onze internetpagina via de volgende QR-code of weblink, voor meer informatie over dit
product of de beschikbare vertalingen van deze gebruiksaanwijzing.
ES
¿Desearía recibir unas instrucciones de uso completas sobre este producto en un idioma determinado?
Entonces visite nuestra página web utilizando el siguiente enlace (código QR) para ver las versiones
disponibles.
IT
Desidera ricevere informazioni esaustive su questo prodotto in una lingua specifica? Venga a visitare
il nostro sito Web al seguente link (codice QR Code) per conoscere le versioni disponibili.
www.bresser.de/P7004220
www.bresser.de/warranty_terms
GARANTIE · WARRANTY · GARANTÍA · GARANZIA
RECYCLAGE (TRIMAN/FRANCE)
DE
Besuchen Sie unsere Website über den folgenden QR Code oder Weblink um weitere Informationen
zu diesem Produkt oder die verfügbaren Übersetzungen dieser Anleitung zu finden.
EN
Visit our website via the following QR Code or web link to find further information on this product or
the available translations of these instructions.
FR
Si vous souhaitez obtenir plus d’informations concernant ce produit ou rechercher ce mode d’emploi en
d’autres langues, rendez-vous sur notre site Internet en utilisant le code QR ou le lien correspondant.
NL
Bezoek onze internetpagina via de volgende QR-code of weblink, voor meer informatie over dit
product of de beschikbare vertalingen van deze gebruiksaanwijzing.
ES
¿Desearía recibir unas instrucciones de uso completas sobre este producto en un idioma determinado?
Entonces visite nuestra página web utilizando el siguiente enlace (código QR) para ver las versiones
disponibles.
IT
Desidera ricevere informazioni esaustive su questo prodotto in una lingua specifica? Venga a visitare
il nostro sito Web al seguente link (codice QR Code) per conoscere le versioni disponibili.
www.bresser.de/P7004220
www.bresser.de/warranty_terms
GARANTIE · WARRANTY · GARANTÍA · GARANZIA
RECYCLAGE (TRIMAN/FRANCE)

English ............................. 4
Deutsch ........................... 17

4
Table of contents
1 Imprint.......................................................................................................5
2 Validity note ..............................................................................................5
3 About this Instruction Manual ...............................................................6
4 General safety instructions.....................................................................6
5 Parts overview and scope of delivery ....................................................9
6 Screen display .........................................................................................10
7 Before commissioning ...........................................................................11
8 Setting up power supply........................................................................12
9 Automatic time setting..........................................................................12
10 Manual time setting...............................................................................13
11 Receiving measurements automatically.............................................13
12 Weather trend.........................................................................................13
13 Trend arrow indicators ..........................................................................14
14 Ice pre-alert.............................................................................................14
15 Disposal....................................................................................................14
16 Technical data.........................................................................................15
17 Warranty..................................................................................................16
18 EC declaration of conformity ................................................................16
19 UKCA declaration of conformity ...........................................................16

5 / 32
1 Imprint
Bresser GmbH
Gutenbergstr. 2
46414 Rhede
Germany
www.bresser.de
For any warranty claims or service inquiries, please refer to
the information on "Warranty" and "Service" in this docu-
mentation. We ask for your understanding that unsolicited
returns cannot be processed.
Errors and technical changes excepted.
© 2023 Bresser GmbH
All rights reserved.
The reproduction of this documentation - even in extracts -
in any form (e.g. photocopy, print, etc.) as well as the use
and distribution by means of electronic systems (e.g. image
file, website, etc.) without the prior written permission of
the manufacturer is prohibited.
The designations and brand names of the respective com-
panies used in this documentation are generally protected
by trade, trademark and/or patent law in Germany, the
European Union and/or other countries.
2 Validity note
This documentation is valid for the products with the follow-
ing article numbers:
7004220
Manual version: 0623
Manual designation:
Manual_7004220_Meteo-Temp-HZ_en-
de_BRESSER_v062023a
Always provide information when requesting service.

6 / 32
3 About this Instruction Manual
NOTICE
These operating instructions are to be considered a
component of the device.
Read the safety instructions and the instruction manual
carefully before using this device.
Keep these instruction manual in a safe place for future ref-
erence. If the device is sold or passed on, the instruction
manual must be passed on to any subsequent owner/user
of the product.
4 General safety instructions
DANGER
Danger of suffocation!
Improper use of this product may result in suffocation, es-
pecially for children. It is therefore imperative that you ob-
serve the following safety information.
• Keep packaging materials (plastic bags, rubber bands,
etc.) away from children! There is a danger of choking!
• This product contains small parts that can be swal-
lowed by children! Choking hazard!
DANGER
Risk of an electric shock!
This device contains electronic parts that are powered by a
power source (AC adapter and/or batteries). Improper use
of this product may result in electric shock. Electric shock
can cause serious or fatal injuries. It is therefore imperative
that you observe the following safety information.

7 / 32
• Never leave children unattended when handling the
device! Follow the instructions carefully and do not at-
tempt to power this device with anything other than
power sources recommended in this instruction
manual, otherwise there is a danger of an electric
shock!
DANGER
Explosion hazard!
Improper use of this product may result in fire. It is essen-
tial that you observe the following safety information in or-
der to avoid fires.
• Do not expose the device to high temperatures. Use
only the recommended batteries. Do not short-circuit
the device or batteries, or throw them into a fire! Ex-
cessive heat or improper handling could trigger a
short-circuit, a fire or an explosion!
NOTICE
Danger of material damage!
Improper handling may result in damage to the unit and/or
accessories. Therefore, use the device only in accordance
with the following safety information.
• Do not disassemble the device! In the event of a defect,
please contact your dealer. They will contact the Service
Center and can arrange the return of this device for re-
pair if necessary.
• Do not immerse the unit in water!
• Do not expose the device to impacts, vibrations, dust,
constant high temperatures or excessive humidity. This
can result in malfunctions, short-circuits or damage to
the batteries and components.

8 / 32
• Use only the recommended batteries. Always replace
weak or empty batteries with a new, complete set of
batteries at full capacity. Do not use batteries from dif-
ferent brands or types or with different capacities. Re-
move batteries from the device if it is not to be used for
a longer period of time!
NOTICE
Risk of voltage damage!
The manufacturer is not liable for damage related to im-
properly installed batteries!

9 / 32
5 Parts overview and scope of delivery
1
2345
6
7
8
A
B
10
12
9
11
Illustration1: Parts overview for base station and wireless sensor
1 Display (Base station) 2 UP button (Value setting up)
3 DOWN button (Value setting
down)
4 SYNC button
5 SET button (Settings and display
change between °C or °F)
6 Wall mount
7 Battery compartment cover 8 Stand, fold-out
9 Display (Sensor) 10 Function indicator light
11 Battery compartment 12 Wall mount

10 / 32
Scope of delivery
Base station (A), remote sensor (B)
Also required (not included):
4x AAA/LR03 batteries (2 each for station and sensor)
6 Screen display
1
3
4
27
8
9
10
11
5
12
13
6
Illustration2: Screen display of the base station
1 Temperature range symbol (base
station)
2 Indoor temperature value (base
station)
3 Battery level indicator (base sta-
tion)
4 Temperature range symbol (re-
mote sensor)
5 Outdoor temperature value (re-
mote sensor)
6 Battery level indicator (remote
sensor)
7 Weather trend arrow 8 Ice pre-alert
9 Graphical 12-24 hours weather
trend display
10 Time
11 Day and month 12 Time signal transmission symbol

11 / 32
13 Symbol for active daylight saving
time (DST)
7 Before commissioning
NOTICE
Avoid connection faults!
In order to avoid connection problems between the devices,
the following points must be observed during commission-
ing.
1. Place the base unit (receiver) and sensor (transmitter)
as close together as possible.
2. Connect the power supply to the base unit and wait un-
til the indoor temperature is displayed.
3. Establish power supply for the sensor.
4. Set up/operate the base unit and sensor within the ef-
fective transmission range.
5. Make sure that the base unit and the radio sensor are
set to the same channel.
When changing the batteries, always remove the batteries
from both the base unit and the sensor and reinsert them in
the correct order so that the radio link can be re-estab-
lished. If one of the two devices is operated via a mains
power connection, the power connection must also be
briefly disconnected for this device when the batteries are
changed. If, for example, only the batteries in the sensor
are replaced, the signal may subsequently not be received
at all or not be received correctly.
Note that the actual range depends on the respective con-
struction materials used for the buildings as well as the re-
spective position of the base unit and the outdoor sensor.
External influences (various radio transmitters and other
sources of interference) can greatly reduce the possible

12 / 32
range. In such cases, we recommend finding other locations
for both the base unit and the outdoor sensor. Sometimes
moving the sensor by just a few centimeters is enough!
8 Setting up power supply
Base station
1. Remove the battery compartment cover.
2. Insert the batteries into the battery compartment. En-
sure that the battery polarity (+/-) is correct.
3. Replace the battery compartment cover.
Remote sensor
4. Remove the battery compartment cover.
5. Insert the batteries into the battery compartment. En-
sure that the battery polarity (+/-) is correct.
6. Replace the battery compartment cover.
9 Automatic time setting
After the power supply was established, the clock will auto-
matically search for the radio signal. This will take approx-
imately 3 to 8 minutes to finish this process.
If the radio signal is received correctly, the date and time
will be set automatically and the radio control signal icon
turns on.
If the clock fails to receive the time signal, go ahead with the
following steps:
1. Press and hold the UP button for 2 seconds to re-initial-
ize RC signal receiving.
2. Is the device still not receiving the signal, the time must
be set manually.

13 / 32
10 Manual time setting
1. Press and hold SET button for approx. 4 seconds to
change to time setting mode.
2. Digits to be set are flashing.
3. Press UP or DOWN button to change the value.
4. Press SET button to confirm and continue to the next
setting.
5. Settings order: Year > Month > Day > Month (M) and
Day (D) / Day (D) and Month) > Time offset (-12 to 12
hours) > 12/24-hour mode > Hours > Minutes
6. Finally press the SET button to save the settings and
exit the setting mode.
11 Receiving measurements automatically
Once batteries are installed, the base station will display the
measurement readings. Readings from the remote sensor
will be displayed within 3 minutes after powering it on.
If no signal will be received, then go ahead with the follow-
ing steps:
1. Press SYNC button for approx. 2 seconds to re-initiate
reception of measurements again.
2. If the device is still not receiving the signal: Press and
hold the DOWN button for approx. 2 seconds to initiate
reception of measurements again.
12 Weather trend
The weather station will calculate a weather trend for the
next 12-24 hours on basis of the measured values.

14 / 32
12345
1 Sunny 2 Partly cloudy
3 Cloudy 4 Rain
5 Snow
13 Trend arrow indicators
123
1 Rising 2 Steady
3 Falling
The temperature trend indicator shows the trends of
changes in the forthcoming few minutes. Arrows indicate a
rising, steady or falling trend.
14 Ice pre-alert
1. When the outdoor temperature hits 3° C (37 ° F), the ice
pre-alert symbol will appear on the display, flashing
continuously.
2. The ice pre-alert symbol will disappear as soon as
the temperature rises above 6° C.
15 Disposal
Dispose of the packaging materials according to its type. In-
formation on proper disposal can be obtained from the muni-
cipal waste disposal service provider or environmental agency.

15 / 32
Do not dispose of electronic devices in the household
garbage!
According to the European Directive 2012/19/EU on Waste
Electrical and Electronic Equipment and its transposition into
national law, used electrical equipment must be collected sep-
arately and recycled in an environmentally sound manner.
Batteries and rechargeable batteries must not be disposed of
with household waste. You are legally obliged to return used
batteries and accumulators and can return them after use
either at our sales outlet or in the immediate vicinity (e.g. in the
trade or in municipal collection points) free of charge.
Batteries and accumulators are marked with a crossed-out
dustbin and the chemical symbol of the pollutant, "Cd" stands
for cadmium, "Hg" stands for mercury and "Pb" stands for lead.
16 Technical data
Base station
Batteries 2x AAA, 1.5 V
Radio controlled signal DCF
Maximum number of sensors 1
Temperature unit °C/°F
Temperature measuring range
(indoor)
-10°C to 50°C (-14°F to 122°F)
Time display HH:MM
Time format 12 or 24 hours
Calendar display DD / MM or MM / DD
Dimensions 127x81x20 mm (W x H x D)
Weight 124 g (without batteries)
Wireless sensor
Batteries 2x AAA, 1.5 V

16 / 32
Transmission frequency 433 MHz
Transmission range 100 m
Maximum RF power below 10mW
Temperature unit °C/°F
Temperature measuring range
(outdoor)
-40°C to 60°C (-40°F to 140°F)
Humidity measuring range 20%-95% HR
Humidity resolution 1% HR
Dimensions 45x101x20 mm (W x H x D)
Weight 42 g (without batteries)
17 Warranty
The regular warranty period is 2 years and starts on the day
of purchase. To benefit from an extended voluntary war-
ranty period as indicated on the gift box, registration on our
website is required.
You can consult the full guarantee terms as well as informa-
tion on extending the guarantee period and details of our
services at www.bresser.de/warranty_terms.
18 EC declaration of conformity
Bresser GmbH hereby declares that the radio equipment
type with item number 7004220 is in compliance with Direct-
ive 2014/53/EU. The full text of the EC Declaration of Con-
formity is available at the following web address:
www.bresser.de/download/7004220/CE/7004220_CE.pdf
19 UKCA declaration of conformity
A "Declaration of Conformity" in accordance with the applic-
able directives and relevant standards has been issued by
Bresser GmbH The full text of the UKCA Declaration of Con-
formity is available at the following web address:
www.bresser.de/download/7004220/
UKCA/7004220_UKCA.pdf
Bresser UK Ltd. • Suite 3G, Eden House, Enterprise Way,
Edenbridge, Kent TN8 6HF, Great Britain

17
Inhaltsverzeichnis
1 Impressum ............................................................................................ 18
2 Gültigkeitshinweis................................................................................ 18
3 Zu dieser Anleitung ..............................................................................19
4 Allgemeine Sicherheitshinweise......................................................... 19
5 Teileübersicht und Lieferumfang....................................................... 22
6 Displayanzeigen.................................................................................... 23
7 Vor der Inbetriebnahme ...................................................................... 24
8 Stromversorgung herstellen............................................................... 25
9 Automatische Zeiteinstellung............................................................. 25
10 Manuelle Zeiteinstellung..................................................................... 26
11 Automatische Messwerteübertragung .............................................26
12 Wettertrend........................................................................................... 26
13 Trendpfeile ............................................................................................ 27
14 Frostwarnung........................................................................................ 27
15 Entsorgung ............................................................................................ 28
16 Technische Daten .................................................................................28
17 Garantie ................................................................................................. 29
18 EG-Konformitätserklärung .................................................................. 29

18 / 32
1 Impressum
Bresser GmbH
Gutenbergstr. 2
46414 Rhede
Germany
www.bresser.de
Für etwaige Gewährleistungsansprüche oder Serviceanfra-
gen verweisen wir auf die Informationen zu „Garantie“ und
„Service“ in dieser Dokumentation. Wir bitten um Verständ-
nis, dass unaufgeforderte Rücksendungen nicht bearbeitet
werden können.
Irrtümer und technische Änderungen vorbehalten.
© 2023 Bresser GmbH
Alle Rechte vorbehalten.
Die Reproduktion dieser Dokumentation – auch auszugs-
weise – in irgendeiner Form (z.B. Fotokopie, Druck, etc.) so-
wie die Verwendung und Verbreitung mittels elektronischer
Systeme (z.B. Bilddatei, Website, etc.) ohne eine vorherige
schriftliche Genehmigung des Herstellers ist nicht gestattet.
Die in dieser Dokumentation verwendeten Bezeichnungen
und Markennamen der jeweiligen Firmen sind im Allgemei-
nen in Deutschland, der Europäischen Union und/oder wei-
teren Ländern waren-, marken- und/oder patentrechtlich
geschützt.
2 Gültigkeitshinweis
Diese Dokumentation ist gültig für die Produkte mit den
nachfolgend aufgeführten Artikelnummern:
7004220
Anleitungsversion: 0623
Bezeichnung dieser Anleitung:
Manual_7004220_Meteo-Temp-HZ_en-de_BRES-
SER_v062023a

19 / 32
Informationen bei Serviceanfragen stets angeben.
3 Zu dieser Anleitung
HINWEIS
Diese Bedienungsanleitung ist als Teil des Gerätes zu
betrachten!
Lesen Sie vor der Benutzung des Geräts aufmerksam die Si-
cherheitshinweise und die Bedienungsanleitung.
Bewahren Sie diese Bedienungsanleitung für die erneute
Verwendung zu einem späteren Zeitpunkt auf. Bei Verkauf
oder Weitergabe des Gerätes ist die Bedienungsanleitung
an jeden nachfolgenden Besitzer/Benutzer des Produkts
weiterzugeben.
4 Allgemeine Sicherheitshinweise
GEFAHR
Erstickungsgefahr!
Bei unsachgemäßer Verwendung dieses Produkts besteht
Erstickungsgefahr, insbesondere für Kinder. Beachten Sie
deshalb unbedingt die nachfolgenden Sicherheitsinforma-
tionen.
• Verpackungsmaterialien (Plastiktüten, Gummibänder,
etc.) von Kindern fernhalten! Es besteht Erstickungsge-
fahr!
• Dieses Produkt beinhaltet Kleinteile, die von Kindern
verschluckt werden können! Es besteht Erstickungsge-
fahr!

20 / 32
GEFAHR
Gefahr eines Stromschlags!
Dieses Gerät beinhaltet Elektronikteile, die über eine Strom-
quelle (Netzteil und/oder Batterien) betrieben werden. Bei
unsachgemäßer Verwendung dieses Produkts besteht die
Gefahr eines Stromschlags. Ein Stromschlag kann zu schwe-
ren bis tödlichen Verletzungen führen. Beachten Sie daher
unbedingt die nachfolgenden Sicherheitsinformationen.
• Lassen Sie Kinder beim Umgang mit dem Gerät nie un-
beaufsichtigt! Die Nutzung darf nur, wie in der Anlei-
tung beschrieben, erfolgen, andernfalls besteht die Ge-
fahr eines Stromschlags!
GEFAHR
Explosionsgefahr!
Bei unsachgemäßer Verwendung dieses Produkts besteht
Explosionsgefahr. Beachten Sie unbedingt die nachfolgen-
den Sicherheitsinformationen, um eine Explosion zu vermei-
den.
• Setzen Sie das Gerät keinen hohen Temperaturen aus.
Benutzen Sie nur die empfohlenen Batterien. Gerät und
Batterien nicht kurzschließen oder ins Feuer werfen!
Durch übermäßige Hitze und unsachgemäße Handha-
bung können Kurzschlüsse, Brände und sogar Explosio-
nen ausgelöst werden!
HINWEIS
Gefahr von Sachschäden!
Bei unsachgemäßer Handhabung können das Gerät und/
oder die Zubehörteile beschädigt werden. Verwenden Sie
das Gerät deshalb nur entsprechend den nachfolgenden Si-
cherheitsinformationen.
