BRK electronic SA340B User manual

SMOKE
ALARM
CAT. SA340B
10-YEAR
LITHIUM POWER
10 years of continuous protection.
No battery change required. Provides
audible notice when alarm has
reached its end of life.
TAMPERPROOF
SEALED ALARM
Powercell cannot be removed after
installation.
DUAL IONIZATION
Dual Ionization sensing chamber.
Generally more effective at detecting
small particles produced by flaming
fires.
SILENCE FEATURE
Silences nuisance alarms.
TAMPER RESISTANT
Locks alarm to mounting bracket.
Perfect for apartment, dormitory or
hotel applications.
Description:
The First Alert Cat. No. SA340B is a battery operated, 9V (three 3V lithium power
cells) single station smoke alarm specifically designed for residential and institu-
tional applications including sleeping rooms of hospitals, hotels, motels, dormi-
tories and other multi-family dwellings as defined in standard NFPA 101. Model
SA340B complies with UL217, CSFM, NFPA 72, HUD, FHA and other agencies that
model their codes after the above agencies. It meets building codes where tam-
perproof 10-year sealed lithium battery operated smoke alarms are required.
First Alert SA340B features a dual ionization smoke sensing chamber, an 85 dB
horn, a sealed 10-year lithium power cell power supply that is permanently in-
stalled upon activation of unit, a single button for test/silence and a red LED that
blinks to indicate unit is receiving power. The tamperproof design will not allow the
powercells to be removed after installation. The low power warning indicator will
cause the alarm to “chirp” when it reaches the end of its service life and needs
to be replaced. Upon end of life, the unit meets UL requirements for disabling the
alarm and non-reinstallation of unit to mounting bracket. Designed for surface
mounting, the SA340B includes mounting anchors and screws. Includes a gasket-
less base for easy installation and a new mounting bracket that keeps the alarm
secure over a wide rotation range to allow for perfect alignment.
Sealed (Three 3V) Lithium Power Cells
Listed to
Standard
UL 217
10-YEAR SEALED

CAT. SA340B
ARCHITECTURAL AND ENGINEERING SPEC
TECHNICAL SPECS
SHIPPING SPECS
INSTALLATION OF ALARM
The smoke alarm shall be a First Alert Model SA340B and shall provide at a minimum
the following features and functions:
1. A dual ionization sensing chamber.
2. The unit shall be capable of self restoring.
3. Powered by a sealed 10-year lithium powercell with a tamperproof design. The
tamperproof design shall not allow the powercell to be removed after installation. A
low power warning indicator shall cause the alarm to “chirp” when it reaches
the end of its service life and needs to be replaced. Upon end of life, the unit shall
meet UL requirements for disabling the alarm and the non-reinstallation of unit to
mounting bracket.
4. A solid state piezo horn rated at 85 dB at 10 feet.
5. A visual LED power-on indicator to confirm unit is receiving power or is in alarm.
6. A full function test button. The test button should check all alarm functions by
stimulating the chamber to simulate a smoke condition, causing the unit to alarm
and also has a silence feature to silence unwanted nuisance alarms.
7. The unit shall be capable of operating between 40°F (4°C) and100°F (38°C) and
relative humidity between 10% and 90%.
8. The unit shall contain mounting hardware and shall be listed for wall or ceiling
mounting.
9. The unit shall at a minimum meet the requirements of UL217, CSFM, NFPA 72,
NFPA 101, ICC.
Alarm Dimensions: 5.6” dia x 2.0”H
Weight: 6.9 oz
Operating Voltage: 9V (three 3V) Lithium Power Cells
Temperature Range: 40°F (4°C) to 100°F (38°C)
Humidity Range: 10% to 95% relative humidity (RH)
Audio Alarm: 85dB at 10 feet
Test/Silence: Electronically simulates smoke condition, causing the
unit to alarm. Press and hold test/silence button.
Alarm Reset: Automatic when smoke clears
Smoke Sensor: Dual Ionization
Indicator Lights/Sounds:
DC Power: Intermittent Red LED
Local Alarm: Audio alarm and rapidly flashing Red LED
Listing: Listed to UL217 Standard
Individual Carton Dimensions 5.75 ”L x 2.00”W x 6.75”H
Weight 0.55 lbs.
Cube 0.05 ft3
UPC 0 29054 00066 8
Master Carton Dimensions 12.75”L x 6.00”W x 7.25”H
Master Pack 6
Weight 3.6 lbs.
Cube: 0.32 ft3
I2of5: 100 29054 00066 5
Pallet Information
Cases per Layer 24
Number of Layers: 6
Cases per Pallet: 144
Units per Pallet: 864
Cube: 46.8 ft3
Weight: 786 lbs.
©2014 BRK Brands, Inc. a Jarden Corporation
Company (NYSE: JAH)
3901 Liberty Street Road
Aurora, IL 60504-8122
All rights reserved
First Alert is a registered trademark of the First Alert Trust
BRK is a registered trademark of BRK Brands, Inc.
CM3180
brkelectronics.com
Installation of this smoke alarm must conform to NFPA 72. Always check your local
building codes. Follow all instructions for placement as outlined in the user’s manual in
sections titled “Recommended Locations for Smoke Alarms” and “Locations to Avoid for
Smoke Alarms”.
THE PARTS OF THIS SMOKE ALARM
1. Mounting Bracket
2. Mounting Slots
3. 10-Year Lithium Powercell
4. De-activation Tab (located
under label)
MOUNTING
BRACKET
TOP VIEW SIDE VIEW
5.6”
2.0”
Inserting Powercell De-activating Alarm
