Bronpi Sena User manual

Modelo SENA
INSTRUCTION MANUAL

Dear customer:
E G We would like to thank you for choosing one of our products. The product
you have just purchased is highly valuable and this is why we kindly invite you
to read carefully this brief manual so as you can make the most of your
equipment.

GE ERAL WAR I GS
E G The installation of the stove must be done according to the local regulations,
including those referred to the national or European rules.
Our responsibility is limited to the supply of the equipment. The installation
must be done according to the foreseen procedures for this type of
equipments, following the prescriptions detailed in these instructions, and the
rules established for this profession. The responsibility of the ensemble of the
installation will fall on the installation engineers or, if it proceeds, on the
company in charge of the installation; however, in both cases they must be
qualified and renowned personnel.
IMPORTA T! This product includes a spray tin inside the combustion chamber
or oven (where applicable) that needs to be removed before starting up the
equipment.


REGULATIO S
E G To get a perfect combustion regulation, this model presents different
regulation. The working process is as follow:
PRIMARY AIR REGULATIO

ARRANGEMENT AND ELEMENTS REPLACEMENT /
E G We will find a rectangular piece inside the combustion chamber, which is the
deflector. The absence of a deflector causes a big depression with a very fast
combustion, excessive wood consumption, and the subsequent overheating
of the equipment. It normally comes installed from the factory and to remove
it we need to proceed as follow:
2.1 DEFLECTOR
2.2 I TER AL SHEETS.
E G The internal part of the combustion chamber consists of vermin
culite sheets and we should never use the equipment if these sheets have
been removed.
In case of breaking the sheets, in order to replace it we need to remove the
deflector and proceed as follow:
Start by removing one of the sides; to do so we need to raise the sheet a little
bit and then bend it so as to get it out.

E G
- A “cold hands” handle to open the door. To install it we need to
introduce it from top to bottom and then spin it around.

TECH ICAL FEATURES /
EXPLODED VIEW DRAWI G /
Potencia calorífica / Puissance nominale/ Nominal output 9 kW
Rendimiento / Rendement / Efficiency / Rendimento 75 %
Emisiones CO (13% O2) / Taux de CO (13%O2) / Emissions of
CO (13%CO) / Emissões CO (13% O2) 0.29 %
Temperatura de humos / T° fumées / Flue gas temperature /
Temperatura de fumos 333 ºC
Conducto de humos / Conduit de fumee / Diameter of pipe /
Conduta de fumos Ø 150 mm
Carga combustible/ Combustible recomendé / Fuel consumption /
Carga combustível 2.7 Kg/h
Longitud maxima de leña / Longueur maximale de buches 55 cm
Peso / Masse de l’appareil / Weigth / Peso 70 Kg

N°
DESCRIÇÃO / DESCRIPTION
N°
DESCRIÇÃO / DESCRIPTION
1 Base 15
Rejilla
2
Salida Humos
16
Maneta Perno
3
Puerta
17
Maneta Tirador
4
Solapa C
ajon
18
Pata
5
Cajon
19
Deflector
6 Regulacion Primaria 20
Vermiculita Trasera
7 Pomo Regulador 21
Vermiculita Lateral
8
Soporte Bisagra
22
Techo
9
Pernio Bisagra
23
Sujeta Vermiculita Lateral
10
Limpia Cristal
24
Sujeta Vermiculita Trasero
11
Cris
tal Puerta
27
Salvatroncos
12 Trasera Techo 28
Doble Combustión
13 Frontal 29
Regulación Secundaria
14
Plano Fuego

IMPORTANT
E G This product can be installed next to the walls of the room, provided that they
meet the following requirements:
•To respect a distance of about 5-10 cm. to the wall.
•To check that the wall is completely made of brick, fireproof brick
blocks, concrete, thin hollow brick, etc., and that they are covered by
a material susceptible to support high temperatures.
Therefore, in the event of the wall being made of any other material
(plasterboard, wood, non glass-ceramic, etc.) the installation engineer should
foresee an adequate isolation or leave a minimum security distance to the wall
of 80-100cm. In this case, it is compulsory to use thermal insulated pipe.

The data provided in this manual are not binding.
The company reserves the right to carry out modifications and
improvements without notice.

Please, do not hesitate to contact your dealer for further information.
