Broyhill LEGACY CASTLE PINES RVS9431 User manual

Need help? We are here for you! 1 (877) 539 – 7436 • Toll Free
ASSEMBLY INSTRUCTION
ITEM#: RVS9431
SKU#: 810487338
CASTLE PINES 2 PC
SWIVEL GLIDERS
[email protected] • Email Address

Use the correct bolts as indicated. Do not tighten any of the bolts until the swivel glider is completely assembled.
Do not discard of any of the packaging until you have checked that you have all of the parts and ttings required.
Keep children away during assembly. This item contains small parts that can be swallowed by children.
Children should always be under direct adult supervision while using this product.
Chairs are for sitting purposes only. Standing on or misuse of chair may result in damage or injury. Not intended
for commercial use. Weight limit is 250 lbs (113 kg).
Read all instructions before starting
Clear a at covered space to begin assembly
Always best to do it with a friend
Note that hardware required is provided for every step
Pay attention to orientation
Letter of the part corresponds to a sticker on the product
Number of the hardware corresponds to its letter in the package
Helpful hints provided along the way
MAINTENANCE:
WARNINGS:
GENERAL BEST PRACTICES FOR ASSEMBLY:
Retain these assembly instructions for future reference.
Wash frame and fabric parts with mild soap and water, rinse thoroughly, and dry completely. Do not use bleach,
acid, or other solvents on the frame or fabric parts.
The cushions may be washed on the surface only by using mild soap and water or a commercial foaming
upholstery cleaner if necessary. If washed, rinse well and hang to dry. Do not machine wash or dry.
We recommend the use of furniture covers when not in use.
Inspect and tighten all of the bolts and fasteners on a regular basis to ensure the proper performance and
safety of your swivel glider.
In order to prolong the life and beauty of your swivel glider, we recommend that it be stored in a dry and
protected area during o season periods.
PAGE 1 OF 7
Regularly check hardware and tighten if necessary

PAGE 2 OF 7E-320
PARTS LIST
500 10 20 30 40 60 70 80 90
mm 100
Ⅰ
Ⅱ
Tools
Ⅰ
Ⅲ
Ⅳ
2
1 1
1
2 1
4
1213
12
14
15
3
PART
NO. MATERIAL CODE PART Q’TY
BACK ASSEMBLY
SEAT ASSEMBLY
ARM WASHER d6.5*D30*2.0
SUPPORT FRAME
WASHER d8.5*D12*2.1
WASHER d8.5*D12.5*1.5
SEAT POST
DECORATIVE
PLASTIC COVER
JAM NUT M8*1.25
JAM NUT M6*1.0BASE ASSEMBLY
SWING BAR
BOLT M6*35
BOLT M6*45
BACK CUSHION
BOLT M8*30
SEAT CUSHION
WASHER d8.5*D17*1.6
RVS9431-CS03-1
RVS9431-CS02-1
RVS9431-CS01-2
17FA05040301-YX
17FA05100701-YX
17FA08060601-YX
17FC08030801-YX
17FD08300501-YX
417
2416
WASHER d6.5*D13*1.0
4
17C01A0814001YX
14
BOLT M8*40
RVS9431-CS14-1
17D03A030301-YX 218
15 RVS966Z-CS19-1
17D03A040401-YX 419
16 18000744004
1
4
7RVS9431-CS12-1
27TAI00009
9
8
17C33A0712001YX
2
9
17C33A0716001YX
61R9431X00001BA 120
61R9431Y00001BA 121
811
10
17C01A0810001YX

PAGE 3 OF 7E-320
STEP 1
PARTS REQUIRED: 3, 8, 11, & 16
Keep the bolts loose.
x2
8
STEP 2
PARTS REQUIRED: 1, 3, 9, & 13
Keep the bolts loose.
x4 x4
9 13
x2
11
x6
16
11
16
16
16
3
8
8
9
13
9
13
1
3
3

PAGE 4 OF 7E-320
STEP 3
PARTS REQUIRED: 2, 3, 9, & 13
Keep the bolts loose.
3
3
2
9
9
13
13
x4 x4
9 13
STEP 4
PARTS REQUIRED: 1, 2, 10, 13, & 18
Keep the bolts loose.
x2
x2
x4
10
18
13
10
13
13
18
1
2

PAGE 5 OF 7E-320
STEP 5
PARTS REQUIRED: 4, 8, 11, & 16
Keep the bolts loose.
4
8
8
8
8
11
16
16
16
x4 x12
11 16
STEP 6
PARTS REQUIRED: 4, 5, 12, 15, 17, & 19
Tighten all bolts by using the supplied Hex key.
4
5
x4 x4
12 15
x4 x4
17 19
12
15
17 17
19
19
5
4
15
12

PAGE 6 OF 7
STEP 7
PARTS REQUIRED: 6 & 7
A
A
6
6
6
7 7
x1
6
STEP 8
PARTS REQUIRED: 5, 7, 9, & 14
Note:
For ease with installation, we recommend that the seat
post (#5) be slightly olied or waxed before fastening it to
the base assembly (#7).
15
5
7
9
14
x1 x1
9 14
E-320

STEP 9
PAGE 7 OF 7
STEP 9
PARTS REQUIRED: 20 & 21
Caution:
To ensure one’s safety during use of this swivel glider,
make sure that all of the bolts are completely tightened.
This chair has the ability to swivel; therefore use by
young children should be adult supervised.
Warranty
• One–year limited warranty.
• Proof of purchase (dated register receipt) is required for warranty claims.
• It remains the customer’s responsibility for freight and packing charges to and from the service center.
20
21
