Broyhill BS20006 User manual

ALL WEATHER WICKER SECTIONAL SET
CORNER SEAT W/O ARM
ASSEMBLY INSTRUCTIONS
ITEM#:
BS20006
SKU# 810459306
Need help? We are here for you! 1-800-730-5292 Toll Free
Call us between 9:00am--4:00pm Eastern Time Monday through Friday

• The cushion covers may be washed only by using mild soap and water or a commercial
foaming upholstery cleaner if necessary. If washed, rinse well and hang to dry. Do not machine wash
or dry.
• We recommend the use of furniture covers (sold separately) when the chair is not in use.
• In order to prolong the life and beauty of your chair, we recommend that it be stored in a dry and protected
area during off season periods.
Warranty
• This product is covered by Sunbay Company Ltd with
one–year limited warranty.
• Proof of purchase (dated register receipt) is required
for warranty claims.
•It remains the customer’s responsibility for freight and
packing charges to and from the service center.
STOP!
Missing A Part?
No Need To Go Back To The Store!
The store where you made your purchase
does not stock parts for this item.
If you need parts,
whether they are missing or damaged.
Please e-mail:
[e-mail]
or Call Toll Free
TEL:[phone]
between 9:00am--4:00pm
Eastern Time Monday through
Friday
WARNINGS:
MAINTENANCE:
SEPARATE AND IDENTIFY ALL OF THE PARTS,MAKING SURE THAT YOU HAVE ALL OF THE PARTS LISTED.
IF YOU DO NOT LOCATE ALL OF PARTS LISTED, INSPECT THE PACKING MATERIAL FOR SMALL PARTS
THAT MAY HAVE BECOME SEPARATED DURING SHIPMENT.
DO NOT DISCARD OF ANY OF THE PACKAGING UNTIL YOU HAVE CHECKED THAT YOU HAVE ALL OF THE
PARTS AND FITTINGS REQUIRED.
USE THE CORRECT BOLTS AS INDICATED. ALL BOLTS SHOULD BE HAND TIGHT UNTIL THE COMPLETE
PIECE IS ASSEMBLED (THIS WILL MAKE THE ASSEMBLY PROCESS MUCH EASIER). ONCE THE PIECE
IS FULLY ASSEMBLED, THEN GO BACK AND TIGHTEN ALL BOLTS WITH PROVIDED TOOL.
KEEP CHILDREN AWAY DURING ASSEMBLY. THIS ITEM CONTAINS SMALL PARTS THAT CAN BE SWALLOWED BY
CHILDREN. CHILDREN SHOULD ALWAYS BE UNDER DIRECT ADULT SUPERVISION WHILE USING THIS PRODUCT.
IF YOU EXPERIENCE ANY DIFFICULTY DURING ASSEMBLY OR IF ANY PARTS ARE MISSING OR DAMAGED,
CALL THE HELP LINE AT 1-800-730-5292 BEFORE RETURING THIS ITEM TO THE STORE.
PROVIDE THE FOLLOWING INFORMATION WHEN CALLING:
1- MODEL NUMBER OF THE PRODUCT.
2- PART NUMBER AND MATERIAL CODE OF THE PART FROM THE PARTS LIST.
MOST PROBLEMS CAN BE RESOLVED WITHOUT RETURNING THIS PRODUCT TO THE RETAILER.
SOFA IS FOR SITTING PURPOSES ONLY. STANDING ON OR MISUSE OF SOFA MAY RESULT IN DAMAGE OR
INJURY. NOT INTENDED FOR COMMERCIAL USE. WEIGHT LIMIT IS 250 LBS (113 KG).
RETAIN THESE ASSEMBLY INSTRUCTIONS FOR FUTURE REFERENCE.

PARTS LIST
HARDWARE LIST
x1
SEAT ASSEMBLY
x1
ARM
SEAT CUSHION
x4
WASHER
x1
BACK CUSHION
x8
BOLT M6*35
x2
x2
BOLT M6*65
B C
I
F
H
E
G
x1
BACK ASSEMBLY
A
x2
D
x14
JAM NUT
J
500 10 20 30 40 60 70 80 90
mm 100
SEAT ASSEMBLY
x2
K
BOLT M6*40
Ⅰ
Ⅱ
Tools
Ⅳ

STEP 1
Attention:
Make sure that each bolt needed for all steps matches the
corresponding figure to ensure proper assembly.
x1 x1
A B x4
Ix4
J
A
B
I
I I
J
J J

A
B
STEP 2
x1 x2
CGx2
Jx2
K
C
B
C
G
J
K

STEP 3
x2
Dx8
J
x8
H
A
B
D
D
C
H
H
J
J

STEP 4
x2 x1
EF
NOTE: Sold Separately
EE
F
