Brute Force SUPA808-L User manual

SUPA808-L
Adjustable Bench with Leg Extension/Leg Curl
Attachment
Pay attention to fixing and operation
1. Please keepthe box and the manual after installing the machine.
2. Check and tighten screws regularly.
3. Please install the machine in a spacious area.
4. Position the machine on level ground and use a mat to protect the floor.
5. This machine is designed for generally healthy people; please don't use if feeling unwell.
6. There are slip proof cover on the nut (little nylon circle on the nut); please tighten them with a wrench.
9. Do not use if the machine is damaged in any way.
10. Do change or modify the machine as this will void your warranty and could be dangerousto use.
11. Avoiding use or storage in damp, wet and/or direct sunlight conditions.
12. Do not use scour or any chemicals/dilutants on frames or seat/bench coverings; clean using rag and warm
water.
13. Don't put your handsinthe aperture and moving part of the machine when you are doing exercise.
14. To extent the life of your machine please follow the preceding recommendations.

Exploded View Diagram

Part List
Key
No. Description Qty. Key No. Description Qty.
1 Main Frame 1 2 Front Base 1
3 Rear Base 1 4 Metal Plate 2
5 Backrest Adjustment 1 6 Plastic Axis 1
7 Backrest Support 1 8 Backrest Pad 1
9 Seat Pad 1 10 Seat Support 1
11 Seat Adjustment 1 12 Bushing  6
13 Lid Nut M10 2 14 Sleeve 60/50 1
15 Round Buffer  2 16 Pop-Pin 1
17 Plug 40*20 6 18 Plug 60*40 1
19 End Cap 4 20 Wheel 2
21 Plastic Cap M12 4 22 Hex Bolt M8*55 3
23 Plastic Handlebar 1 24 Hex Bolt M8*45 6
25 Washer 811 26 Washer 10 18
27 Nylon Lock Nut M10 9 28 Big Washer 10 2
29 Washer 12 8 30 Nylon Lock Nut M12 4
31 Hex Bolt M12*100 2 32 Hex Bolt M12*120 2
33 Hex Bolt M10*95 4 34 Hex Bolt M10*75 2
35 Hex Bolt M10*70 3 36 Lock-Pin 1
37 Nylon Lock Nut M8 2 38 Leg Press Support 1
39 Foam Roller Tube 4 40 Foam Roller 8
41 Out Side Cap 4 42 Inner Side Cap 4
43 Hex Socket Head Bolt M8*20 8 44 Round Plug  1
45 Plug 50*50 5 46 Buffer  1
47 OP Tube 1 48 Hex Socket Set Screws M8X10 1
49 Spring Clip 1 50 Leg Press 1
51 Comfort Grip 1 52 Plastic Cap 1
53 Ball Head Pin 1 54 Handlebar 1

Assembly Instruction
Note:
1. Washer should be placed on both ends of all bolts (against the head of the bolt and against
the nut) unless otherwise specified in these instructions.
2. Hand tighten all bolts on initial assembly and finally tighten with the wrench once the
entire structure is erect.
3. Some parts may be pre-assembled at the factory.
Step 1
Key No.
Description
Qty.
Key No.
Description
Qty.
15
Buffer 38*7
1
24
Hex Bolt M8*45
2
25
Washer 8
4
26
Washer 10
14
27
Nylon Lock Nut M10
8
28
Big Washer 10
2
33
Hex Bolt M10*95
4
34
Hex Bolt M10*75
2
35
Hex Bolt M10*70
2
37
Nylon Lock Nut M8
2

Assembly Instruction
Step 2
Note: Wrench tighten the bolt(#31,#32) then loosen nut just enough for part(#5,#7,#10) to pivot
freely.
Step 3
Key No.
Description
Qty.
13
Lid Nut M10
2
26
Washer 10
2
29
Washer 12
8
30
Nylon Lock Nut M12
4
31
Hex Bolt M12*100
2
32
Hex Bolt M12*120
2
Key No.
Description
Qty.
15
Buffer 38*7
1
22
Hex Bolt M8*55
3
24
Hex Bolt M8*45
4
25
Washer 8
7

Assembly Instruction
Step 4
Note: Wrench tighten the bolt(#35) then loosen nut just enough for part(#50) to pivot freely.
Step 5
Wrench tighten all bolts.
Your machine should now be fully assembled,
please check that all bolts are tight before using.
Key No.
Description
Qty.
26
Washer 10
2
27
Nylon Lock Nut M10
1
35
Hex Bolt M10*70
1
43
Hex Socket Head Bolt M8*20
6
Key No.
Description
Qty.
43
Hex Socket Head Bolt M8*20
6
