Buffalo 600 Series User manual

Model • Modèle • Modell • Modello • Modelo • Malli:
CU476 / CU477
600 Series
Electric Fryer
Instruction manual
CU476-CU477_EN_A5_v1_20231020.indb 1CU476-CU477_EN_A5_v1_20231020.indb 1 2023/10/20 13:202023/10/20 13:20

2
EN
Safety Instructions
DANGER OF HIGH VOLTAGE!
Electrical requirements:
Always switch off and disconnect the power supply
to the appliance before installation, when not in use,
before cleaning and maintenance/service.
This appliance should only be connected to the mains
electricity supply by a qualified electrician. Hardwire
the appliance into a suitable power supply with correct
voltage and sufficient power capacity. Refer to the
rating label on the appliance for voltage and wattage
requirements.
Connect the appliance to a circuit protected by an
appropriate RCD (Residual Current Device).
Under no circumstances put a plug on the cable.
Failure to comply with these safety instructions will
release Buffalo from any responsibility and the warranty
will become null and void.
• Position on a flat, stable surface.
• A service agent/qualified technician should carry out
installation and any repairs if required. Do not remove any
components on this product.
• Consult Local and National Standards to comply with the
following:
- Health and Safety at Work Legislation
- BS EN Codes of Practice
- Fire Precautions
- IEE Wiring Regulations
- Building Regulations
CU476-CU477_EN_A5_v1_20231020.indb 2CU476-CU477_EN_A5_v1_20231020.indb 2 2023/10/20 13:202023/10/20 13:20

3
EN
• This is an Attended Appliance and must be supervised
when in use.
• Switch off after use.
• If Oil begins to Smoke or Overheat then Switch Off
Immediately.
• Caution! Hot surface!
• DO NOT immerse the appliance in water.
• DO NOT clean with jet/pressure washers.
• DO NOT move or carry the appliance when it is switched on.
• DO NOT leave the appliance unattended during operation.
• Caution! Never switch on the deep fryer without oil inside.
• ALWAYS ensure oil levels are within the ‘MIN’ and ‘MAX’
levels. Failure to do so could result in fire.
• ALWAYS use a suitable cooking oil.
• ALWAYS remove excess moisture/water from food before
frying to avoid excess foaming and spitting of the oil.
• Change oil regularly. The flashpoint of oil (the point at which it
ignites) gradually reduces the more it is used.
• In case of fire, never use water to extinguish.
Never pour water onto hot oil or fat. Use the lid to
cover the fire instead.
• During and after cooking, the unit is still hot. Never touch the
surface to avoid scalding.
• Suitable for indoor use only.
• Oil spilled on the ground during use must be wiped away.
Otherwise it will cause the ground to be slippery.
• Keep all packaging away from children. Dispose of the
packaging in accordance to the regulations of local authorities.
CU476-CU477_EN_A5_v1_20231020.indb 3CU476-CU477_EN_A5_v1_20231020.indb 3 2023/10/20 13:202023/10/20 13:20

4
EN
• If the power cord is damaged, it must be replaced by a Buffalo
agent or a recommended qualified technician in order to avoid
a hazard.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience or knowledge, unless they have been
given supervision or instruction concerning the use of the
appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play
with the appliance.
• Buffalo recommend that this appliance should be periodically
tested (at least annually) by a Competent Person. Testing
should include, but not be limited to: Visual Inspection,
Polarity Test, Earth Continuity, Insulation Continuity and
Functional Testing.
Introduction
Please take a few moments to carefully read through this manual. Correct maintenance and operation of
this machine will provide the best possible performance from your Buffalo product.
Buffalo will not accept liability for product failures in the event that:
• The instructions in this manual have not been followed correctly.
• Unqualified or unauthorized personnel have adjusted the Fryer.
• Non-original spare parts are used.
• The Fryer has not been handled and cleaned correctly.
• The Fryer has been used for a purpose for which it was not intended.
• The Fryer is used by personnel not trained or unfamiliar with the usage of the unit.
Pack Contents
The following is included:
• Buffalo 600 series electric fryer
• Basket: CU476 x 1 / CU477 x 2
• Lid: CU476 x 1 / CU477 x 2
• Instruction manual
BUFFALO prides itself on quality and service, ensuring that at the time of unpacking the contents are
supplied fully functional and free of damage.
Should you find any damage as a result of transit, please contact your BUFFALO dealer immediately.
CU476-CU477_EN_A5_v1_20231020.indb 4CU476-CU477_EN_A5_v1_20231020.indb 4 2023/10/20 13:202023/10/20 13:20

5
EN
Installation
Warning: Incorrect installation, operation, maintenance or cleaning of the
equipment, as well as any modification can cause property damage and personal
casualty. Fully read and understand all instructions before installation.
Before installation and operation, it is the user’s responsibility to ensure that all
Health & Safety regulations concerning safe positioning, spacing, ventilation,
electrical installation, and fire risk, are complied with.
• Remove the Fryer from the packaging, ensuring that all protective packaging, plastic and residues are
thoroughly cleaned from its surfaces.
• Place the unit on a heat-resistant surface (Or Fryer stand if purchased). Avoid placing it on or close
to flammable materials. Maintain a distance of 20cm (7 inches) between the appliance and walls or
other objects for ventilation.
• Keep the unit away from splashing water and countertop’s edge.
Electrical wiring
DANGER of electric shock from incorrect connection
There is a danger to life if the wires are incorrectly connected.
Connection to a suitable power supply should only be carried out by a qualified and
competent electrical engineer.
Warning: The fixed wiring of the power cord connection must be equipped with a
disconnect device (leakage protection switch) with a contact distance greater than 30mm
according to the wiring rules.
Connect the unit in accordance with the applicable regulations of your country, federal state, city or local
authority.
Connect the unit to a standard energy supply network.
For a proper electrical connection, adjust the power ratings to the local circumstances and requirements.
Equipotential bonding terminal in electrical appliances is to connect exposed metal and conductive
parts of electrical devices and other devices in electrical appliances with artificial or natural grounding
conductors to reduce potential differences (reduce and prevent the risk of electric shock).
• This appliance is supplied unplugged and require hardwiring to a suitable electrical power supply.
CU476 requires a 6kW 400V three-phase circuit at 50Hz
CU477 requires a 2x6 kW 400V three-phase circuit at 50Hz
• Connect the wires correctly according to their colour coding. This appliance is wired as follows:
Wire colour Wire function To terminals of power supply
Yellow/green Earth wire, protective conductor Terminal marked E
Blue Neutral wire, neutral conductor Terminal marked N
Brown, grey and black Live wires, Phase L1, L2, L3 Terminal marked L1, L2, L3
• The appliance must be earthed. If in doubt consult a qualified electrician.
• Electrical isolation points must be kept clear of any obstructions. In the event of any emergency
disconnection being required they must be readily accessible.
CU476-CU477_EN_A5_v1_20231020.indb 5CU476-CU477_EN_A5_v1_20231020.indb 5 2023/10/20 13:202023/10/20 13:20

6
EN
Operation Model shown: CU476
Oil tank
Drainage tap
Lifting mechanism
Heating element
Thermostat with on/off function
Reset switch
Heating indicator light
Overheat indicator
light
Note: Before using for the first time, clean all parts well. Let dry completely.
Assembly
• Position the heater of the fryer in place.
There is a safety switch located inside the lifting mechanism, which will shut off power
supply when it is lifted or when heater is not positioned well inside the oil tank.
Start frying
1. Pour cooking oil into the oil tank between the MIN and MAX markings.
2. Connect the appliance to the mains power supply.
3. Set the thermostat to the desired temperature (Note: 170°C to 180°C is suitable for general
cooking). The heating indicator light turns On and the appliance begins to heat the oil.
4. When the set temperature is reached, the Heating indicator light turns Off.
5. Lower the basket with food into the oil. The heating indicator light turns On again.
• Note: During use, the heating indicator light will cycle on/off, indicating the set
temperature is being maintained.
6. When the food is cooked, lift the basket and hang it up to allow the oil to drain for about 1 minute.
WARNING: The food and oil are very hot! Take care when removing the basket as oil may
drip.
7. After use, set the thermostat to “O” (OFF position) and disconnect the appliance from power supply.
CU476-CU477_EN_A5_v1_20231020.indb 6CU476-CU477_EN_A5_v1_20231020.indb 6 2023/10/20 13:202023/10/20 13:20

7
EN
Thermal Cut-out Reset
The appliance is fitted with a Thermal Cut-Out safety switch. Should the temperature exceed safe levels
the appliance will automatically cut off power.
The thermal Cut-out switch is located on the front of the unit. To reset the appliance after a sufficient
cool-down period:
1. Unscrew the reset switch cover.
2. Press the small reset switch down until it clicks, using a blunt pointed instrument.
3. The appliance is now reset and can be used as normal.
Cleaning, Care & Maintenance
The Fryer should be cleaned after each day’s operation; however it may require cleaning
more often, depending on the volume of frying carried out.
Failure to clean the appliance regularly may result in premature activation of the thermal
cut-out switch.
Do not use any abrasive cleaning agents on the appliance.
1. Switch off the power and disconnect from the power supply.
2. Allow the appliance and oil to cool before cleaning.
3. Check the temperature with a suitable probe thermometer. 40ºC is the MAXIMUM temperature at
which oil should be removed. Empty the oil tank by opening the drainage tap on the front of the unit.
Note: If the remaining oil is to be reused, filtering it before storage will extend the oil’s
cooking life.
4. Remove the heaters before cleaning takes place. The lifting mechanism cannot be immersed in
water, but can be wiped down with a damp cloth.
5. Use a suitable detergent to clean the oil tank. Let it dry well, ensuring no moisture enters the inside
of the appliance.
6. The main body can also be cleaned with warm soapy water.
7. After cleaning as above, please use a dry cloth to clean the appliance to ensure there is no water on
the heating element and in the oil tank.
Clean removable parts
• Use warm, soapy water and a soft brush to clean the lids and baskets.
• Dry thoroughly.
Technical Specifications
Note: Due to our continuing program of research and development, the specifications herein may be
subject to change without notice.
Model Voltage Power
(Max.)
Temperature
Range
Capacity
(Max.)
Dimensions
h x w x d (mm)
Net
Weight
CU476 400V 3N~,
50-60Hz
6kW 60ºC - 190ºC 8L 280 x 400 x 600 20kg
CU477 12kW 60ºC - 190ºC 2 x 8L 280 x 600 x 600 34kg
CU476-CU477_EN_A5_v1_20231020.indb 7CU476-CU477_EN_A5_v1_20231020.indb 7 2023/10/20 13:202023/10/20 13:20

8
EN
Troubleshooting
A qualified technician must carry out repairs if required.
Fault Probable Cause Solution
The unit is not
working
The unit is not switched on Check the residual current relay and the
overcurrent fuse in the power supply line and
switch on
Lead is damaged Replace lead
Mains power supply fault Check mains power supply
Appliance does
not reach set
temperature, or slow
to heat up
Faulty thermostat Consult a qualified technician
Faulty heating element Consult a qualified technician
Build-up of fat on heating
element
Clean the appliance
Appliance heats up
but indicator light
does not come on
Indicator light has expired Consult a qualified technician
Heating indicator
light comes on but
appliance does not
heat up
Faulty thermostat Consult a qualified technician
Faulty heating element Consult a qualified technician
Thermostat set incorrectly Check thermostat
No power Thermal cut-out activated Please check your machine is safe with no obvious
damage and then press the re-set switch
Oil overheats or starts
to smoke
Thermostat damaged Switch Off immediately. Consult a qualified
technician
Compliance
The WEEE logo on this product or its documentation indicates that the product must not
be disposed of as household waste. To help prevent possible harm to human health and/or
the environment, the product must be disposed of in an approved and environmentally safe
recycling process. For further information on how to dispose of this product correctly, contact
the product supplier, or the local authority responsible for waste disposal in your area.
Buffalo parts have undergone strict product testing in order to comply with
regulatory standards and specifications set by international, independent,
and federal authorities.
Buffalo products have been approved to carry the following symbol:
All rights reserved. No part of these instructions may be produced or transmitted in any form or by any means, electronic,
mechanical, photocopying, recording or otherwise, without the prior written permission of Buffalo.
Every effort is made to ensure all details are correct at the time of going to press, however, Buffalo reserves the right to
change specifications without notice.
CU476-CU477_EN_A5_v1_20231020.indb 8CU476-CU477_EN_A5_v1_20231020.indb 8 2023/10/20 13:202023/10/20 13:20

CU476-CU477_EN_A5_v1_20231020.indb 9CU476-CU477_EN_A5_v1_20231020.indb 9 2023/10/20 13:202023/10/20 13:20

UK
[phone]
Eire
NL 040 – 2628080
FR 01 60 34 28 80
BE-NL 0800-29129
BE-FR 0800-29229
DE 0800 – 1860806
IT N/A
ES 901-100 133
CU476-CU477_EN_A5_v1_20231020.indb 10CU476-CU477_EN_A5_v1_20231020.indb 10 2023/10/20 13:202023/10/20 13:20

CU476-CU477_EN_A5_v1_20231020.indb 11CU476-CU477_EN_A5_v1_20231020.indb 11 2023/10/20 13:202023/10/20 13:20

CU476-CU477_EN_A5_v1_2023/10/20
http://www.buffalo-appliances.com/
CU476-CU477_EN_A5_v1_20231020.indb 12CU476-CU477_EN_A5_v1_20231020.indb 12 2023/10/20 13:202023/10/20 13:20
