Buffalo DL891-A User manual

Fryer
Instruction manual
Model
DL891-A / DL892-A

1
Safety Tips
• Position on a flat, stable surface.
• A service agent/qualified technician should carry out installation and any repairs if required. Do not
remove any components on this product.
• Consult Local and National Standards to comply with the following:
• Health and Safety at Work Legislation
• BS EN Codes of Practice
• Fire Precautions
• IEE Wiring Regulations
• Building Regulations
• ALWAYS ensure oil levels are within the ‘MIN’ and ‘MAX’ levels. Failure to do so could result in fire.
• ALWAYS use a suitable cooking oil.
• ALWAYS remove excess moisture/water from food before frying to avoid excess foaming and spitting
of the oil.
• Change oil regularly. The flashpoint of oil (the point at which it ignites) gradually reduces the more it
is used.
• DO NOT cover the oil pan when frying.
• DO NOT immerse the appliance in water.
• Some surfaces become hot during operation - take care when using the appliance.
• Always switch off and disconnect the power supply to the appliance when not in use.
• Not suitable for outdoor use.
• This appliance must only be used in accordance with these instructions and by persons competent to
do so.
• This appliance is not suitable for use by children.
• Keep all packaging away from children. Dispose of the packaging in accordance to the regulations of
local authorities.
• If the power cord is damaged, it must be replaced by a BUFFALO agent or a recommended qualified
technician in order to avoid a hazard.
Product Description
Introduction
Please take a few moments to carefully read through this manual. Correct maintenance and operation of
this machine will provide the best possible performance from your BUFFALO product.
Pack Contents
The following is included:
BUFFALO prides itself on quality and service, ensuring that at the time of packaging the contents are
supplied fully functional and free of damage. Should you find any damage as a result of transit, please
contact your BUFFALO dealer immediately.
•DL892-A - Single 5 litre fryer
•DL891-A - Double 5 litre fryer
•BUFFALOFryer
•Basket(DL891-Ax2))
• Element guard (DL891-A x 2)
• Lid (DL891-A x 2)
• Instruction manual

2
Telephone Helpline: 1300225960
Operation
Connecting the Element/Control Panel
The Element and Control Panel are supplied as a single detachable
part to aid in cleaning the appliance.
To connect to the body of the appliance:
1. Locate the lugs on the rear of the appliance with the tabs on the
rear of the element/panel unit.
2. Ensure the safety switch is aligned with the slots on the
appliance [A].
3. Lower the unit onto the appliance, ensuring the tabs are located
inside the lugs on the rear of the appliance [B].
Cooking
1. Connect the appliance to the mains power supply.
2. Set the thermostat to the desired temperature. The amber power indicator light turns On.
3. The appliance begins to heat the oil.
Note: 170°C to 180°C is suitable for general cooking.
Note: The red Heat indicator light turns On during heat-up. When the oil is at the set
temperatures the light turns Off.
Thermal Cut-out reset cover
Thermal Cut-out reset switch
Power indicator light
Thermostat
Element
Safety switch
[B]
[A]

3
4. Once the oil is at the set temperature lower the food into the oil using the basket supplied.
5. Remove the basket from the oil once the food is cooked. Shake gently above the oil pan to remove
any excess oil.
Thermal Cut-Out Reset
Buffalo Fryers are fitted with a Thermal Cut-Out safety feature. Should
the temperature exceed safe levels the appliance will automatically cut
power.
To reset the appliance aftera sufficient cool-down period:
1. Unscrew the cover of the Safety Cut-Out reset switch.
2. Press the small reset switch down until it clicks, using a blunt
pointed instrument.
3. The appliance is now reset and can be used as normal.
Cleaning, Care & Maintenance
• Always turn Off the appliance and disconnect from the power supply before cleaning.
• Always allow the oil to cool before cleaning, ideally for at least 6 hours.
• Check the temperature with a suitable probe thermometer; 40ºC is the MAXIMUM temperature at
which oil should be removed.
• For best performance, BUFFALO recommend that the appliance is cleaned after each day of operation.
• Remove the Element/Control Panel for ease of cleaning.
• Empty the oil to clean the appliance thoroughly.
• If the oil is to be reused then filtering it before refilling the pan will extend the oils cooking life.
• Use a suitable detergent to clean the interior of the appliance.
• Use warm, soapy water and a damp cloth to clean the exterior of the appliance.
• Dry thoroughly after cleaning, ensure there is no water left in the fryer.
• A BUFFALO dealer or qualified technician should carry out repairs if required.
WARNING: Ensure the basket is securely located on the basket mounts. These are
located towards the front of the oil pan
WARNING: The food and oil are very hot! Take care when removing the basket as oil may
drip.
Note: Failure to clean the appliance regularly may result in premature activation of the
thermal cut-out switch.
WARNING: DO NOT remove the oil pan until AFTER it has been emptied.
Reset
Switch

4
Telephone Helpline: 1300225960
Tro u b l e s h o o t i n g
If your BUFFALO appliance develops a fault, please check the following table before making a call to the
Helpline.
Technical Specifications
Fault Probable Cause Action
The appliance is not working The appliance is not switched on Check the appliance is plugged in correctly
and switched on
Plug and lead are damaged Call BUFFALO agent or qualified technician
Fuse in the plug has blown Replace the plug fuse
Power supply Check power supply
Internal wiring fault Call BUFFALO agent or qualified technician
Thermal cut-out activated Reset thermal cut-out
Safety switch not located properly Refit control/element unit
Appliance does not reach set
temperature
Faulty thermostat Call BUFFALO agent or qualified technician
Faulty element Call BUFFALO agent or qualified technician
Build-up of fat on the element Clean the appliance
Appliance heats up but indicator light
does not come on
Indicator light has expired Call BUFFALO agent or qualified technician
Power indicator light comes on but
appliance does not heat up
Faulty element Call BUFFALO agent or qualified technician
Faulty thermostat Call BUFFALO agent or qualified technician
Thermostat set incorrectly Check thermostat
Appliance slow to heat up Faulty element Call BUFFALO agent or qualified technician
Build-up of fat on the element Clean the appliance
Model Voltage Power Current Capacity
(litres)
Maximum
single load
(kg)
Dimensions
h x w x d (mm)
Weight
(kg)
DL892-A 230V 50Hz 2800W 12.2A 5 2 300 x 270 x 400 5.8
DL891-A 230V 50Hz 2 x 2800W 2 x 12.2A 2 x 5 2 x 2 300 x 540 x 400 10.8

5
Telephone Helpline: 1300225960
Electrical Wiring
The plug is to be connected to a suitable mains socket.
This appliance is wired as follows:
• Live wire (coloured brown) to terminal marked L
• Neutral wire (coloured blue) to terminal marked N
• Earth wire (coloured green/yellow) to terminal marked E
This appliance must be earthed, using a dedicated earthing circuit.
If in doubt consult a qualified electrician.
Electrical isolation points must be kept clear of any obstructions. In the event of any emergency
disconnection being required they must be readily accessible.
Compliance
The WEEE logo on this product or its documentation indicates that the product must
not be disposed of as household waste. To help prevent possible harm to human
health and/or the environment, the product must be disposed of in an approved and
environmentally safe recycling process. For further information on how to dispose of
this product correctly, contact the product supplier, or the local authority responsible
for waste disposal in your area.
BUFFALO parts have undergone strict product testing in order to comply with
regulatory standards and specifications set by international, independent, and federal
authorities.
BUFFALO products have been approved to carry the following symbol:
All rights reserved. No part of these instructions may be produced or transmitted in any form or by any means,
electronic, mechanical, photocopying, recording or otherwise, without the prior written permission of BUFFALO.
Every effort is made to ensure all details are correct at the time of going to press, however, BUFFALO reserve the
right to change specifications without notice.

DECLARATION OF CONFORMITY
I, the undersigned, hereby declare that the equipment specified above conforms to the
above Legislation and Standard(s).
Equipment Type Fryer
Model DL891-A DL892-A
Legislation C-Tick
AS/NZ 3820 Essential Safety Requirements for Low
Voltage Electrical Equipment
Standards EN 55014-1:2006, EN 55014-2:1997+A1
EN 61000-3-2:2006, EN 61000-3-3:1995+A1+A2
EN 60335-2-37:2002+A1
EN 60335-1:2002+A11+A1+A12+A2+A13 with AS/NZS
60335-1:2002+ A1+A2+A3, EN 62233:2008
Producer Name Buffalo
Producer Address Unit 2, 34-38 Anzac Ave,
Smeaton Grange,
NSW 2567
Date 22/03/11
Signature
Full Name Richard Cromwell
Position Marketing Director

DL891_DL982_A5_v2
