Bull ESCALA PL 240 Series User manual

Bull ESCALA PL 240
Your Guide to Removing, Replacing, and
Installing Parts
86 A1 13EM 00
ORDER REFERENCE

Bull ESCALA PL 240
Your Guide to Removing, Replacing, and
Installing Parts
Hardware
October 2003
BULL CEDOC
357 AVENUE PATTON
B.P.20845
49008 ANGERS CEDEX 01
FRANCE
86 A1 13EM 00
ORDER REFERENCE

The following copyright notice protects this book under the Copyright laws of the United States of America
and other countries which prohibit such actions as, but not limited to, copying, distributing, modifying, and
making derivative works.
Copyright Bull S.A. 1992, 2003
Printed in France
Suggestions and criticisms concerning the form, content, and presentation of
this book are invited. A form is provided at the end of this book for this purpose.
To order additional copies of this book or other Bull Technical Publications, you
are invited to use the Ordering Form also provided at the end of this book.
Trademarks and Acknowledgements
We acknowledge the right of proprietors of trademarks mentioned in this book.
AIXRis a registered trademark of International Business Machines Corporation, and is being used under
licence.
UNIX is a registered trademark in the United States of America and other countries licensed exclusively through
the Open Group.
Linux is a registered trademark of Linus Torvalds.
The information in this document is subject to change without notice. Bull will not be liable for errors contained
herein, or for incidental or consequential damages in connection with the use of this material.

Contents
Safety Notices .................................vii
Rack Safety Instructions ..............................vii
Electrical Safety .................................viii
Laser Safety Information ..............................ix
Laser Compliance ...............................ix
Data Integrity and Verification ...........................xi
About This Book ................................xiii
ISO 9000 ...................................xiii
Highlighting ..................................xiii
References to AIX Operating System .........................xiii
Related Publications ...............................xiii
Trademarks ..................................xiv
Chapter 1. Overview ...............................1
Step 1. Check the Operator Panel...........................1
Step 2. Record Needed Information ..........................1
Step 3. Report the Problem .............................1
Chapter 2. Removal, Replacement, and Installation Procedures ..............3
Handling Static-Sensitive Devices ...........................4
Procedure List ..................................5
Placing the 296/C3 into the Service Position .......................6
Returning the 296/C3 to the Operating Position ......................7
Placing the 296/E3 into the Service and Operating Position .................7
Starting the System ................................8
Starting the System without a Hardware Management Console (HMC) Attached .........8
Starting the System with an HMC Attached ......................8
Stopping the System................................9
Stopping the System without a Hardware Management Console (HMC) Attached ........9
Stopping the System with an HMC Attached and AIX Installed ...............9
Stopping the System with an HMC Attached and Linux Installed...............9
Drawer Release Latch Bracket (296/C3) ........................10
Removing a Drawer Release Latch Bracket ......................10
Replacing a Drawer Release Latch Bracket ......................10
296/C3 Cable-Management Arm ...........................11
Removing the Cable-Management Arm .......................11
Replacing or Installing the Cable-Management Arm ...................11
Covers ....................................12
Removing the 296/C3 Service Access Cover .....................12
Replacing the 296/C3 Service Access Cover .....................12
Removing the 296/E3 Service Access Cover .....................13
Replacing the 296/E3 Service Access Cover .....................13
Bezel Door (296/E3) ...............................14
Removing the Bezel Door ............................14
Replacing the Bezel Door ............................14
Bezels ....................................15
Removing the 296/C3 Front Bezel .........................15
Replacing the 296/C3 Front Bezel .........................15
Removing the 296/E3 Front Bezel .........................16
Replacing the 296/E3 Front Bezel .........................16
PCI Adapters ..................................17
iii

Removing a Non-Hot-Pluggable PCI Adapter .....................18
Replacing or Installing a Non-Hot-Pluggable PCI Adapter .................20
Removing a Hot-Pluggable PCI Adapter .......................22
Replacing a Hot-Pluggable PCI Adapter .......................25
Installing a Hot-Pluggable PCI Adapter .......................28
Accessing the PCI Hot-Swap Manager .......................31
PCI Adapter Dividers and Light Pipes .........................33
Removing a PCI Adapter Divider ..........................33
Replacing a PCI Adapter Divider ..........................34
Removing the PCI-Adapter-Divider Light Pipes.....................35
Replacing the PCI-Adapter-Divider Light Pipes.....................35
Service Processor Assembly ............................36
Removing the Service Processor Assembly ......................36
Replacing the Service Processor Assembly ......................38
Battery ....................................39
Removing and Replacing the Battery ........................39
Hot-Swap System Fans ..............................40
Removing a Hot-Swap System Fan .........................404041
Replacing a Hot-Swap System Fan .........................41
Fan Tray Assembly ................................42
Removing the Fan Tray Assembly .........................42
Replacing the Fan Tray Assembly .........................44
Media Devices .................................46
Slimline Media Devices .............................464748
SCSI Media Devices ..............................48
Disk Drive Bezels and Fillers ............................51
Removing a Disk Drive Bezel from a Disk Drive or Filler .................51
Replacing or Installing a Disk Drive Bezel onto a Disk Drive................52
Hot-Swap Disk Drives ...............................53
Deconfiguring a Disk Drive for Removal .......................53
Configuring a Disk Drive after Replacement or Installation ................53
Removing a Hot-Swap Disk Drive .........................55
Replacing or Installing a Hot-Swap Disk Drive .....................57
Removing a Hot-Swap Disk Drive with the System Power Off ...............58
Replacing or Installing a Hot-Swap Disk Drive with the System Power Off...........58
Media Bay Chassis................................59
Removing the Media Bay Chassis .........................59
Replacing the Media Bay Chassis .........................60
Operator Panel Power Cable ............................61
Removing the Operator Panel Power Cable......................61
Replacing the Operator Panel Power Cable ......................62
Power Supply ..................................63
Power Supply LEDs ..............................63
Removing a Power Supply with the System Power Off..................63
Replacing a Power Supply with the System Power Off ..................66
Installing or Replacing a Power Supply with the System Power On .............68
Chapter 3. Parts Information............................71
System Parts ..................................72
296/C3 Parts .................................74
296/E3 Parts .................................75
Internal Cables ................................76
Power Cable .................................77
Keyboards and Mouse (White) ..........................78
Appendix A. Environmental Notices .........................79
iv 296/C3 and 296/E3 Parts Guide

Product Recycling and Disposal ...........................79
Acoustical Noise Emissions.............................80
Declared Acoustical Noise Emissions .........................80
Appendix B. Notices ...............................81
Appendix C. System Locations...........................83
Power Supply Locations (296/C3 and 296/E3) ......................87
Fan Locations (296/C3 and 296/E3)..........................88
System Backplane Locations (296/C3 and 296/E3) ....................89
PCI-X Slot Locations (296/C3 and 296/E3) .......................90
Memory DIMM Locations..............................91
Operator Panel Component Locations .........................93
SCSI IDs and Bay Locations ............................94
296/C3 ...................................94
296/E3 ...................................95
System LED Locations ..............................96
Appendix D. Component and Attention LEDs .....................97
Index .....................................99
Contents v

vi 296/C3 and 296/E3 Parts Guide

Safety Notices
A danger notice indicates the presence of a hazard that has the potential of causing death or serious
personal injury. Danger notices appear on the following pages:
vviii
v3
v63
A
caution notice indicates the presence of a hazard that has the potential of causing moderate or minor
personal injury. Caution notices appear on the following pages:
vviii
vix
v4
v39
Note: For a translation of these notices, see
System Unit Safety Information , order number SA23-2652.
Rack Safety Instructions
vDo not install this unit in a rack where the internal rack ambient temperatures will exceed 35 degrees C.
vDo not install this unit in a rack where the air flow is compromised. Any side, front or back of the unit
used for air flow through the unit must not be in direct contact with the rack.
vCare should be taken to ensure that a hazardous condition is not created due to uneven mechanical
loading when installing this unit in a rack. If the rack has a stabilizer it must be firmly attached before
installing or removing this unit.
vConsideration should be given to the connection of the equipment to the supply circuit so that
overloading of circuits does not compromise the supply wiring or overcurrent protection. To provide the
correct power connection to the rack, refer to the rating labels located on the equipment in the rack to
determine the total power requirement for the supply circuit.
vAn electrical outlet that is not correctly wired could place hazardous voltage on the metal parts of the
system or the devices that attach to the system. It is the responsibility of the customer to ensure that
the outlet is correctly wired and grounded to prevent an electrical shock.
vii

Electrical Safety
Observe the following safety instructions any time you are connecting or disconnecting devices attached to
the workstation.
In the system you are about to setup or service:
vThe ac power interface connector is considered the main power disconnect device.
vThis system has redundant power supply capabilities, meaning that it has the ability to have two power
supplies running simultaneously in the same system unit. When instructed to disconnect the power
source, ensure that all power cables have been unplugged.
DANGER
To prevent electrical shock hazard, disconnect all power cables from the electrical outlet before
relocating the system.
D01
CAUTION:
This product is equipped with a three-wire power cable and plug for the user’s safety. Use this
power cable with a properly grounded electrical outlet to avoid electrical shock.
C01
DANGER
To prevent electrical shock hazard, disconnect all power cables from the electrical outlet before
relocating the system.
D01
viii 296/C3 and 296/E3 Parts Guide

Laser Safety Information
CAUTION:
This product may contain a CD-ROM, DVD-ROM, or laser module on a PCI card, which are class 1
laser products.
C30
Laser Compliance
All lasers are certified in the U.S. to conform to the requirements of DHHS 21 CFR Subchapter J for class
1 laser products. Outside the U.S., they are certified to be in compliance with the IEC 825 (first edition
1984) as a class 1 laser product. Consult the label on each part for laser certification numbers and
approval information.
CAUTION:
All laser modules are designed so that there is never any human access to laser radiation above a
class 1 level during normal operation, user maintenance, or prescribed service conditions. Data
processing environments can contain equipment transmitting on system links with laser modules
that operate at greater than class 1 power levels. For this reason, never look into the end of an
optical fiber cable or open receptacle. Only trained service personnel should perform the
inspection or repair of optical fiber cable assemblies and receptacles.
C25, C26
Safety Notices ix

x296/C3 and 296/E3 Parts Guide

Data Integrity and Verification
These computer systems contain mechanisms designed to reduce the possibility of undetected data
corruption or loss. This risk, however, cannot be eliminated. Users who experience unplanned outages,
system failures, power fluctuations or outages, or component failures must verify the accuracy of operations
performed and data saved or transmitted by the system at or near the time of the outage or failure. In
addition, users must establish procedures to ensure that there is independent data verification before relying
on such data in sensitive or critical operations. Users should periodically check our support websites for
updated information and fixes applicable to the system and related software.
xi

xii 296/C3 and 296/E3 Parts Guide

About This Book
This book provides information about identifying problems that are related to parts, removing and replacing
those parts, installing optional parts (features), and verifying that parts are installed and operating correctly
in your 296/C3 and 296/E3. In this book, the 296/C3 and 296/E3 are hereafter referred to as the
system .
ISO 9000
ISO 9000 registered quality systems were used in the development and manufacturing of this product.
Highlighting
The following highlighting conventions are used in this book:
Bold Identifies commands, subroutines, keywords, files, structures, directories, and other items
whose names are predefined by the system. Also identifies graphical objects such as buttons,
labels, and icons that the user selects.
Italics Identifies parameters whose actual names or values are to be supplied by the user.
Monospace Identifies examples of specific data values, examples of text similar to what you might see
displayed, examples of portions of program code similar to what you might write as a
programmer, messages from the system, or information you should actually type.
References to AIX Operating System
This document may contain references to the AIX operating system. If you are using another operating
system, consult the appropriate documentation for that operating system.
This document may describe hardware features and functions. While the hardware supports them, the
realization of these features and functions depends upon support from the operating system. AIX provides
this support. If you are using another operating system, consult the appropriate documentation for that
operating system regarding support for those features and functions.
Related Publications
The following publications provide additional information about your system:
vThe 296/C3and296/E4InstallationGuide ,ordernumber86 A1 54EG,containsinformationonhowto
set up and cable the system, install and remove options, and verify system operation.
vThe
296/C4and296/E4User’sGuide ,ordernumber86 A1 55EG,containsinformationtohelpusersuse
the system, use the service aids, and solve minor problems.
vThe
DiagnosticInformationforMultipleBusSystems ,ordernumber86 A1 26HX,containsdiagnostic
information, service request numbers (SRNs), and failing function codes (FFCs).
vThe
Adapters InformationforMultipleBusSystems ,ordernumber86 A1 27HX,contains information about
adapters foryoursystem.Thismanualisintendedtosupplement the service information found in the
DiagnosticInformationforMultipleBusSystems .
vThe Site Preparation for Rack Systems ,ordernumber86 A1 30PX,containsinformationtohelpyouplan
your installation.
vThe
SystemUnitSafetyInformation ,ordernumber86 X1 11WD,containstranslationsofsafety
information used throughout this book.
xiii

vThe HardwareManagementConsoleInstallationandOperationsGuide ,ordernumber86 A1 83EF,
contains information for operators and system administrators about how to install and use a hardware
management console to manage a system.
vThe
HardwareManagementConsoleMaintenanceGuide ,ordernumber86 A1 84EF,containsMAPS,
removal and replacement, error code, and parts information that helps trained service representatives
diagnose and repair the system.
Note
In this document, 296/C3 stands for PL 240R, and 296/E3 stands for PL 240T.
xiv 296/C3 and 296/E3 Parts Guide

Chapter 1. Overview
The 296/C3 and 296/E3are designed to allow customers to remove, replace and install certain options and
parts.
If you are installing an optional part in your system, use the installation procedure for the part in Chapter 2,
“Removal, Replacement, and Installation Procedures”, on page 3.
If the system contains a part that is damaged, a part that fails to operate correctly, or the system needs
service, perform the following steps:
Step 1. Check the Operator Panel
When a failing part is detected in your system, the amber-colored attention LED on the operator panel is
turned on solid (not blinking). A failing part might also generate an error code. If an error code is
generated, it is shown on the operator panel display.
1Operator Panel Display 5Power LED
2Front Serial Connector (FS1) 6Power-On Button
3Attention LED 7Service Processor Reset Switch (Pinhole)
4System Reset Button 8Serial Number Label
Step 2. Record Needed Information
Record the following information:
vMachine type and model
vSystem serial number
vAny error codes that appear in the operator panel display or console
vAny LEDs lit on the operator panel
Step 3. Report the Problem
Call your service organization. The service organization provides you with information about how to:
vIdentify the part in your system that is damaged or failing to operate correctly
vDetermine if a damaged or failing part can be replaced by the customer
vHave a replacement part shipped to your location
vComplete the repair when a part is replaced or installed in your system
1

2296/C3 and 296/E3 Parts Guide

Chapter 2. Removal, Replacement, and Installation
Procedures
This chapter provides removal, replacement, and installation procedures for both the 296/C3 rack-mounted
system unit and the 296/E3 deskside system unit.
Notes:
1. Servicing of the 296/E3 can be performed with the system either in the vertical or horizontal position.
Servicing of the 296/C3 is performed with the system in the rack and placed into the service position.
The service position for the 296/C3 is described in “Placing the 296/C3 into the Service Position” on
page 6.
2. Before performing any of the removal or replacement procedures in this chapter, read the following
danger and caution notices.
3. If your system has a failure for one of the listed devices, refer to Appendix D, “Component and
Attention LEDs”, on page 97. When you have determined which device is the source of the problem,
return to these procedures.
4. Only optional parts that are available for your system have installation procedures.
5. In the system, the ac power interface connector is considered the main power disconnect device.
6. This system has redundant power supply capabilities, meaning that it has the ability to have two power
supplies running simultaneously in the same system unit. When instructed to disconnect the power
source, ensure that all power cables have been unplugged.
DANGER
An electrical outlet that is not correctly wired could place hazardous voltage on metal parts of
the system or the devices that attach to the system. It is the responsibility of the customer to
ensure that the outlet is correctly wired and grounded to prevent an electrical shock.
Before installing or removing signal cables, ensure that the power cables for the system unit
and all attached devices are unplugged.
When adding or removing any additional devices to or from the system, ensure that the power
cables for those devices are unplugged before the signal cables are connected. If possible,
disconnect all power cables from the existing system before you add a device.
Use one hand, when possible, to connect or disconnect signal cables to prevent a possible
shock from touching two surfaces with different electrical potentials.
During an electrical storm, do not connect cables for display stations, printers, telephones, or
station protectors for communications lines.
D05
3

CAUTION:
This product is equipped with a three-wire power cable and plug for the user’s safety. Use this
power cable with a properly grounded electrical outlet to avoid electrical shock.
C01
CAUTION:
This unit has more than one power supply cord. To reduce the risk of electrical shock, disconnect
two power supply cords before servicing.
C21
Handling Static-Sensitive Devices
The following procedures describe how to handle static-sensitive devices.
Attention: Electronic boards, adapters, media drives, and disk drives are sensitive to static electricity
discharge. These devices are wrapped in antistatic bags to prevent this damage.
Take the following precautions:
vIf you have an antistatic wrist strap available, use it while handling the device.
vDo not remove the device from the antistatic bag until you are ready to install the device in the system.
vWith the device still in its antistatic bag, touch it to the metal frame of the system.
vGrasp cards and boards by the edges. Hold drives by the frame. Avoid touching the solder joints or
pins.
vIf you need to lay the device down while it is out of the antistatic bag, lay it on the antistatic bag. Before
picking it up again, touch the antistatic bag and the metal frame of the system at the same time.
vHandle the devices carefully to prevent permanent damage.
4296/C3 and 296/E3 Parts Guide
