Bullet tools Magnum 526 User manual

Tools needed: #2 & #3 Phillips head screwdrivers, 1/2” socket or wrench.
Quick Start Guide
for Magnum Shear Model #526
(1) Power Assembly
(1) Handle Assembly
(1) Angle Guide
(1) Table
The Hardware Kit is used in multiple models. Your Shear may not use all of the items listed.
(1) Tail
(4) Rails
(1) Hone Stone
(1) Hardware Kit
In the Box: In the Hardware Kit:
ASSEMBLING YOUR SHEAR
Item A. (8) #14 x 3” Self-Tapping Screws
Item B. (8) 6mm x 25mm PH Phillips Machine Screws
Item C. (6) M6 x 16mm FH Phillips Machine Screws
Item D. (4) #10 x 1 FH Phillips Self Tapping Screws
Item E. (2) M8 x 50mm Hex Bolts
Item F. (1) M6 Thumbscrew (installed)
• IMPORTANT •
Start all screws BY HAND
when assembling your shear.
This will help avoid cross-threading.
Avoid cross-threading by using
your fingers to start all screws
1. AT TACH R AIL S 2. AT TACH TAI L
Attach rails to Power Assembly base using
Item A screws.
Attach tail to rails using Item C screws.
Make sure holes in tail are facing up.
12
Power Assembly
Tail
SET UP
3. AT TACH TABLE
A. Attach front of table to base,
using Item C screws. Tighten
with #3 Phillips.
B. Attach back of table to tail using
Item D self tapping screws.
Tighten with #2 Phillips.
33B
3A
Item D
Item C
Tail

CUT GUIDE
Maximum Thickness = 1”
Carpet Tile
Luxury Vinyl Tile
Commercial Vinyl Tile
VCT
Parquet
PVC Tile
Rubber Tile
Soft Plastic
Your Magnum Shear cuts a wide variety of products. Please refer to cut guide for recommended products and thicknesses.
Please note: Approved materials may vary in density and hardness. If extreme
pressure is required to cut a product, it may result in damage to your machine.
Please contact Bullet Tools before proceeding. Warranty is void if an unapproved
product damages the machine.
For manuals, registration,
warranty info, accessories, & tips
on using and maintaining your
Magnum Shear, go to
BulletTools.com
or scan the QR code ->
PRT-INS-QRCT REV.C.4.18 ©2018 Bullet Tools Hayden, ID USA • 208-772-0175
MAKING CUTS
4
Item E
4. TO ATTACH HANDLE:
Insert Item E bolts and tighten with 1/2”
(13mm) wrench.
5
5. ATTACH ANGLE GUIDE
Install angle guide and tighten Item F
thumbscrew.
While gently pushing
handle down, pull Safety
Lock pin out, lift handle.
Pull Safety Lock pin
1
HANDLE UNDER
EXTREME PRESSURE
DO NOT ALLOW TO
SLAM BACK!
Place product on table.
Bring handle down until
blade touches material.
Push the handle down until
thematerialiscompletelycut.
3
2
Do NOT remove plastic
tie and orange tag until
handle is bolted in place
Item F
SET UP continued
REPLACEMENT BLADE
26" MAGNUM™ Flooring Blade #526B
DON’T
FORGET
TO HONE
YOUR
BLADE!
