Burrow PROSPECT User manual

1
PROSPECT
10-DRAWER &
15-DRAWER
TA LL D RES S ER
Assembly Instructions

22
Dresser parts
2 or 3x
Back walls
2 or 3x
Suport panels
10 or 15x
Drawer backs
20 or 30x
Drawer sides (L, R)
10 or 15x
Drawer fronts
10 or 15x
Drawer bases
6 or 8x
Legs
6 or 8x
Leg plates
12 or 16x
Thumbscrews
2 or 3x
Base panels
2 or 3x
Top panels
2x
Side walls (L, R)
2 or 4x
Interior walls (L, R)
Everything you need is
included
Thanks for bringing Burrow into your home.
We’ve worked hard to make your work
setting up your new furniture as easy as
possible. You’ll need an extra set of hands,
so be sure to grab a friend before you get
started. One big tip: assemble your dresser
as close to the final position as possible, to
minimize movement.

33
For a 15-drawer conguration, you will have
the greater of the two quantities shown for
some parts.
Anti-tip hardware
8 or 12x
Brackets
8 or 12x
Split pins
8 or 12x
Anchor pins
8 or 12x
Wood screws
8 or 12x
Wall claw anchors
8 or 12x
Wall claw screws
Feel free to contact [e-mail]
with any specific questions!
4 or 6x
Cables
1x
Screwdriver
To help you identify different but similar-
looking pieces, we’ve created a system
of removable label stickers. Pieces with a
green “A” sticker are on the right-hand side
of the piece, if you’re facing the front of it.
Pieces with the yellow “B” sticker are on the
left-hand side. The arrows indicate which
direction you should push pieces to secure
the clip connections.

4
1
Screw in two of the anti-tip brackets to the
underside of each top panel, using the wood
screws and the pilot holes as guides.
2
Put the eye at the end of an anti-tip cable
in between the brackets. Then, thread an
anchor pin though the bracket and eye.
Secure the assembly by fitting the straight
side of the split pin through the hole on the
end of the anchor pin.

5
3
Take a back wall panel, and lean it against
the wall as close to the final position of your
dresser as possible. Flip to the last page of
this booklet, use the printed ruler to measure
above the holes on the back wall panel and
4
Screw one leg onto each of the leg plates
in a clockwise direction. If you’re building a
15-drawer dresser, you’ll put together one
extra set of support legs.
make a mark where each screw will go. Then,
hammer in the wall claw anchors at each of
the marks, and use the wall claw screws to
attach brackets to the wall.
__
__ __
__
__
__

6
5
Place the base panels upside-down in a
row on the floor, as shown. Using two
thumbscrews for leg plate, screw the leg and
plate assemblies into the outer corners of the
base panels. Where the base panels meet,
6
Flip the base panels upright so they’re resting
on the legs.
screw in two leg and plate assemblies
across the gap, with the legs in the
innermost position.

7
7
Attach the center walls to each other by
lining up the screw holes on the left and right
sides. The flat faces should be touching, and
the drawer tracks should be mirrored. Secure
using two thumbscrews, and set aside.
8
Attach the left wall to the left base panel by
lining up the yellow (B) stickers, with the “Top
B” sticker at the top. There are six clips: three
on the edge of the base panel, and three on
the edge of the wall. Align these clips, and
press them together until you hear a click.
x

8
9
While someone holds the left wall upright,
attach an interior wall to the meeting point
of the base panels by lining up the green
(A) and yellow (B) stickers. There are twelve
clips: six on the edges of the base panels,
10
One person should stand at the front of
the dresser, holding both walls upright.
The other should attach the support panel
to the left and interior walls, matching up
the yellow (B) and green (A) stickers. There
are two holes on the support panel; those
should be at the top. Push in the direction of
the arrows on the support panel.
and six on the edges of the walls. Align these
clips, and press them together until you hear
a click.

9
11
Attach the right wall to the right base panel
by lining up the green (A) stickers, with the
“Top A” sticker at the top. There are six clips:
three on the edge of the base panel, and
three on the edge of the wall. Align these
clips, and press them together until you hear
a click. If you have a 9-drawer configuration,
you will need to attach the second interior
wall between the remaining two base panels,
in a similar manner to Step 9.
12
Make sure one person holds the unsupported
walls in place. The other person can attach
the support panel to the right and interior
walls, and between the two interior walls
on a 9-drawer configuration, matching up
the yellow (B) and green (A) stickers. There
are two holes on the support panels; those
should be at the top. Push in the direction of
the arrows on the support panel.

10
13
Attach the top panels to the walls by aligning
the yellow (B) and green (A) stickers, and
clicking down into place at all connection
14
Thread the anti-tip cables through the holes
in the support panels. Then, place the back
walls on the lip of each base panel while you
align the anti-tip hardware holes with the
ones on the support panel. Thread the cables
through the back walls, and then click the
back walls into place and push down to lock
them in.
points. Push or pull the top panel towards the
back of the dresser to lock the clips.

11
15
Gently, and with diligent care, place the
dresser in its final position, and attach the
anti-tip cables to their counterparts on the
wall, following the instructions from Step 2.
16
Next, you’ll assemble the drawers. Gather
a drawer front, left and right drawer sides,
a drawer back, and a drawer base. Place a
drawer front face down on your work surface
(so the stickers are facing up), attach the
right side of the drawer by lining up the green
(A) stickers, making sure the groove at the
bottom creates a continual line between the
front and side.
Important tip: The clips on the drawers are
permanent and cannot be undone once
clicked into place. Please carefully follow
these instructions.
Tip: If your oors are just a hair uneven, you
can unscrew each leg a little bit to raise that
section of the dresser to compensate.

12
17
Attach the left side of the drawer by lining
up the yellow (B) stickers, making sure the
groove at the bottom creates a continual line
between the front and side.
18
Slide the base into the grooves on the sides
and front of the drawer, making sure the side
with the sticker will be on the bottom of
the drawer.

13
20
Repeat steps 16 through 19 for all
your drawers.
19
Finally, attach the back of the drawer by
lining up the yellow (B) and green (A) stickers
with the stickers on the drawer sides, making
sure the groove at the bottom creates a
continual line between the back and sides.
1 2 3

14
21
Pull out the bottom-most drawer tracks from
the dresser as far as they’ll go. Disengage
the orange pin at the front of each track by
pulling the trigger inward. The pins should
22
Lay the drawer onto the tracks. The back
corners of the drawer each have little
holes, and the tracks have corresponding
hooks. The hook should slip into the holes
to lock the back of the drawer in place.
be flush with the inside of the track before
placing the drawer.

15
23
Once that’s in place, lower the front of the
drawer onto the track. Here, there are two
pins: one gray and one orange. The gray pin
will fit into the bottom edge of the drawer.
The orange pin fits into the inside edge of
the drawer, horizontally, and is engaged by
switching the orange tabs outward. You
should feel a satisfying click once they’re
in place.
24
Repeat steps 21 through 23 for all remaining
drawers, working from bottom to top. If
the drawer isn’t shutting fully, or seems
misaligned, make sure all connection pins/
inserts between the drawer and the tracks are
complete. Then, you’re all set! Time to Marie
Kondo your closet and start using your new
Prospect Dresser. Be sure to tag @burrow on
Instagram and use the hashtag #myburrow to
share your setup with us.
Tip: If the drawers seem uneven, rotate the
circle-shaped tab at the end of the drawer
sliders to raise or lower the height of each
side. Push the tab in to lower, pull it toward
the front to raise.

16
1
The holes along the top edge of the back
wall panel allow the anti-tip hardware to
connect from the inside of the dresser to
your wall. Lean a back wall panel against
2
Repeat the process by shifting the back wall
panel to the left or right, in the approximate
positions of the other drawer stacks, and
marking additional spots for each bracket.
your wall, and using the printed ruler to the
right, mark two spots on your wall for each
bracket, as indicated. This is where the
anchors and wall claw screws will go.
Anti-tip hardware template

17
3
You can set the back wall panel aside
after that, and return to step 3 to continue
assembling your dresser.
Mark a spot on the wall here, for the
top screw
Mark a spot on the wall here, for the
bottom screw
Align center of hole here
Measurement tool

18

19

Need a hand?
Send an email to [e-mail]
or text us at [phone] and our
world-class support team will help you
sort things out.
