BWI Eagle AIR-EAGLE XLT 441AN/DP-5-0002-120VAC Manual

PRODUCT INFORMATION
BULLETIN
105 Bonnie Drive
Butler, PA 16002
724-283-4681
724-283-5939 (fax)
www.bwieagle.com
AIR-EAGLE®XLT
Analog & Digital 900 MHz RF Receiver
MODEL 441AN/DP-5-0002-120VAC
DESCRIPTION
The AIR-EAGLE XLT, MODEL 441AN/DP-5-0002-120VAC Is an RF
receiver equipped with one analog output and one relay output. It is
designed to work with the handheld transmitter model 441P-HH-4-002
for both “On/Off” and “Speed” control. This unit is capable of receiving
commands from up to 2500 feet away. Eight network frequencies to
allow multiple systems to operate simultaneously in the same area
without interference.
INSTALLATION
1. Mount the AIR-EAGLE SR RECEIVER in a convenient location
2. Install wiring to terminal strip.
3. Install antenna onto TNC connector onside of unit.
4. Plug supplied AC-DC wall plug adapter into 120VAC outlet.
TERMINAL STRIP WIRING
TER1 (LEFT BLOCK)
TER2 (RIGHT BLOCK)
1
(-) 12VDC*
1
Analog Output (-)
2
(+) 12VDC*
2
(+) Current Output
*From supplied 120VAC
wall plug adapter
3
(+) Voltage Output
4
N/O Relay
5
C Relay
6
N/C Relay
7
N/O Relay –2nd Pole
8
C Relay –2nd Pole
9
N/C Relay –2nd Pole
10
Open Drain Output (not used)
Note #1 –Output type MUST be selected for the terminal strip wiring to
take effect! (See OUTPUT OPTIONS & FREQUENCY SET-UP)
Dimensions (with mounting plate) 6.3” L x 4.8” W x 2.3” H
CONTROLS & INDICATORS
POWER LED
Illuminates GREEN when powered on
OUTPUT
FAULT LED
Used in 4-20mA mode only –Illuminates RED when
current loop open
ANALOG
OUTPUT
Output increased by button 2 on the handheldtransmitter
and decreased by button 4
RELAY
OUTPUT
Energized by button 1 on the handheld transmitter and de-
energized by button 3

AIR-EAGLE®XLT
Analog & Digital 900 MHz RF Receiver
MODEL 441AN/DP-5-0002-120VAC
OUTPUT OPTIONS & FREQUENCY SET-UP
This receiver is factory set with an analog output of 0-24mA selected and
to operate onfrequency #1. If you wish to change the default settings,
follow the instructions using the table below:
1) Remove power from unit then remove top cover.
2) Select desired output option and/or frequency using table below.
3) Reattach cover and apply power. Programming is now complete.
OUTPUT CONFIGURATION
SEL1
SW1 & 2
OUTPUT TYPE
SW1
SW2
0-24mA Output (default)
TER2 Pins 1 and 2
OPEN
OPEN
0-20mA Output
TER2 Pins 1 and 2
CLOSED
OPEN
4-20mA Output
TER2 Pins 1 and 2
OPEN
CLOSED
Voltage Output
TER2 Pins 1 and 3
CLOSED
CLOSED
SEL1
SW3
VOLTAGE TYPE
OPEN
CLOSED
SW3
0-10V Output (default)
0-5VDC Output
Note –SW3 is only to be used if running in “voltage mode”
SEL1
SW4
OUTPUT OPERATION
OPEN
CLOSED
SW4
Normal operation
Output resets to lowest
setting at power up and
when relay turned off
FREQUENCY SET-UP
SEL1
(SW5-7)
Network
Frequency
SW5
SW6
SW7
1 (default)
OPEN
OPEN
OPEN
2
CLOSED
OPEN
OPEN
3
OPEN
CLOSED
OPEN
4
CLOSED
CLOSED
OPEN
5
OPEN
OPEN
CLOSED
6
CLOSED
OPEN
CLOSED
7
OPEN
CLOSED
CLOSED
8
CLOSED
CLOSED
CLOSED
SPECIFICATIONS
Outputs
One 4-20mA or voltage output (0-5 or 0-10 VDC)
One DPDT 2amps @120VAC or 30VDC relay output
Fuse Protected
2 amp slow-blow
Safety Timer
15 seconds
AC Input
100-240 VAC, 16 W, 50/60 Hz from
supplied wall adapter
Enclosure
Polycarbonate NEMA 4 (IP66)
Frequency
900MHz Spread Spectrum
8 Independent Networks
Reception Range
Up to 2500 Feet w/Standard Antenna
Note: Max range figures are estimates, based on free-air terrain with limited sources of
interference. Actual range will vary based on transmitting power, orientation of
transmitter and receiver, height of transmitting antenna, height of receiving antenna,
weather conditions, interference sources in the area, and terrain between receiver and
transmitter, including, but not limited to, indoor and outdoor structures such as walls,
metal objects, trees, buildings, hills, and mountains.
Operating Temperature
-40oF to +185oF
APPROVALS
United States (FCC)
MCQ-XB900HP
Canada (IC)
1846A-XB900HP
Australia
RCM
Brazil
ANATEL 3727-12-1209
ACCESSORIES
Standard Antenna (Included):
900MHz TNC “Rubber Duck” Antenna
49-1103
Mobile/Base Antennas –
Used to help achieve max range in both non line of sight and line
of sight applications. - Contact BWI Eagle for recommendations
900MHz Thru-Hole Mount Mobile Antenna
49-2101
900MHz Magnet Mount Mobile Antenna
49-2102
900MHz Omni Directional Base Antenna
49-3101
900MHz Yagi Directional Base Antenna
49-3102
High Quality Coax Cables –
Used to connect external high gain antennas to control unit
Flex Coax Cable w/Connectors –Available
in 5’,15’,25’,30’,40’,60’,80’,100’ Lengths
49-4000-XX
(XX = # of Feet)
Bulkhead Extensions –
Used to provide an external antenna connection whenmounting
control unit inside another enclosure
TNC Male to TNCBulkhead Cable Assembly
- Available in 2’, 4’, 7’ Lengths
49-5004-X-ISO
(X = # of Feet)
LIMITED WARRANTY STATEMENT
BWI Eagle Inc. warrants the Air-Eagle Remote Control System, if properly
used and installed, will be free from defects inmaterial and workmanship
for a period of 1 year after date of purchase. Said warranty to include the
repair or replacement of defective equipment. This warranty does not
cover damage due to external causes, including accident, problems with
electrical power, usage not in accordance with product instructions,
misuse, neglect, alteration, repair,improper installation, or improper
testing. This limited warranty, and any implied warranties that may exist
under state law, apply only to the original purchaser of the equipment, and
last only for as long as such purchaser continues to own the equipment.
This warranty replaces all other warranties, express or implied including,
but not limited to, the implied warranties or merchantability and fitnessfor
a particular purpose. BWI Eaglemakes noexpress warranties beyond
thosestated here. BWI disclaims without limitation, implied warranties of
merchantability and fitness for a particular purpose. Some jurisdictions do
not allowthe exclusion of implied warranties so this limitation may not
apply to you. To obtain warranty service, contact BWI Eagle for a return
material authorization. When returning equipment to BWI Eagle, the
customer assumes the risk of damage or loss during shipping and is
responsible for the shipping costs incurred.
DOCUMENT DATE: 04/25/23 / PRODUCT REV.4
