Byte Brothers Camera Wizard II VTX455 User manual

IP/CCTV Tester Manual
V2.10

CAMERA WIZARD II
TESTS
IP CAMERA TESTS
IP address scan: Scan IP cameras and network device’s for IP address
Link monitor: Displays all IP addresses for a given gateway
Port flicker: Blink a port’s link LED to identify cable location
PING test: Search for IP address to verify connectivity
POE tester: Displays PoE voltage
CAT5/6 cable tester: Performs a pairs test on CAT5/6 cables
Note: IP video image is not displayed on LCD
CCTV CAMERA TESTS
Video image display: 3.5" LCD with 960x240 resolution
Video signal level meter: Display peak to peak value
PTZ camera controls for numerous camera types
RS485/RS422 input and data logging
3.5mm audio input
Built in speaker
Color bar signal generator
BNC input with 3' M-to-M BNC pigtail
POWER AND ACCESSORIES
Up to 11 hour battery life
4 hour recharge time
12VDC 1A output to power camera with 3’ pigtail
5VDC 2A AC adaptor powers and charges tester
Li-ion 3.7V 3000mAh rechargeable battery (replacement battery available)
Carrying case included

Contents
1、Safety information.................................................................................................................................1
2、Introduction............................................................................................................................................2
2.1 General........................................................................................................................................2
2.2 Features.......................................................................................................................................2
2.3 Function ......................................................................................................................................3
2.3.1 Video signal testing (CCTV) ........................................................................................3
2.3.2 Video signal level test (CCTV).....................................................................................3
2.3.3 PTZ controller (CCTV).................................................................................................3
2.3.4 Enhanced Color bar generator (CCTV)........................................................................3
2.3.5 DC12V 1A output power (CCTV)................................................................................3
2.3.6 Audio testing (CCTV)...................................................................................................3
2.3.7 Cable tester (CCTV AND IP).......................................................................................3
2.3.8 RS485 Data Test (CCYV).............................................................................................4
2.3.9 PTZ address scanning (CCTV).....................................................................................4
2.3.10 Image magnification（CCTV) ...................................................................................4
2.3.11 Video snapshot (CCTV)..............................................................................................4
2.3.12 Video record (CCTV) .................................................................................................4
2.3.13 Video playback (CCTV).............................................................................................4
2.3.14 Port flicker (IP) ...........................................................................................................4
2.3.15 IP address scan (IP).....................................................................................................4
2.3.16 Link monitor (IP) ........................................................................................................4
2.3.17 PING test (IP)..............................................................................................................4
2.3.18 POE tester (IP) ............................................................................................................4
2.3.29 LED flashlight.............................................................................................................5
2.3.20 F1、F2 User-defined shortcut keys............................................................................5
2.4 Accessories..................................................................................................................................5
2.5 Front Panel..................................................................................................................................6

3、Operation .............................................................................................................................................10
3.1 Installing the Battery.................................................................................................................10
3.2 Quick tester connection for CCTV use.....................................................................................11
3.3 OSD Menu ................................................................................................................................11
3.3.1 PTZ controller.............................................................................................................12
3.3.2 Color-bar generator.....................................................................................................15
3.3.3 Video in level..............................................................................................................15
3.3.4 PTZ address search .....................................................................................................16
3.3.5 10x zoom image display and Video out......................................................................17
3.3.6 Photograph ..................................................................................................................17
3.3.7 Video record................................................................................................................18
3.3.8 Record playback..........................................................................................................18
3.3.9 PING Test....................................................................................................................19
3.3.10 Cable tester................................................................................................................19
3.3.11 Port flicker.................................................................................................................20
3.3.12 Link monitor..............................................................................................................20
3.3.13 IP address scan..........................................................................................................21
3.3.14 PoE tester ..................................................................................................................21
3.3.15 Data monitor..............................................................................................................22
3.3.16 Time setup.................................................................................................................23
3.3.17 Device (tester) setup..................................................................................................23
3.3.18 USB...........................................................................................................................24
3.4 DC12V 1A power output..........................................................................................................24
3.5 Audio input test.........................................................................................................................25
3.6 LED flashlight...........................................................................................................................25
4、Specifications.......................................................................................................................................25
4.1 General Specifications..............................................................................................................25

IP/CCTV Tester User’s Manual
1
1、Safety information
Notice
The tester is intended to be used in a responsible and safe manner and not in areas where the use
of electrical instruments could be dangerous (hospitals, gas stations etc.).
The tester should be kept dry. Dust and liquid should be avoided.
Like any instrument, treat carefully. Avoid dropping .
Don’t leave the tester alone when charging. If the battery is hot, the tester should be
disconnected from the electric source. The tester should not be charged for more than 8 hours.
Don’t use the tester where the humidity is high. Once the tester is damp, power off immediately
and move it away from other connected cables.
The tester should not be used in the environment with the flammable gas.
Do not disassemble the instrument, since no component inside can be repaired by the user. If the
disassembly is necessary, please contact the factory.
The instrument should not be used in an environment with strong electromagnetic interference.
Do not touch the tester with wet hands.
Do not use detergent to clean. Instead, use a dry cloth. If the dirt is not easy to remove, a soft
cloth with water or neutral detergent can be used.
Limited Warranty
Byte Brothers test equipment warrants to the original consumer that this product is in good
working order for a period of one year from the date of purchase. During the period this product
will be repaired or replaced without charge for either parts or labor unless this unit has been
damaged by the user. Repair or replacement as provided under this warranty is the exclusive
remedy of the purchaser.

IP/CCTV Tester User’s Manual
2
2.Introduction
2.1 General
The Camera Wizard II IP/CCTV tester is designed for the installation and maintenance of IP and CCTV
cameras and devices. CCTV tests: Video display, PTZ control, DC12V output power, audio test, color
generator, RS485 data decoding, picture and video recording, and image magnification. IP camera
tests: IP address scanning, PING testing, Link monitor, POE measurement, Port flicker and CAT5/6
cable testing. Note: The color LCD screen will only display CCTV images (not IP images).
2.2 Features
High definition 3.5”TFT-LCD color display, 480(RGB)x320 (CCTV only)
Built-in LED flashlight
User-defined shortcut keys（F1 and F2）
Support for both NTSC/PAL video formats
10x zoom feature to magnify the video image (CCTV only)
Record and playback CCTV snapshots and videos using a micro SD card
(removable).
IP address scan to determine an IP camera’s IP address
PING an IP address to verify the connectivity of IP cameras or network devices
POE measurement to test the PoE switch’s voltage to the IP camera
Port Flicker blinks a switch port’s link LED. Perfect for tracing cable locations.
Cable testing jack to test the pairs of a CAT5/6 cable.
Link monitor to display IP address usage on the network.
PTZ address scan to determine the address of a CCTV camera.
RS232/RS485/RS422 communication link to drive the PTZ unit.
PTZ testing for cameras so equipped. Driver supports more than thirty protocols.
DC12V 1000ma power output to temporarily power CCTV camera during test.
Audio input jack to test audio signals
Lithium Ion Polymer Battery . This power-efficient battery can last 11 hours during
normal use. Charging time is 4 -5 hours.

IP/CCTV Tester User’s Manual
3
2.3 Functions
2.3.1 Video signal display
Display the CCTV image on the built-in high definition 3.5”LCD-TFT 480（RGB）x320
full-view display color screen. Supports PAL/NTSC. The LCD screen brightness/contrast/color and
saturation are adjustable. Note: The color LCD screen will only display CCTV images (not IP images)
2.3.2 Video signal level test
Test the CCTV video signal strength (attenuation). Longer video cables cause the image to dim and
reduces the image’s dynamic range. If the video signal is too strong, it will cause a virtual shadow and
reduce the sharpness of the image. The level test also displays the video level value and, if out of range,
a notice will be displayed on the screen.
2.3.3 PTZ controller
While displaying the CCTV image, this feature pans, tilts and zooms the PTZ base, if the camera is so
equipped. The tester emulates many common PTZ protocols and sets up the controlling parameters like
protocol, communication port, baud rate, PTZ ID and pan/tilt speed. These parameters can be stored and
recalled (“preset” positions).
2.3.4 Enhanced Color bar generator
The video generator is a PAL/NTSC multi-system color bar video generator used to test the security
system’s video monitors. With the video generator, you can judge whether the color is different because
of the transmission loss or interference.
2.3.5 DC12V 1000ma output power
Power the CCTV camera with the DC12V (1A) power output from the tester. This is helpful during
installation when camera power might not be available.
2.3.6 Audio testing
Test the audio input from pickup devices. Connect the tester and pickup device with the audio cable.
2.3.7 Cable tester
Test a CAT5/6 cable’s pinouts by using the cable test jack (UTP/SCAN) and the included remote.
Connect the CAT5/6 cable to the cable test jack. Connect the remote on the far end of the cable. The
cable test results show the pin-to-pin termination of the wires.

IP/CCTV Tester User’s Manual
4
2.3.8 RS485 data test
Analyze the data coming from a RS485/RS422 device. The data is displayed in hexadecimal format.
2.3.9 PTZ address scanning
Discover the address of the PTZ camera.
2.3.10 Image magnification（10xZoom）
Set image 10x zoom, can view and display the details by 1x、2x、3x、4x、5x、6x – 10X zoom in the
monitor and tester.
2.3.11 Video snapshot
Capture the video image and save the current video frames as a JPEG file
2.3.12 Video record
Record and save the current video on a SD card.
2.3.13 Video playback
Playback the video images that have been saved on the SD card. The file directory name that is created
is based on the date setting of the tester.
2.3.14 Port flicker
Use this feature to blink the link LED on a switch port. Perfect for tracing the location of a cable that is
terminated into a live switch port.
2.3.15 IP address scan
Quickly determine a camera’s IP address with the IP address scan feature. The IP address scan steps
through every possible address in the network’s subnet to determine the IP camera’s address. The
subnet is entered into the tester as part of making the tester a part of the same network .
2.3.16 Link monitor
The link monitor lists the IP address of all network devices that it discovers in its own subnet. This is
useful in making sure there is not a conflict with new IP addresses that are added to an existing network.
2.3.17 PING test
PINGING is a very popular network debugging tool. First, configure the tester with its own IP address
to make it a network device, then you use the tester to contact (ping) other Ethernet devices.
2.3.18 POE tester
Detect and display the existence of PoE power. When PoE power is present, the tester will measure and

IP/CCTV Tester User’s Manual
5
display the voltage that the PoE switch or injector is supplying to the IP camera.
2.3.19 LED flashlight
Light up the workspace with the ultrabright LED on the front of the tester.
2.3.20 F1, F2 User-defined shortcut keys
The user-defined shortcut keys can be setup to do your most popular tests.
2.4 Accessories
1). IP/CCTV camera and device tester
2). Power Supply: DC5V 1.2～1.5A（with included USB cable）
3). Cable test remote adaptor
4). Lithium Ion Polymer Battery（3.7V DC 3000mAh ）
5). BNC cable
6). RS485 cable
7). CCTV camera power cable
8). Audio cable
9). Safety cord
10). Tool bag
11). Instruction Manual

2
2
.5 Front Pa
n
IP/C
C
n
el
C
TV Tester Us
e
6
r’s Manual
