Cadco CBC-PHR-2 User manual

WARRANTY
(Cart & Buffet Server only; See Range Insert Manual for separate warranty)
Cadco warrants that this Cart/Buffet Server be free from defects in material and workmanship
for a period of one year from date of purchase. (Skirt has 30 day initial defect warranty only.)
( arranty provides repair of unit.) A copy of your original purchase receipt is required for proof of
purchase date. This warranty does not cover consequential damage of any kind or damages
resulting from accident, misuse, abuse, or external service or repair attempts by unauthorized
personnel. Inquiries concerning this warranty and the use and maintenance of this unit should be
directed to Cadco, Ltd.
This Cart / Buffet Server section only is on-site service item; call us at 860-738-2500 for
the location of your nearest authorized service center.
Please note: Range Insert is a carry-in service item; see Range Insert Manual for
separate warranty Customer is responsible for removing Range Insert from cart and
packaging securely and returning to Cadco* for service, along with a copy of your original
purchase receipt, a description of the problem, and your name, shipping address and phone
number. Ship to: Cadco, Ltd., Attn: REPAIR, 145 Colebrook River Road, insted, CT 06098. If
shipping the unit for service, we recommend that you insure it for its original purchase price. Cadco
is not responsible for damage or loss of unit in transit to us.
*If not sending it directly to Cadco for service, call us at 860-738-2500 for the location of your
nearest authorized service center. **Save original carton in case required for possible future
service needs.
*Call Cadco at 8 0-738-2500 for Return Authorization Number BEFORE returning any
item for repair. Return Authorization Number MUST be written on outside of carton to track
the unit and avoid service delays. Warranty covers repairing the unit and returning it to
customer.
Warranty is applicable only in the 48 contiguous US states.
for pan specifics (size & quantity) of each model.
6. Stainless steam pans may be used in an oven, but NOT the lid!!!
7. Food placed in steam pans should be fully cooked and already hot. Buffet Cart is designed for
keep-warm function only. To retain heat and moisture in foods, keep lids on when not
serving.
8. Foods containing little or no liquid should be kept warm on Low setting, and stirred periodically.
9-17-2009 RV00
Use & Care Manual
Models: CBC-PHR-2, CBC-PHR-3, CBC-PHR-6:
Manual for CART / BUFFET SERVER part only
(See separate manual for the Glass-Ceramic Range Insert that is
included with this model cart)
Keeps prepared food hot & ready to serve
Mobile Chef Cart
with Glass-Ceramic Range
CARE AND CLEANING : Cart & Buffet Server
Before initial use and after each subsequent use, wash removable parts* in warm sudsy water, rinse and
dry. The clear lids are top-rack dishwasher safe.The most effective and safe way to clean the warming tray
base is with a mild detergent and a soft moist cloth. Do not use any scouring agents! DO NOT SUBMERGE
THE ARMING TRAY BASE OR LET THE HEAT CONTROL COME IN CONTACT ITH ATER.
* Skirt does not need to be washed before initial use. ash nylon, fire-retardant skirt when necessary. Do
not use bleach. (Replacement skirts are avaialble for purchase if/when desired.)
If there is any food residue remaining on the surface, it should be removed after each use. To do so,
scrub gently with a fine cleansing pad such as nylon mesh or other ordinary cleansing pad. DO NOT USE
STEEL OOL OR ABRASIVE KITCHEN CLEANERS. To polish, use a non-abrasive glass cleaner. Any
food residue remaining can be whisked away with a gentle stroke of a nylon mesh pad. Rinse and wipe
dry. Do not allow water to spill or seep into frame. NOTE: It is normal for the heating surface to eventually
discolor due to heat. Any maintenance required for this product other than normal household care
and cleaning, should be performed by our Factory
Cadco, Ltd.
145 Colebrook River Road, Winsted, CT 06098
860-738-2500 l
Fa 860-738-9772
E-mail: [email protected]
l Website: www.cadco-ltd.com
(Front) (Back)
Includes:
l Stainless steel cart with handle & wheels (2 wheels w/brakes; 2 without)
l uilt-in uffet Server: (C C-PHR-2 w/ 2 half size steam pans,
C C-PHR-3 w/ 3 third size steam pans, C C-PHR-6 w/ 6 sixth size steam pans
l uilt-in Glass Ceramic Range l 22 Maple Cutting oard
(Frying pans, sheet pans & utensils not included)
CBC-PHR (Buffet Server Section Only): 300 atts / 2.5 amps / 120 Volts / 60 Hz
1 Temperature Control (active heat area: 22-1/8 x 15)
(See separate Range Insert manual for Range info, specs, and warranty)

Assemble Cart
1. Attach the casters to the bottom of the cart legs. (Casters just pop into the bottom of the legs.)
Put the 2 casters with brakes on front legs for best stability.
2. Place pan holder on the top warming surface, with the notched edge positioned over the
positioning/ stabilizing knobs. (Fig. B)
3. Attach skirt to cart (on sides & front) with Velcro strips provided.
4. ( hen actually using cart to keep foods warm) place steam pans with hot food into the pan
holder, and put the lids in place.
Initial Use (Buffet Server) (Fig. C):
Turn unit on by pressing the ON/OFF rocker switch at the back of the cart to the ON position.
Turn the variable thermostat knob counterclockwise to maximum setting. Heat the warming
base without foods on it for approximately 10 minutes in order to seal the special coating. (Only
top level of the cart in buffet server area heats up.) Temporary smoking is normal during initial use.
Subsequent Use:
1. The buffet server heating element is equipped with a variable thermostat knob, located in back
of cart. Heat range is from 1550 to 2000 F, to keep foods at serving temperatures. (Unit is designed
for keeping food warm, not for warming up cold food.) For best results, use maximum heat setting
to quickly reach your desired temperature, then adjust to desired temperature. Set heat level
by turning the knob so that the white line on the knob mark lines up with the signal light line.
2. The light will come on only during heat cycle. Due to the low wattage necessary for warming
trays, it can be 20-30 minutes before the light cycles off.
3. Attach the pan holder to the top of the cart warming base before placing the pans in place.
5. The unit comes with stainless steam pans and clear polycarbonate rolltop lid. See manual cover
HOW TO USE
Before using for the first time, become familiar with the Buffet Cart features, Figure A. ash
removable parts in warm sudsy water, rinse and dry. Clean the warming tray base & cart with a
mild detergent and a soft moist cloth. Do not use any scouring agents! DO NOT SUBMERGE THE
ARMING BASE OR LET THE PLUG COME IN CONTACT ITH ATER. Rinse and wipe dry.
Do not allow water to spill or seep into the frame.
23
We recommend that you record the following information for warranty
purposes: Model #________
Purchase Date:_____________Dealer:__________________________
Pan Holder
Storage shelves
Congratulations on your purchase of a Cadco Mobile Chef Cart!
uffet Server
Controls Area
(see Fig. C for closeup)
Casters/Wheels ( rakes on 2)
Rolltop Lid
Fig. A
To reduce the risk of personal injury or property damage when using electrical appliances,
basic safety precautions should always be followed, including the following:
1. READ ALL INSTRUCTIONS BEFORE USE.
2. Do not touch hot surfaces! Always Use Handles. Always use hot pads or pot holders until unit cools.
3. To protect against electrical shock, do not immerse tray base, cord or plug in water or other liquid.
4. Close supervision is necessary when any appliance is used by or near children.
5. Unplug from outlet when not in use and before cleaning. Allow to cool completely before
putting on or taking off parts, and before cleaning or storing the appliance.
6. Do not operate any appliance with a damaged cord or plug or after the appliance malfunctions
or has been damaged in any manner. Call the Cadco Factory Service Department at 860-
738-2500 for a Return for Repair Authorization, or for the nearest authorized service center.
(**See back page for Warranty info (Cart/buffet server warranty applies in 48 contiguous US
states only )
7. The use of accessory attachments not recommended by the appliance manufacturer may
cause injuries.
8. Do not use outdoors.
9. Do not let cord hang over edge of table or counter or touch hot surfaces.
10. Do not place on or near a hot gas or electric burner or in a heated oven.
11. It is recommended that this appliance not be moved when it contains hot oil or other hot liquid.
12. Do not clean with metal scouring pads. They can scratch and ruin the finish of your unit.
13. Always attach plug to appliance first, then plug cord into the wall outlet. To disconnect, turn
any control to Off, then remove plug from wall outlet.
14. Do not use appliance for other than intended use.
15.
DO NOT USE PLASTIC DISHES OR PLASTIC WRAP ON WARMING SURFACE .
SAVE THESE INSTRUCTIONS
NOTE: A 72(6) power supply cord (or cord set) (for cart/buffet server; range has its own
separate cord) has been provided to reduce the hazards resulting from becoming entangled in or
tripping over a longer cord. Longer cord sets or extension cords may be used if care is properly
exercised in their use. If a long cord set or extension cord is used, the marked electrical rating of
the cord set or extension cord should be at least as great as the electrical rating of the appliance.
The longer cord should be arranged so that it will not drape over the counter top or table top where
it can be pulled on by children or tripped over accidentally.
The high-tech warming surface will remain unblemished for a long time with appropriate care.
The warming surface and high-grade, long-life stainless chafing pans allow for an attractive
alternative for keeping appetizers and other foods warm. For best results use nylon, plastic, wooden
or rubber utensils. Metal utensils may be used with care but should not be used to cut food on
the cooking surfaces.
IMPORTANT SAFEGUARDS Handle
Cord Storage Slot
Cutting oard (removable)
Steam Pans (See
manual cover
for qty. by model)
uilt-in Range
(Separate cord/plug.
Range removable for
service)
Skirt
(removable)
Cord & Plug
for uffet Server
(Frying pans, sheet pans
& utensils not included)
Variable
Thermostat
Knob
ON/OFF
Rocker Switch
Light
ON
LOW
WARM
HI
ON
OFF
Fig. C
(Cutting oard)
Pan Holder
Position Knob
on front of cart
Pan Holder
Fig. B
Notch on
lower edge
of Pan Holder
Supports for up to 5
1/2 size Sheet Pans
(Pans not included)
(Area fits
optional 1/4
or 1/2 Size
Cadco
convection
oven)
Cord & Plug
for Range
Handle
Cord Storage Slot
