Cala C14724WB Assembly instructions

Visit our website at: http://www.calaindustries.com
SAVE THIS MANUAL Keep this manual for the safety warnings, assembly, inspection,
maintenance and cleaning procedures.
OWNER’S MANUAL & SAFETY INSTRUCTIONS
ITEM# C14724WB
During unpacking, and before assembly check to make
sure the parts are undamaged. If anything is missing or
broken, please contact Cala Industries, Inc. at:
619-448-2252 or email: [email protected]
CALA Industries, INC. Copyright ©2015 All Rights Reserved Item #C14724WB
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.

Visit our website at: http://www.calaindustries.com
2
CALA Industries, INC. Copyright ©2015 All Rights Reserved Item #C14724WB
TABLE OF CONTENTS
WARNING SYMBOLS AND DEFINITIONS
IMPORTANT SAFETY INFORMATION
Safety .....................................................2 Specifications...................................... 3
Parts List................................................3 Assembly .........................................4–9
Maintenance .......................................10 Warranty............................................10
This safety symbol is used to alert you to potential personal injury hazards.
Indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
WORK SAFE DURING ASSEMBLY, USE PRECAUTIONS TO INSURE PROPER
ASSEMBLY
1. Read all pages before starting assembly.
2. Assemble according to the instruction manual.
3. Improper assembly can create a hazardous situation.
4. Do not overtighten screws/bolts as it could damage the workbench support beams.
5. Wear ANSI approved safety glasses and protective gloves during assembly.
6. Keep children and bystanders out of assembly area.
7. Assemble in a clear, flat area with good lighting.
8. Max weight capacity only applies to completely assembled product.
9. Do not exceed weight capacity per each section.
10. Inspect before every use, do not use if any parts are loose or damaged.

Visit our website at: http://www.calaindustries.com
3
CALA Industries, INC. Copyright ©2015 All Rights Reserved Item #C14724WB
PARTS LIST
SPECIFICATIONS
44 lb.
220 lb.
25 lb.
Each
200 lb.
Z
514 lb. evenly distributed as follows:
Bench Top - 220 lb.
Bottom Shelf - 200 lb.
Each Drawer - 25 lb.
Top Shelf - 44 lb.
MAXIMUM WEIGHT CAPACITY
Front Post
Back Post
Rubber Feet
Side Beam
Bottom Beam
Top Beam
Back Top Shelf Beam
Front Top Shelf Beam
Drawer Bracket
Left Drawer Mount
Right Drawer Mount
Middle Drawer Mount
Middle Drawer Mount
Front Drawer Panel
Back Drawer Panel
Left Drawer Panel
Right Drawer Panel
Lower Pegboard Bracket
Back Upper Post
Left Top Shelf Beam
Right Top Shelf Beam
Bottom Shelf
Bench Top
Pegboard
Top Shelf
Drawer Bottom
Drawer Handle
Bolt (M4x10), Washer, Nut
Bolt (M6x10), Washer, Nut
Pegboard Hooks
QTY.DESCRIPTIONPART QTY.DESCRIPTIONPART
Bolt (M6x14), Washer, Nut
Bolt (M4x14), Washer, Nut

Visit our website at: http://www.calaindustries.com
4
CALA Industries, INC. Copyright ©2015 All Rights Reserved Item #C14724WB
ASSEMBLY INSTRUCTIONS
Figure A
Read the “IMPORTANT SAFETY INFORMATION” section
before starting any assembly.
NOTE: Unless otherwise stated, the connections are made using Bolts, Washers and Nuts (W).
NOTE: Finger tighten all connections until assembly is completed, then tighten all bolts/nuts.
NOTE: Assemble workbench on a hard, level, flat surface.
STEP 1:
Attach Side Beams (D x 2pc) to Lower Section of Front (A x 2pc) and Back Posts (B x 2pc).
NOTE: Back Post are longer with 6 holes on top.
Front Post are shorter with 4 holes on top.
STEP 2:
Attach Rubber Feet (C x 4pc) to bottom of each post.

Visit our website at: http://www.calaindustries.com
5
CALA Industries, INC. Copyright ©2015 All Rights Reserved Item #C14724WB
ASSEMBLY INSTRUCTIONS
STEP 3:
Attach Bottom Beams (E x 2pc) to
Front and Back Posts.
STEP 4:
Attach Side Beams (D x 2pc).
NOTE: Top two holes on Front
Post.
NOTE: Middle two holes on
Back Post.
STEP 5:
Attach Top Beams (E x 2pc)
NOTE: Top two holes on
Front Post.
NOTE: Middle two holes on
Back Post.
*Note: Warning label on side beam.
Figure C
Figure B
Figure D
BenchTop 220 lb
Bottom Shelf 200 lb
Each Drawer 25 lb
TopShelf 44 lb
MAXIMUM WEIGHT CAPACITY
514 lb. evenly distributed as follows:
ITEM# C14724WB
TOPREVENT SERIOUS INJURY:
1. Setup and use indoors only. Keep your work bench dry.
2. Do not exceed 514 lb. maximum load capacity, evenly distributed. Be aware of
dynamic loading! Sudden load movement may briefly create excess load causing
productfailure.
3. Wear ANSI-approved safety goggles and heavy-duty work gloves during assembly.
4. Do not overtighten workpiece; damage to workpiece may occur. Be careful not to
pinchfingers when working.
5. Locate work bench on a flat, level, solid surface that is capable of supporting the
weightof the workpiece, workbench and tools.
6. Do not allow children to play with or near work bench.
7. Donot remove this label.
WARNING

Visit our website at: http://www.calaindustries.com
6
CALA Industries, INC. Copyright ©2015 All Rights Reserved Item #C14724WB
ASSEMBLY INSTRUCTIONS
STEP 6:
Attach Front Bracket(G x 1pc) and
Back Bracket (G x 1pc) with Pegboard
Mount (M x 1pc)
STEP 7:
Attach Middle Drawer Mounts
(I-R x 1pc) and (I-L x 1pc) to
Front and Back Drawer Brackets.
STEP 8:
Attach Left (H-L x 1pc) and Right
(H-R x 1pc) Drawer Mounts to Front
and Back Posts.
STEP 9:
Tighten all Nuts/Bolts at this time.
*Make sure workbench is on a flat
surface.
Figure E
Figure F
(Steps 7 & 8)

Visit our website at: http://www.calaindustries.com
7
CALA Industries, INC. Copyright ©2015 All Rights Reserved Item #C14724WB
ASSEMBLY INSTRUCTIONS
STEP 10:
Attach Drawer Handle (U x 1pc)
to the Front Drawer Panel
(J x 1pc) using Bolts/Washers/
Nuts (V x 4pc)
*Note: Tighten all Nuts/Bolts at
this time.
STEP 11:
Lay Wood Drawer Bottom
(T x 1pc) down on a flat surface.
Attach Right (L-R x 1pc) and
Left (L-L x 1pc) Drawer Panels to
the Front (J x 1pc) and
Back (K x 1pc).
STEP 12:
Install the two drawers into the
workbench.
*Note: When sliding in, make sure
the runners on the drawer are level
with the drawer mounts.
Repeat Steps 10 & 11
for second drawer.
Figure G
Figure H
(Step 12)

Visit our website at: http://www.calaindustries.com
8
CALA Industries, INC. Copyright ©2015 All Rights Reserved Item #C14724WB
ASSEMBLY INSTRUCTIONS
STEP 13:
Attach left and right Upper Back Post
(N x 2pc) to the left and right
Back Post.
STEP 14:
Attach Back Shelf Beam (F x 1pc) to
Upper Back Posts.
STEP 15:
Attach Left Shelf Beam (O-L x 1pc)
and Right Shelf Beam (O-R x 1pc)
to Back Shelf Post.
STEP 16:
Attach Front Shelf Beam (F1x 1pc) to
Left and Right Shelf Beams
STEP 17:
Attach Pegboard (R x 1pc) to Upper
Posts & Middle Drawer Mount Using
Bolts/Washers/Nuts (X x 8pc)
Figure J
Figure I
(Steps 13 - 16)

Visit our website at: http://www.calaindustries.com
9
CALA Industries, INC. Copyright ©2015 All Rights Reserved Item #C14724WB
ASSEMBLY INSTRUCTIONS
STEP 18:
Lay Wood Bench Top (Q x 1pc) on
Top Beams and lay Bottom Wood
Shelf (P x 1pc) on Bottom Beams
STEP 19:
Attach Wood Top Shelf (S x 1pc)
to Shelf Beams using
Bolts/Washers/Nuts (Y x 4pc)
Z
Figure K
Figure L

Visit our website at: http://www.calaindustries.com
10
CALA Industries, INC. Copyright ©2015 All Rights Reserved Item #C14724WB
CLEANING, MAINTENANCE AND LUBRICATION
LIMITED 90-DAY WARRANTY
1. BEFORE EACH USE:
Inspect the overall condition of the workbench and look for...
• Misalignment or binding of moving parts.
• Cracked, Broken or Loose parts.
• Any other conditions that could affect a safe working environment.
2. AFTER EACH USE:
Clean off working area and wipe down all surfaces with a dry clean cloth
The Cala Industries 90-day warranty is warranted to be free from defects in materials and workmanship for 90 days
after the date of purchase by the original owner of the product. If this product is defective, please call Cala Industries
at [phone]. Cala Industries shall not be liable for any damage for loss of the product or consequential
damages of any kind. Some states do not allow the exclusion or limitation of incidental or consequential damages,
so the above limitation or exclusion may not apply to you. This warranty gives you specific legal rights, and you may
also have other rights which vary from state to state.
