CAMDEN CX-DE502SO User manual

Page 1 of 2
CX-DE502SO Remote Annunciator
INSTALLATION INSTRUCTIONS
Door Activation Devices
THIS PACKAGE INCLUDES:
1. GENERAL DESCRIPTION
CAMDEN DOOR CONTROLS CX-DE502SO LED Sounder Annunciator is
designed for industrial and commercial applications, where both audible
and visual indication is required. The RGB LED is capable of visually
displaying three distinct colors for designated states: red, green and
yellow.
The faceplate is Stainless Steel with a piezo and tri-colour LED. This unit
requires 12/24V AC/DC to operate.
2. APPLICATION
Camden LED Annunciator with sounder is ideal for applications that
require a visual and audible indicator such as a remote annunciator
station for delayed egress locks, emergency call or access control
alarms. It can be surface or ush mounted. Camden LED Annunciator is
designed to be controlled by delayed egress maglocks, automatic doors,
emergency call systems and other low voltage systems.
(1) Foam Gasket
(2) #6-32 Tamperproof screws
(2) #6-32 1" SS FLT HD screws
(1) Tamper proof driver
Device Wire Color Connection
RGB LED
Red + 12 VDC
Green +12 VDC
White Negative
Sounder Red + 12 VDC
Black Negative
3. WIRING
NO C NC
GRN RlyRED Rly Ex-Trig Reset R-Exit
NO CNC NO C NO CNO C
Bypass
NO C
CX‐DE502SO
Remote
Audible-
Visual Station
PWR
+-
+-
PWR
B
NO C NC
DPS Bond-S
NO CNC
RED
GRN WHT
BLK
RED
CX-DE1200 Delayed Egress Wiring
23
4''
[69.9mm]
41
2''
[114.3mm]
1
4''
[5.3mm]
1''
[24.6mm]
1
4''
[7.1mm]
4. FRONT AND SIDE - CX-DE502SO
23
4''
[69.9mm]
41
2''
[114.3mm]
1
4''
[5.3mm]
1''
[24.6mm]
1
4''
[7.1mm]

Page 2 of 2
CX-DE502SO Remote Annunciator
INSTALLATION INSTRUCTIONS
Call: 1.877.226.3369 / 905.366.3377
Visit: www.camdencontrols.com
Opening New Doors to
Innovation, Quality, and Support!
CX-DE502SO is supplied with a stainless-steel faceplate that can be easily mounted to a single gang electrical box.
Only 9/18” depth is required!
3
4C
1
2
5
4B
4A
4D
4C
MODEL NUMBERS
ITEM NUMBER MODEL NUMBER QTY DESCRIPTION
1 60-64A002 1 PIEZO ALERT BUZZER
2 60-49H038 1 STAINLESS STEEL SINGLE GANG FACEPLATE
3 60-73C019 1 12-VOLT TRI-COLOR LED
PARTS KIT
ITEM NUMBER PART NUMBER QTY DESCRIPTION
4. 60-34B042 1
(A) KEY FOR TAMPER PROOF SCREWS (SNAKE EYE) W/CAMDEN LOGO 1 Pc
(B) SNAKE EYE TAMPER PROOF SCREW 6-32 X 3/4" 2 Pc
(C) 6-32 X 3/4 PHIL OVAL HD S/S SCREW 2 Pc
(D) GREY PLASTIC WIRE NUT C/W SPRING 5 Pc
COMPATIBLE MOUNTING BOXES
ITEM NUMBER PART NUMBER DESCRIPTION
5
CM-34D SURFACE MOUNT BOX WITH EXTRA DEPTH HEAVY DUTY GREY POLYMER
4 1/2"H X 2 3/4"W X 1 3/4"D [114MM X 70MM X 44MM]
CM-34BL SINGLE GANG BLACK ABS BOX, SURFACE MOUNT 4 5/8"H X 2 7/8" W X 1 3/4"D (117MM X 73MM X 44MM
CM-34AL SURFACE MOUNT BOX WITH STANDARD DEPTH AND THREADED CONDUIT ENTRY. HEAVY DUTY CAST
ALUMINUM 2-3/4"H X 4-1/2"W X 1-3/4"D [70MM X 144MM X 44MM]
File: CX-DE502S0_Manual.indd
Rev: 1 | Date: October 27, 2022
Part No#: 40-82B274
5. PARTS INFORMATION
Not Included
