INSTRUCTION MANUAL
HS2 and HS2P
(HydroSense II)
Revision: 3/14
Copyright © 2011-2014
Campbell Scientific, Inc.

Warranty
“PRODUCTS MANUFACTURED BY CAMPBELL SCIENTIFIC, INC. are
warranted by Campbell Scientific, Inc. (“Campbell”) to be free from defects in
materials and workmanship under normal use and service for twelve (12)
months from date of shipment unless otherwise specified in the corresponding
Campbell pricelist or product manual. Products not manufactured, but that are
re-sold by Campbell, are warranted only to the limits extended by the original
manufacturer. Batteries, fine-wire thermocouples, desiccant, and other
consumables have no warranty. Campbell’s obligation under this warranty is
limited to repairing or replacing (at Campbell’s option) defective products,
which shall be the sole and exclusive remedy under this warranty. The
customer shall assume all costs of removing, reinstalling, and shipping
defective products to Campbell. Campbell will return such products by surface
carrier prepaid within the continental United States of America. To all other
locations, Campbell will return such products best way CIP (Port of Entry)
INCOTERM® 2010, prepaid. This warranty shall not apply to any products
which have been subjected to modification, misuse, neglect, improper service,
accidents of nature, or shipping damage. This warranty is in lieu of all other
warranties, expressed or implied. The warranty for installation services
performed by Campbell such as programming to customer specifications,
electrical connections to products manufactured by Campbell, and product
specific training, is part of Campbell’s product warranty. CAMPBELL
EXPRESSLY DISCLAIMS AND EXCLUDES ANY IMPLIED
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE. Campbell is not liable for any special, indirect,
incidental, and/or consequential damages.”

Assistance
Products may not be returned without prior authorization. The following
contact information is for US and international customers residing in countries
served by Campbell Scientific, Inc. directly. Affiliate companies handle
repairs for customers within their territories. Please visit
www.campbellsci.com to determine which Campbell Scientific company serves
your country.
To obtain a Returned Materials Authorization (RMA), contact CAMPBELL
SCIENTIFIC, INC., phone [phone]. After an application engineer
determines the nature of the problem, an RMA number will be issued. Please
write this number clearly on the outside of the shipping container. Campbell
Scientific’s shipping address is:
CAMPBELL SCIENTIFIC, INC.
RMA#_____
815 West 1800 North
Logan, Utah 84321-1784
For all returns, the customer must fill out a “Statement of Product Cleanliness
and Decontamination” form and comply with the requirements specified in it.
The form is available from our web site at www.campbellsci.com/repair. A
completed form must be either emailed to [e-mail] or faxed to
[phone]. Campbell Scientific is unable to process any returns until we
receive this form. If the form is not received within three days of product
receipt or is incomplete, the product will be returned to the customer at the
customer’s expense. Campbell Scientific reserves the right to refuse service on
products that were exposed to contaminants that may cause health or safety
concerns for our employees.

Table of Contents
PDF viewers: These page numbers refer to the printed version of this document. Use the
PDF reader bookmarks tab for links to specific sections.
1. Introduction .................................................................1
2. Cautionary Statements...............................................2
3. Quickstart ....................................................................2
4. Overview......................................................................3
5. Specifications .............................................................6
5.1 Display Specifications..........................................................................6
5.1.1 Current Drain ................................................................................7
5.2 Sensors Specifications..........................................................................7
5.2.1 Volumetric Water Content Measurement .....................................7
5.2.2 Physical .........................................................................................7
5.3 HS2P Pole Assembly ...........................................................................7
5.3.1 Height............................................................................................8
5.3.2 Weight...........................................................................................8
6. Operation.....................................................................8
6.1 Assembly and First Use .......................................................................8
6.2 Measurements ......................................................................................8
6.3 Water Content Data..............................................................................8
6.4 Water Deficit Data ...............................................................................9
6.4.1 Soil Types .....................................................................................9
6.4.2 Configuring Soil Profiles ............................................................10
6.4.3 Storage ........................................................................................12
6.4.4 Proper Measurement Technique and Limitations .......................12
6.4.4.1 Measurement Principle.....................................................12
6.4.4.2 Rod Insertion ....................................................................12
6.4.4.3Soil Factors Affecting Measurement................................13
6.4.4.4 Measurements in Special Materials..................................13
7. User Interface............................................................13
7.1 Buttons ...............................................................................................14
7.2 Splash Screen .....................................................................................14
7.3 Main Screen .......................................................................................14
7.3.1 GPS Information .........................................................................15
7.3.2 Status Information.......................................................................15
7.3.3Measurement Display .................................................................16
7.3.4 Deficit Display ............................................................................17
8. Data Storage and Retrieval ......................................17
8.1 Storing Data .......................................................................................17
i

Table of Contents
8.2 What is stored? .................................................................................. 18
8.3 Software ............................................................................................ 18
8.4 Connecting via Bluetooth .................................................................. 18
8.5 Collecting Data.................................................................................. 19
9. GPS ............................................................................19
9.1 GPS Synchronization......................................................................... 19
9.2 Geotagging and Zones....................................................................... 19
10. Troubleshooting........................................................21
11. Maintenance ..............................................................22
11.1 Batteries............................................................................................. 22
11.1.1 Replacing the Battery Pack ........................................................ 22
11.2 Removing Display from HS2P Pole.................................................. 23
11.3 Rod Replacement .............................................................................. 24
11.4 Replacing an HS2P Sensor................................................................ 26
11.5 Operating System Updates ................................................................ 26
Appendix
A. Configuration Menus ..............................................A-1
A.1 Main Menu ...................................................................................... A-1
A.2 Deficit Mode.................................................................................... A-1
A.3 Bluetooth Power .............................................................................. A-1
A.4 Time/Date Menu.............................................................................. A-2
A.5 Time Set .......................................................................................... A-2
A.6 Date Format..................................................................................... A-2
A.7 Time Zone ....................................................................................... A-3
A.8 Time Synchronization ..................................................................... A-4
A.9 Display Settings............................................................................... A-4
A.10 Contrast ........................................................................................... A-4
A.11 Brightness........................................................................................ A-5
A.12 Backlight on Time ........................................................................... A-5
A.13 Light Sensing................................................................................... A-5
A.14 GPS Settings.................................................................................... A-6
A.15 GPS Power ...................................................................................... A-6
A.16 Coordinate Format........................................................................... A-6
A.17 System Settings ............................................................................... A-7
A.18 System on Time............................................................................... A-7
A.19 Restore Settings............................................................................... A-7
A.20 Serial Number.................................................................................. A-8
Figures
1-1. HS2 HydroSense II System ................................................................. 1
1-2. HS2P HydroSense II Pole System....................................................... 1
4-1. HS2 Parts in Hard Carrying Case ........................................................ 5
4-2. HS2P Carrying Tote ............................................................................ 6
4-3. HS2P Parts........................................................................................... 6
ii

Table of Contents
Tables
4-1. Comparison of HydroSense II and HydroSense(I)...............................3
4-2. HydroSense II Parts..............................................................................5
6-1. Default Soil Profiles...........................................................................10
7-1. Status Icons ........................................................................................16
iii

Table of Contents
iv

HS2 and HS2P
1. Introduction
FIGURE 1-1. HS2 HydroSense II System
FIGURE 1-2. HS2P HydroSense II Pole System
1

HS2 and HS2P
The HydroSense II is an easy-to-use, portable device for measuring volumetric
water content of soil. The major components of the system are the display, the
sensor, and the software. A sensor with 12 cm rods (model CS659 or CS659P)
and a sensor with 20 cm rods (model CS658 or CS658P) are available.
Campbell Scientific offers the HS2, the standard HydroSense II system, and
the HS2P, a HydroSense II system with a strong handle and pole. FIGURE
1-1, HS2 HydroSense II System (p. 1) shows the HS2 and FIGURE 1-2, HS2P
HydroSense II Pole System (p. 1) shows the HS2P.
Throughout the manual, HydroSense II refers to both the HS2 and
HS2P, unless specified otherwise.
2. Cautionary Statements
•The connectors that connect the HydroSense II display to the sensor are a
push-pull type with locators to align the connectors. DO NOT TWIST.
The connectors can be damaged if the user twists them or attempts to
screw or unscrew them.
•Remove the AA batteries before putting the HydroSense II display into
storage.
•An unobstructed view of the sky may be required to achieve the most
accurate global position data possible from the HydroSense II GPS.
•Sensor rods must be completely inserted into the soil before making a
measurement.
3. Quickstart
1. Remove the HS2 display or HS2P from the carry case.
2. Remove the blue protective strip from the display window.
Steps 3 and 4 are for the HS2 only because the HS2P comes fully
assembled. If using an HS2P, go directly to step 5.
3. Remove the HS2 sensor from the carry case.
4. Connect the HS2 sensor to the display by mating the connector on the
cable to the connector at the bottom of the display. DO NOT TWIST the
connectors.
The connector is a push-pull type with locators to align the
connectors. The connectors can be damaged if the user
attempts to screw or unscrew them. To mate the
connectors, simply bring them together and turn until they
are aligned, then applying firm pressure, slide them together
until they click. To disconnect, pull back on the connector
collar with the thumb and forefinger and pull the two
connectors apart.
NOTE
NOTE
CAUTION
2
