INSTRUCTION MANUAL
Hydrosense
Revision: 2/01
Copyright (c) 1999-2001
Campbell Scientific, Inc.

Warranty and Assistance
The HYDROSENSE is warranted by CAMPBELL SCIENTIFIC, INC. to be
free from defects in materials and workmanship under normal use and service
for twelve (12) months from date of shipment unless specified otherwise.
Batteries have no warranty. CAMPBELL SCIENTIFIC, INC.'s obligation
under this warranty is limited to repairing or replacing (at CAMPBELL
SCIENTIFIC, INC.'s option) defective products. The customer shall assume all
costs of removing, reinstalling, and shipping defective products to CAMPBELL
SCIENTIFIC, INC. CAMPBELL SCIENTIFIC, INC. will return such
products by surface carrier prepaid. This warranty shall not apply to any
CAMPBELL SCIENTIFIC, INC. products which have been subjected to
modification, misuse, neglect, accidents of nature, or shipping damage. This
warranty is in lieu of all other warranties, expressed or implied, including
warranties of merchantability or fitness for a particular purpose. CAMPBELL
SCIENTIFIC, INC. is not liable for special, indirect, incidental, or
consequential damages.
Products may not be returned without prior authorization. The following
contact information is for US and International customers residing in countries
served by Campbell Scientific, Inc. directly. Affiliate companies handle repairs
for customers within their territories. Please visit www.campbellsci.com to
determine which Campbell Scientific company serves your country. To obtain
a Returned Materials Authorization (RMA), contact CAMPBELL
SCIENTIFIC, INC., phone [phone]. After an applications engineer
determines the nature of the problem, an RMA number will be issued. Please
write this number clearly on the outside of the shipping container.
CAMPBELL SCIENTIFIC's shipping address is:
CAMPBELL SCIENTIFIC, INC.
RMA#_____
815 West 1800 North
Logan, Utah 84321-1784
CAMPBELL SCIENTIFIC, INC. does not accept collect calls.

i
HydroSense Table of Contents
PDF viewers note: These page numbers refer to the printed version of this document. Use
the Adobe Acrobat® bookmarks tab for links to specific sections.
1. General Description....................................................1
1.1 Introduction...............................................................................................1
1.2 HydroSense Modes...................................................................................2
2. Specifications .............................................................2
3. Unpacking and Setup .................................................3
4. Water Content Measurement Mode...........................4
4.1 Introduction...............................................................................................4
4.2 Display Information..................................................................................4
4.3 Description of Water Content Measurement Mode ..................................5
4.4 Selecting Probe Rod Length .....................................................................5
4.5 Measuring Volumetric Water Content......................................................6
4.6 Measurements in Special Materials...........................................................6
5. Water Deficit Mode......................................................6
5.1 Description of Water Deficit Mode ..........................................................6
5.2 Display Information..................................................................................6
5.3 Calibration—Setting the Lower and Upper Reference Levels..................7
5.4 A Water Deficit Mode Example ...............................................................8
6. Proper Measurement Technique and Method
Limitations ...............................................................9
6.1 Probe Rod Insertion................................................................................10
6.2 Soil Factors Which Can Affect the Measurement—Clay, Soil
Electrical Conductivity, Organic Matter and Rocks...........................10
6.3 Rod Length and Insertion Angle.............................................................11
6.4 Interpreting Measurement Results ..........................................................11
7. Description of HydroSense Measurement Method.11
8. Maintenance..............................................................13
8.1 Replacing Battery....................................................................................13
8.2 Rod Installation/Replacement.................................................................13

1
HydroSense
1. General Description
FIGURE 1-1. HydroSense display unit and probe with 12 cm rods.
1.1 Introduction
The HydroSense Soil Water Content Measurement System provides a simple
and portable means to measure soil water content. Two modes of operation
allow the display of volumetric water content in percent or relative water
content based on lower and upper reference values chosen by the user. The
relative water content is complemented by deficit values showing how much
water is required to bring water content to the upper reference value.
The combined probe and display weight is approximately 600 gm (1.3 lb).
Two alkaline AAA batteries in the handheld display provide enough power for
several thousand readings. A measurement is made by fully inserting the probe
rods into the soil and pressing a READ button and takes less than one-half
second. To save power, HydroSense automatically goes into sleep mode after
approximately two minutes of inactivity.

HydroSense
2
1.2 HydroSense Modes
The Water Content Measurement Mode displays the measurement result as
percent volumetric water content and shows the period of the probe output in
milliseconds.
In the Water Deficit Mode, HydroSense measurements are taken at lower and
upper water contents chosen by the user and stored in memory as reference
values. The reference values are then applied to subsequent measurements to
determine the amount of water that must be added to bring the soil to the upper
water content. The relative water content based on the reference values is also
displayed.
See sections 4 and 5 for detailed operating information.
2. Specifications
HydroSense Display Unit
Measurement % Volumetric Water Content
Resolution 1.0%
Environmental Splash resistant
Display 16 character, 2 line LCD
Keypad Two button membrane keypad
Power 2 x AAA 1.5V DC alkaline batteries
Current Consumption Sleep <50µA
Idle 1.5mA
Measurement 70mA
Battery Life Approximately 12 months
Dimensions 120 (w) x 73 (d) x 24 (h) mm
Weight 166 gm
CS620 Water Content Reflectometer
Accuracy +/- 3.0% volumetric water content with electrical
conductivity <2 dS m-1.
Range 0% to saturation*
Stabilization time Instantaneous
Response time < 50 milliseconds
Power requirement 100 milliamps at 5 ±0.03 volts
Output Square wave with +/- 2.5V DC amplitude
Dimensions Head 105 x 70 x 18 mm
Rods 120 or 200 mm length , 5 mm diameter, 32
mm spacing

HydroSense
3
Weight approx 400 gm
Cable Spiral cable, 200cm extended.
*saturation is typically around 50% volumetric water content
3. Unpacking and Setup
•Remove the protective strip from the display window.
•Screw the rods into the probe threaded inserts to finger tight, use pliers to
apply a small force and give a snug fit. Threads should be clean before
rods are screwed into probe. (see Section 8.2).
•Connect the probe to the display unit by mating the coiled cable connector
to the connector on the display unit.
The connector is a push-pull type and can be damaged if
twisted while connecting or disconnecting.
•The READ button is used
1) to power-up HydroSense,
2) to make a measurement,
3) and in combination with the MENU button to select options.
READ
ENTER
Press the READ button and check that HydroSense is in Water
Content Measurement Mode. The display should be similar
to the following graphic but may have different numerical
values.
VWC 0% P12cm
Period 0.77ms
•An NC after VWC indicates the probe is not properly connected.
•If it is necessary to change operating modes, the HydroSense must be in
sleep mode (no display). The unit automatically goes into sleep mode after
approximately two minutes of inactivity. To change modes, press and hold
the MENU button then press the READ button. Release both buttons.
Unless the mode is changed again, HydroSense will be in Water Content
Measurement Mode when READ is next pressed to wake the unit.
•While holding the probes so rods are in free air, press READ. The VWC
displayed should be between -3% and 3%.
CAUTION

HydroSense
4
VWC 0% P12cm
Period 0.77ms
MENU
SELECT
In Water Content Measurement Mode, MENU is used to select
the rod length. In the Water Deficit Mode, MENU is used to
select the site number and to store reference water content
values.
•To save power, HydroSense automatically goes into sleep mode after
approximately two minutes of inactivity. Pressing the READ button wakes
the unit and makes a measurement.
4. Water Content Measurement Mode
4.1 Introduction
The Water Content Measurement Mode displays the measurement result as
percent volumetric water content and also shows the period of the probe output
in milliseconds. The HydroSense operating system applies standard
calibrations to convert the probe response to volumetric water content. The
calibrations were derived from laboratory measurements in typical agronomic
soils. Section 6.2 discusses the soil factors which can affect probe response
such that standard calibrations do not work well.
4.2 Display Information
VWC 22% P12cm
Period 0.93ms
Volumetric
Water
Content
Probe
Rod Length
Probe
Output
Period
The two-line display provides the following information
1) The volumetric water content in percent (VWC). See Appendix A for
definition of water content.
2) Which probe rod length is selected (see Section 4.4 for rod length
selection).
3) The period of the square wave output from the probe in milliseconds.

HydroSense
5
4.3 Description of Water Content Measurement Mode
The Water Content Measurement Mode applies calibration coefficients to
the output of the probe to give volumetric water content in percent. The
calibration coefficients reside in the operating system and were determined by
the manufacturer. The calibration was derived from laboratory measurements
in typical agronomic soils. See Section 6.2 for discussion of HydroSense use in
high salinity, high clay or other atypical materials.
4.4 Selecting Probe Rod Length
VWC 22% P12cm
Period 0.93ms
MENU
SELECT
Probe
Exit
MENU
SELECT
Probe
12cm
MENU
SELECT
Probe
20cm
MENU
SELECT
READ
ENTER
FIGURE 4-1. Selecting probe rod length

HydroSense
6
4.5 Measuring Volumetric Water Content
To measure volumetric water content fully insert probe rods and press READ.
The correct rod length must be selected so the HydroSense display unit applies
the correct calibration to convert the probe output to water content.
4.6 Measurements in Special Materials
The HydroSense was principally designed for use in agricultural soils, but the
technology underlying the instrument supports many potential applications.
Soils with characteristics as described in Section 6.2 and many other porous
media can also be monitored with HydroSense using the period value presented
in the display. The period is directly related to the dielectric permittivity of the
material surrounding the probe rods and can be used as a relative value to
monitor changes in the material of interest. As water content increases so does
period. If actual water content values are needed, a calibration can be
performed using an independent measurement of the water content. A
calibration equation can then be derived using curve fitting methods to relate
the independently measured water contents to the probe output periods.
5. Water Deficit Mode
5.1 Description of Water Deficit Mode
To use the Water Deficit Mode, a lower reference level and an upper reference
level must be chosen and a HydroSense reading taken at each level and stored
in memory (see Section 5.4 for calibration). Measurements taken after
reference levels are stored will display the relative water content and the
amount of water in millimeters which must be added to bring the water content
to the same value as the upper reference level. The relative water content is a
value between 0 and 100 with 0 corresponding to the lower reference level and
100 the upper level. Upper and lower reference levels can be stored in
HydroSense for up to 5 sites.
A typical application of the Water Deficit Mode is irrigation scheduling. The
lower reference level might correspond to the lowest water content that would
be allowed for a particular crop and the upper level the point where irrigation
would be ceased.
5.2 Display Information
The two-line display provides the following information
1) The relative water content (RWC)
2) Which site reference level is selected
3) The water deficit for 12 and 20 cm profiles

HydroSense
7
RWC 33 Site 1
Deficit mm 34 20
Relative
Water
Content
Site
Currently
Selected
Deficit
12 cm Probe Deficit
20 cm Probe
FIGURE 5-1. HydroSense display in Water Deficit Mode
5.3 Calibration—Setting the Lower and Upper Reference Levels
Lower and upper reference levels must be set to use the HydroSense in the
Water Deficit Mode. HydroSense measurements are used to set the reference
levels for a particular site. Once the reference levels are stored in the
HydroSense, further measurements provide a relative water content and a water
deficit value. The water deficit is the amount of water which must be added to
bring the soil water content to the upper reference level.
The water deficit calculation applies to a soil depth equal to the probe rod
length, i.e. 12 or 20 cm. Knowledge of the particular soil allows extrapolation
for other depths. For example, if the soil profile is known to be homogeneous
in the surface 30 cm, a water deficit calculation of 15 mm using 20 cm rods can
be multiplied by the ratio of extrapolated depth (30 cm) to rod length (20 cm)
to give a corrected deficit value of 22.5 mm .
Figure 5-2 presents the button sequence to set the lower (0) and upper (100)
reference levels for any of 5 separate sites. The 0 and 100 values are stored in
memory by taking a HydroSense measurement in the soil which is at a water
content corresponding to the desired 0 and 100 values.

HydroSense
8
WC 33 Site1
Deficit 34 20
MENU
SELECT
Site
Exit
MENU
SELECT
MENU
SELECT
READ
ENTER
Site
1
Site
2..5
READ
ENTER Cal
Exit
MENU
SELECT
Cal
0
Cal
100
MENU
SELECT
READ
ENTER
Press Select
until desired
Site is
selected
Press Enter
to select Site
Note: To enter reference values for a site, the site must be selected once to enter a
Cal 0 value and again to enter a Cal 100 value.
Press ENTER to store Cal 0 or Cal 100
readings or to exit the selection routine.
FIGURE 5-2. Selecting the site, lower (0) and upper (100) reference levels
When using the Water Deficit Mode, the same rod length
must be used for measurement as was used during
calibration of the reference levels.
5.4 A Water Deficit Mode Example
Consider an application where the HydroSense is used to help make irrigation
decisions for a crop. It is known that unacceptable plant stress occurs at water
contents less than 15% and excessive water drains from the plant root zone
when water content is greater than 30%. The 15% is chosen for the lower
reference level and the 30% for the upper reference level. The actual water
content values may be less important than the agronomist’s knowledge of soil
water conditions for a particular crop.
With the water content at the lower reference level, a measurement is taken
with the HydroSense after the site number is selected and while the CAL 0
CAUTION

HydroSense
9
prompt is displayed. With CAL 0 displayed, the probe rods are inserted and
the READ button is pressed. This stores the measured value in HydroSense
memory as the lower reference level for the chosen site.
After irrigating to the desired upper reference level, the HydroSense is set to
CAL 100 and a measurement taken by inserting the probe rods and pressing
READ. This value is stored as the upper reference level for the chosen site.
HydroSense is now calibrated for the chosen site.
0
20
40
60
80
100
10 15 20 25 30 35
volumetric water content (%)
relative water content
0
5
10
15
20
25
30
water deficit (mm)
relative water content water deficit
FIGURE 5-3. Relative water content and deficit for example application
Figure 5-3 presents the relationship between relative water content and water
deficit for the chosen reference levels. A measurement taken at this site when
water content is 20% would give a relative water content (RWC) value of
approximately 33% and a water deficit value of 20 mm. Adding 20 mm of
water would bring the water content to 30% for a soil depth equal to the probe
rod length.
6. Proper Measurement Technique and Method
Limitations
Detailed instructions for making measurements with HydroSense are given in
Sections 4 and 5 and are specific for the Water Deficit Mode and Water
Content Measurement Mode. The following information applies to
HydroSense measurements in general and provides operational information that
will optimize measurement quality.

HydroSense
10
6.1 Probe Rod Insertion
Making a measurement with HydroSense is a simple matter of inserting the
probe rods and pressing the READ button. However, the accuracy of the
measurement can be degraded if the rods are inserted incorrectly.
The rods must be completely inserted. If the probe rods are not fully inserted
and air instead of soil occupies the space around the rods, a portion of the
sensitive volume is not occupied by the medium intended to be measured and
error will result. Additionally, if the rods are inserted closer than 3 cm from a
material other than the soil being measured, e.g. the wall of a container, error
can result.
The most sensitive region for the measurement is that region immediately
adjacent to the rod surface. Sensitivity decreases with distance away from the
rod surface. It is important to push the probe so rods insert in a straight path
with minimum sideways motion to prevent establishing an air void around the
rod.
During insertion, contact of probe rods with consolidated material such as rock
can cause deflection and possibly bend the rods. Bent rods should be replaced
as soon as possible because continued bending can lead to breakage at the point
where the rod threads into the probe body making repair difficult. See Section
8.2 for replacement instructions. The 12 cm rods are less likely to bend than 20
cm rods.
If rods become loose in probe body threading, bending of
the rods near the thread is more likely than if the rods are
properly tightened. Please see maintenance Section 8.2.
6.2 Soil Factors Which Can Affect the Measurement—Clay, Soil
Electrical Conductivity, Organic Matter and Rocks
HydroSense is very sensitive to changes in dielectric permittivity and the probe
has water content measurement resolution better than 0.1%. While the
HydroSense is predominantly sensitive to dielectric permittivity (and
consequently volumetric water content), other physical properties of the soil
can affect the measurement. If the soil contains a large amount of clay or has
high electrical conductivity (EC), the applied signal can be attenuated and this
affects detection of the reflected signal in the probe electronics. Very high
organic matter content has a similar effect. HydroSense will still respond to
changes in water content but not the same as if the attenuation factors were
present in small, noninterfering amounts. The calibration coefficients used to
transform the probe output signal to water content or deficit reside in the
HydroSense operating system and were determined in laboratory studies on
typical soils. User determined coefficients can be applied to the probe output
period value that is displayed in the Water Content Measurement Mode.
Rocky soils can make rod insertion difficult (see Section 6.1) and introduce
variability in water content measurements taken in the same general area. The
rocks occupy space otherwise occupied by the fine soil fraction but do not hold
water in the same manner as soil. If two proximal measurements are made in a
CAUTION

HydroSense
11
rocky soil, the measured water content can differ by several percent if a large
rock occupies part of the sensitive volume of one measurement but not the
other.
6.3 Rod Length and Insertion Angle
Rods for the HydroSense probe are available in 12 and 20 cm length. There is
no significant difference in performance between rod lengths and the choice of
length depends on the application. Threaded inserts on the probe body allow
easy replacement of damaged rods (see Section 8.2) or use of different length
rods. Bent rods should be replaced immediately since unparallel rods can
introduce error and more bending can lead to breaking. Spare/ replacement
rods are available from Campbell Scientific. See Table 1 of Section 8.2.
Since the water content is averaged over the length of the rod, the reading from a
probe with 20 cm rods inserted vertically into the soil surface will be the average
value for the surface 20 cm of soil. Probe rods can be inserted at an angle. For
example, 20 cm rods inserted at a 30 degree angle to the surface will provide
average water content in the top 10 cm.
6.4 Interpreting Measurement Results
It is important to recognize some intrinsic soil properties and understand how
these properties affect water content distribution and the measurement of water
content. One such property is the spatial variability of the water content, i.e.,
the difference in actual water content in proximal locations which are
apparently similar. The water contents in two locations which are only tens of
centimeters apart can differ by several percent.
The scale of the measurement using a device such as the HydroSense must be
considered in relation to the scale of the field or plot being monitored. The
sensitive volume of the HydroSense measurement covers the length of the rods
and extends out radially from the rod surface about 3 cm. The shape is
approximately elliptical extended over the rod length. The total volume is
approximately 650 cubic centimeters for 12 cm rods and 1100 cubic
centimeters for 20 cm rods.
Soil is not necessarily a homogeneous medium on the scale of most soil water
content measurement methods. Soil features such as cracks, rocks, pore size
distribution, plant roots and texture layers are not always distributed evenly
throughout a measured profile. If the water content over a large area such as a
cropped field is to be determined, either a measurement method must be used
which is sensitive on a very large scale or several measurements can be taken
with a device such as the HydroSense and an average value used. See
Appendix B for a discussion of statistical methods that can be applied to
optimize measurement quality.
7. Description of HydroSense Measurement Method
The HydroSense uses the soil physical property dielectric permittivity to
estimate the volumetric water content. The dielectric permittivity of liquid
water is more than one order of magnitude greater than other soil constituents

HydroSense
12
making it possible to relate water content to measured dielectric permittivity.
Additionally, water and air are the only soil constituents that change with time.
The electronics embedded in the probe body generate the high frequency
electromagnetic energy necessary to polarize water molecules to the extent
needed to measure the dielectric permittivity. The travel time of
electromagnetic energy along a waveguide is dependent on the dielectric
permittivity. The probe rods act as a waveguide and the applied signal travels
to the end of the rods and reverses the direction of travel. Electronics
encapsulated in the probe head both generate the applied signal and sense the
return. The measurement reflects the average water content over the length of
the rods. The high frequency signals are transformed to a square wave output
with a frequency proportional to the water content. The HydroSense display
unit converts the output of the probe to a readout which gives information about
volumetric water content. The display output can be configured to display
volumetric water content or a deficit value derived from the present measured
value and reference levels previously determined.
The HydroSense is operated in the Water Content Measurement Mode or the
Water Deficit Mode. The mode is easily changed by holding down the
MENU button while pressing the READ button when the HydroSense is in the
sleep mode. The HydroSense automatically goes into sleep mode if either of
the buttons are not pressed for about 2 minutes. Pressing only the READ
button starts HydroSense in the last mode selected.
The Water Content Measurement Mode applies calibration coefficients to
the output of the probe to give volumetric water content in percent. The
calibration coefficients reside in the operating system and were determined by
the manufacturer. The amount of pore space in a typical soil is about 50%.
The pore space can be occupied by water in liquid or vapor phase or by air.
The other 50% of the soil is the solid portion. If the soil is saturated, that is, all
the pore space is filled with water, the water content is 50%. Volumetric water
content is defined as the volume of water per volume of soil.
In the Water Deficit Mode upper and lower reference measurement levels are
combined with the present measurement to provide relative water content
information and the amount of water that must be added to bring the water
content back to the upper reference value. Reference levels for up to 5 sites can
be stored in the HydroSense. Use of this mode requires the user take
measurements with the HydroSense when the soil is at the chosen upper and
lower reference levels and store the value. The reference levels might
correspond to the minimum desired water content for a crop and the water
content desired after irrigation. A value of 50 indicates the actual water content
is halfway between the reference levels and the value will be 100 after an
irrigation to the upper reference value.

HydroSense
13
8. Maintenance
8.1 Replacing Battery
FIGURE 8-1. Rear view of the HydroSense display unit with battery
cover removed
The only user-replaceable components in the HydroSense display unit are the
two 1.5 volt AAA batteries used to power the unit. Under normal use, battery
life should be well in excess of 1 year. When the batteries require replacement,
a small battery symbol will appear on the bottom right hand corner of the
display. It is recommended that high quality, long-life alkaline batteries be
used. To replace the batteries, remove the two silver screws from the back of
the HydroSense display, remove and replace the batteries, making sure that the
positive end of each battery is inserted into the end of the battery holder with
the RED polarizing washers. It is important that batteries are not reversed
during replacement as damage to the unit can occur. Do not remove the red
polarizing washers. Replace the cover plate and silver screws. Calibration
settings will NOT be lost when batteries are replaced.
8.2 Rod Installation/Replacement
Threaded inserts in the probe epoxy body allow user replacement of the 12 and
20 cm rods. Using rods of different length increases the versatility of
HydroSense. Additionally, if the probe rods are accidentally bent, simple
replacement using spare rods prevents instrument downtime.
The rods have a disc-shape collar at the base of the unthreaded portion of the
rod. This collar distributes lateral forces over a relatively large area and
reduces rod bending/deformation during probe rod insertion for measurements.
The rods must be fully inserted into the threaded inserts of the probe with the
collar in full contact with the probe body threaded inserts.

HydroSense
14
The friction between the rod collar and the insert surface along with thread
friction will generally provide good rod attachment and loosening is unlikely.
If rod loosening does occur, a thread coating compound can be used to enhance
friction. There are two thread compounds that laboratory testing indicates
minimal effect on the HydroSense measurement.
A package with Loctite222MS THREADLOCKER is included with each
CS620 probe. There is enough thread coating to treat several rods. The
compound should be used sparingly as a thick coating will cause slightly higher
measured water content values.
Another product that works well is Vibra-Tite by ND Industries. This
compound has a higher viscosity than most thread coatings and a narrow strip is
painted on the threads. The applied compound must cure aerobically before the
rods are threaded into the probe inserts. The cured compound is a resilient
plastic which is reusable several times. It is important that the rod threads are
not completely coated because this can affect response of the probe.
Replacement of the rods is a simple matter of screwing the threaded end of each
rod into the insert of the probe body with attention to the following details.
•Threads should be clean before rod attachment.
•After screwing the rods into the probe threaded inserts to finger tight, use
pliers to apply a small force and give a snug fit.
•Full contact between the rod collar and probe body is required for proper
operation.

A-1
Appendix A. Definition of Water
Content Terms
A.1 Definition of Water Content Terms
Soil water content is expressed on a gravimetric or volumetric basis.
Gravimetric water content (
θ
g) is the mass of water per mass of dry soil. It is
measured by weighing a soil sample (mwet), drying the sample to remove the
water, then weighing the dried soil (mdry).
θgwater
soil
wet dry
dry
m
mmm m
==
−
Volumetric water content ( θ
v) is the volume of liquid water per volume of soil.
Volume is the ratio of mass to density (
ρ ) which gives
θρ
ρ
θρ
ρ
vwater
soil
water
water
soil
soil
gsoil
water
volume
volume
m
m
===
∗.
Soil bulk density (
ρ
bulk) is used for
ρ
soil and is the ratio of soil dry mass to
sample volume. The density of water,
ρ
water, is close to 1 and is often ignored.
Another useful property, soil porosity, (
ε ) is related to soil bulk density as
shown by the following expression.
ερ
ρ
=−1bulk
solid
The term ρ
solid is the density of the soil solid fraction and is well approximated
by the value 2.6 g cm-3.
A simple data set is given here as an example. A sample of known volume was
weighed before and after oven drying at 105°C for 24 hours.
mwet 94 g
mdry 78 g
sample volume 60 cm3
θgwater
soil
m
m
==
−=−
94 78
78 0205 1
g g
g g g.
ρbulk dry
m
volume
===−
78
60 13
33
g
cm g cm.

Appendix A. Definition of Water Content Terms
A-2
θθρ
ρ
vgsoil
water
=∗=− 0267 33 . cm cm
ερ
ρ
=− =− =
−
−
11
13
26 050
3
3
bulk
solid
... g cm
g cm
The porosity of 0.50 defines the maximum possible volumetric water content.
The measured
θ
vvalue of 0.267 indicates the pore space is just over half-full of
water. If the sample is froma 20 cm depth profile, there are 5.3 cm of water in
the profile.
Water content indicates how much water is present in the soil. It can be used to
estimate the amount of stored water in a profile or how much irrigation is
required to reach a desired soil wetness.
