TW-411 Multi-Sport Watch
User Manual
WARNING
Use only USB chargers with 5V output that comply with the CE/FCC
standard. Using non-standard USB chargers will void the warranty.
82-410G-01010

[GPS Locating Tips]:
• Receive a GPS signal in an open space, and refer to
the following instructions.
• GPS receiver is located at the bottom of the watch. Do
NOT cover the receiver and face it towards the sky.
• The first positioning will take 2~5 minutes.
Subsequent positioning will take 1~2 minutes.
• If you are unable to complete GPS positioning, press ②
to exit. Move to an open space and try again.
Open Space
Correct
Building Nearby
Cover GPS Receiver
In car
In houseUnder eaves
Wrong
1.

1. Device Overview
①③
④
②⑤
①Power and Backlight
Hold to turn the device on/off.
Press to turn the backlight on/off.
②Back/Lap
Press to return to the previous page or step.
Switch time display mode.
③Up
Press to scroll up the menus.
④OK and Enter
Press to accept an entry or to move forward on a menu.
⑤Down
Press to scroll down the menus.
2.

2. Starting with the Watch
At first time use, or after factory reset, or after software update, please
choose language and set time. You can set the time by manual or by GPS.
please refer to [GPS Locating Tips] on Page 1.
If you choose to set time by GPS
1. At first time use, please charge the device more than 2
hours in advance.
2. If the watch battery runs out, time will need to be reset.
NOTE
4. Watch Menus
1. Press ④to enter main menu.
2. Press ③/⑤to scroll up/down the menu.
3. Choose a selected function and press ④to enter.
GOLF TOOLS SETTINGS
3. Time Mode
Under the Time Mode, press
②to switch Time display
interface.
22
WED
②
3.

5. Watch Settings
Press ④to enter main menu. Use ③/⑤to scroll to [SETTINGS].
Once in [SETTINGS], you will find the following options:
[Language] : Select your preferred language.
[Clock] : Set time, toggle between 12-hour and 24-hour mode, and
Daylight Saving <1>.
[Backlight] : Set the duration for the back light to remain on.
[Alert] : Select either Sound, Light or Vibrate for your alert mode.
[Unit] : Toggle between imperial/metric units.
[Geolocation]: Set the format of GPS coordinate.
[SmartBand]: Turn on or off the Smartband.
[Orientation]: Choose to rotate the watch screen (180° or no rotate).
[Key lock] : Lock the watch buttons <2>.
[Factory Reset] : Reset the watch to factory settings.
[About Watch] : Check the Watch firmware and course version.
<1> When Daylight Saving is on, the time will be adjusted one hour head.
<2> To unlock Key Lock, press ②+④, and release them together.
4.

6. Fitness Calculators
Under the Time Mode, press ③/⑤to browse the step walked,
distance, and calories burned. Press ④under each mode, you can
set daily targets and set the achievement alarm.
•The Fitness calculator will be reset at 00:00am daily.
•To reset manually, please enter [Tools] → [Pedometer].
55555
55555
STEPS
TODAY
50.03
50.03
Km
TODAY
5555
5555
Kcal
TODAY
To set or view Alarm, Compass, Pedometer, Bubble Level, Timer or
view your Geolocation.
7. TOOLS
8. Troubleshooting
If any errors or malfunctions occur, use
factory reset. If that does not work try
hardware reset.
Press ④+⑤together, and then press
①. Release three buttons at same time.
①
④
⑤
5.

9. Golf Mode
1. Press ④to enter main menu.
2. Select [GOLF], and press ④to enter.
3. Select [Play Golf], and press ④to enter.
4. Satellites will be located automatically<3>, and a list of golf courses will be
shown by proximity.
5. Press ③/⑤to scroll up/down, and press ④to enter a selected golf course.
<3> Refer to [GPS Location Tips] on Page 1.
9-1 Play Golf
Course List
Campass
Pantai_Mentiri
Airport_Course
Empire_Hotel
ScordCard
Score History
Demo
Play Golf
GOLF
Locating GPS 186
173
160
12:34
PAR
12
4
B
C
F
When playing golf, you will notice that there are five metrics displayed on the
screen. The list below explains what each of those pieces of information
represents.
9-2 On The Course
Current hole number.
PAR for the hole.
Distance to the back of green.
Distance to the center of green.
Distance to the front of green.
186
173
160
12:34
PAR
12
4
B
C
F
(The default unit is Yard. To switch the display unit, please refer to 8. Watch settings)
6.

123Yar d
Hold ③for three seconds to access Shot Distance.
Travel to your ball, and the distance will be calculated. To
exit, press ②.
12:34
PAR 418
Save & Exit
Discard & Exit
Cancel
To finish the round, press ②. Press ③/⑤to choose
whether save the record, and then press ④to confirm.
•Press ③/⑤to go to previous/next hole.
• Auto Hole: The auto hole will trigger after the following conditions are
met: Approach to within 30 yards of the center of the
green, and then move at least 30 yards away from the
center of the green.
• Dual Green: If the course has dual greens, hold ④for three
seconds to switch right/left green distance.
12:34
PAR 418
299 - 305
298 - 306
Hold ⑤for three seconds to access the Hazard screen,
then press ③/⑤to scroll up/down to see all Hazards. To
exit, press ②.
Total 7 +4
PAR 418
Score 7
GIR N
Putt --
Press ④to enter score card, and then use ③/⑤to enter
your score. To save and exit, press ④.
While in GOLF mode. Follow below instructions to access
Scorecard, Shot Distance, Hazard or Save this record.
7.

10. Charge the Watch
1. Attach the magnetic charger on the charging contact located at the bottom
of the watch. Be sure the pins are aligned. Keep the watch on a stable
surface while charging.
2. Insert the USB end of the charging cord into a computer USB port or CE/FCC
certified 5V output USB charger (exceeding 5V will void the warranty).
Battery/ Charging Information
Battery Specifications: 3.7V / 400mAh
Charging Specifications: 5V / 500mA
Clean the charging contact port frequently
to ensure the charging efficiency.
AVOID touching the magnetic end of the charging cable with metallic objects
to prevent short circuits and damage to the cable.
For safety reasons, after the watch is fully charged, disconnect the charging
cable from USB power source.
CAUTION
1. Press ④to enter main menu.
2. Press ④to enter [Golf].
3. Press ④to select [Score History].
4. Press ③/⑤to select a history record,
and press ④to enter.
5. To return, press ②.
9-3 Golf Score History
Score History
Putts 0
GIR 0
Score 18 PAR 36
1 - 9
10 - 18
1 - 18
Score History
2018.01.15
2018.01.10
2018.01.03
2018.01.01
Score 1 - 18
S
0
0
0
0
0
P
4
3
4
4
3
H
1
2
3
4
5
ScordCard
Score History
Demo
Play Golf
GOLF
8.

11. Limited Warranty
The products are warranted to be free from defects in materials or
workmanship for 12 Months from the date of purchase. Within the
period, the manufacture will, at its sole option, repair or replace any
components that fail in normal use. Such repairs or replacement will
be made at no charge to the customer for parts or labor. The
customer shall be responsible for any transportation cost.
The limited warranty does not apply to
1.
2.
3.
4.
5.
Cosmetic damage, such as scratches, nicks and dents.
Consumable parts, such as batteries, watch band/ bunkle, clip,
iron, charging cable…etc. unless product damage has occurred
due to the defect in materials or workmanship.
Damage to a product that has been fallen accidentally, modified or
altered without written permission of the manufacturer.
Damage to a product that has been connected to a non-CE/FCC
certified 5V power supply.
Damage caused by failure to observe the safety instruction.
The manufacture reserves the right to refuse warranty claims against
products or services that are obtained or used in contravention of the
laws of any country. The device is intended to be used only as a
sport or leisure aid and must not be used for any purpose requiring
precise measurement of direction, distance, and location.
9.

The manufacture makes no warranty to the accuracy or complete-
ness of the course data.
To obtain warranty service, an original or copy of the sales receipt
from the retailer is required. Securely pack the device and a copy of
the original sales receipt. Send the device, freight charges prepaid.
12. Safety Instructions
Failure to heed the following warnings could result in an accident or
medical event resulting in death or serious injury.
1. There is a built-in Li-polymer battery inside. Do not expose the
device to fire, explosion, or other hazard.
2. Do not leave the device exposed to a heat source or in a
high-temperature location, such as in the sun or in an unattended
vehicle. To prevent the possibility of damage, remove the device
from the vehicle or store it out of direct sunlight.
3. Do not operate the device outside of the temperature lower than
0 or over 45 degrees Celsius (from 32º to 113ºF).
4. AVOID touching the magnetic end of the charging cable with
metallic objects to prevent short circuits and damage to the cable.
For safety reasons, after the watch is fully charged, disconnect the
charging cable from USB power source.
5. Do not disassemble, modify, remanufacture, drop, or puncture with
forces.
10.

13. Contact Us
For further information, for golf course update,
firmware renew, or any other support, please visit
http://www.canmore-sport.com/
The content are subject to change without notice.
For latest user manual, please visit our website.
11.
6. Do not remove or attempt to remove the non-user replaceable
battery.
7. Do not use while driving or be in any situations or environments
require concentration.
8. The device trackers reply on sensors that track your movement
and other metrics. The data provided by the device is intended to
be a close estimation of your activity, but may not be completely
accurate.
9. Contact your local waste disposal department to dispose the
device in accordance with applicable local laws and regulations.
