Canon PIXMA MP210 Series User manual

Quick Start Guide
Kurzanleitung
Guide de démarrage rapide
Aan de Slag-gids
QT5-1213-V01 XXXXXXXX © CANON INC. 2007 PRINTED IN VIETNAM
The following FINE Cartridges are compatible with this product.
Die nachstehend aufgeführten FINE-Tintenpatronen (FINE Cartridges) sind mit diesem
Produkt kompatibel.
Les cartouches FINE (FINE Cartridges) suivantes sont compatibles avec ce produit.
De volgende inktpatronen FINE (FINE Cartridges) zijn compatibel met dit product.
QT51213V01
www.canon-europe.com
DEUTSCHFRANÇAIS
NEDERLANDS
ENGLISH
Quick Start Guide

Regulatory Information
FCC Notice (U.S.A. Only)
For 120V, 60Hz model
Model Number: K10308
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is con-
nected.
Consult the dealer or an experienced radio/TV technician for help.
Use of a shielded cable is required to comply with Class B limits in Subpart B of Part 15 of the FCC
Rules.
Do not make any changes or modifications to the equipment unless otherwise specified in the
manual. If such changes or modifications should be made, you could be required to stop operation of
the equipment.
Canon U.S.A., Inc.
One Canon Plaza
Lake Success, NY 11042
1-516-328-5600
Sicherheitsvorkehrungen
Lesen Sie die in diesem Handbuch aufgeführten Warnungen und Vorsichtsmaßnahmen sorgfältig durch,
um sicherzustellen, dass Sie den Drucker auf eine sichere Art und Weise verwenden. Setzen Sie
den Drucker nicht auf eine Weise ein, die nicht in diesem Handbuch beschrieben ist.
Weitere Sicherheitsvorkehrungen finden Sie im Benutzerhandbuch.
Warnung
Die Nichtbeachtung der Sicherheitsvorkehrungen kann einen Stromschlag oder Brand auslösen bzw. den
Drucker beschädigen.
Vorsicht
Die Nichtbeachtung dieser Sicherheitsvorkehrungen kann zu Verletzungen oder Schäden
am Drucker führen.
Maschinenlärminformations-Verordnung 3. GPSGV:
Der höchste Schalldruckpegel beträgt 70 dB(A) oder weniger gemäß EN ISO 7779.
Canon Europa N.V., Bovenkerkerweg 59-61, 1185 XB Amstelveen, The Netherlands
Stecken Sie den Netzstecker des Druckers nicht mit nassen Händen in die Steckdose, und ziehen Sie
den Netzstecker nicht mit nassen Händen aus der Steckdose.
Stecken Sie den Stecker immer vollständig in die Steckdose.
Das Netzkabel darf nicht beschädigt, verändert, gedehnt oder übermäßig gebogen
bzw. verdreht werden. Stellen Sie keine schweren Gegenstände auf das Netzkabel.
Schließen Sie den Drucker nicht gemeinsam mit anderen Geräten
(Verlängerungskabel, Mehrfachsteckdose usw.) an eine Steckdose an.
Verwenden Sie den Drucker nicht mit zusammengebundenem Netzkabel.
Wenn Rauch, ungewöhnliche Gerüche oder Geräusche aus dem Drucker dringen, ziehen Sie
umgehend das Netzkabel des Druckers aus der Steckdose, und wenden Sie sich an den Kundendienst.
Ziehen Sie regelmäßig den Netzstecker des Druckers aus der Steckdose, und
wischen Sie mit einem trockenen Tuch Staub- und Schmutzpartikel ab, die sich
an Stecker und Steckdose abgelagert haben. Wenn der Drucker an einem Ort
aufgestellt ist, der Staub, Rauch oder hoher Luftfeuchtigkeit ausgesetzt ist, kann der
Staub auf dem Stecker Feuchtigkeit aufnehmen und zu Isolationsdefekten und
Bränden führen.
Verwenden Sie das im Lieferumfang des Geräts enthaltene Netzkabel.
Achten Sie darauf, dass der Bereich um die Steckdose jederzeit zugänglich ist,
damit Sie das Netzkabel bei Bedarf problemlos herausziehen können.
Ziehen Sie den Stecker niemals am Kabel heraus.
Verwenden Sie kein Verlängerungskabel.

ENGLISH
Quick Start Guide
Table of Contents
Introduction 1
How to Use the Documentation Provided 3
Preparing the Machine 4
Installing the MP Drivers 6
Reading the On-screen Manuals 8
Loading Paper 9
Operation Panel 10
Copying 11
Printing from Your Computer 12
Scanning Images 14
Printing Photographs Directly from a Compliant Device 15
Replacing a FINE Cartridge 20
Specifications 22

ENGLISH
European Union (and EEA) only.
This symbol indicates that this product is not to be disposed of with your
household waste, according to the WEEE Directive (2002/96/EC) and your
national law. This product should be handed over to a designated collection point,
e.g., on an authorized one-for-one basis when you buy a new similar product or to
an authorized collection site for recycling waste electrical and electronic
equipment (EEE). Improper handling of this type of waste could have a possible
negative impact on the environment and human health due to potentially
hazardous substances that are generally associated with EEE. At the same time,
your cooperation in the correct disposal of this product will contribute to the
effective usage of natural resources. For more information about where you can
drop off your waste equipment for recycling, please contact your local city office,
waste authority, approved WEEE scheme or your household waste disposal
service.
For more information regarding return and recycling of WEEE products, please
visit www.canon-europe.com/environment.
(EEA: Norway, Iceland and Liechtenstein)
For Customers in Europe, Middle-East, Africa and
Russia only
For Canon Customer Support contacts, please see the back cover of the European Warranty
Systems (EWS) Booklet or visit www.canon-europe.com.
Model Number: K10308 (MP210)

1Introduction
ENGLISH
Introduction
This Quick Start Guide uses the following symbols to indicate important information. Always observe
the instructions indicated by these symbols.
Warning
Instructions that, if ignored, could result in death or serious personal injury caused by incorrect
operation of the equipment. These must be observed for safe operation.
Caution
Instructions that, if ignored, could result in personal injury or material damage caused by incorrect
operation of the equipment. These must be observed for safe operation.
Important
Instructions that must be observed for safe operation.
Trademark Notices
z“Microsoft” is a registered trademark of Microsoft Corporation.
z“Windows” is a trademark of Microsoft Corporation, registered in the U.S. and other countries.
z“Windows Vista” is a trademark of Microsoft Corporation.
z“Macintosh” and “Mac” are trademarks of Apple Inc., registered in the U.S. and other countries.
© CANON INC. 2007
All rights reserved. No part of this publication may be transmitted or copied in any form
whatsoever without the express written permission.

2Introduction
ENGLISH
Exif Print
This machine supports ExifPrint.
Exif Print is a standard for enhancing the communication between digital cameras and
printers. By connecting to an Exif Print-compliant digital camera, the camera’s image
data at the time of shooting is used and optimized, yielding extremely high quality
prints.
International ENERGY STAR®Program
As an ENERGY STAR®Partner, Canon Inc. has determined that this
product meets the ENERGY STAR®guidelines for energy efficiency.
Power Requirements
Never use a power supply voltage other than that supplied in the country of purchase.
Using the incorrect voltage could cause a fire or electric shock. The correct power
supply voltages and frequencies are as follows:
AC 100-240V, 50/60Hz
About Consumables
Consumables (ink tanks / FINE Cartridges) are available for 5 years after production
has stopped.
Safety Precautions
.
Warning
zNever attempt to plug the power cord into the power outlet or unplug the power cord when your hands
are wet.
zNever damage, modify, stretch, or excessively bend or twist the power cord. Do not place heavy objects
on the power cord.
zNever use any power supply other than the standard power supply available in the country of purchase.
Using the incorrect voltage and frequency could cause a fire or electric shock.
zAlways push the plug all the way into the power outlet.
Caution
zFor safety reasons, store FINE Cartridges out of the reach of small children.
zDo not drop or shake FINE Cartridges as this may cause the ink to leak out and stain your clothes and
hands.
Also read the Safety Precautions in the User’s Guide on-screen manual. Observe the warnings
and cautions to avoid personal injury or damage to the machine.

3How to Use the Documentation Provided
ENGLISH
How to Use the Documentation Provided
Printed Documentation
Setup Sheet
Be sure to read this sheet first.
This sheet includes instructions for setting up your machine and getting it ready
for use.
Quick Start Guide (This guide)
Read this guide when starting to use the machine.
After following instructions in your setup sheet, we recommend you read this
guide to familiarize yourself with the basic operation of some of the main
functions that can be performed on your machine.
On-screen Manuals
User’s Guide
Read this guide when starting to use the machine.
If the Quick Start Guide does not provide you enough information please refer to
the User’s Guide which can be installed from the Setup CD-ROM. This guide
provides detailed instructions for:
zcopying
zprinting from your computer
zscanning
Additional guides are also available for advanced features.
Scanning Guide
Refer to this guide for full instructions on scanning operation and settings.
PC Printing Guide
Refer to this guide for full instructions on printer driver setting.
PC Photo Printing Guide
Refer to this guide for instructions on using the various application software
included on the Setup CD-ROM.

4Preparing the Machine
ENGLISH
Preparing the Machine
Be sure to read your setup sheet first for setting up your machine and getting it ready for use.
The diagrams and computer screens in your setup sheet refer to the MP220 series.The operations
are exactly the same as those for the MP210 series, unless otherwise described.
Unpack the machine
Please confirm the included items against the illustration printed on the lid of the packing box.
1Turn on the machine.
2Prepare the FINE Cartridges.
Important
A USB cable is necessary to connect the machine with your computer.
Caution
Be sure to remove the tapes and protective material before you turn on the machine.
Note
The tape or the protective material position is subject to change.
Caution
zDo not touch internal parts other than the FINE Cartridge Holder.
zDo not drop or shake FINE Cartridges as this may cause the ink to leak out and stain your
clothes and hands.
Important
zIf the Scanning Unit (Printer Cover) is left open for more than 10 minutes, the FINE Cartridge
Holder moves to the right side. Close and reopen the Scanning Unit (Printer Cover) to return the
holder to the left.
zDo not touch the electrical contacts or Print Head Nozzles on a FINE Cartridge. The machine
may not print out properly if you touch it.
zDo not reattach the protective tape once it has been removed.
zHandle the removed protective tape carefully to avoid getting your hands dirty or staining
surrounding work area.

5Preparing the Machine
ENGLISH
3Install the FINE Cartridges.
Be sure to use the machine with both Black and Color FINE Cartridges.
Otherwise, the machine cannot print. When either of ink runs out while printing, you can
select to use either Color or Black ink as a printer driver setting. However you must use the
machine with both Black and Color FINE Cartridges installed regardless of the printer driver
setting.
Important
zMake sure that all the FINE Cartridges are installed in the correct position. The machine cannot
be used unless all the FINE Cartridges are installed.
zOnce you have installed the FINE Cartridges, the LED will flash green. Wait until the LED stops
flashing and displays 1. It takes about one to two minutes.
Note
An error code will be displayed on the LED if a FINE Cartridge is not installed properly. Open the
Scanning Unit (Printer Cover) and make sure that position of all the FINE Cartridges is appropriate.

6Installing the MP Drivers
ENGLISH
Installing the MP Drivers
Information Common to Windows®and Macintosh®
Notes on the Installation Process
zIf the Select Language screen appears, select a language, then click Next.
zIf the Select Your Place of Residence screen appears, select your place of residence, then
click Next.
zThere are two ways of installing the MP Drivers and other software*:
Easy Install: the items included on the Setup CD-ROM are installed automatically
Custom Install: you can select particular items to install
* The available software programs included on the Setup CD-ROM may vary depending on
the country or region of purchase.
zWhen the User Registration screen appears, click Next. If your computer is connected to the
Internet, the on-screen instructions to register your product will appear.
Registration can also be performed from the icon on the desktop after installation is completed.
Notes on the Print Head Alignment
zIf the straight line is misaligned or print quality is not satisfactory after installing the MP
Drivers, you may need to align the Print Head. Refer to “Aligning Print Head on the Machine”
in the User’s Guide on-screen manual.
Information for Windows
zLog into a user account with the administrator privilege.
zBefore installing the MP Drivers, disable all anti-virus programs and automatically loading
programs.
zIf the Found New Hardware or Found New
Hardware Wizard screen appears automatically,
remove the USB cable connected to your
computer. Click Cancel to quit the screen. In
Windows Vista™ operating system (hereafter
referred to as “Windows Vista”), the screen may
close automatically when the USB cable is
unplugged. Then turn off the machine and start the
installation process again. For details on the
installation process, refer to your setup sheet.
zIf the AutoPlay screen appears, click Run
Msetup4.exe. In Windows XP and Windows 2000,
this screen will not appear.
zIf the User Account Control screen appears, click Continue. In Windows XP and Windows
2000, this screen will not appear.
zA message asking for your confirmation to restart your computer may appear during the
installation process. If this message is displayed, follow the on-screen instructions and click OK.
The installation resumes from where it left off when your computer has been restarted.
zWe would appreciate it if you would take part in the PIXMA Extended Survey Program
regarding the use of Canon printers. For details, refer to the on-screen instructions.
zIf the connection is not recognized, refer to “Cannot Install the MP Drivers” in the User’s
Guide on-screen manual.
Users in Asia
zScan Soft OmniPage SE can be installed only on an English operating system.

7Installing the MP Drivers
ENGLISH
Information for Macintosh
zSince Mac®OS 9, Mac OS X Classic environments, or Mac OS X v.10.2.7 or earlier are not
supported, do not connect the machine to these.
zDo not remove or insert the USB cable during installation, as this may result in the computer
or machine not operating normally.
zBefore installing the MP Drivers, disable all anti-virus programs and automatically loading
programs or remove them from your system folder.
When using Mac OS X v.10.2.8 to v.10.3.x:
zBefore using the Operation Panel on the machine to save originals scanned from the Platen
Glass to the computer, it is necessary to select MP Navigator EX 1.0 or MP Navigator EX 1
as the launch application on Image Capture under Applications. For details, refer to
“Scanning Images” in the User’s Guide on-screen manual.
When using Mac OS X v.10.2.8 to v.10.3.3:
zRestarting the computer while connected to the machine may cause the machine not to be
detected. To resolve this, either unplug the USB cable then plug it back in again, or turn the
machine off then back on again.
Users in Asia
zTo install the User’s Guide on-screen manual in a language other than the installed one,
double-click the Manual folder in the Setup CD-ROM, Canon folder, and then copy a
language folder to your hard disk.

8Reading the On-screen Manuals
ENGLISH
Reading the On-screen Manuals
For detailed instructions on installing the on-screen manuals, refer to your setup sheet.
You can view the on-screen manuals in the following way:
To view the on-screen manual, double-click the XXX On-screen Manual shortcut icon on the
desktop, or click Start > All Programs (or Programs) > Canon XXX Manual > XXX On-screen
Manual (where “XXX” is your machine’s name).
System Requirements
Browser: Windows HTML Help Viewer
To view the on-screen manual, double-click the XXX On-screen Manual alias (where “XXX” is your
machine’s name) on the desktop.
System Requirements
Browser: Help Viewer
Note
zMicrosoft®Internet Explorer 5.0 or later must be installed.
zThe on-screen manual may not be displayed properly depending on your operating system or
Internet Explorer version. We recommend that you keep your system up to date with Windows
Update.
Note
Users in Asia
If you installed the User’s Guide from the Manual folder in the Setup CD-ROM, open the folder in which
you copied the User’s Guide and double-click top.htm.
Note
zThe on-screen manual may not be displayed properly depending on your operating system. We
recommend that you keep your system up to date.
zWe recommend using Safari as your Web browser to view the HTML format on-screen
manuals. If Safari is not installed on your computer, download it from Apple Inc. website and
install it.

9Loading Paper
ENGLISH
Loading Paper
1Open the Paper Support, then pull out the
Paper Support Extension.
2Open the Paper Output Tray.
3Open the Output Tray Extension.
4Adjust the position of the Paper Thickness
Lever.
Set it to the right when printing on envelopes or
T-shirt transfers, and left when printing on any
other type of paper. Refer to “Compatible Media
Types” in the User’s Guide on-screen manual.
5Load the paper in the Rear Tray with the print
side facing UP.
Do not load higher than the Load Limit Mark (A).
6Align the paper stack against the right side of
the Rear Tray.
7Pinch the Paper Guide and slide it against the
left side of the paper stack.
Important
zIf you cut plain paper to 4" x 6" / 101.6 x 152.4 mm, 5" x 7" / 127.0 x 177.8 mm, or 2.13" x 3.39" / 54.0 x
86.0 mm (credit card-size) for a trial print, it can cause paper jams.
zAlways load paper in portrait orientation. Loading paper in landscape orientation can cause the paper
to be jammed.
2
1
3
4
5
(A)
6
7

10 Operation Panel
ENGLISH
Operation Panel
(1) ON/OFF button / Power lamp
Turns the machine on and off. Lights or flashes green to
indicate the power status. Before turning on the
machine, make sure the Document Cover is closed.
(2) LED (Light Emitting Diode)
Displays the number of copies, Maintenance menu
selections or the operational status.
(3) [+] button
Increases the number of copies.
(4) Alarm lamp
Lights or flashes orange when an error, such as paper-
out or ink-out, occurs.
(5) Black/Color Ink lamps
Lights or flashes to show the ink status.
(6) SCAN button
Opens the MP Navigator EX to scan a document to your
computer according to the settings selected. To use this
button, the machine must be connected to a computer.
For details, refer to the Scanning Guide on-screen
manual.
(7) Stop/Reset button
Cancels operations or a print job in progress.
(8) Color button*
Starts color copying. Also, finalizes your selection for the menu or setting item.
(9) Black button*
Starts black & white copying. Also, finalizes your selection for the menu or setting item.
(10) (Maintenance) button
Accesses the Maintenance menu.
(11) Fit to Page button / Fit-to-Page lamp
Enables/disables the Fit-to-Page copying. Lights when Fit-to-Page copying is enabled.
(12) Paper button
Switches the page size and media type for copying.
For information on how to switch the page size between A4 and Letter, refer to “Setting
The Default Page Size” in “Changing the Copy Settings” of the User’s Guide on-screen
manual.
(13) Paper lamp
Displays the selected page size and media type for copying.
* In the software applications or manuals, the Black and Color buttons are collectively called
the “Start” or “OK” button.
(1) (2)
(3)
(4)
(5)
(6)
(7)
(8)(9)
(10)
(11)
(12)
(13)

11Copying
ENGLISH
Copying
Making Copies
This section describes the basic procedure to make copies.
1Turn on the machine.
2Load paper.
3Load the original on the Platen Glass.
4Specify the copy settings.
(1) Press the +button repeatedly to specify the number of copies (max. 20 copies).
(2) Press the Paper button repeatedly to specify the page size and media type.
The Paper lamp indicates the selected page size and media type.
A4 or Letter Plain Paper / A4 or Letter Photo Paper / 4" x 6" Photo Paper
5Press the Color button for color copying, or the Black button for black & white
copying.
Using Useful Copy Function
For details, refer to “Fit-to-Page Copying (MP210 series)” in “Making Copies” of the User’s Guide on-
screen manual.
Note
By pressing the +button repeatedly, Fwill be displayed on the LED.The number of copies will
be set as 20.
Fit-to-Page Copying

12 Printing from Your Computer
ENGLISH
Printing from Your Computer
This section describes procedure for basic printing.
Printing with Windows
1Turn on the machine and load the paper in the machine.
2Create a document or open a file to print using an appropriate application software.
3Select Print on the application software’s File
menu.
4Make sure that Canon XXX Printer (where
“XXX” is your machine’s name) is selected in
Select Printer, and click Preferences (or
Properties).
5Specify the required settings and click OK.
6Click Print (or OK).
Note
Depending on your application program, operations may differ. For details, refer to the instruction manual
of your application.
The steps described in this section are for printing in Windows Vista.
Note
For details on the printer driver functions, click Help or
Instructions to view the online help or the PC Printing
Guide on-screen manual. Instructions is only
displayed when the on-screen manuals are installed.

13Printing from Your Computer
ENGLISH
Printing with Macintosh
1Turn on the machine and load the paper in the machine.
2Create a document or open a file to print using an appropriate application software.
3Select Page Setup on the application
software’s File menu.
4Make sure that your machine’s name is
selected in Format for.
5Select the page size of the loaded paper in
Paper Size.
6Click OK.
7Select Print on the application software’s File
menu.
8Select Quality & Media in the pop-up menu.
9Specify the required settings.
10 Click Print.
Note
Depending on your application program, operations may differ. For details, refer to the instruction manual
of your application.
The steps described in this section are for printing in Mac OS X v.10.4.x.
Note
For details on the printer driver functions, click to
view the PC Printing Guide on-screen manual. If the
on-screen manuals are not installed, the PC Printing
Guide on-screen manual is not displayed even if is
clicked.

14 Scanning Images
ENGLISH
Scanning Images
You can scan images from the machine to a computer without printing them and save them in
popular image types such as JPEG, TIFF, bitmaps, or PDF. If you are scanning printed text, you can
use the OCR (Optical Character Recognition) software to convert it to text data.
Scanning Methods
You can select from the various scanning methods.
zIf You Want to Edit or Print the Scanned Images
MP Navigator EX enables you to edit the scanned images, such as optimizing or trimming.
You can also start application software from MP Navigator EX to edit or print the scanned
images.
For detailed operations of MP Navigator EX, refer to the Scanning Guide on-screen manual.
You can also use the Operation Panel to open MP Navigator EX as well as open it using the
computer.
See “Opening MP Navigator EX using the Operation Panel” on page 14.
zIf You Want to Scan Originals with Advanced Settings
ScanGear enables you to scan originals with advanced settings such as the resolution.
For detailed operations of ScanGear, refer to the Scanning Guide on-screen manual.
Besides the above-mentioned methods, you can use a TWAIN- or WIA- (Windows Vista and
Windows XP only) compliant application software and the Control Panel (Windows Vista and
Windows XP only) to scan originals with this machine. For detailed operations, refer to the Scanning
Guide on-screen manual.
Opening MP Navigator EX using the Operation Panel
1Turn on the machine.
2Load the original document on the Platen Glass.
3Press the SCAN button.

15Printing Photographs Directly from a Compliant Device
ENGLISH
Printing Photographs Directly from a
Compliant Device
You can connect a PictBridge compliant device such as a digital camera, camcorder, or mobile
phone using a USB cable recommended by the device’s manufacturer, and print recorded images
directly without using a computer.
zConnectable Devices
PictBridge is an industry standard enabling a range of digital photo solutions, including the direct
printing of photos from a digital still camera, camcorder or mobile phone* without the need to use
a computer. A device can be connected to this machine for direct printing regardless of the
manufacturer or the model as long as it complies with the PictBridge standard.
* PictBridge compliant digital still cameras, digital camcorders, and camera-equipped mobile
phones are hereafter collectively referred to as “PictBridge compliant device”.
A device with this mark is PictBridge compliant.
zPrintable Image Data Format
This machine prints images taken with a DCF (Design rule for Camera File system) ver. 1.0/2.0-
compatible digital camera (Exif ver. 2.2/2.21 compliant), as well as PNG files.
Printing Photographs Directly from a Compliant
Device
To connect a PictBridge compliant device to this machine, use a USB cable recommended by the
device’s manufacturer.
1Prepare for printing.
(1) Turn on the machine.
(2) Load paper.
Caution
Do not connect any equipment other than PictBridge compliant devices to the Direct Print Port of the
machine. If you do so, electric shock, fire, or damage to the machine could result.
Important
Never disconnect the USB cable during printing unless when explicitly allowed to by the PictBridge
compliant device. When disconnecting the USB cable between the PictBridge compliant device and
machine, follow the instructions given in the device’s instruction manual.
Note
When printing photos with the PictBridge compliant device connected to the machine, we recommend the
use of the AC adapter supplied with the device. If you are using the device battery, be sure to charge it
fully.

16 Printing Photographs Directly from a Compliant Device
ENGLISH
2Connect the PictBridge compliant device to the machine.
(1) Make sure that the PictBridge compliant device
is turned off.
(2) Connect the PictBridge compliant device to the
machine using a USB cable recommended by
the manufacturer of the device.
The device turns on automatically.
If your device does not turn on automatically,
turn it on manually.
(3) Set up the PictBridge compliant device for
direct printing.
will appear on the LCD of the device when
the machine is correctly connected.
3Specify the print settings such as paper type and layout.
See “About PictBridge Print Settings” on page 17.
You can make settings using the menu on the LCD of your PictBridge compliant device.
Select the size and type of paper that you loaded in the machine.
If your PictBridge compliant device does not have setting menu, change the setting from the
machine. For details, see “Setting on the Machine” on page 19.
4Start printing from your PictBridge compliant device.
Note
Depending on the model or brand of your device, you may have to select a print mode compliant
with PictBridge before connecting the device. You may also have to turn on the device or select
Play mode manually after connecting the device to the machine.
Perform necessary operations on the PictBridge compliant device before connecting it to this
machine according to instructions given in the device’s instruction manual.
(2)
