Canon PIXMA MP620 series User manual

Make sure to read this manual before using the machine. Please keep it in hand for future reference.
MP620
Getting Started
=Read Me First=
series
Photo All-In-One

Symbols■
The following symbols are used to mark important instructions. Observe these instructions.
Instructions that, if ignored, could result in personal injury or material damage.
Instructions that must be observed for safe operation.
Additional explanations.
Descriptions for operations that take some time to complete.
Model Number: K10325(MP620)
Microsoft is a registered trademark of Microsoft Corporation.
Windows is a trademark or registered trademark of Microsoft Corporation in the U.S. and/or other countries.
Windows Vista is a trademark or registered trademark of Microsoft Corporation in the U.S. and/or other countries.
Macintosh, Mac, and AirPort are trademarks of Apple Inc., registered in the U.S. and other countries.
Wi-Fi is a registered trademark of the Wi-Fi Alliance.
The Wi-Fi CERTIFIED logo is a certication mark of the Wi-Fi Alliance.
•
•
•
•
•

1
Contents
Check the Included Items
Turn the Power On
Install the Print Head
Install the Ink Tanks
Setup the Machine and the Computer
Loading Paper
Conrming the Setup Flow
After Installing the Machine

2
(A)
1
Manuals
Setup CD-ROM (containing the drivers, applications and on-screen manuals)
Warranty
•
•
•
Check the Included Items
Before turning on the machine, remove all the orange tapes and the protective sheets.•
Open the Paper Output Tray with your hands, and take out the Print Head.
The Print Head is placed inside of the Paper Output Tray (A).
ink tank
Print Head
power cord USB cable
The USB cable is used during the
network setup procedure.

3
(A)
(B)
(C)
(D)
(1)
(2)
2
23
1
Turn the Power On
Do NOT connect the USB cable at this
stage.
•
Plug in the power cord on the left
side at the back of the machine and
connect the other end to the wall
outlet.
Open the Operation Panel (A), then press the ON button (B)
to turn on the machine.
Make sure that the Document Cover (C) is closed.
If an unintended language is displayed on the LCD, press the Back button on the Operation Panel to return to the
Language selection screen.
•
•
Use the { or } button (D) on the
Operation Panel to select the language
for the LCD, then press the OK button.
The standby screen is displayed.
The machine may make some operating noises. This is normal operation.•

4
(E)
(A)
(B)
(C)
(D)
3
12
Install the Print Head
Close the Document Cover (D) and lift it with the
Scanning Unit (Cover).
• Firmly raise the Print Head Lock Lever until it stops. (The
Print Head Lock Lever may feel heavy.)
•
If the Print Head Holder does not move, make sure that the
machine is turned on.
•
Open the Paper Output Tray (A), then lift the
Scanning Unit (Cover) (B) until it locks into place.
Raise the Print Head Lock Lever (E).
Do not handle the Print Head
roughly such as applying them
excessive pressure or dropping
them.
•
The Print Head Holder makes a noise as it moves.
This is normal operation.
•
The Scanning Unit (Cover) (B) is fixed automatically.
The Print Head Holder (C) comes out. (This is where
you install the Print Head.)

5
(E)
5
4
3
Remove the Print Head from the
silver package.
Remove and discard the orange
protective cap.
Tilt the Print Head and set it in place. Lower the Print Head Lock Lever
(E) completely.
There may be some transparent or light blue ink on the inside of the bag the Print
Head comes in, or the inside of the protective cap - this has no effect on print
quality. Be careful not to get ink on yourself when handling these items. Be careful
not to stain your hands.
•
Do not knock the Print Head against the sides of the Holder.
Be sure to install it in a well-lit environment.
Pinch the Print Head Lock Lever rmly and lower it gently.
Once you have installed the Print Head, do not remove it unnecessarily.
•
•
•
•

6
(A)
(1)
(2)
4
12
Install the Ink Tanks
Do not hold the sides of the ink tank; ink may splash.•
Pull the orange tape (1) in the direction of the
arrow to peel off the protective film and remove
the film (2) completely.
If the Print Head Holder moves
to the right, close and reopen
the Scanning Unit (Cover).
Be sure to use the supplied ink
tanks.
•
•
Do not handle the ink tanks
roughly such as applying them
excessive pressure or dropping
them.
•
While pressing down with your left thumb, twist off the
orange protective cap (A) located on the bottom of the
ink tank.

7
(B)
453
Wait until the screen above appears (about 4
minutes) and go to the next step.
The machine may make some operating noises
when preparing to print. This is normal operation.
•
•
If an error message is displayed on the LCD, make
sure that the Print Head and the ink tanks are correctly
installed.
•
Install all the other ink tanks in the
same way.
Install all the ink tanks.
Make sure all the Ink lamp lights red.•
Once you have installed the ink tanks,
do not remove them unnecessarily.
•
Close the Scanning Unit (Cover) (B).Press the PUSH mark on the ink
tank until it clicks into place.
Make sure the Ink lamp lights red.
Install the Ink Tank
Be sure to install it in a well-lit
environment.
•
Match the labels when installing.•

8
(C)
4
7
6
Press the OK button.
For details, refer to "21 Loading Paper" on page 56.
Close the Paper Output Tray to make it easier to pull out the
Cassette.
•
•
For better print results, it is recommended that you align the Print Head before printing photos. To
align the Print Head, use the {or }button to select Perform head alignment, then press the OK
button. Follow the steps in "Align the Print Head" on page 67 for alignment.
You can perform Print Head Alignment at any time. For details, refer to the on-screen manual: Basic
Guide.
•
•
Load three or more sheets of A4 or Letter-sized plain
paper into the Cassette (C), then press the OK button.
Confirm that the above screen appears.
