Canon imageCLASS 2200 User manual

networked
workgroup
solutions

AAssmmaallllffoooottpprriinnttiinntthheeoofffificcee......aaggiiaannttlleeaappiinnoofffificceepprroodduuccttiivviittyy..
Canon designed the imageCLASS 2200 as an advanced digital
imaging system that can function as a stand-alone copier or as a
networked multifunction document-processing system, offering the
convenience of copying, networkprinting and faxing.* Either way,
it providesthe reduced maintenance and superior reliability of
Canon’s EP-62 replaceableSingle Cartridge technology. Now, more
businesses than ever can enjoy the productivity of several advanced
office machines in a fraction of the space, at a fraction of the cost.
In one space-saving design, you’ll be able to generate, duplicate
and communicate information faster and easier than ever before.
With the Canon imageCLASS 2200, you’ll spend less time running
from machine to machine, and more time running your business.
TThheeCCaannoonnDDiiggiittaallTTeecchhnnoollooggyyAAddvvaannttaaggeess..
SCAN-ONCE-PRINT-MANY. Faster and more efficient, Canon
digital technology allows originalsto be scanned once and
stored in memory, greatly increasing productivity.
IMAGE QUALITY. With up to 600-dpi resolution, the
imageCLASS 2200 offers outstanding reproduction, faithful
to the original in every detail. Even difficult originals, such as
illustrations, photographs and textured drawings, reproduce
with superior image quality.
PRODUCTIVITY. Advanced copying features, plus built-in
expansion capabilities for networking, allow companies to
customize the system to their ever-changing needs.
YYoouu’’rreeoonnaappaatthhttootthheeffuuttuurree——tthheessppeeeeddlliimmiittiissuuppttooyyoouu..
With the imageCLASS2200, you’re able to configure the system
to meet your specific requirements.Thanksto its flexible modular
design, you can optimizeyour capabilities now, or expand them
asyour business grows. Start with a 16-copy-per-minute, walk-up
digital copier.Then add networkexpansion boards and accessories
to make your workgroup more productive: a 50-page Automatic
Document Feeder, an additional 250-sheet universal Cassette Feeding
Module or Super G3 Facsimile Expansion Board.You can even enhance
your capabilitiesfurther with the MultiSpot™NetworkPrinter option,
which includes NetSpot™NetworkDevice ManagementSoftware.*
* May require optional equipment.
** Approximate 3-second-per-page fax transmission time based on ITU-T No. 1 Chart (MMR,Standard Mode) at 33.6 Kbps modem speed.
The PublicSwitched Telephone Network(PSTN) currently supports 28.8 Kbps modem speeds or lower, depending on telephone line conditions.
▲
Source: Based on a study of V.34 phone bill savings prepared byDavidson Consulting, 1997.
◆
Based on ITU-T No. 1 Chart (Standard Mode).
Digital Technology for any workplace.
Step up to the versatility of the imageCLASS™2200 from Canon.
It’s the expandable digital solution that’s powerful enough to give
any size workgroup the outstanding performance enhancements
of digital copying technology, yet flexible enough to incorporate
the productivity of networked document management now or
later—whenever your business is ready.

AAddddSSuuppeerrGG33TTeecchhnnoollooggyyaannddwwaattcchhyyoouurrccoosstt--ssaavviinnggssmmuullttiippllyy..
By adding the optional Facsimile Expansion Board, you’ll gain
the significant cost-saving advantages of high-speed Super G3
Fax technology. Transmitting documents at 33.6 Kbps
(approximately 3 seconds per page**),Super G3 technology
results in substantially reduced telephone line charges. So, a
typical high-volume user, for example, can save over $10,000
during a five-year period
▲
if upgrading from an older, conven-
tional fax machine. What’s more, with 9MB of standard fax
memory, it will store up to 576 pages
◆
for transmitting or
receiving documents.
IIttiissnn’’ttjjuusstthhoowwpprroodduuccttiivveeiittiiss,,iitt’’sshhoowwpprroodduuccttiivveeiitt
mmaakkeessyyoouu..
Connected to your network, the imageCLASS 2200 makes
it easy to print images, up to 11"x 17," directly from your
computer while providing the ability to interface with the
entire workgroup.The MultiSpot
™
Network Printer Option,
operating in Windows
®
95/98 and Windows NT
®
4.0 environ-
ments, offers PCL
®
6 support, making it an excellent primary or
secondary networkprinter within the workgroup, delivering
true 600-dpi text and images. Designed for maximum output
quality and throughput speed, it prints 16 razor-sharp, letter-
sized pages per minute.
Bundled with the MultiSpot Network Printer Option is
Canon’s NetSpot
™
Network Device Management Software,
which provides every user with an intuitive interface to make
network device management simpler. Easy-to-follow “point-
and-click” screens enable users to interact with the devices
on the network directly from the desktop. With NetSpot,
you’ll be able to complete multiple tasks in minimal time,
such as confirming printer configurations or inquiring about
paper supply, job status, device features or system conditions.
Whichever platform you use, NetSpot offers a level of user-
friendly functionality not available from any other network
device-management software.
IImmaaggeeooffaalleeaaddeerr..
As the leading producer of network-connected multifunction
devices in the industry, as well as America’s #1 black-and-
white Copier and #1 Laser Facsimile manufacturer, Canon
continues to set new standards for quality, performance and
reliability. That’s why you can trust Canon to provide you with
the solutions you need to make any workgroup more produc-
tive, and any business more competitive.
networked
workgroup
solutions

3-00947
0700-iC2200-25M
CPRINTED ON RECYCLED
PAPER IN THE U.S.A.
iimmaaggeeCCLLAASSSS22220000BBaassiiccSSppeecciifificcaattiioonnss
Type/Configuration: Desktop/Stationary,Digital,Multifunction
ImagingSystem: LaserDryElectrostaticTransfer
DevelopingSystem: DryMonocomponentToner Projection
ImageServer Memory: 6MBStandard
MulticopySpeed: 16cpm—Letter(8.5"x11")
9cpm—Legal(8.5"x14")
9cpm—Ledger(11"x17")
Acceptable Originals: Sheets,Bookand3-DimensionalObjects
MaximumOriginalSize: 11"x17"
CopySizes
Cassette Feeding: Statementto Ledger
Bypass: Statementto Ledger
PaperSupply
Standard: Front-loading250-sheetCassette
100-sheetStackBypass
Optional: 250-sheetCassetteFeedingModule
(Total:600sheets)
AcceptablePaperWeights
Cassette: 17to24 lb.
Bypass: 17to 32lb.
ScanningResolution: 400x600dpi (Direct), 300x 600dpi(Memory)
EngineResolution: 1200x600 dpi(Direct),600 x600 dpi (Memory)
Gradation: 256(Direct), 64(Memory)
Duplexing: NotAvailable
Magnification: 25%– 400%(Platen),50% – 200% (ADF)
in1%increments
First-copyTime: 12Seconds(LTR,Upper Cassette)
Warm-upTime: 15Seconds(Warm-upfrom Power-OffStatus)
MultipleCopies: 1-99
ExposureControl: Manual
PowerRequirements: 115V,8A, 60Hz
Dimensions(HxWxD): 14.3"x23.0"x25.2"
Weight: 98lb.(44.4kg) withADF
AAuuttoommaattiiccDDooccuummeennttFFeeeeddeerr--HH11((wwiitthh88MMBBooffMMeemmoorryy))
AcceptableOriginals: Letterto 11"x18"
AcceptablePaperWeights: 13to 28 lb.
PaperCapacity: 50Sheets(LTR/20lb.)
OOppttiioonnaallAAcccceessssoorriieess
CCaasssseetttteeFFeeeeddiinnggMMoodduullee--DD11
NumberofCassettes: 1
AcceptablePaperSizes: LDR,LGL,LTR,LTR-R(User-adjustable)
AcceptablePaperWeights: 17to 24lb.Bond
PaperCapacity: 250Sheets
AsanE NERGY S TAR
®partner,CanonU.S.A.,Inc.hasdeterminedthatthisproductmeetsthe
E
NERGY S TAR
®guidelinesfor energy efficiency.TheE
NERGY S TAR nameis a registered trademark
ofthe U.S.EnvironmentalProtection Agency. PCLisa registeredtrademarkofHewlett-Packard
Company. Intellifont is a registered trademarkofAgfaCorporation,a division of Miles, Inc.
NDSisa registeredtrademarkandIPX/SPX isatrademarkofNovell,Inc.inthe UnitedStates
andothercountries.AppleTalkandTrueType are registered trademarksof Apple Computer,Inc.
WindowsandWindowsNT are registeredtrademarksof MicrosoftCorporation.Canonisa registered
trademark,and CanonKnowHow,IMAGECLASS,MultiSpotandNetSpotaretrademarksofCanonInc.
TheSUPER G3 logo isa trademark,and IMAGEANYWARE isaservicemarkofCanonU.S.A.,Inc.All
othertermsand product namesmaybe trademarksor registeredtrademarksoftheir respective
owners,and areherebyacknowledged.
Specificationssubjecttochangewithoutnotice.
SSuuppeerrGG33FFaaxxOOppttiioonn--GG11
ApplicableLine: PSTN(PublicSwitchedTelephoneNetwork)
Compatibility: G3
Modem: FAXModem/33,600 bps/V.34,V.8,V.17,V.33,V.29,V.27tar,V.21
TransmissionSpeed: 3Seconds
DataCompression: MH,MR,MMR
Resolution
Transmission: 200x100dpi,200x200 dpi,200x400dpi, 400x400dpi
Reception: 200x100dpi, 200x200dpi,200x400 dpi, 400x400dpi
Printing: 600x600 dpi
ScanningSpeed: 25page/min.
ADF: 50Sheets(Letter)/20Sheets(11"x17")
Memory: 9MB (576Pages/Based on ITU-T No.1 Chartat200x100dpimode)
Max.Memory: 9MB
MemoryBackup: Standard(Approx.3 hours)
AutoDialing: One-touch:84Locations;Coded:116Locations
MMuullttiiSSppoottNNeettwwoorrkkPPrriinntteerrOOppttiioonnJJ--11
PDL: PCL6,PCL5e,HPGL
PrintSpeed: 16ppm
Resolution: 600x600 dpi
Memory: Standard4MB/Option+ 4/8/16MB
Max.ImageSize: 11"x17"/A3
PaperOutput: Face-up
Font: 45Scalable(35Intellifont,
®10TrueType®),6Bitmap
Setup: RemoteONLY (NetSpot3.03or Higher)
Connectivity: NetworkOnly(NoParallelConnection)
NNeettwwoorrkkFFuunnccttiioonn
Connectivity: Ethernet 10Base-TOnly
NetworkProtocol: IPX/SPX,,
™TCP/IP,SNMP Only
AutomaticProtocol: SwitchingStandard
Application
IPX/SPX: Pserver/Rprinter,NDS®Pserver/NDSRprinter
TCP/IP: LPD
AppleTalk®: N/A
NetBIOS: N/A
NetSpot: NetSpot3.03 or Higher
PPrriinntteerrDDrriivveerrFFuunnccttiioonn
Supporting OSWindows®3.1x(PCL5eMode),Windows®95/98,WindowsNT®4.0
