Canon G4000 series User manual

Hưng dn bt đu
Mari Memulai

입문 가이드
入門指南
Getting Started

1
2
Lp đt My in ................................................................................... trang1
Kt ni vi my tnh v smartphone/my tnh bng .......................... trang5
Yêu cu thao tc mc cn thn đi vi sn phm ny. Mc c th văng ra khi np mc vo cc bnh mc.
Mc c th không ty đưc khi dnh vo qun o hoc đ đc c nhân.
Menginstal Pencetak ....................................................................halaman1
Menghubungkan dengan Komputer dan Ponsel Pintar/Tablet .....halaman5
Produk ini membutuhkan penanganan tinta yang seksama. Tinta mungkin terpercik ketika kotak tinta diisi. Jika
tinta menodai pakaian Anda atau benda lain, mungkin tidak akan dapat dibersihkan.
............................................................................................................ 
.................................................................. 


프린터 설치하기 ..............................................................................1페이지
컴퓨터 및 스마트폰/태블릿과 연결하기 ...........................................5페이지
이 제품의 잉크는 조심스럽게 다루어야 합니다. 잉크 탱크에 잉크를 채울 때 잉크가 튈 수 있습니다. 옷이나
소지품에 잉크가 묻은 경우 지워지지 않을 수 있습니다.
安裝印表機 .......................................................................................... 第1頁
與電腦和智慧型手機/平板連接 ............................................................ 第5頁
本產品需要小心處理墨水。向墨水盒填充墨水時，墨水可能會濺出。如果墨水沾到衣物或物品上，可能無法清
除。
Installing the Printer ............................................................................page1
Connecting with Computer and Smartphone/Tablet ...........................page5
This product requires careful handling of ink. Ink may splatter when the ink tanks are lled with ink. If ink gets
on your clothes or belongings, it may not come off.

1
ENGLISH
1. Installing the Printer
For the procedure with icon, you can watch the video
tutorials for installing the printer by accessing the following
URL or scanning the QR codes.
Video
Guides
Checking Included Items
CD-ROM for
computer
(Windows)
Manuals
Removing Packing Materials
You can watch the procedure on a movie by scanning
the QR codes.
Android iOS
1 Remove the packing materials (such as tape) from
outside the printer.
2 aRemove the orange tape.
bOpen the scanning unit / cover.
b
a
3 Remove the orange tape and the protective
material and discard them.
Installing the Cartridge
You can watch the procedure on a movie by scanning
the QR codes.
Android iOS
1 aGrab the knob on the cartridge locking cover.
bOpen the cartridge locking cover.
a
b
2 Take out the C (color) cartridge from the box and
remove the label.
3 Remove the protective tape.
4 Insert the C (color) cartridge on the left.

2
5 Repeat steps 2 to 4 to insert the B (black)
cartridge on the right.
6 Close the cartridge locking cover and push it
down.
7 Press down both joint buttons.
Pouring Ink
You can watch the procedure on a movie by scanning
the QR codes.
Android iOS
1 Open the left ink tank cover.
2 Grab and remove the tank cap of the ink tank, and
then place it on the upper tank cap holder.
3 aTake the BK (black) ink bottle out of its
package.
bHold the ink bottle upright and remove the
bottle cap.
b
a
4 Insert the nozzle of the ink bottle into the inlet and
stand the ink bottle upside down.
5 Pour all ink into the ink tank.
6 Close the tank cap.

3
ENGLISH
7 Close the ink tank cover.
8 aOpen the right ink tank cover.
bRepeat steps 2 to 6 to pour all ink into the
corresponding ink tanks on the right according
to the label.
cClose the ink tank cover.
b
a
c
9 Check that all ink in the bottles is poured into the
ink tanks.
10
Close the scanning unit / cover.
Turning on the Printer
You can watch the procedure on a movie by scanning
the QR codes.
Android iOS
1 Connect the power cord.
Do not connect any cables except the power cord
yet.
Back
2 Press the ON button.
If an error message appears, make sure the
cartridges are installed correctly.
3 Use the [ or ] button to select a language, and
then press the OK button.
4 If the following screen appears, select your country
or region, and then press the OK button.
5 aWhen the following screen appears, make
sure the ink preparation is complete.
bSelect Yes, and then press the OK button.
a
b

4
Selecting a Printer Connection Method
The connection method varies depending on how you use the printer. Select a printer connection method according to the
table below. In the following description, smartphones and tablet devices are collectively described as smartphone.
Using the printer with your computer or smartphone connected Using the printer without
connecting any other devices
Wireless LAN USB Do not connect
Connecting the printer to your
computer or smartphone via a
wireless router
router
Connecting the printer to your
computer or smartphone directly
without a wireless router *
USB cable
Use the [ or ] button to select
Do not connect on the connection
method selecting screen, and then
press the OK button. Follow the on-
screen instructions to proceed with
the setup. Wait for about 6 minutes
until the following screen appears.
The setup is now complete.
* You may not connect your smartphone to the Internet wirelessly during connecting
the printer to the smartphone directly. In that case, you may be charged depending
on the contract with your service provider.
* Up to 5 devices can be connected to the printer via wireless LAN connection
directly.
1 Select your printer connection method, and then
press the OK button.
Follow the on-screen instructions to proceed
with the setup.
Users who select USB:
Do not connect a USB cable until you are
instructed.
2 If the following screen appears, proceed to the
next page.
■ If you select Wireless LAN:
■ If you select USB:

5
ENGLISH
Connecting with Computer
You need connection setup for each computer. Proceed
with the setup from step 1 for each computer.
The following describes the procedures for Windows and
Mac OS.
If you use a computer except for Windows or Mac OS
such as Chrome OS, access "http://canon.com/ijsetup",
and then follow the instructions on the Canon website to
set up your computer.
1 Select one of the following steps or to start
up the setup le.
Accessing the Canon Website
aVisit the Canon website below and click Set Up.
Follow the on-screen instructions to proceed
with the setup.
bIf the following screen appears, click Download.
cStart up the downloaded le.
Using the Setup CD
aInsert the setup CD into your computer.
When using Windows 10, Windows 8.1 or Windows 8:
bClick or File Explorer on the taskbar.
cSelect This PC or Computer on the left side of the
opened window.
dDouble-click the CD-ROM icon on the right side
of the window.
* If the contents of the CD-ROM appear, double-click
MSETUP4.EXE.
2 Click Start Setup.
Follow the on-screen instructions to proceed
with the setup.
You can set up your smartphone in the middle
of the steps.
On the following screen, click Instructions to
proceed with setup of your smartphone.
* Depending on your settings, the screen above may
not appear. In that case, proceed to "Connecting with
Smartphone" on page 6 after nishing the connection
to your computer.
3 If the following screen appears, click Exit.
The connection with your computer
is now complete. You can print from
your computer.
2. Connecting with Computer and Smartphone/Tablet
If you connect the printer to both your computer and your smartphone, connect it to the
computer rst.
To connect the printer only to your smartphone, proceed to "Connecting with
Smartphone" on page 6.

6
Connecting with Smartphone
You need connection setup for each smartphone. Proceed with the setup from step 1 for each smartphone.
Preparation
• Turn on Wi-Fi on your smartphone.
• If you have a wireless router, connect your smartphone to the wireless router.
* For operations, refer to manuals of your smartphone and the wireless router or contact those manufacturers.
1 Install the application software Canon PRINT Inkjet/SELPHY in your smartphone.
: Search "Canon PRINT" in App Store.
: Search "Canon PRINT" in Google Play.
Or access the Canon website by scanning the QR code.
2 Check the display on the printer.
The screen turns off when no operation is made for 10 minutes. Press one of the buttons on the operation panel
(except for the ON button) to display the screen.
If appears, the printer can not communicate by
wireless LAN connection. For details, access "http://canon.
com/ijsetup" to see Frequently Asked Questions.
No (Proceed to .)
Yes
aTap the installed application software.
bFollow the on-screen instructions to register the
printer.
cMake sure that the following screen appears.
The connection with your smartphone is
now complete. You can print from your
smartphone.
To print photos, load photo paper. Proceed to "Loading
Paper" on page 8.
a Does the following screen appear?
b Does (the printer is connected to the network) appear on the screen displayed by pressing the
COPY button?
No Yes (Proceed to .)

7
ENGLISH
Procedures below vary depending on iOS or Android. Select your operating system and proceed to its
procedure.
aTap Settings on the HOME screen, and then tap
Canon_ij_XXXX on the Wi-Fi settings.
If Canon_ij_XXXX does not appear on the list, see
"Preparation of the Printer" below to operate the
printer, and then repeat step a.
bTap the installed application software.
cFollow the on-screen instructions to register the
printer.
Follow the on-screen instructions to proceed
with the setup.
If you select Auto Select Conn. Method
(recommended) on the connection method
selecting screen, the appropriate connection
method is selected automatically depending on
your environment.
dMake sure that the following screen appears.
aTap the installed application software.
bFollow the on-screen instructions to register the
printer.
If a message saying "Printer is not registered.
Perform printer setup?" does not appear, see
"Preparation of the Printer" below to operate the
printer, and then wait for a while until a message
appears.
Follow the on-screen instructions to proceed
with the setup.
The appropriate connection method is selected
depending on your environment.
cMake sure that the following screen appears.
The connection with your smartphone is now complete. You can print from your
smartphone.
To print photos, load photo paper. Proceed to "Loading Paper" on page 8.
aPress the Setup button on the printer. bUse the [ or ] button to select Wireless LAN
setup > Easy WL connect, and then press the
OK button.
cReturn to the operation of your smartphone.
Preparation of the Printer

8
1 Open the paper support and the paper support
extension.
2 Slide the right paper guide to the right end.
3 Insert several sheets of paper until it stops with
the print side facing up.
4 Slide the right paper guide to align it with the
side of the paper stack.
5 aPull out the paper output tray.
bOpen the output tray extension.
a
b
Loading Paper
Using Fax Function
Before using the fax function, refer to the following manual to set up the fax function of your printer.
■ Setting Up the FAX on the Online Manual
a Visit the Canon website below and click Set Up.
Follow the on-screen instructions to proceed with the setup.
b Click Making Fax Ready for Use.
■ Setting Up the FAX in the Basic Manual which is installed into your computer.

1
繁體中文
1.安裝印表機
對於帶有 圖示的步驟，可以透過存取以下URL或掃描QR
代碼來觀看安裝印表機的影片教學課程。
影片指南
檢查隨附的物品
用於電腦
(Windows)的
CD-ROM
手冊
移除包裝材料
可以透過掃描QR代碼觀看短片中的步驟。
Android iOS
1 移除印表機外部的包裝材料(膠帶等)。
2 a移除橙色膠帶。
b開啟掃描單元/機蓋。
b
a
3 移除並捨棄橙色膠帶和保護材料。
安裝墨水匣
可以透過掃描QR代碼觀看短片中的步驟。
Android iOS
1 a捏住墨水匣鎖定蓋上的把手。
b開啟墨水匣鎖定蓋。
a
b
2 從包裝盒中取出C(彩色)墨水匣並移除標籤。
3 移除保護膠帶。
4 在左側插入C(彩色)墨水匣。

2
5 重複步驟2到4，在右側插入B(黑色)墨水匣。
6 關閉並按下墨水匣鎖定蓋。
7 按下兩個接合按鈕。
倒入墨水
可以透過掃描QR代碼觀看短片中的步驟。
Android iOS
1 開啟左側墨水盒艙蓋。
2 捏住並取下墨水盒蓋，然後將其放置於上方的墨水
盒蓋支撐件之上。
3 a從包裝中取出BK(黑色)墨水瓶。
b直立握住墨水瓶並取下瓶蓋。
b
a
4 將墨水瓶的瓶口插入注入口，然後將墨水瓶倒置。
5 將所有墨水倒入墨水盒。
6 關閉墨水盒蓋。

3
繁體中文
7 關閉墨水盒艙蓋。
8 a開啟右側墨水盒艙蓋。
b重複步驟2到6，根據標籤將所有墨水倒入右側
的對應墨水盒。
c關閉墨水盒艙蓋。
b
a
c
9 確認墨水瓶中的所有墨水已倒入墨水盒。
10
關閉掃描單元/機蓋。
開啟印表機
可以透過掃描QR代碼觀看短片中的步驟。
Android iOS
1 連接電源線。
除電源線外，請勿預先連接其他任何電纜線。
背面
2 按電源按鈕。
如果出現錯誤訊息，請確保墨水匣安裝正確。
3 使用[或]按鈕選擇語言，然後按OK按鈕。
4 如果顯示以下螢幕，請選擇所在國家或地區，然後
按OK按鈕。
5 a顯示以下螢幕時，確保墨水準備工作已完成。
b選擇是(Yes)，然後按OK按鈕。
a
b

4
選擇印表機連接方法
根據印表機的使用方式不同，連接方法也不同。根據下表選擇印表機連接方法。在以下說明中，將智慧型手機或平板裝置統
一描述為智慧型手機。
在連接電腦或智慧型手機的情況下使用印表機 在不連接其他任何裝置的情況下使
用印表機
無線LAN(Wireless LAN) USB 不連接(Do not connect)
透過無線路由器將印表機連接至電腦或
智慧型手機
路由器
不使用無線路由器將印表機直接連接至
電腦或智慧型手機*USB電纜線
使用[或]按鈕在選擇連接方法螢幕
上選擇不連接(Do not connect)，然
後按OK按鈕。按照螢幕上的說明繼續
進行設定。等待大約6分鐘後，會顯示
以下螢幕。
設定現已完成。
* 將印表機直接連接至智慧型手機時，可能無法以無線方式將智慧型手機連接至網際
網路。在這種情況下，根據與服務提供者的合約，您可能需要支付費用。
* 透過無線LAN連接最多可以將5個裝置直接連接至印表機。
1 選擇印表機連接方法，然後按OK按鈕。
按照螢幕上的說明繼續進行設定。
選擇USB的使用者：
顯示說明前請勿連接USB電纜線。
2 如果顯示以下螢幕，請繼續執行下一頁。
■ 如果選擇無線LAN(Wireless LAN)：
■ 如果選擇USB：

5
繁體中文
與電腦連接
需要為每台電腦執行連接設定。從步驟1開始繼續設定每台
電腦。
以下針對Windows和Mac OS的步驟進行說明。
如果使用的電腦並非Windows或Mac OS作業系統(如
Chrome OS等)，請存取「http://canon.com/ijsetup」，然
後按照Canon網站上的說明設定電腦。
1 從步驟 或 中選擇其一以啟動安裝程式檔案。
存取Canon網站
a瀏覽下方的Canon網站，然後按一下設定。
按照螢幕上的說明繼續進行設定。
b如果顯示以下螢幕，請按一下下載。
c啟動下載的檔案。
使用安裝光碟
a將安裝光碟插入電腦。
使用Windows 10、Windows 8.1或Windows 8時：
b按一下工作列上的 或檔案總管(File Explorer)。
c在開啟的視窗之左側選擇本機(This PC)或電腦
(Computer)。
d按兩下視窗右側的 光碟圖示。
* 如果顯示光碟內容，則按兩下MSETUP4.EXE。
2 按一下開始設定(Start Setup)。
按照螢幕上的說明繼續進行設定。
可以在執行步驟的過程中設定智慧型手機。
在以下螢幕上按一下使用說明(Instructions)可繼續
設定智慧型手機。
* 根據設定的不同，可能不顯示以上螢幕。在這種情況
下，完成與電腦的連接後，請繼續執行第6頁的「與智
慧型手機連接」。
3 如果顯示以下螢幕，請按一下結束(Exit)。
與電腦的連接現已完成。可以從電腦列
印。
2.與電腦和智慧型手機/平板連接
如果印表機需要同時連接電腦和智慧型手機，則首先將其連接至電腦。
如果僅需要將印表機連接至智慧型手機，請繼續執行第6頁的「與智慧型手機連接」。

6
與智慧型手機連接
需要為每部智慧型手機執行連接設定。從步驟1開始繼續設定每部智慧型手機。
準備工作
• 請開啟智慧型手機上的Wi-Fi。
• 如果有無線路由器，則將智慧型手機連接至無線路由器。
* 關於操作的詳細資訊，請參閱所用智慧型手機和無線路由器的手冊，或與其製造商聯絡。
1 將應用程式軟體Canon PRINT Inkjet/SELPHY安裝到智慧型手機中。
：在App Store中搜尋「Canon PRINT」。
：在Google Play中搜尋「Canon PRINT」。
或者透過掃描QR代碼存取Canon網站。
2 查看印表機上的顯示。
10分鐘內未進行操作時，螢幕會關閉。按操作面板上的任一按鈕(電源按鈕除外)可顯示螢幕。
如果顯示 ，則印表機無法透過無線LAN連接通訊。
關於詳細資訊，請存取「http://canon.com/ijsetup」以查看
常見問題。
否(繼續執行 。)
是
a點選已安裝的應用程式軟體。
b按照螢幕上的說明註冊印表機。
c請確保顯示以下螢幕。
與智慧型手機的連接現已完成。可以從智慧
型手機列印。
要列印相片，請載入相片紙。繼續執行第8頁的「載入紙
張」。
a 是否顯示以下螢幕？
b 按影印按鈕後顯示的螢幕上是否出現 (印表機已連接至網路)？
否是(繼續執行 。)

7
繁體中文
以下步驟視iOS或Android而有所不同。選擇所用作業系統，然後繼續執行相應步驟。
a點選主頁螢幕上的設定(Settings)，然後點選Wi-Fi設
定上的Canon_ij_XXXX。
如果Canon_ij_XXXX未顯示在清單上，請參見下方
的「印表機準備工作」來操作印表機，然後重複步
驟a。
b點選已安裝的應用程式軟體。
c按照螢幕上的說明註冊印表機。
按照螢幕上的說明繼續進行設定。
如果在選擇連接方法的螢幕上選擇自動選擇
連接方法(推薦)(Auto Select Conn. Method
(recommended))，則會根據使用環境自動選擇適當
的連接方法。
d請確保顯示以下螢幕。
a點選已安裝的應用程式軟體。
b按照螢幕上的說明註冊印表機。
如果不顯示訊息「印表機未註冊。是否執行印表機
設定？(Printer is not registered. Perform printer
setup?)」，請參見下方的「印表機準備工作」來操
作印表機，訊息顯示前，請稍候片刻。
按照螢幕上的說明繼續進行設定。
根據使用環境選擇適當的連接方法。
c請確保顯示以下螢幕。
與智慧型手機的連接現已完成。可以從智慧型手機列印。
要列印相片，請載入相片紙。繼續執行第8頁的「載入紙張」。
a按印表機上的設定按鈕。 b使用[或]按鈕選擇無線LAN設定(Wireless LAN
setup) > 簡易無線連接(Easy WL connect)，然後
按OK按鈕。
c返回智慧型手機的操作。
印表機準備工作

8
1 開啟托紙架和托紙架擴展架。
2 移動右紙張導引器至最右端。
3 裝入幾張紙，將列印面向上插入到位。
4 移動右紙張導引器使其與紙疊邊緣對齊。
5 a拉出出紙托盤。
b開啟出紙托盤擴展架。
a
b
載入紙張
使用傳真功能
使用傳真功能前，請參閱以下手冊來設定所用印表機的傳真功能。
■ 線上手冊中的設定傳真
a 瀏覽下方的Canon網站，然後按一下設定。
按照螢幕上的說明繼續進行設定。
b 按一下使傳真準備就緒。
■ 基本手冊(安裝於電腦)中的設定傳真。

1
한국어
1. 프린터 설치하기
아이콘이 있는 절차의 경우, 다음 URL에 액세스하거나
QR 코드를 스캔하여 프린터 설치에 관한 비디오 자습서를
볼 수 있습니다.
비디오
가이드
동봉품 확인하기
컴퓨터용 CD-
ROM(Windows)
설명서
포장 재료 제거하기
QR 코드를 스캔하면 동영상으로 절차를 볼 수
있습니다.
Android iOS
1 프린터 외부에서 포장 재료(테이프 등)를
제거합니다.
2 a오렌지색 테이프를 제거합니다.
b스캔 유닛/커버를 엽니다.
b
a
3 오렌지색 테이프 및 보호 재료를 제거하여
버립니다.
카트리지 설치하기
QR 코드를 스캔하면 동영상으로 절차를 볼 수
있습니다.
Android iOS
1 a카트리지 잠금 커버의 손잡이를 잡습니다.
b카트리지 잠금 커버를 엽니다.
a
b
2 C(컬러) 카트리지를 상자에서 꺼내고 레이블을
제거합니다.
3 보호 테이프를 제거합니다.
4 C(컬러) 카트리지를 왼쪽에 삽입합니다.

2
5 2~4단계를 반복하여 B(블랙) 카트리지를 오른쪽에
삽입합니다.
6 카트리지 잠금 커버를 닫고 아래로 누릅니다.
7 두 연결 버튼을 모두 누릅니다.
잉크 주입하기
QR 코드를 스캔하면 동영상으로 절차를 볼 수
있습니다.
Android iOS
1 왼쪽의 잉크 탱크 커버를 엽니다.
2 잉크 탱크의 탱크 캡을 잡고 제거한 다음 이를
위쪽의 탱크 캡 홀더에 놓습니다.
3 aBK(블랙) 잉크병을 포장에서 꺼냅니다.
b잉크병을 똑바로 잡고 병 캡을 제거합니다.
b
a
4 잉크병의 노즐을 주입구에 삽입하고 잉크병을
거꾸로 세웁니다.
5 잉크 탱크에 모든 잉크를 주입합니다.
6 탱크 캡을 닫습니다.
