Canon PIXMA E300 series User manual

Para Começar
Leia Informações Importantes e Sobre
Segurança (adendo) primeiro.
Guía de inicio
Lea primero Información de seguridad
e información importante (apéndice).
Getting Started
Read Safety and Important Information
(addendum) rst.

1
2
Instalando a impressora .................................................página 1
Conectando a um computador e smartphone/tablet ......página 4
Como segurar
a impressora
Filmes explicativos
Instalación de la impresora.............................................página 1
Conexión con el ordenador y con el teléfono
inteligente o la tableta.....................................................página 4
Cómo sujetar
la impresora
Películas explicativas
Installing the Printer...........................................................page 1
Connecting with Computer and Smartphone/Tablet..........page 4
How to Hold Printer Explanatory Movies

1
ENGLISH
1. Unpack Box
□ Power cord □ FINE cartridge
□ Safety and Important Information
□ Getting Started (this manual)□ Setup CD-ROM for
Windows PC
2. Remove Tape and Turn on
1 Stand the printer on its back and remove the
orange tape stuck to the bottom of it. Return the
printer to its original position.
a
b
c
2 Remove the packing materials (such as orange
tape) from outside the printer.
3 Open the cover.
4 Remove the orange tape and the protective
material and discard them both.
5 Close the cover.
6 Connect the power cord.
Do not connect any cables except the power cord
yet.
7 Press the ON/Stop button.
The ON lamp lights.
Lit
• If the Alarm lamp (A) ashes 9 times at a time,
press the ON/Stop button to turn off the power,
and then try again from step 3 of chapter 2
"Remove Tape and Turn on".
• If the Alarm lamp (A) ashes 4 times at a time,
proceed to the next step as it is.
(A)
Flashing

2
3. Install Inks
1 Open the cover.
2 aTake out the Color FINE cartridge from the
package.
bRemove the protective tape.
a
Do not touch.
b
Be careful of ink on the protective tape.
3 aInsert the Color FINE cartridge into the FINE
cartridge holder on the left at a slight upward
angle.
bPush the FINE cartridge in and up rmly until it
snaps into place.
Make sure that the FINE cartridge is installed
horizontally.
Do not bump it against
the surrounding parts.
Click!
a
b

3
ENGLISH
4 Repeat steps 2 to 4 and install the Black FINE
cartridge as well, on the right.
5 Close the cover.
If the Alarm lamp ashes 4 times at a time, go
back to step 3 of chapter 3 "Install Inks" and check
whether the FINE cartridges for Color and Black are
installed correctly.
4. Load Paper
1 Open the paper support.
2 Slide the paper guide to the left.
3 Load plain LTR or A4 size paper against the right
edge with the print side facing up.
4 Slide the paper guide to align it with the side of the
paper stack.
5 Pull out the paper output tray and output tray
extension.

4
5. Preparing for Connection
From here on, the procedure differs depending on the device used to connect to the printer.
First, after checking that the Wireless (Inalámbr./Sem o) lamp is ashing 2 times at a time, proceed to the following operations.
In the following description, smartphones and tablet devices are collectively described as smartphone.
When the Wireless (Inalámbr./Sem o) lamp does not
ash, try again from chapter 2 "Remove Tape and Turn on".
Flashing
• To use the printer by connecting only to a computer or both to a computer and smartphone
"6-A. Connecting to Computer"
• To use the printer by connecting only to a smartphone
"6-B. Connecting to Smartphone" on page 6
6-A. Connecting to Computer
macOS
Windows
You need a connection setup for each computer. Proceed with the setup from step 1 for each computer.
1 Start the setup le for either method or method .
aOpen a web browser ( etc.) on your computer.
bInput the following URL and access the Canon
website.
cSelect Set Up.
dInput the model name of your printer and click OK.
You can select a model name from the list.
eClick Setup.
The procedures for Windows and macOS are shown
below. If you are using a computer with an OS other
than Windows or macOS, such as a Chrome OS, do
the setup according to the on-screen instructions.
fClick Download and download the setup le.
gExecute the downloaded le.
Proceed to step on the next page to
continue.
Downloading from the Internet

5
ENGLISH
The connection with your computer is now complete. You can print from your
computer.
If the following screen appears, click Exit.
Follow the on-screen
instructions to proceed
with the setup.
Using Setup CD-ROM (Windows Only)
aLoad the Setup CD-ROM in your computer.
■ When using Windows 10 or Windows 8.1:
bWhen the following message appears on the right
side of your computer screen, click it.
cIf the following screen appears, click Run
Msetup4.exe.
dIf the User Account Control dialog box appears,
click Yes.
When This Message Does Not Appear (or Has
Disappeared)
1. Click File Explorer on the taskbar.
or
2. Click This PC on the left side of the opened window.
3. Double-click the CD-ROM icon on the right side of
the window.
If the contents of the CD-ROM appear, double-click
Msetup4.exe.
4. Proceed to step d.
■ When using Windows 7:
b When the AutoPlay screen appears, click Run
Msetup4.exe.
c If the User Account Control dialog box appears,
click Continue.
When AutoPlay Screen Does Not Appear
1. Click Computer from the start menu.
2. Double-click the CD-ROM icon on the right side of
the opened window.
If the contents of the CD-ROM appear, double-click
Msetup4.exe.
Proceed to step to continue.
2 Click Start Setup.

6
6-B. Connecting to Smartphone
Android
iOS
You need a connection setup for each smartphone. Proceed with the setup from step 1 for each smartphone.
Preparation
• Turn on Wi-Fi on your smartphone.
• If you have a wireless router, connect your smartphone to the wireless router you want to connect to the printer.
* For operations, refer to manuals of your smartphone and the wireless router or contact those manufacturers.
1 Install the application software Canon PRINT Inkjet/SELPHY in your smartphone.
: Search "Canon PRINT" in App Store.
: Search "Canon PRINT" in Google Play.
Or access the Canon website by scanning the QR code.
* You may not connect your smartphone to the Internet wirelessly during connecting the printer to the smartphone directly.
In that case, you may be charged depending on the contract with your service provider.
* Up to 5 devices can be connected to the printer via wireless LAN connection directly.
2 Check the Wireless (Inalámbr./Sem o) lamp, and then proceed to or .
aTap the installed application software.
bFollow the on-screen instructions to register the
printer.
cMake sure that the following screen appears.
The connection with your smartphone is
now complete. You can print from your
smartphone.
To print photos, load photo paper. Proceed to "Loading
Photo Paper" on page 8.
If the Wireless (Inalámbr./Sem o) lamp is
not lit and the Network (Red/Rede) lamp is lit,
the printer cannot send transmissions using a
Wireless LAN connection. For details, access
"http://ij.start.canon" to see the "Frequently
Asked Questions".
Lit
Off or ashing (continue to )
Lit (continue to )

7
ENGLISH
Procedures below vary depending on iOS or Android. Select your operating system and proceed to its
procedure.
aTap Settings on your smartphone's home screen,
and tap Canon_ij_XXXX in the Wi-Fi settings.
If Canon_ij_XXXX does not appear on the list, see
"Troubleshooting" below to operate the printer, and
then repeat step a.
bTap the installed application software.
cFollow the on-screen instructions to register the
printer.
Follow the on-screen instructions to proceed
with the setup.
If you select Auto Select Conn. Method
(recommended) on the connection method
selecting screen, the appropriate connection
method is selected automatically depending on
your environment.
dMake sure that the following screen appears.
aTap the installed application software.
bFollow the on-screen instructions to register the
printer.
If a message saying "Printer is not registered.
Perform printer setup?" does not appear, see
"Troubleshooting" below to operate the printer, and
then wait for a while until the message appears.
Follow the on-screen instructions to proceed
with the setup.
The appropriate connection method is selected
depending on your environment.
cMake sure that the following screen appears.
The connection with your smartphone is now complete. You can print from your
smartphone.
To print photos, load photo paper. Proceed to "Loading Photo Paper" on page 8.
aPress and hold the Direct button on the printer for about 2 seconds until the Direct lamp starts to ash.
Flashing
bReturn to the operation of your smartphone.
Troubleshooting
Printer is not found from your smartphone.

8
1 Open the paper support.
2 Slide the paper guide to the left.
3 aLoad photo paper against the right edge with
the print side facing up.
bSlide the paper guide to align it with the side
of the paper stack.
a
b
4 Conrm that the Paper lamp that is lit matches
the paper size that is loaded.
LTR/
4"×6"/10×15cm
A4/Hagaki/L
If the Paper lamp that lights does not match the
paper size, press the Paper Select button.
LTR/
4"×6"/10×15cm
A4/Hagaki/L
5 Pull out the paper output tray and output tray
extension.
Loading Photo Paper
Smartphone Copy
You can copy documents by using the Canon PRINT Inkjet/SELPHY application software for
smartphones. To install the application, refer to step 1 on page 6. For the operation procedure, refer
to the Online Manual.
1 Load the document on the
printer.
2 Take a photo of the document
by using Canon PRINT Inkjet/
SELPHY.
3 Send the image data to the
printer and print it.
