Canon imagePROGRAF PRO-6100 User manual

QT6-3114-V01 XXXXXXXX © CANON INC. 2019
QT63114V01
PRINTED IN XXXXXXXX
IMPRIMÉ XX XXXXXXXX
RMC (Regulatory Model Code): K10508
RMC (Regulatory Model Code): K10507
RMC (Regulatory Model Code): K10506
RMC (Regulatory Model Code): K10505
RMC (Regulatory Model Code): K10504
Setup Guide
Read this manual before attempting to operate the printer. Keep this manual for future reference.
Furthermore, in order to ensure that this product is used safely, you should always also read the “Quick Guide (separate
manual)”.
ENGLISH
Guide d’installation
Lisez ce manuel avant d’essayer d’utiliser l’imprimante. Conservez ce manuel pour toute consultation ultérieure.
De plus, an de vous assurer que ce produit est utilisé en toute sécurité, lisez également le “Guide rapide (manuel
distinct)”.
FRANÇAIS
Guia de conguração
Leia este manual antes de tentar operar a impressora. Guarde este manual para referência futura.
Além disso, para garantir que este produto seja usado com segurança, leia também o “Guia rápida (manual separado)”.
PORTUGUÊS
Guía de conguración
Lea este manual antes de intentar operar la impresora. Conserve este manual a mano para futuras referencias.
Además, para garantizar que este producto se utilice de manera segura, siempre debe leer también la “Guía rápida
(manual aparte)”.
ESPAÑOL

1
Windows is a trademark or registered trademark of Microsoft Corporation in the U.S. and/or other countries.
Overview of Setup Conrming the Installation Space
The illustrations in this manual using the PRO-4100 as an example for explanation. Note that your printer may look different from these
illustrations in some cases.
The specifications and appearance of this product are subject to change without notice.
Set up the printer using the following procedure. Note that if an error
message appears during setup or other problems occur, refer to "Responding
to Messages" on p. 15.
1
Removing the Packaging Material Page 4
2
Assembling the Printer Stand Page 4
3
Attaching the Roll Unit Page 4
4
Installing the Printer Page 4
5
Turning On the Printer Page 5
6
Installing the Ink Tanks Page 6
7
Installing the Print Head Page 8
8
Performing Print Head Adjustment Page 10
9
Selecting the Method of Connecting
to Your Computer Page 12
10
Installing the Software on Your
Computer Page 13
Loading Paper Page 14
Performing Color Calibration Page 14
Storage Location for Accessories Page 14
Printing From a Smartphone or Tablet Page 14
Displaying the Online Manual Page 14
Responding to Messages Page 15
When installing the printer, it is recommended that you secure the following
space around the printer.
Important
● The printer stand may not be included with the model you purchased.
● The space required in front of the printer varies depending on how the
basket (accessory) is used.
■ PRO-6100 / PRO-6100S
Required space (W x D x H)
94.5 x 66.3 x 61.5 inches
2399 x 1684 x 1560 mm
7.9 inches
(200 mm)
7.9 inches
(200 mm)
23.6 inches
(600 mm)
3.9 inches
(100 mm)
5.9 inches
(150 mm)
■ PRO-4100 / PRO-4100S
Required space (W x D x H)
78.5 x 66.3 x 61.5 inches
1993 x 1684 x 1560 mm
7.9 inches
(200 mm) 7.9 inches
(200 mm)
23.6 inches
(600 mm)
3.9 inches
(100 mm)
5.9 inches
(150 mm)
■ PRO-2100
Required space** (W x D x H)
59.5 x 56.5 x 40.2 inches
1510 x 1434 x 1020 mm
Required space* (W x D x H)
59.5 x 66.3 x 61.5 inches
1510 x 1684 x 1560 mm
3.9 inches
(100 mm)**
3.9 inches
(100 mm)*
23.6 inches
(600 mm)*
5.9 inches
(150 mm)
7.9 inches
(200 mm)
7.9 inches
(200 mm)
23.6 inches
(600 mm)**
* When using the SD-21 printer stand
** When not using the printer stand
ENGLISH

2
Checking the Package Contents
Check that the following included accessories are contained in the package. Note that a cable to connect the printer to a computer is not provided with the
printer.
Note
● Although the included accessories also contain items that are not explained in this manual, you should store them without losing any since they will be
required when using various functions.
● For instructions on the included items not described in this manual, refer to the Online Manual by following the instructions in "Displaying the Online Manual"
on p. 14.
a
b
c
d
fg
i
h
j
k
k
m
m
q
nop
r
il
e
e
*1 Only included with models where the printer stand is included as standard. Note that it may be packaged in a separate box depending on the region
where you purchased the printer.
The items included with the printer stand are described in the Printer Stand Setup Guide.
*2 The included ink tanks for initial installation differ depending on the model.
PRO-2100, PRO-4100, PRO-6100: MBK, PBK, C, M, Y, PC, PM, R, CO, B, GY, PGY
PRO-4100S, PRO-6100S: MBK, PBK, C, M, Y, PC, PM, GY
*3 These items might not be included depending on your region.
*4 This is used when loading roll paper. For details, refer to the Online Manual.
Manuals Included with This Product
Setup Guide (this manual)
Describes how to setup the printer.
Printer Stand Setup Guide
Describes how to assemble the stand. This may not be included depending on your region and selected purchase options.
Quick Guide
Contains information related to warnings for using this product safely and information related to replacing paper, ink tanks, and the print head.
Online Manual (Electronic Manuals)
The Online Manual describes all aspects of printer use from basic instructions for printing on roll or cut sheet paper, to tips for saving paper and maintaining the
best printing quality. It also describes how to print posters and banners from the supplied software. To view the Online Manual, refer to "Displaying the Online
Manual" (p. 14).
aPrinter
bBasket rod / Basket cloth *1
cPaper for print head adjustment
dSetup Guide (this manual)
eStarter ink tanks *2
fSet of CD-ROMs
gSet of printer documentation
hPower cord
iRod holder (2 pieces) *1
jPrint head
kStand leg (2 pieces) *1
lStand stay *1
mBasket arm (2 pieces) *1
nBasket locking support (2 pieces) *3
o3-inch paper core attachment (2 pieces)
pPrinter stand mounting bracket set *1
qAccessory pocket
rHolder stopper *4
sRoll Unit
Provided as an optional accessory.
Refer to the included setup guides for details on the
products included in the boxes.

3
Handling Cautions
Moving the Printer Standing Up the Printer Other
● Firmly grasp the carrying handles on each side
in the base (the area shown shaded in the
diagram). Holding the printer at other positions
is dangerous and may cause injury and damage
if the printer is dropped.
● When standing up the printer, hold the metal
parts of the printer. If you hold a plastic part, the
printer may become damaged.
● Do not put the printer down or carry the printer
with only the center of the printer supported.
This may cause damage to the printer.
● Have the following number of people grasp the
carrying handles on each side in the base of the
printer. The weight may cause pain such as back
pain.
• PRO-6100 Approx. 273 lb (124 kg)
6 people or more
• PRO-6100S Approx. 268 lb (122 kg)
6 people or more
• PRO-4100 Approx. 233 lb (106 kg)
6 people or more
• PRO-4100S Approx. 229 lb (104 kg)
6 people or more
• PRO-2100 Approx. 187 lb (85 kg)
6 people or more
For the PRO-6100
● When standing the printer up, place cardboard
or other material underneath to prevent
damage and scratching, and make sure the side
with the operation panel is up. Furthermore,
make sure that the weight of the printer is taken
by the corner of the printer. If the weight is
taken by any other part of the printer, the printer
may become damaged.
● When setting the printer down temporarily,
make sure to put the printer on a flat, stable
surface.

4
4
Installing the Printer
If you are not using the stand, install the printer in a location like the following.
2
Assembling the Printer Stand
Assemble the stand by referring to the Printer Stand Setup Guide (separate manual). If you are
not using the stand, proceed to "
4
Installing the Printer".
3
Attaching the Roll Unit
If you purchased the optional roll unit, attach the roll unit by referring to the Roll Unit Setup
Guide (separate manual). If you are not using the roll unit, proceed to "
4
Installing the Printer".
1
Removing the Packaging Material
1
Lift up the printer.
● For details on how to carry and the number of people, refer to
"Handling Cautions" (p. 3).
2
Place the printer on a stable at location.
1
Remove the packaging material.
2
Remove all of the tape and other packaging material.
Remove the tape axed to the roll holder.

5
5
Turning On the Printer
1
Open the top cover.
2
Pull up and remove the belt stopper.
● Keep the belt stopper for future use. You will need it in case you
move the printer to another location.
3
Remove the tape and protective material.
● Peel off the tape affixed to the carriage, and then pull the
protective material (the area shown shaded in the diagram)
towards you and remove it. Remove the protective sheet if there
is one attached.
4
Close the top cover.
5
Connect the power cord to the printer.
● Insert the power cord into the power connector on the rear of the printer.
For the PRO-2100 For the PRO-4100 / PRO-4100S / PRO-6100 / PRO-6100S
6
Plug the power cord into the outlet,
and then turn on the printer.
7
When the language selection screen
appears on the touch screen, select
and tap a language (lightly with
your nger, and then move your
nger away). Then, if the screen for
selecting a time zone appears, select
and tap your region.
8
When a message prompting you to
start the setup appears on the touch
screen, tap OK.

6
6
Installing the Ink Tanks
Instructions on ink tank installation are shown on the touch screen. Install the ink tanks as instructed. The PRO-2100 / PRO-4100 / PRO-6100 require 12 ink tanks
while the PRO-4100S / PRO-6100S require 8 ink tanks. If the ink tank is cold, allow it to adjust to room temperature before attaching it to the printer.
1
Open the ink tank covers.
2
Pull the ink tank lock lever towards
you.
● Hook your finger into the knob (A)
on the back of the handle and pull it
towards you.
A
3
With it in this state, pull the ink tank
lock lever up.
4
Continue pulling until the entire ink tank lock lever is
tilted towards you.
● Make sure the ink tank lock lever stays in the locked position.
5
Shake each ink tank gently 7 or 8 times before opening its
pouch.
Important
● Failure to shake the ink tanks may
result in reduced print quality
because ink ingredients have settled
on the bottom of the tank.
6
Open the pouch and remove the ink tank.
Important
● Never touch the ink holes or metal contacts (the area shown shaded in the diagram).
Touching these parts may cause stains, damage the ink tank, and affect print quality.
● Avoid dropping the ink tank after removing it from the pouch.
Otherwise, ink may leak and cause stains.
● Do not remove ink tanks to shake them after they have been mounted.
Doing so may cause ink to spill.
7
Check that the color of the ink tank is the same as the color displayed on the label in the printer, and insert the ink tank into
the holder in the orientation shown in the diagram.
● Insert with the ink tank label facing up and ensuring that the text on the label is not upside-down.
Match the color of the ink tank label
to the color of the label in the printer

7
8
Lift up the ink tank lock lever once and then push it
down.
9
Firmly push down the handle part of the ink tank lock
lever all the way in.
10
Make sure the ink lamp lights red.
Important
● If the ink lamp does not light, repeat steps 2 to 4and 8to 9.
11
Repeat steps 2 to 10 to install each of the ink tanks.
12
Close the ink tank covers.

8
7
Installing the Print Head
Instructions are now shown on the touch screen regarding print head installation. Install the print head by following the instructions.
1
Open the top cover.
Important
● Do not move the carriage (the area enclosed by a circle in the
diagram). If you accidentally move it, temporarily close the top
cover and it will return to its original position.
2
Tilt the print head lock lever towards you.
● While pushing the button in the center of the lever, tilt the
lever towards you. Remove the protective sheet if there is one
attached.
3
Open the print head locking cover.
Do not touch here with your hands
4
Grasp the print head as shown in the diagram and
remove it from the bag.
5
Remove the 2 orange protective caps.
● Keep holding the print head in your hand while you work.
Important
● The print head is filled with ink. Be careful to avoid getting your clothes and surrounding items dirty when removing the
protective caps.
● Do not touch anywhere other than the handles. In particular, do not touch the part that was being protected by the
protective cap (part shown shaded in the diagram) under any circumstances. Touching it may cause damage to the print head
or printing problems.
● Do not reattach the protective caps after removing them. Furthermore, dispose of them according to local regulations.

9
6
Install the print head.
● Align the print head so that the area enclosed by a circle in the
diagram is facing you, and carefully push the print head firmly
into the printer, ensuring that the part covered by the protective
caps does not touch the carriage.
7
Pull the print head locking cover down toward you to lock
the print head in place.
8
Push the print head lock lever all the way to the end.
● Push firmly until you hear a click sound.
9
Close the top cover.
Note
● If the roll unit is installed, the roll unit calibration starts automatically
after the print head is attached.
If the roll holder is mounted on the roll unit at this time,
calibration cannot be executed. Do not mount the roll holder on
the roll unit until the setup has finished.
