Highly efficient workflow
with 3 media paths
Built-in colour calibration so
no need for external devices.
Encompassing a twin
print head design,
the printers deliver:
• Superb quality with
12-colour lightfast
pigment inks
• 2,400 x 1,200 dpi
reproduction
• Draft A1 prints in just over 1
minute and glossy A1 prints
in under 4 minutes
• Smooth colour graduation
and scratch resistance prints
with reduced graininess and
no bronzing Borderless printing for stunning
photographic and fine art prints.
Create head-turning posters easily with Canon’s PosterArtist tool (bundled with Lite ver-
sion – Full version Optional) offering easy to use templates and a database of images to
enhance your posters.
Automatic skew correction, large LCD and ink level displays for ease-of-use.
Intuitive software including Digital Photo Front Access and Adobe Photoshop Plug-In.
80GB HDD as standard on the iPF6200.
•
•
•
•
The imagePROGRAF iPF6100 and iPF6200 are both 12-colour pigment ink 24” (A1) large
format printers designed for the photographic, fine art and proofing market with the added
benefit of a built-in 80Gb Hard disk drive with the iPF6200 and the Canon printer driver,
ensuring optimum printer efficiency.
Ideal for Photography,
Fine Art and Proofing
iPF6100 / iPF6200
Large Format Print Solutions
2 400
x
1 200dpi 12
colours
80GB
HDD
(iPF6200)
30.720
nozzles
Borderless
Printing
24
inch
Glossy A1
4 minutes
4pl
Built-in
Colour
Calibration
iPF6100 / iPF6200
iP6100
iPF6100-6200 Specsheet English-U1 1 9-9-2008 12:26:22

Class IPF6100/iPF6200: 24 inch
Ink Type LUCIA Pigment ink, 12 colours
(MBK, BK, PC, C, PM, M, Y, R, G, B, GY, PGY)
Maximum Print Resolution 2,400 x 1,200 dpi
Printing Speed (A1 Roll)
Plain Paper 1:07 (Draft)
Coated Paper 2:05 (Standard)
Photo Glossy Paper 3:58 (Standard)
Dimensions weight (net)
W x D x H (mm), (kg) Main Unit with Palett: 1,320 x 914 x 645 weight approx: 79 kg
Power Supply
Input power AC 220 – 240 V (50/60Hz), AC 100 – 120 V (50/60Hz)
Power Consumption 100 W or less
Standby power consumption
(At the low power mode)
220 – 240 V 6 W or less (9 W: when IEEE1394 is mounted)
Power off (standby) 1 W or less
Operational Environment Temperature: 15 – 30ºC, Humidity: 10 – 80% (Condensation Free)
Acoustic Noise
Acoustic Pressure Operation: 49 dB (A) or less, Standby: 35 dB (A) or less
Acoustic Power Operation: 6.3 Bels or less
Operation Panel Display Large LCD: 16 columns x 1 rows, Key x 11, LED x 5
Language on LCD US-English, French, German, Italian, Spanish, Chinese (simplified),
Korean, Japanese (Kanji), Russian
Hard Disk
Interface USB2.0 Hi-Speed
Type Built-in
Mode Full Speed (12 Mbit/sec), High Speed (480 Mbit/sec), Bulk transfer
Connector Type Series B (4 pins)
Ethernet Type Built-in
Standard IEEE 802.3 10base-T, IEEE 802.3u 100base-TX / Auto Negotiation,
IEEE 802.3 x Full Duplex
Protocol IPX/SPX (Netware 3.2(J), 4.1 (J), 4.11(J), 4.2(J), 5.0(J), 5.1(J)
SNMP (Canon-MIB), HTTP, TCP/IP, AppleTalk
IEEE1394 (0ption)
Type Slot card type
Standard IEEE1394 – 1995, P1394a, Half duplex, Data/Strb differential serial
Data-transfer time 100 / 200 / 400 Mbit/sec.
Connector type In compliance with IEEE1394 – 1995, 6 pins, No power supply
Operating Systems supported Windows 2000, XP, Vista 32 bit/64 bit,
Macintosh OS 9, OS 10, Leopard
Software bundled ImagePROGRAF Printer Driver 2007 (Win/Mac),
imagePROGRAF Status Monitor, Media Configuration Tool,
Print Plug-in for Photoshop, Print Plug-in for Digital Photo Professional,
Digital Photo Front-Access, PosterArtist Lite
Regulations CE Mark, CB Certification
PRINT HEAD
Model PF-03
Type Bubble-jet on demand
Head configuration 6 colours integrated type (6 chips per print head x 2 print heads)
Nozzle pitch 1,200 dpi x 2
Nozzle per chip 2,560 nozzles per chip
Droplet size 4pl per colour
INK TANK
Model PFI-101 (130ml C, M, Y, PC, PM, R, G, B)
PFI-103 (130ml BK, MBK, GY, PGY)
MEDIA HANDLING
Roll-paper One roll, Top-loading, Front Output
Cut-Sheet Manual Feed (1 sheet), Front Loading and Front Output.
Top Loading and Front Output
Media Type
Roll medias Standard Paper 80gsm/90gsm,
Matt Coated Paper 90gsm/120gsm/140gsm,
Extra Matt Coated 180gsm, Opaque Paper 120gsm,
High Resolution Graphic Paper – Self Adhesive 140gsm,
High Resolution Barrier Paper 180gsm,
Glossy Photo Paper 190gsm/240gsm,
Instant Dry Paper Glossy 200gsm, Instant Dry Paper Satin 200gsm,
Photo Paper High Gloss 255gsm, Photo Paper Semi Matt 255gsm,
Photo Paper Pearl 260gsm, Photo Realistic Paper 210gsm,
Heavy Weight Glossy Photo Paper 300gsm,
Heavy Weight Satin Photo Paper 300gsm,
Commercial Proofing Paper 200gsm,
Commercial RC Proofing Paper 210gsm/270gsm,
Glossy Proofing Paper 195gsm,
Semi Glossy Proofing Paper 195gsm/255gsm,
Art Paper Extra Smooth 250gsm,
Premium Art Paper Embossed 225gsm,
Premium Art Paper Smooth 225gsm,
Water Resistant Art Canvas 340gsm, Scrim Banner 370gsm,
Backlit Film 160, Universal Opaque Film 170,
Roll-Up Film 180, Matt Stretch Vinyl 270.
Media Size
Roll Paper (width) ISO: A3, A2, A1 Others: 8”, 10”, 14”, 16”, 17”, 24” B4, B2,
300mm, A3+
Cut Sheet ISO: A4, A3, A3+, A2, A2+, A1 B4, B3, B2, DIN: C4, C3, C2,
JIS: B4, B3, B2,
ANSI: 8.5 x 11”, 8.5 x 14”, 11 x 17”, 13 x 19”, 17 x 22”, 22 x 34”
ARCH: 9 x 12”, 12 x 18”, Photo: 14 x 17”, 12 x 16”, 10 x 12”, 10 x
15”, 8 x 10”, 16 x 20”, (US Photo Size), 18 x 24”, 24 x 36”
Poster: 20 x 30”, 300 x 900 mm
Media Thickness Roll Paper & Cut Sheet: 0.07 – 0.8 mm, Front Manual Feed: 0.5 – 1.5
mm
Maximum Outside Diameter
of Roll Paper 150.0 mm
Media Core Size Internal diameter of roll core: 2” / 3”
Media Width Roll Paper: 203 – 610 mm
Cut Sheet: 203.2 – 610 mm
Minimal Printable Paper Length 203 mm
Maximum Printable Paper Length Roll paper: 18 m (varies according to the OS and application)
Cut Sheet: 1.6 m
Margins (Top, Bottom, Sides)
Recommended Area Roll Paper: Top: 20 mm, Bottom: 5 mm, Side: 5 mm
Cut Sheet: Top: 20 mm, Bottom: 27 mm, Side: 5 mm
Printable Area Roll Paper: Top: 3 mm, Bottom: 3 mm, Side: 3 mm
Roll Paper (borderless print): Top: 0 mm, Bottom: 0 mm, Side: 0 mm
Cut Sheet: Top: 3 mm, Bottom: 23 mm, Side: 3 mm
Media Width for
Borderless Printing 257 mm (JIS B4), 329 mm (JIS A3+), 420 mm (ISO A2),
431.8 mm (ISO A2+/17”), b2 (515 mm), A1 (594 mm),
10”, 14”, 16”, 24” (610 mm)
OPTION
Printer Stand ST-25
Roll Holder Set (2-inch core
spindle with 3-inch media
tube attachment and
borderless printing space) RH2-24
IEEE1394 Expansion Board EB-05
CONSUMABLES
Ink Tank (130ml) PFI-101 (C, M, Y, PC, PM, R, G, B), PFI-103 (BK, MBK, GY, PGY)
Print Head PF-03
Maintenance Cartridge MC-16
Some images are simulated for clarity of reproduction. All data is based on Canon’s standard testing methods. This leaflet
and the specifications of the product have been developed prior to the date of product launch. Final specifications are subject
to change without notice. ™ and ®: All company and/or product names are trademarks and/or registered trademarks of their
respective manufacturers in their markets and/or countries.
Canon recommends you use Canon Media for the best results. Please check media (paper) compatibility list to see which vari-
ety of paper/media is recommended.
Superior print quality only comes with Canon ink and media.
Specifications iPF6100 / iPF6200
English-UK Edition 0127W500 -
5026173428729
© Canon Europa N.V., 2008 (0908)
