Canon PCL PRINTER KIT-Jl Operating and maintenance manual

PCL PRINTER KIT-J1
Installation Procedure
PUB No.F-IM-6472-000 PRINTED IN JAPAN or CHINA
Follow the instructions herein when installing the PCL PRINTER KIT-J1 to its host
machine. E N G L I S H
All manuals and user guides at all-guides.com
all-guides.com

2
1.1 Checking components
1.1.1 Checking the Contents
F-1-1
[1] 32MB ROM 1 pc.
[2] 256MB RAM 1 pc.
[3] Screw (binding; M3x4) 1 pc.
[4] User software CD-ROM 1 pc.
[5] Release Note 1 pc.
[6] User's Manual CD-ROM 1 pc.
[1] [2] [3]
[4] [5] [6]
All manuals and user guides at all-guides.com

3
1.2 Installation procedure
1.2.1 Mounting to the
Host Machine
1) Turn off the main power switch, and disconnect the
power plug.
2) Remove the rear cover [1].
- 4 screws [2]
F-1-2
3) Remove the rear left cover [1].
- 3 screws [2]
F-1-3
4) If a Super G3 Fax Board-T1 is found, disconnect
the connector [1] of the IP-modem cable.
If an optional Super G3 Fax Board-T1 is found, the
SDRAM and the super capacitor remain powered to
back up the image memory (even after the main power
switch has been turned off and the power plug has
been disconnected).
Be sure to disconnect the IP modem cable before
removing the RAM.
F-1-4
5) Remove the RAM cover [1].
- 4 screws [2]
F-1-5
[1]
[2]
[1]
[2]
[1]
[2]
[1]
All manuals and user guides at all-guides.com

4
6) Remove the 128MB RAM [1] in the direction of
[A].
- 2 locking levers [2] (shift in the direction of [B])
F-1-6
7) If a UFRII LT PRINTER KIT-J2 is installed,
perform steps 7-1) and 7-2).
7-1) Remove the LAN cover [1].
- 4 screws [2]
F-1-7
7-2) Disconnect the connector [1] of the IP-LAN
cable.
- 1 wire saddle [2]
- IP-LAN cable [3]
F-1-8
8) Disconnect the soft ID cable [1].
- 1 cable clamp [2]
F-1-9
9) Release the claw [1] of the cable guide, and free the
cable guide [2] in upward direction.
F-1-10
[2] [1]
[B]
[B]
[A]
[2]
[1]
[2]
[1] [2]
[3]
[1]
[2]
[1]
[2]
All manuals and user guides at all-guides.com

5
10) Remove the IP cover [1].
- 10 screws [2]
F-1-11
11) Shift the 2 locking levers [1] back to their initial
position.
F-1-12
12) Connect the connector [1] of the 32MB ROM to
the connector [2] of the IP PCB.
- 1 screw (binding; M3x4) [3]
F-1-13
13) Attach the IP cover you removed in step 10).
When attaching the IP cover, take care not to damage
the grounding plate [2] by the USB port [1].
Also, after attaching the IP cover, check to make sure
that the grounding plate is in firm contact with the
USB port.
F-1-14
[2]
[2]
[2]
[1]
[1]
[1] [2]
[3]
[1]
[2] [2]
All manuals and user guides at all-guides.com

6
14) Put all the parts that you have removed back in
place.
- cable guide
- soft ID cable
- IP-LAN cable (if a UFRII LT PRINTER KIT-J2
is mounted)
15) Attach the LAN cover removed in step 7-1).
(if a UFRII LT PRINTER KIT-J2 is mounted)
When attaching the LAN cover, take care not to
damage the grounding plate [2] by the LAN port [1].
Also, after attaching the LAN cover, check to make
sure that the grounding plate is in firm contact with the
LAN port.
F-1-15
16) Mount the 256MB RAM [1].
F-1-16
17) Put back the parts that have been removed.
- RAM cover
- the connector of the IP-modem cable (if a Super
G3 Fax Board-T1 is mounted)
- rear left cover
- rear cover
18) Connect the power plug, and turn on the main
power switch.
1.2.2 Checking the
Connection
When you have installed the kit, go through the
following to make sure that it is properly recognized:
1) Start service mode.
User Mode key > 2 > 8 > Use Mode key
In response, [#SSSW] appears.
2) Press [ ] 5 times. When [REPORT] has
appeared, press [OK].
3) Press [ ] once. When [REPORT OUTPUT]
has appeared, press [OK].
4) Press [ ] 5 times. When [SPEC LIST] has
appeared, press [OK].
5) See that a SPEC REPORT is printed out. Check to
be sure that 'PCL' is 'ON'.
[1]
[2] [2]
[1]
