Canon Printing Using a Direct Camera/Printer Connection Guide Direct... Instruction Manual

Direct Print User Guide
Printing Using a Direct Camera/Printer Connection
Guide d’utilisation de l’impression directe
Imprimer au moyen d’une connexion directe appareil photo/imprimante
Guía del usuario de impresión directa
Impresión mediante una conexión directa entre una cámara y una impresora
zDepending on your camera model, some printing instructions may also be included
in the Camera User Guide. However, you must read this guide as well for complete
printing instructions.
zSelon le modèle d’appareil photo, certaines instructions d’impression peuvent aussi
se trouver dans le Guide d’utilisation de l’appareil photo. Vous devez cependant lire
également le présent guide pour disposer de l’ensemble des instructions
d’impression.
zDependiendo de su modelo de cámara, algunas instrucciones de impresión también
pueden aparecer en la Guía de usuario de la cámara. Sin embargo, deberá leer
también esta guía para tener unas instrucciones de impresión completas.
ESPAÑOL
FRANÇAIS
ENGLISH

ENGLISH
Direct Print User Guide
Printing Using a Direct Camera/Printer Connection
Depending on your camera model, some printing instructions may also be included in
the Camera User Guide. However, you must read this guide as well for complete
printing instructions.

2
The following printers can be connected to your camera. Printing operations may vary
depending on your printer model. After you have connected the camera to the printer,
check the icon that appears in the upper left corner of the camera’s LCD monitor and
refer to the relevant pages accordingly.
* When connecting a Non-Canon PictBridge Compliant camera, please refer to the camera’s user guide.
** CP-100/CP-10: Direct Interface Cable DIF-100 (Supplied with the printer)
Confirm Your Printer Model
zFor camera and printer connection instructions, please refer to page 5.
Printer
Canon Printer Non-Canon
PictBridge
Compliant
Printers
CP Printer Bubble Jet Printer
PictBridge
Compliant*
Canon
Direct Print
Compatible
PictBridge
Compliant*
Canon
Direct Print
Compatible
Cable
USB Interface Cable
IFC-300PCU**
(Supplied with the camera)
USB Interface
Cable
IFC-300PCU
(Supplied with the
camera)
See your
Bubble Jet
printer’s user
guide.
USB Interface
Cable
IFC-300PCU
(Supplied with the
camera)
LCD
Monitor
Display
PictBridge Compliance
This camera complies with the industry standard “PictBridge”*. This allows you to also
connect your camera to non-Canon PictBridge compliant printers and print images
with simple operations using the camera buttons.
* PictBridge: PictBridge is a new industry standard for direct printing that allows you to print images
without using a computer by directly connecting digital cameras and digital camcorders (hereafter
“camera”) to a printer, regardless of the devices’ brand and model.
Printing Selected Images with DPOF Settings
This option allows you to select images for printing and print settings, such as the
number of copies, with the camera (DPOF* print settings). This is very
convenient when you want to print several images at once or have them printed
at a photo lab.
* Digital Print Order Format
Please see the Camera User Guide for details on how to select DPOF print settings.
This guide explains how to print images that have already been selected.
Canon Direct
Printing with
CP Printers
p. 6 – 12
PictBridge
Printing with
Bubble Jet
Printers
p. 13 – 21
Canon Direct
Printing with
Bubble Jet
Printers
p. 22
PictBridge
Printing with
Non-Canon
Printers
p. 23

3
Table of Contents
Read This First . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Camera/Printer Connection . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Canon Direct Printing with CP Printers . . . . . . . . . . . . . .6
PictBridge Printing with Bubble Jet Printers . . . . . . . . .13
Canon Direct Printing with Bubble Jet Printers. . . . . . .22
PictBridge Printing with Non-Canon Printers . . . . . . . .23
Settings that Can Be Set with the Camera . . . . . . . . . . . . . .24
Trademark Acknowledgements
zCanon, PowerShot and Bubble Jet are trademarks of Canon, Inc.
zOther names and products not mentioned above may be registered trademarks or
trademarks of their respective companies.
Copyright ©2003 Canon Inc. All rights reserved.
Disclaimer
zNo part of this guide may be reproduced, transmitted, transcribed, stored in a
retrieval system, or translated into any language in any form, by any means, without
the prior written permission of Canon.
zCanon reserves the right to change the specifications of the hardware described
herein at any time without prior notice.
zWhile every effort has been made to ensure that the information contained in this
guide is accurate and complete, no liability can be accepted for any errors or
omissions.
zCanon makes no warranties for damages resulting from corrupted or lost data due
to a mistaken operation or malfunction of the camera, the software, the memory
cards, personal computers, peripheral devices, or use of non-Canon memory
cards.

4
Read This First
Preparing the Camera and the Printer
* Some camera models do not come with a compact power adapter.
Connecting the Camera to the Printer
Please refer to page 5 to correctly connect your camera.
zFor details regarding the printer connection settings, refer to the user guide that
came with it.
Printing
Use the camera controls to select settings and start printing. Some printers may be
equipped with an operation panel, but printing cannot be performed from the panel.
Printing operations may vary depending on your printer model. Please refer to the
reference pages in the Confirm Your Printer Model section (p. 2).
Printing Procedures
Camera When printing, the use of the compact power adapter* (separately sold
and/or included with the camera) is recommended. If a battery pack or
batteries are used, be sure to use a fully charged battery pack or new
batteries. For details, see the Camera User Guide.
Printer Please refer to the user guide that came with your printer and make the
necessary preparations (paper, ink cassette, cartridge, etc.).
For the latest information regarding connections between Canon printers and
cameras, please refer to the following URL:
http://web.canon.jp/Imaging/BeBit-e.html

5
Camera/Printer Connection
Connect the camera to the printer using the following procedures. (Please refer to your
printer user guide for details about the printer connection.)
zOnce the camera and printer are ready for printing, the , or icon appears
on the camera’s LCD monitor.
zPrinting procedures differ according to the icon that appears on the LCD monitor
(p. 2).
Before You Connect the Camera
zPrepare the printer. (Refer to the printer’s user guide.)
zConfirm which connection cable should be used (see page 2).
1
Connect the camera to the printer.
2
Turn the printer’s power on.
3
Set the camera to Playback mode and turn the power on.
Some camera models power up when the printer’s power is turned on.
4
, or appears on the upper left corner of the LCD
monitor. You can now print.
zThe following operations are not available during a camera/printer connection.
• Movie playback.
• Language settings that use the SET button and the MENU button.
Disconnecting the Camera and the Printer
1. Detach the cable from the printer.
2. Turn the camera’s power off.
3. Detach the cable from the camera.
• When you detach the cable, hold the plug and do not pull by the cable.
Camera: Connect the cable to the DIGITAL terminal.
Printer: Refer to the printer's user guide.
To Printer
This illustration shows the PowerShot S400DIGITAL ELPH/
DIGITAL IXUS 400 as an example.
DIGITAL terminal

6
Canon Direc
t
Printing with CP Printer
s
Printing
1
Make sure that displays in the
upper left corner of the LCD monitor.
2
Display the images you wish to print
and press the SET button.
The print order screen appears.
3
Select print settings as required.
4
Select [Print] and press the SET button.
You cannot print movies or images recorded in the RAW format.
Cancel Printing
zTo cancel printing between images printed, press the SET button. Once the
current print is finished, a confirmation dialog appears. Select [OK] and press
the SET button.
Printing Errors
zAn error message appears if an error occurs for some reason during the
printing process. Select [Stop] or [Resume] and press the SET button.
The [Resume] option may not appear with some types of errors. In that case,
select [Stop].
Print Order Screen
Setting the Print Style (p. 7)
Selecting the Number of Copies (p. 7)
Setting the Printing Area (Trimming) (p. 8)

7
Canon Direct Printing with CP Printers
Selecting the Number of Copies
Setting the Print Style
You can select from among the following print styles.
* This option can be selected when printing on card size paper.
Selecting Print Settings
1
In the print order screen, select [Copies] and specify the
number of copies.
You can specify from 1 to 99 prints.
Image Standard Prints one image per page.
Multiple* Prints eight copies of the same image on one page.
Borders Borderless Prints right to the edges of the page.
Bordered Prints with a border.
Date On Adds the date to the print.
Off Prints without the date.
1
In the print order screen, select [Style] and press the SET
button.
2
Select [Image], [Borders], or [Date].
3
Select settings as needed.

Canon Direct Printing with CP Printers
8
Setting the Printing Area (Trimming)
You can specify which portion of an image gets printed.
Please set the Print Style (Image, Paper, Borders and Date) first before setting the
trimming settings. If the print style is changed after having made trimming settings, you
must select the settings again.
4
Press the MENU button to end the
setting selection process.
With borderless or multiple prints, the top, bottom and
sides of the image may be cropped slightly. If you
have not specified a trimming setting, a frame will
appear around the area of the image that will be
printed, allowing you to check the portion that will be
cropped.
zWhen printing multiple prints, the borders and the date cannot be set. (Images
are printed without any date or borders)
zPractically all of the image area displayed on the LCD monitor is printed on
bordered prints.
With the PowerShot A60, the printing area settings differ. Please refer to the
Specifying the Printing Area (PowerShot A60) section in the Camera User Guide.
1
In the print order screen, select
[Trimming] and press the SET button.
The trimming frame will appear at the center of the
image. If a trimming setting has already been selected
for the image, the frame will appear around the
previously selected portion.
The trimming setting screen differs depending on the camera model. Check which
of the following screens appear before selecting settings.
Print Area Frame
Steps 2a and 3a
Trimming Frame
Steps 2b and 3b

9
Canon Direct Printing with CP Printers
2a
Trim the image.
Changing the Size of the Trimming Frame
zPress the zoom lever or the zoom button to adjust the size of the trimming
frame.
zThe trimming frame can be changed to a minimum selection of approximately
half the displayed image or a maximum selection that is virtually the same size
as the image.
zExpanding the trimming frame beyond its maximum size cancels the trimming
setting.
zWhen printing an image that has been magnified using the trimming option,
the image quality may become coarser and grainier depending on the level of
magnification. If this happens, the trimming frame displays in red.
Moving the Trimming Frame
zMove the trimming frame using the multicontroller or the up, down, right and
left buttons.
Rotating the Trimming Frame
zYou can rotate the trimming frame by pressing the DISP. button or the
DISPLAY button.
3a
Press the SET button to close the setting menu.
Pressing the MENU button cancels the settings.
2b
Trim the image.
Changing the Size of the Trimming Frame
zPress the up and down buttons to adjust the size of the trimming frame.
zThe trimming frame can be changed to a minimum selection of approximately
half the displayed image or a maximum selection that is virtually the same size
as the image.
zExpanding the trimming frame beyond its maximum size cancels the trimming
setting.
zWhen printing an image that has been magnified using the trimming option,
the image quality may become coarser and grainier depending on the level of
magnification. If this happens, the trimming frame displays in red.
Rotating the Trimming Frame
zYou can rotate the trimming frame using the left and right buttons.
Moving the Trimming Frame
zPress the SET button and use the up, down, right and left buttons to move the
trimming frame. Pressing the SET button again allows you to change the size
of the frame and to rotate it.
3b
Press the MENU button, select [OK]
and press the SET button.
Selecting [Cancel setting] cancels the selected
trimming setting. If [Edit] is selected, the display
returns to the previous screen.

Canon Direct Printing with CP Printers
10
For instructions on how to set DPOF print settings, please refer to the DPOF
print settings section of the Camera User Guide.In this section, we will explain how
to print several images already specified with DPOF print settings.
zThe trimming setting only applies to one image.
zThe trimming setting is canceled with the following operations.
• When you set the trimming settings for another image.
• When you close the Print mode (when you turn the camera power off,
change the camera mode, or detach the connection cable).
zThe selected image, paper and border settings determine the shape of the
trimming frame.
zPlease use the LCD monitor to set the trimming settings. The trimming frame
may not display correctly on a TV screen.
Printing with DPOF Print Settings
1
In the [ (Play)] menu, select [Print
Order] and press the SET button.
2
Select [Print] and press the SET
button.
3
Set the print style settings as
required.
zSee Setting the Print Style (p. 7).
zA print style cannot be set if the print type is set to
[Index] in the DPOF print setting.

11
Canon Direct Printing with CP Printers
4
Select [OK] and press the SET button.
The image will start to print and, when it is completely
finished, the display will revert to the standard
playback mode.
zTo print the date, set the [Date] setting in the print order menu in Step 2 to [On].
You cannot set the date to print with the [Style] menu in Step 3.
zWhen the print type is set to Index, the date cannot be printed.
zWhen the print type is set to Standard, the file number cannot be printed.
zThe maximum number of images printed on one page in the Index print type
depends on the selected paper size.
• Card Size: 20 images
• L Size: 42 images
• Postcard Size: 63 images
Cancel Printing
zTo cancel printing between images printed, press the SET button.
Once the current print is completed, a confirmation dialog appears. Select [OK]
and press the SET button.
Restarting Printing
zIn the print order menu, select [Resume] and press the SET button. The
remaining images can be printed.
zPrinting cannot be restarted under the following circumstances.
• If the print settings have been changed before restarting.
• If the image for which the print settings were set has been deleted before
restarting.
• If there was very little free space on the memory card when the printing was
canceled.
If these circumstances apply, you can select [OK] in the print order menu and
reprint starting from the first image.
zIf printing is canceled because the camera battery is depleted, you are
recommended to power the camera with a compact power adapter* (sold
separately and/or included). If you are using a battery pack or batteries, please
use either a fully charged battery pack or new batteries. After replacing the
spent battery pack or batteries, turn the camera power on again.
* Some camera models do not come with a compact power adapter.
Printing Errors
zAn error message appears if an error occurs for some reason during the
printing process. Select [Stop] or [Resume] and press the SET button.
zThe [Resume] option may not appear with some types of errors. In that case,
select [Stop].

Canon Direct Printing with CP Printers
12
The following messages may appear on the camera’s LCD monitor when an error
occurs during a camera and CP printer connection. (Depending on the CP printer
model, some messages may not display.)
zPlease refer to the CP printer’s user guide for solutions.
List of Messages
No Paper Paper cassette is incorrectly inserted or out of paper. Or the paper
feed is not operating correctly.
No Ink The ink cartridge has not been inserted or has run out of ink.
Incompatible paper size Wrong paper size is loaded in the printer.
Incompatible ink size Wrong ink cassette size is loaded in the printer.
Ink Cassette Error The ink cassette is experiencing a problem.
Paper and ink do not
match
The paper and ink are from different sets.
Paper Jam The paper jammed during printing.
Paper has been
changed
Paper was changed after the print menu was displayed.
Recharge the printer
battery
The printer’s battery pack is depleted.
Communication Error The printer is experiencing a data transmission error.
Readjust trimming You attempted to print the image with a different style than the one
used when the trimming settings were set.
Cannot Print!
You attempted to print an image from another camera, one
recorded in a different format, or one that has been edited on a
computer.
Could not print xx
images
You attempted to use the DPOF print settings to print xx images
that are from another camera, that have been recorded in a different
format, or that have been edited in a computer.

13
PictBridg
e
Printing with Bubble Jet
Printers
PictBridge Printing
1
Make sure that displays in the
upper left corner of the LCD monitor.
If appears on the LCD monitor, please refer to
Canon Direct Printing with Bubble Jet Printers
(p. 22).
2
Display the images you wish to print and press the SET
button.
The print order screen appears.
Depending on the Bubble Jet printer model, some setting options may not
display.
3
Select print settings as needed.
4
Select [Print] and press the SET button.
The image will start to print and, when it is completely finished, the display will
revert to the standard playback mode.
You cannot print movies or images recorded in the RAW format.
Sets the date On or Off (p. 14)
Sets the print effect (p. 15)
Sets the number of copies (p. 15)
Sets the trimming portion (p. 16)
Sets the paper size, type
and layout (p. 18)
Starts the printing process

PictBridge Printing with Bubble Jet Printers
14
Setting the Date Printing Option
Cancel Printing
zTo cancel printing between images, press the SET button. A confirmation
dialog will display. Select [OK] and press the SET button.
The printer will stop printing the current image and eject the paper.
Printing Errors
zAn error message appears if an error occurs for some reason during the
printing process. Select [Stop] or [Continue] and press the SET button.
Depending on the type of error, printing may resume once the problem is
solved. See List of Messages (p. 21) for details.
zOn Bubble Jet printers equipped with an operation panel, an error number
displays on the panel. Please refer to the Bubble Jet printer user guide for the
remedies corresponding to the error numbers.
Selecting Print Settings
Available settings differ depending on the Bubble Jet printer model. Some
settings are not available (they will not appear in the menu). For details, refer to
the user guide that came with your Bubble Jet printer.
Default Setting
zThe [Default] option is a fixed setting of the Bubble Jet printer.
zThe [Date], [Print Effect], paper setting [Paper Type] and [Layout] options are
available. When [Default] is selected, images are printed with the Bubble Jet
printer’s settings.
zThe setting contents of the Default option differ depending on the Bubble Jet
printer model. For details, please refer to the Bubble Jet printer user guide.
1
Select [ ] and set [On], [Off] or
[Default].

15
PictBridge Printing with Bubble Jet Printers
Setting the Print Effect
This function uses the camera’s shooting information to optimize the image data,
yielding high quality prints. You can select the following print effects.
Setting the Number of Copies
On Uses the camera’s shooting information to deliver beautiful prints.
Off Prints without any effects.
VIVID Prints more vibrant colors, such as the green of trees or the blue of the sea or
sky, than the [On] option.
NR Prints with a noise reduction effect.
VIVID+NR Prints using both the [VIVID] and [NR] options.
Default Print settings differ according to your Bubble Jet printer model.
1
Select [ ] and choose a print effect
option.
1
Select [ ] and set the number of
prints.
1 to 99 copies can be set.

PictBridge Printing with Bubble Jet Printers
16
Setting the Printing Area (Trimming)
Please set [Paper Settings] first (p. 18) before setting the trimming settings. If the print
style is changed after having made trimming settings, you must select the settings
again.
1
Select [Trimming] and press the SET
button.
The trimming frame will appear at the center of the
image. If a trimming setting has already been selected
for the image, the frame will appear around the
previously selected portion.
The trimming setting screen differs depending on the camera model. Check which
of the following screens appear before selecting settings.
2a
Trim the image.
Changing the Size of the Trimming Frame
zPress the zoom lever or the zoom button to adjust the size of the trimming
frame.
zThe trimming frame can be changed to a minimum selection of approximately
half the displayed image or a maximum selection that is virtually the same size
as the image.
zExpanding the trimming frame beyond its maximum size cancels the trimming
setting.
zWhen printing an image that has been magnified using the trimming option,
the image quality may become coarser and grainier depending on the level of
magnification. If this happens, the trimming frame displays in red.
Moving the Trimming Frame
zMove the trimming frame using the multicontroller or the up, down, right and
left buttons.
Rotating the Trimming Frame
zYou can rotate the trimming frame by pressing the DISP. button or the
DISPLAY button.
3a
Press the SET button to close the setting menu.
Pressing the MENU button cancels the settings.
Trimming Frame
Steps 2a and 3a Steps 2b and 3b

17
PictBridge Printing with Bubble Jet Printers
2b
Trim the image.
Changing the Size of the Trimming Frame
zPress the up and down buttons to adjust the size of the trimming frame.
zThe trimming frame can be changed to a minimum selection of approximately
half the displayed image or a maximum selection that is virtually the same size
as the image.
zExpanding the trimming frame beyond its maximum size cancels the trimming
setting.
zWhen printing an image that has been magnified using the trimming option,
the image quality may become coarser and grainier depending on the level of
magnification. If this happens, the trimming frame displays in red.
Rotating the Trimming Frame
zYou can rotate the trimming frame using the left and right buttons.
Moving the Trimming Frame
zPress the SET button and use the up, down, right and left buttons to move the
trimming frame. Pressing the SET button again allows you to change the size
of the frame and to rotate it.
3b
Press the MENU button, select [OK]
and press the SET button.
Selecting [Cancel setting] cancels the selected
trimming setting. If [Edit] is selected, the display
returns to the previous screen.
zThe trimming setting only applies to one image.
zThe trimming setting is canceled with the following operations.
• When you set the trimming settings for another image.
• When you close the Print mode (when you turn the camera power off,
change the camera mode, or detach the connection cable).
zThe selected image, paper size and border settings determine the shape of the
trimming frame.
zPlease use the LCD monitor to set the trimming settings. The trimming frame
may not display correctly on a TV screen.

PictBridge Printing with Bubble Jet Printers
18
Selecting the Paper Settings
1
Select [Paper Settings] and press the
SET button.
The paper size setting screen appears.
2
Select a paper size and press the SET
button.
The following paper sizes* are available: 8.5” ×11” or
A4, 5” ×7” or 13 ×18 cm, 4” ×6” and Default.
• Some sizes are not available with certain Bubble
Jet printer models.
• The paper type setting screen appears.
* Paper sizes vary according to region.
3
Select a paper type and press the SET
button.
The following paper types can be selected.
* Canon brand paper
The Page Layout screen appears.
4
Select a layout.
The following print effects can be selected.
5
Select a layout and press the SET button. This ends the
paper settings operations.
The display returns to the print order screen.
With Bubble Jet printers, when [Plain Paper] is selected with the printer and
[Default] is selected in the camera’s [Paper Type], images will print with borders,
even if [Borderless] was selected with the camera.
Photo Prints on Photo Paper Plus Glossy paper*.
Fast Photo Prints on Photo Paper Pro paper*.
Default Print settings differ according to your
Bubble Jet printer model.
Borderless Prints right to the edges of the page.
Bordered Prints with a border.
Default Print settings differ according to your
Bubble Jet printer model.
