Canvas 088-1682-2 User manual

ASSEMBLY INSTRUCTIONS
Toll-free: 1-888-670-6684
IMPORTANT: Please read this manual carefully before beginning assembly of this product.
Keep this manual for future reference.
Day Bed and Swing
MODEL NO. 088-1682-2
VALENCIA COLLECTION

TABLE OF CONTENTSIMPORTANT SAFETY INSTRUCTIONS
Important Safety Instructions
2
TABLE OF CONTENTS
2
Parts List 3
Assembly 5
Cleaning and Maintenance 14
Technical Specifications 14
Warranty 14
IMPORTANT: Retain for future reference, and read carefully.
• SET UP YOUR FURNITURE PROPERLY
Ensure that all parts are assembled properly and fully tightened as per the instructions.
When placing in the desired location, ensure that all legs are resting on the same surface.
You may adjust the legs levellers as required to ensure that the item stands in a rigid position.
• EXAMINE YOUR FURNITURE
Examine occasionally to ensure that there are no loose parts. If loose parts are found,
they must be retightened fully before additional use.
• Do not completely tighten bolts and nuts until indicated in assembly step.
2MODEL NO. 088-1682-2

3
PARTS LIST
Leg post - 2
Leg post - 2
1
2
Side panel - 2
3
Long top crossbar - 2
4
Short top crossbar - 2
5
Rear leg crossbar - 1
6
7
8
9
10
11
Right arm - 1
Left arm - 1
Front seat support bar - 1
Rear seat support bar - 1
Seat and back - 1
12
Hanging bar - 4
13
Large canopy frame - 1
14
Canopy frame bar - 4
15
16
17
18
19
20
21
22
A
B
C
Net - 1
Throw pillow - 2
M6*25 bolt - 2
M6*30 bolt - 4
D
M6*36 bolt - 2
E
M8*15 bolt - 4
F
M8*35 bolt - 8 + 1 spare
Small canopy frame - 2
Small canopy frame bar - 1
Cushion - 1
Pillow - 2
Large canopy - 1
Small canopy - 1
M6*12 bolt - 4

PARTS LIST
G
H
I
J
K
L
M
N
O
P
Q
Plastic washer - 2
S-hook - 2
U-bracket - 4
Open wrench - 1
Hex wrench - 1
R
M8 wrench - 1
M8*60 bolt - 4
M8*80 bolt - 2
M6 nut - 4
M8 nut - 6
M6 metal washer - 4
M8 metal washer - 22
4MODEL NO. 088-1682-2

Needed for assembly:
2 people
ASSEMBLY PREPARATION
Let us help you!
DO NOT RETURN YOUR PRODUCT TO THE STORE. CALL US FIRST!
1-888-670-6684
If you have questions regarding your product, require warranty
assistance, or have damaged or missing parts, please call our customer
service toll-free helpline. Contact us for assistance; we’re here to help.
IMPORTANT:Please read and understand this manual before any assembly. Before beginning
assembly of product, make sure all parts are present. Compare parts with packaging contents
list. If any part is missing, or if you have any questions, contact the service centre at
1-888-670-6684 (toll-free).
Place all parts from the box in a cleared area and position them on the floor in front of you.
Remove all packing materials and place them back into the box. Do not dispose of the packing
materials until assembly is complete. Read each step carefully before beginning any assembly
and make sure you understand each step. If you are missing a part, please call our toll-free
number for assistance: 1-888-670-6684 between 9:00 am to 5:00 pm Eastern standard time
Monday through Friday.
5

ASSEMBLY
Step 1
Requires 1, 2, A, O.
Insert a bolt Athrough the U-shaped bracket O, and secure into the leg top 1
or 2. Do not tighten. Repeat for the remaining 3legs.
AO
Not actual size.
Step 2
Requires 1, 2, 3, F, L.
Attach the side panel 3 to 2 legs 1 and 2by inserting a bolt F through a metal
washer L, through the hole of the side panel 3, and secure into the leg 2.
Make sure the arrow “↑↑” is pointing up. Repeat procedure for the other
leg 1. Do not tighten completely. Repeat procedure for the other side panel.
6MODEL NO. 088-1682-2
FL
Not actual size.
1
1
O
A
2
1
3
3
2
L
F

ASSEMBLY
Step 3
Requires 1, 2, 4, E, L.
Insert two long top crossbars 4into the holes at the top of each leg. Line up the
holes. For each hole insert a bolt Ethrough a metal washer L, through the leg,
and secure into the long top crossbar 4. Do not tighten completely. Repeat
procedure for the other long top crossbar.
7
Step 4
Requires 4, 5, G, J, L.
Attach a short top crossbar 5onto the long top crossbars 4. Make sure the U-shaped
brackets of the short top crossbar 5are facing down. Line up the holes. For each
hole, insert a bolt G through a metal washer L, then through the outer side of the
bracket on the short top crossbar 5, the long top crossbar 4, the inner side of the
bracket on the short top crossbar 5, another metal washer L, and secure with a
nut J. Do not tighten completely. Repeat procedure for the other side.
G
Not actual size.
EL
Not actual size.
JL
1
4
4
4
1
2
2
1
2L
E
4
L
G
LJ
5
4
4
5
5
4

ASSEMBLY
Step 5
Requires 3, 6, D, K, P, Q, R.
Place the rear leg crossbar 6between the side panels 3. Line up the holes.
Insert a bolt Dthrough a metal washer K, through the side panel 3, and secure
into the rear leg crossbar 6. Do not tighten completely. Repeat procedure for
the other side. Tighten all bolts and nuts from step 1 to step 5 by using the
wrenches provided (except bolt A).
DK
Not actual size.
Step 6
Requires 7, 8, 9, 10.
Lay out the right arm 7, left arm 8, front seat support bar 9and rear seat
support bar 10. Make sure that the labels marked “FRONT’’ on the arms and
seat support bars are all facing the front edge of the seat. Attach the seat
support bars to the arms by pressing the tabs on the ends of the seat support
bars down into the brackets on the arms. Make sure they are securely seated.
8MODEL NO. 088-1682-2
P
Q
6
3
K
D
6
3
FRONT
8
7
10
9
7
10
7
R

ASSEMBLY
Step 7
Requires 7, 8, 11, H, J, L, M, P, R.
Unfold the seat and back 11 and lay it on top of the frame. Line up the holes
in the arms 7 and 8 with the holes in the side tubes of the seat and back 11.
Insert a bolt H(from outside to inside) through the bracket of the arm, through
a plastic washer M, through the side bar on the seat and back, through a metal
washer Land secure with a nut J. Do not tighten completely. Repeat procedure
for the other side. Then securely tighten the bolts and nuts.
9
Step 8
Requires 10, 11.
Raise the back side of the seat and back 11 and fasten the U-shaped bracket of the
back support tube to the rear seat support bar 10 as per the drawing.
HJLM
11
JLM
H
8
11
7
11
11
10
Not actual size.
P
R

ASSEMBLY
Step 9
Requires 5, 7, 8, 12, N.
Attach the hanging bars 12 to the arms by sliding the bottom hole in the bars
over the pins on the outside of the arms 7 and 8. Position the bars so that the
end labelled “TOP” is up and facing toward the swing seat. At each end of the
seat assembly, bring together the holes in the top ends of the hanging bars and
thread them on to a “S” hook N. Hang the “S” hooks from the loops on the
short top crossbar 5.
N
Step 10
Requires 13, 14, 19.
Insert large canopy frame bars 14 into the large canopy frame 13 as per drawing.
Place the large canopy 19 over the assembled canopy frame 13 and 14 as shown.
10 MODEL NO. 088-1682-2
TOP
8
7
5
12
12
N
12
8
14
14
13
13
13
14
19

ASSEMBLY
Step 11
Requires 13, 15.
Insert the small canopy frame 15 into the large canopy frame 13 as per drawing.
11
Step 12
Requires 15, 16, 20, B, K.
Insert a bolt Bthrough the metal washer K, through the small canopy frame 15,
and into the small canopy frame bar 16. Repeat procedure on the other side. Do
not tighten completely. Then insert the small canopy frame 15 into the small
canopy 20.
BK
15
13
15
13
15
16
15
K
B15
20
20
16 15
Not actual size.

ASSEMBLY
Step 13
Requires
14, 19, 20, C, I, O, P, Q, R.
Place the assembled canopy top frame on the assembled swing frame. Insert a
bolt C through one side of the U shaped bracket Oat the top of the leg, through
the canopy frame bar 14, through the other side of the U shaped bracket, and
secure with a nut I. Do not completely tighten. Repeat procedure for the
remaining 3canopy frame bars 14. Tighten all bolts and nuts from step 1to
step 13 using the wrenches.
Step 14
Requires 14, 17, 18, 19, 20, 22.
12 MODEL NO. 088-1682-2
CI
19
20
14
I
C
O
19
20
14
17
18 22
Not actual size.
P
Q
R
Insert the large canopy frame 14 into the large canopy 19 and 20.
Put cushion 17, pillow 18 and throw pillow 22 on.
O

ASSEMBLY
Step 15
To convert the swing into a hanging bed, push down the spring ring-pull on rear
seat support bar 10 first.Then release the back support tube from the rear seat
support bar 10 and fasten it to the U-shaped bracket on the rear leg crossbar 6.
When used as a bed, the seat assembly should be secured by these holders and
not allowed to swing.
13
Step 16
Attach the net 21 to the large canopy 19 by
hook-and-loop strip.
The net zipper goes in the centre of the
top crossbar.
Your swing is ready for use!
Requires
19, 21.
Requires 6, 10, 11
10
10
10
11 11
10
6
11
21

14
MAINTENANCETECHNICAL SPECIFICATIONS
Dimensions (L x W x H) 208 x 131 x 229 cm
82 x 51 1/2 x 90"
Product weight 70 kg
154 lb
MODEL NO. 088-1682-2
• Though its powder-coated finish is rust-resistant, steel is prone to rust over time
with exposure to the elements. In case of rust or scratches, lightly sand the
affected area and apply touch-up paint. To maintain the finish, periodically apply
wax with a soft cloth.
• Wash frames with a mild solution of soap and water; rinse thoroughly. Do not use
bleach or solvents.
• CARING FOR OUTDOOR FURNITURE WITH CUSHIONS:
Wash frames and cushions with a mild solution of soap and water; rinse thoroughly.
Dry frame completely and allow cushions to drip-dry. Do not use bleach or solvents.
WARRANTY
This CANVAS product carries a one (1) year warranty against defects in workmanship
and materials. Trileaf Distribution agrees to replace the defective product free
of charge within the stated warranty period, when returned by the original purchaser
with proof of purchase. This product is not guaranteed against rust, wear or
breakage due to misuse and/or abuse.
Made in China
Imported by
Trileaf Distribution Trifeuil Toronto, Canada M4S 2B8
WARRANTY
Weight capacity 275 kg
600 lb
