Canvas ARC DINING TABLE 068-7597-8 User manual

MODEL NO. 068-7597-8
ASSEMBLY INSTRUCTIONS
Toll-free 1-888-670-6684
IMPORTANT: Please read this manual carefully before beginning assembly of this product.
Keep this manual for future reference.
ARC DINING TABLE

2MODEL NO. 068-7597-8
Important Safety Instructions 2
Parts List 3
Assembly 4
Warranty 8
Warning! To reduce the risk of serious injury, read the following safety
instructions before assembling and using the dining table.
• This product is intended for domestic indoor use only.
• The product should be placed on a flat horizontal surface.
• Arrange necessary manpower when assembling or moving the product.
• Do not push furniture, especially on a carpeted floor. Have someone help you lift heavy items and set it
in place.
• Check all screws periodically for tightness. When required, tighten them again.
IMPORTANT SAFETY INSTRUCTIONS TABLE OF CONTENTS

3
5/8” Hex Screw- 8
1
Spring Washer - 8
2
Flat Washer - 8
3
5/8” Hex Screw - 6
4
Hex Wrench - 1
5
PARTS LIST
Top - 1
A
Long Leg - 1
B
Brackets
Short Leg with Brackets - 1
C
Short Leg without Brackets - 1
D

4MODEL NO. 068-7597-8
ASSEMBLY
Step 1
Requires A, B, 1, 2, 3, 5
Fasten the LONG LEG (B) to the TOP (A). Tighten four 5/8” HEX SCREWS (1), four
SPRING WASHERS (2), and four FLAT WASHERS (3) using the HEX WRENCH (5).
WARNING! Do not tighten screws until you have completed assembly.
123
5
A
B

5
ASSEMBLY
Step 2
Requires B, C, D, 4, 5
Fasten the SHORT LEG WITH BRACKETS (C) to the LONG LEG (B) and SHORT
LEG WITHOUT BRACKETS (D). Tighten six 5/8” HEX SCREWS (4) using the HEX
WRENCH (5).
NOTE: The lower three screws should be fastened first.
1st
2nd
5
4
Brackets
D
B
C

6MODEL NO. 068-7597-8
ASSEMBLY
Step 3
Requires A, C, D, 1, 2, 3, 5
Fasten the SHORT LEGS (C and D) to the TOP (A). Tighten four 5/8” HEX SCREWS (1),
four SPRING WASHERS (2), and four FLAT WASHERS (3) using the HEX WRENCH (5).
A
5
1
2
3
5
1
2
3
C
D

7
ASSEMBLY
Step 4
Requires 5
Completely tighten all of the SCREWS using the HEX WRENCH (5).
Carefully stand your unit upright.
This completes assembly. Clean with your favourite furniture polish or a damp cloth.
Wipe dry.
5

8MODEL NO. 068-7597-8
WARRANTY
This CANVAS™ product carries a one (1) year warranty against defects in workmanship and
materials. Trileaf Distribution agrees to replace the defective product free of charge within the
stated warranty period, when returned by the original purchaser with proof of purchase. This
product is not guaranteed against wear or breakage due to misuse and/or abuse.
Made in China
Imported by
Trileaf Distribution Trifeuil Toronto, Canada M4S 2B8
1-YEAR LIMITED WARRANTY

N° DE MODÈLE : 068-7597-8
CONSIGNES D’ASSEMBLAGE
Numéro sans frais : 1 888 670-6684
IMPORTANT : Veuillez lire attentivement ce guide avant de procéder à l’assemblage de ce
produit. Conservez ce guide aux fins de consultation ultérieure.
TABLE ARC

10 N° DE MODÈLE : 068-7597-8
Consignes de sécurité importantes 10
Liste des pièces 11
Assemblage 12
Garantie 16
Avertissement! Pour réduire le risque de blessures graves, lisez les
consignes de sécurité suivantes avant d’assembler et d’utiliser la table.
• Ce produit est uniquement destiné à un usage domestique et doit être utilisé à l’intérieur.
• Le produit doit être placé sur une surface plane et horizontale.
• Au besoin, demandez à d’autres personnes de vous aider à assembler ou déplacer le produit.
• Ne poussez pas le meuble, particulièrement sur un plancher en tapis. Demandez à quelqu’un de vous aider
à soulever les articles lourds et à les mettre en place.
• Vérifiez périodiquement que les vis sont bien serrées. Au besoin, resserrez-les.
CONSIGNES DE SÉCURITÉ IMPORTANTES TABLE DES MATIÈRES
