Canvas CARBON 168-0068-2 User manual

CARBON NESTING SIDE TABLES
MODEL NO. 168-0068-2
ASSEMBLY INSTRUCTIONS
HAVING TROUBLE?
TOLL-FREE:
1-888-670-6684

4
8
14
14
No. 2 Phillips Screwdriver
Tip Shown Actual Size 1 person
TABLE OF CONTENTS
TOOLS REQUIRED
•
•
•
Check all screws periodically for tightness. When required, tighten them again.
Do not exceed maximum weight capacity of 22lb (10kg) on top on small table.
Do not exceed maximum weight capacity of 33lb (15kg) on large table.
WARNING! TO REDUCE THE RISK OF SERIOUS INJURY,
READ THE FOLLOWING SAFETY INSTRUCTIONS BEFORE
ASSEMBLING AND USING THE SIDE TABLES.
3
•This product is intended for domestic indoor use only.
•The product should be placed on a flat horizontal surface.
• Arrange necessary manpower when assembling or moving the product.
Do not push furniture, especially on a carpeted floor. Have someone help
you lift heavy items and set in place.
CARBON NESTING SIDE TABLES
We believe
That's why the CANVAS assortment gets
the power of decor and
how it makes up the fabric of your home.
its inspiration from Canadians and the
way they live.
From on-trend furniture pieces, to
Holiday Decor and Outdoor Living,
CANVAS m
space
ake
ee
s it easy to refresh your
your unique style and
the way you live.
We welcome your thoughtful
comments and feedback p so lease
visit our website to tell us about
your experience.
We would love to see how you bring
CANVAS to life. Please share your
photos using #mycanvasstyle.
o
Warranty
Caring for your item
Parts List/ Exploded View
Step-by-Step Instructions

4 5
ITEM DESCRIPTION QUANTITY
Metal Top 1
Metal Top Frame 1
Long Metal Legs 4
Metal Base 1
Wooden Top 1
Metal Top Frame 1
Short Metal Legs 4
Metal Base 1
PARTS LIST
1
2
3
4
5
6
7
8
CARBON NESTING SIDE TABLES CARBON NESTING SIDE TABLES
EXPLODED VIEW

6 7
ITEM DESCRIPTION QUANTITY
A Long Size Screws M6x30 16
B 8
C Small Size Screws M6x12 8
D Tapping Screws 4x30 4
E Spanner
EVA Pads
1
PARTS LIST
A
B
C
D
E
CARBON NESTING SIDE TABLES CARBON NESTING SIDE TABLES
EXPLODED VIEW
ø

8 9
STEP 1
REQUIRES A, C, E, 6, 7, 8
NOTE: Two people are needed to build this unit.
Fasten four SHORT METAL LEGS (7) to the METAL TOP FRAME (6), using four
LONG SIZE SCREWS (A). Hand tighten four LONG SIZE SCREWS.
Fasten the other end of four SHORT METAL LEGS (7) to the METAL BASE (8),
using four LONG SIZE SCREWS (A) and SMALL SIZE SCREWS (C). Hand tighten
LARGE and SMALL SIZE SCREWS (C).
Note: Ensure the SCREWS are in the exact holes.
: SMALL TABLE ASSEMBLY STEP 2
CARBON NESTING SIDE TABLES CARBON NESTING SIDE TABLES
A
A
C
AE
A
EA
6
8
A
REQUIRES D, 5, 6
Fasten the assembled SMALL FRAME to the WOODEN TOP (5),
using four TAPPING SCREWS (D).
Note: Ensure the SCREWS are in the exact holes.
Ensure all SCREWS are tightened.
STEP-BY-STEP INS STRUCTION
D

10 11
STEP 3 STEP 4
REQUIRES 1
Place the METAL TOP (1) onto the LARGE FRAME.
CARBON NESTING SIDE TABLES CARBON NESTING SIDE TABLES
REQUIRES A, C, E, 2, 3, 4
Fasten four LONG METAL LEGS (3) to the METAL BASE (4), using four
LONG SIZE SCREWS (A). Hand tighten four LONG SIZE SCREWS.
Fasten the other end of four LONG METAL LEGS (3) to the METAL TOP FRAME (2),
using four LONG SIZE SCREWS (A) and SMALL SIZE SCREWS (C).
Hand tighten LARGE and SMALL SIZE SCREWS.
NOTE: Ensure the SCREWS are in the exact holes.
Ensure all SCREWS are tightened.
: LARGE TABLE ASSEMBLY
A
A
A
A
STEP-BY-STEP INS STRUCTION
C E

12
STEP 5
Put the assembled SMALL SIZE TABLE under the LARGE SIZE TABLE.
Tear o the protective paper from the EVA PADS (B), place the adhesive
side on the bottom side of the SHORT and LONG METAL LEGS.
MAXIMUM WEIGHT CAPACITY:
This unit has been designed to support the maximum loads shown. Exceeding these load limits
could cause sagging, instability, product collapse, and/or serious injury.
Please make sure that all the objects are removed before moving the assembled unit.
13
CARBON NESTING SIDE TABLES
CARBON NESTING SIDE TABLES
B
B
B
B
B
B
B
B
33 lb (15 kg)
22 lb (10 kg)
STEP-BY-STEP INS STRUCTION
B
This completes assembly.

14
WARRANTY
CARING FOR YOUR ITEM
This CANVAS™ product carries a one (1) year warranty against defects in workmanship and
materials. Trileaf Distribution agrees to replace the defective product free of charge within the
stated warranty period, when returned by the original purchaser with proof of purchase. This
product is not guaranteed against wear or breakage due to misuse and/or abuse.
Made in China
Imported by Trileaf Distribution Trifeuil Toronto, Canada M4S 2B8
MODEL NO. 168-0068-2
Exclusively at Canadian Tire
CARBON NESTING SIDE TABLES
Do not exceed maximum weight capacity of 33 lb (15 kg) on large table.
Weight Capacity:
1
2
3Avoid direct sunlight.
Wipe clean with a damp cloth.
Do not exceed maximum weight capacity of 22 lb (10 kg) on small table.
