Canvas MONTCLERC 168-0008-6 User manual

MONTCLERC
2-DOOR CABINET
MODEL NO. 168-0008-6
ASSEMBLY INSTRUCTIONS
Toll-free: 1–888–670–6684
IMPORTANT: Please read and understand this manual before beginning assembly of the
product, and make sure all parts are present. Compare parts with packaging contents
list. If any part is missing, or if you have any questions, contact the service centre at
1–888–670–6684 (toll free).

Made in China
Imported by Trileaf Distribution Trifeuil Toronto, Canada M4S 2B8

I
3
IMPORTANT SAFETY INSTRUCTIONS
Table of Contents 3
Important Safety Instructions 3
Parts List 4
Assembly
6
19
Technical Specifications
19
Warranty
IMPORTANT: Retain for future reference, and read carefully.
I
I
D
.
I
D
I
TOP
FENCE
I
TOP
FENCE
• This product is intended for indoor use.
•The product should be placed on flat, horizontal ground.
• Any assembly or maintenance of the product must be carried out by adults only.
•Plastic bags can be dangerous. To avoid danger of suocation keep all bags
away from babies and children.
TABLE OF CONTENTS
Warning! To reduce the risk of serious injury, read the following safety
instructions before assembling and using this product.

4 MODEL NO. 168-0008-6
Right side panel - 1
Left side panel - 1
Back rail - 1
Bottom trim - 1
Fixed shelf - 1
Adjustable shelf - 2
Bottom - 1
Back panel - 1
Bottom front trim - 1
Left door panel - 1
Right door panel - 1
Top trim - 1
PARTS LIST
1
11
12
13
2
3
4
5
6
7
8
9
Top - 1
10

PARTS LIST
F
G
H
I
J
K
N
O
Cam bolt - 18
Door stop - 1
Cam - 18
Bolt M4 x 22 mm - 4
Wood dowel 7.8 x 30 mm - 24
Metal plate - 1
Screw 3.8 x 20 mm - 2
Screw 4 x 14 mm - 36
A
B
C
D
E
Hinge - 6
P
Q
Wall anchor - 2
Screw 4 x 40 mm - 2
Screw 4 x 14 mm - 6
Glue - 2
R
Connector - 1
S
Metal washer - 4
T
Fabric strip - 2
5
L
M
Nail - 28
Support - 8
Sticker - 4
Handle - 2

6 MODEL NO. 168-0008-6
ASSEMBLY
•
•
•
•
HELPFUL HINTS
Read each section carefully before starting. It is very important that each step is performed in
the correct order. If these steps are not followed in sequence, assembly diculties will occur.
Make sure all parts are included. Most board parts are labelled or stamped on the raw edge.
Work in a spacious area, preferably on a carpet, near the place the unit will be located.
Do not use power tools to assemble your furniture. Power tools may strip or damage the parts.
• Identify, sort and count the parts before beginning assembly.
• Compression dowels should be tapped in with a rubber mallet.
• Slides have a lip on the right side only.
• Back panels provide stability and support. Unit may collapse without the back panel installed.
• Clean the product with your choice of furniture polish and a soft cloth. DO NOT USE harsh
chemicals nor abrasive cleaners.
• Move your new furniture carefully. Two people are needed to lift and carry the unit to its new
location.
• Never push nor drag your furniture (especially on a carpet).
Needed for assembly:
Rubber mallet Star-head
screwdriver
Flat-head
screwdriver
2 people
Important Note:
+/- on the cam should be positioned
as shown.
Do not overtighten the cam bolt.
1. 2. 3.
4. 5.
These illustrations show how the cam fastening system works.
160°~185°

7
Step 1
Requires 6, 7, C, D, E, Q, R
Step 2
Requires 5, 8, A, C, Q
ASSEMBLY
A
C
C
E
E
Q R
Q
D
A
5
7
C
Q
8
C
Q
D
R
R
D
C
6
Q

I
D
.
I
D
.
Step 3
Requires 3, C, Q
Step 4
Requires 4, 5, B, C, Q
ASSEMBLY
8 MODEL NO. 168-0008-6
C Q
3
C
Q
B C Q
B
4
C
5
Q

9
Step 5
Requires 1, A, C, Q
Step 6
Requires 2, A, C, Q
ASSEMBLY
A
A
1
2
C
C
Q
Q
A C Q
A C Q

10 MODEL NO. 168-0008-6
Step 7
Requires 1, 3, 4, 6, 7, 8, B
ASSEMBLY
B
B 1
3
4
8
6
7

11
Step 8
Requires 1, 2, B
ASSEMBLY
B
1
2
B

12 MODEL NO. 168-0008-6
I
D
.
I
D
.
Step 9
Requires 10, A, B, E, S, T
ASSEMBLY
A
10
A B E ST
10
B
E
S
T
1
2
E
10
6

13
Step 10
Requires 9, L
ASSEMBLY
L
L
9
°90

14 MODEL NO. 168-0008-6
I
D
.
I
D
.
Step 11
Requires 11, H, I, J, K
Step 12
ASSEMBLY
Requires 12, H, I, J, K
H J K
I
H J K
I
H
I
J
K
12
H
I
J
K
11

15
Step 13
Requires 11, 12, F, G, I
ASSEMBLY
I
F
G
11
12
I
F G

16 MODEL NO. 168-0008-6
I
D
.
I
D
.
Step 14
Requires N, O, S, P
ASSEMBLY
N S P O
O
S
P
N
Wall

17
Step 15
Requires 13, M
ASSEMBLY
M
M
13
13
M

Step 17 Enjoy your furniture
WEIGHT LIMITS
Please make sure that all objects are
removed before moving the assembled unit.
The unit must be lifted by more than one person,
not dragged nor pushed. Failure to do so will
cause product damage, instability, product
collapse, and/or serious injury.
This unit has been designed to support the
maximum loads shown. Exceeding these load limits
could cause sagging, instability, product collapse,
and/or serious injury.
18 MODEL NO. 168-0008-6
I
D
.
I
D
.
ASSEMBLY
Adjust if doors
are not aligned.
Adjust if there is a
gap between doors.
Adjust if doors are
too far from/close
to the frame.
DOOR DOOR
DOOR
FRONT VIEW FRONT VIEW
SIDE VIEW
Step 16
38 lb 13 oz
(17.6 kg)
38 lb 13 oz
(17.6 kg)
38 lb 13 oz
(17.6 kg)
To adjust doors A: Loosen
A screws. Tighten A screws.
To adjust doors B: Loosen
C screws. Turn B to move
door. Tighten C screws.
To adjust doors C: Loosen
C screws. Adjust door.
Tighten C screws.

19
TECHNICAL SPECIFICATIONS
Dimensions (H x W x D) 72 x 31 3/8 x 15 3/16"
183 x 79.7 x 38.6 cm
Product weight
35.4 kg
78 lb
WARRANTY
This CANVAS product carries a one (1) year warranty against defects in
workmanship and materials. Trileaf Distribution agrees to replace a
defective product free of charge within the stated warranty period,
when returned by the original purchaser with proof of purchase. This product
is not guaranteed against wear or breakage due to misuse and/or abuse.
