Canvas PERTH 168-0073-8 User manual

PERTH KITCHEN CART WITH GRANITE TOP
MODEL NO. 168-0073-8
ASSEMBLY INSTRUCTIONS
HAVING TROUBLE?
TOLL-FREE:
1-888-670-6684

4
8
Warranty 25
Caring for your item 25
TABLE OF CONTENTS
TOOLS REQUIRED
• Check all screws periodically for tightness. When required, tighten them again.
WARNING! TO REDUCE THE RISK OF SERIOUS INJURY,
READ THE FOLLOWING SAFETY INSTRUCTIONS BEFORE
ASSEMBLING AND USING THE KITCHEN CART.
• Do not exceed maximum weight capacity of 66 lb (30 kg) on top.
3
PERTH KITCHEN CART WITH GRANITE TOP
• This product is intended for domestic indoor use only.
• The product should beplaced on a flat horizontal surface.
•
Arrange necessary manpower when assembling or moving the product.
Do not push furniture, especially on a carpeted floor. Have someone help
you lift heavy items and set in place.
Parts List/ Exploded View
Step-by-Step Instructions
We believe
That's why the CANVAS assortment gets
the power of decor and
how it makes up the fabric of your home.
its inspiration from Canadians and the
way they live.
From on-trend furniture pieces, to
Holiday Decor and Outdoor Living,
CANVAS m
space
ake
ee
s it easy to refresh your
your unique style and
the way you live.
We welcome your thoughtful
comments and feedback p so lease
visit our website to tell us about
your experience.
We would love to see how you bring
CANVAS to life. Please share your
photos using #mycanvasstyle.
o
No. 2 Phillips Screwdriver
Tip Shown Actual Size Hammer 2 people
To avoid damage, ensure screws are
hand tightened. DO NOT USE POWER
TOOLS TO ASSEMBLE YOUR UNIT

4 5
ITEM DESCRIPTION QUANTITY
1 1
2 Left End 1
3 Right End
Drawer Bottom Rail
1
4 1
5 Back Panel 1
6 Drawer Bottom Support Rails 3
7 Support Rail 1
8 Base Panels 2
9 Storage Door 1
10 Drawer front 1
11 Drawer Left 1
12 Drawer Right 1
13 Drawer Back 1
14 Drawer Bottom 1
PARTS LIST
Granite Top
PERTH KITCHEN CART WITH GRANITE TOP PERTH KITCHEN CART WITH GRANITE TOP
EXPLODED VIEW

6 7
PARTS LIST EXPLODED
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
W
ITEM DESCRIPTION QUANTITY
A Cam Bolts 12
B Hidden Cams 12
C Hooks 3
D Flat Head Screws 4
E Handle Bolt 1
F Bolts 12
G Barrel Nuts 12
H Drawer Handle 1
I Locking Wheels 2
J Wheels 2
K Slide Runners 2
L Slide Tracks 2
M Door Hinges 2
N Screws 12
O Wood Dowels 20
P Door Handle 1
Q Magnetic Catch 1
R Metal Plate 1
S Screws 15
U Wood Plugs 12
T Hook Bolts 6
WSpanner 1
PARTS LIST
PERTH KITCHEN CART WITH GRANITE TOP PERTH KITCHEN CART WITH GRANITE TOP
1
VIEW
X
Y
Z
Aa
Ab
AC
X Expansion Screws
Flat Head Screws
2
Y
Anti-tip Restraints
2
Z
Washers
2
Aa
Short Pan Head Screws
4
Ac 2
Ab 2
Handle Bolt

8 9
STEP 1 STEP 2
REQUIRES L, K
The SLIDE TRACK (L) and the SLIDE RUNNER (K) will need to be separated for assembly.
To do so, slide the SLIDE TRACK (L) slightly out from inside the SLIDE RUNNER (K) until
the TRI
In the groove of the SLIDE RUNNER (K), press the TRIGGER DISCONNECT LEVER
upwards as the same time while sliding the SLIDE TRACK (L) out.
GGER DISCONNECT LEVER is visible.
REQUIRES A, N, K, 3
Fasten one SLIDE RUNNER (K) to the RIGHT END (3), using three SCREWS (N).
Hand tighten the SCREWS.
Fasten four CAM BOLTS (A) to the RIGHT END (3).
NOTE: Ensure the screws are tightened.
PERTH KITCHEN CART WITH GRANITE TOP PERTH KITCHEN CART WITH GRANITE TOP
STEP-BY-STEP INS STRUCTION
A
N
N
N
KA
A
A
A
3
KN
K
L
K

10 11
STEP 3 STEP 4
REQUIRES A, K, N, Q, S,C,T,2
Fasten one SLIDE RUNNER (K) to the LEFT END (2), using three SCREWS (N).
Fasten the MAGNETIC CATCH (Q) to the LEFT END (2), using two SCREWS (S) .
Hand tighten the SCREWS.
Fasten four CAM BOLTS (A) to the LEFT END (2).
NOTE: Ensure the screws are tightened.
REQUIRES F, G, O,W, 1, 3, 4
Insert two BARREL NUTS (G) into the granite top support rail as shown.
Insert two WOOD DOWELS (O) into the DRAWER BOTTOM RAIL (4).
Fasten the granite top support rail to the RIGHT END (3), using two BOLTS (F).
Hand tighten the BOLTS (F).
PERTH KITCHEN CART WITH GRANITE TOP PERTH KITCHEN CART WITH GRANITE TOP
STEP-BY-STEP INS STRUCTION
A
S
Q
KN
CT
OF
F
F
G
O
G
1
3
4
O
G
K
N
S
N
N
K
A
A
A
A
2
Q
90°
C
W
T
2
W
Lift LEFT END (2) and place on its side. Attach three HOOKS (C) to the LEFT END (2),
using six HOOK BOLTS (T). Hand tighten the HOOK BOLTS.

12 13
STEP 5 STEP 6
REQUIRES B, F, G, O, 3,W, 6, 7, 8
Put together DRAWER BOTTOM SUPPORT RAIL (6), BASE PANEL (8) and DRAWER BACK
SUPPORT RAIL (7) as shown. No tools are needed at this stage.
Insert two WOOD DOWELS (O) into the DRAWER BOTTOM SUPPORT RAIL (6) and
DRAWER BACK SUPPORT RAIL (7).
Insert two HIDDEN CAMS (B) and two WOOD DOWELS (O) into the BASE PANEL (8) as shown.
Insert two BARREL NUTS (G) inside the bottom end of DRAWER BOTTOM SUPPORT
RAIL (6) and DRAWER BACK SUPPORT RAIL (7) as shown.
Fasten the DRAWER BOTTOM SUPPORT RAIL (6), BASE PANEL (8) and DRAWER BACK
SUPPORT RAIL (7) to the RIGHT END (3), using two BOLTS (F).
Hand tighten the BOLTS.
NOTE: Ensure the (B) and BOLTS (F) are in the exact holes.
Ensure all BOLTS are hand tightened.
REQUIRES B, F, G, O,W, 3, 6, 8
Put together two DRAWER BOTTOM SUPPORT RAIL (6) and BASE PANEL (8) as shown.
No tools are needed at this stage.
Insert two WOOD DOWELS (O) into the SUPPORT RAIL (6).
Insert two HIDDEN CAMS (B) and two WOOD DOWELS (O) into the BASE PANEL (8)
as shown.
Fasten two SUPPORT RAIL (6) and BASE PANEL (8) to the RIGHT END (3), using
two BOLTS (F).
Hand tighten the BOLTS .
NOTE: Ensure the Hidden Cams (B) and BOLTS (F) are in the exact holes.
Ensure all BOLTS are tightened.
PERTH KITCHEN CART WITH GRANITE TOP PERTH KITCHEN CART WITH GRANITE TOP
STEP-BY-STEP INS STRUCTION
OFGB
3
8
7
6
F
F
G
B
O
F
W
G
B
OFGB
3
8
6
6
G
B
O
WW
F
F
W
Hidden Cams
Insert two BARREL NUTS (G) inside the bottom end of DRAWER BOTTOM SUPPORT
RAILS (6) as shown.

14 15
STEP 7
STEP 8
REQUIRES 1, 5, 7
Unfold the BACK PANEL (5) and lay it over your unit.
Slide the BACK PANEL (5) into the groove in granite top support rail and
DRAWER BACK SUPPORT RAIL (7) as shown.
REQUIRES B, F, G, O,W, 1, 2, 4, 6, 7, 8
Insert two BARREL NUTS (G) into the granite top support rail as shown.
Insert two WOOD DOWELS (O) into the DRAWER BOTTOM RAIL (4).
Insert two HIDDEN CAMS (B) and two WOOD DOWELS (O) into each BASE PANEL (8) as shown.
Insert two BARREL NUTS (G) inside the bottom end of each DRAWER BOTTOM SUPPORT
RAILS (6) and DRAWER BACK SUPPORT RAIL (7) as shown.
Insert two WOOD DOWELS (O) into the other end of DRAWER BOTTOM SUPPORT RAIL (6) and
DRAWER BACK SUPPORT RAIL (7).
Insert two WOOD DOWELS (O) into the SUPPORT RAILS (6).
Fasten above parts to the LEFT END (2) as shown, using six BOLTS (F).
Hand tighten the BOLTS.
PERTH KITCHEN CART WITH GRANITE TOP PERTH KITCHEN CART WITH GRANITE TOP
STEP-BY-STEP INS STRUCTION
57
1
O
B
F
W
FGB
G
2
8
8
6
6
61
4
O
O
O
F
F
F
F
F
O
G
O
O
B
B
G
G
W
7

16 17
STEP 9 STEP 10
REQUIRES M, R, S, 9
Fasten METAL PLATE (R) to the STORAGE DOOR (9), using one SCREW (S).
Fasten two DOOR HINGES (M) to the STORAGE DOOR (9), using six SCREWS (S).
NOTE: Ensure all screws are in the exact holes.
Ensure all screws are tightened.
PERTH KITCHEN CART WITH GRANITE TOP PERTH KITCHEN CART WITH GRANITE TOP
REQUIRES I, J
Identify two LOCKING WHEELS (I) and two WHEELS (J) for the specific legs.
each leg.
STEP-BY-STEP INS STRUCTION
J
J
I
R
S
S
S
M
M
I
JI
RSM
9

18 19
STEP 12
STEP 11
REQUIRES E, S, P, 9
Attach STORAGE DOOR (9), using six SCREWS (S).
Fasten the DOOR HANDLE (P) to the STORAGE DOOR (9), using one
HANDLE BOLT (E) as shown. Hand tighten the HANDLE BOLT.
REQUIRES A, D, H, Ac, 10, 11, 12, 13
Fasten the DRAWER HANDLE (H) to the DRAWER FRONT (10), using two HANDLE BOLT (Ac).
Hand tighten the SCREWS.
Insert four CAM BOLTS（A）
to DRAWER FRONT (10).
Fasten DRAWER LEFT (11) and DRAWER RIGHT (12) to the DRAWER BACK (13), using
four FLAT HEAD SCREWS (D).
PERTH KITCHEN CART WITH GRANITE TOP PERTH KITCHEN CART WITH GRANITE TOP
STEP-BY-STEP INS STRUCTION
E
P
9
S
S
S
PESADAc H
A
A
D
H
Ac
Ac
10
D11
13
12
