ASSEMBLY INSTRUCTIONS
HAVING TROUBLE?
TOLL-FREE:
1-888-670-6684
IMPORTANT: Please read this manual carefully
before beginning assembly of this product.
Keep this manual for future reference.
BAFFIN
SECTIONAL SET
PRODUCT NO. 088-2273-0

We believe in the power of décor and its
ability to make up the fabric of your home.
That’s why CANVAS® collections draw
inspiration from Canadians and the way
they live.
From on-trend furniture pieces to holiday
décor and all your outdoor living essentials,
CANVAS® makes it easy to refresh your space
your unique style and the way you
live every day.
We would love to hear from you and welcome
your thoughtful feedback. Visit our website
at canadiantire.ca to tell us about your
experience, and share your photos with us
using #mycanvasstyle.
Show us how you bring CANVAS® products
to life. We can’t wait to see!

Table of Contents 3
Parts List - Single Chair 7
Step-by-step Guide 9
Parts List - Corner Chair 12
Step-by-step Guide 15
Instructions for Use 5
Parts List - Square Table 19
Step-by-step Guide 20
Parts List - Rectangular Table 21
Step-by-step Guide 22
Caring for Your Item 23
Warranty 23
TABLE OF CONTENTS
• Please read and understand this entire manual before attempting to assemble,
operate, or install the product.
• The maximum weight capacity for the chair is 225 lb (102 kg) per seat.
The maximum weight capacity for the table is 44 lb (20 kg).
Do not stand on chairs; do not sit or stand on tables.
• Any assembly or maintenance of the product must be carried out by adults only.
• Some parts may contain sharp edges. Wear protective gloves if necessary.
• To prevent damage, place all parts on a level surface during assembly. Add a
layer of protective surface if needed.
WARNING! TO REDUCE THE RISK OF SERIOUS INJURY,
READ THE FOLLOWING SAFETY INSTRUCTIONS BEFORE
ASSEMBLING AND USING THE PRODUCT.
3BAFFIN SECTIONAL SET

TOOLS REQUIRED
Hex Key 2 people
Before beginning assembly of this product be sure all parts are present. Compare parts with
package contents list and hardware contents list. If any part appears to be missing or damaged
do not begin assembly of this product and call customer service immediately.
BAFFIN SECTIONAL SET4

1
2
3
INSTRUCTIONS FOR USE
Total 4 individual arms in this set, arms can be assembled on the single chair freely.
Choose configuration and arm placement before beginning assembly.
NOTE: For some configurations, not all parts can be used. Take care to store these
parts properly for future use.
5BAFFIN SECTIONAL SET

4
6
4
5
6
BAFFIN SECTIONAL SET

PARTS LIST - SINGLE CHAIR
ITEM DESCRIPTION THUMBNAIL QUANTITY
1Chair frame 5
2Chair arm 4
3Seat cushion 5
4Back cushion 5
7BAFFIN SECTIONAL SET

EXPLODED PARTS
1
2
2
3
4
HARDWARE LIST
ITEM DESCRIPTION THUMBNAIL QUANTITY
A
B
Screw M6*40 8
C
Screw M6*20 8
D
Washer 16
Hex Key 1
8BAFFIN SECTIONAL SET

STEP-BY-STEP GUIDE
2X2 1X1
STEP 1
Place the chair frame 1onto a non-abrasive surface, such as
carpet, with its bottom facing upwards. Attach the chair
arms 2to the chair frame 1using screws A, washers Cand
hex key D, aligning the holes on the seat bottom. CX4
DX1
AX4
NOTE:
Do not fully tighten screws
until you have assembled
the chair. Once assembly is
complete, then fully tighten
each screw.
1
2
C
A
2
9
BAFFIN SECTIONAL SET

STEP 2
Fasten the chair arms 2to the chair frame 1through
the holes on the side of the seat panel, using screws B,
washers Cand hex key D.
When assembled, tighten all screws with hex key D.
2
1
2
B
C
CX4
DX1
BX4
NOTE:
Do not fully tighten screws
until you have assembled
the chair. Once assembly is
complete, then fully tighten
each screw.
8
10 BAFFIN SECTIONAL SET

STEP 3
Put seat cushion 3and back cushion 4on the seat, tie
all velcro loops on the frame.
Same steps to assemble the other chairs.
4X1 3X1
4
3
11
STEP-BY-STEP GUIDE
BAFFIN SECTIONAL SET

PARTS LIST
ITEM DESCRIPTION THUMBNAIL QUANTITY
1Chair base 1
2Back panel 2
3Seat cushion 1
4Large back cushion 1
5Small back cushion 1
12 BAFFIN SECTIONAL SET

2
2
3
45
1
EXPLODED PARTS
13
BAFFIN SECTIONAL SET

HARDWARE LIST
ITEM DESCRIPTION THUMBNAIL QUANTITY
A
B
Screw M6*40 6
C
Screw M6*20 20
D
Washer 6
Hex Key 1
ECorner Connector 4
FSingle Chair Connector 6
14 BAFFIN SECTIONAL SET

STEP-BY-STEP GUIDE
2X1 1X1
STEP 1
Place the back panel 2onto a non-abrasive surface, such
as carpet, with its bottom facing upwards. Attach the chair
base 1to the back panel 2using screws A, washers Cand
hex key D, aligning the holes.
When assembled, tighten all screws with hex key D.
CX3
DX1
AX3
NOTE:
Do not fully tighten screws
until you have assembled
the chair. Once assembly is
complete, then fully tighten
each screw.
1
2
C
A
15
BAFFIN SECTIONAL SET

STEP 2
Attach the chair base 1to the other back panel 2using
screws A, washers Cand hex key D, aligning the holes.
When assembled, tighten all screws with hex key D.
1
2
2
X1
CX3 DX1
AX3
NOTE:
Do not fully tighten screws
until you have assembled
the chair. Once assembly is
complete, then fully tighten
each screw.
C
A
16 BAFFIN SECTIONAL SET

STEP 3
Put the seat cushion 3, large back cushion 4and small
back cushion 5on the seat, tie velcro loops of seat
cushion 3on the frame.
5
4
3
4X1 3X1
5X1
17
STEP-BY-STEP GUIDE
BAFFIN SECTIONAL SET

Connect the single chair and corner chair together using
screws Band Corner Chair connector E.
Connect the single chair and single chair together using
screws Band single chair connector F.
EX4
FX4 BX8
E
F
18
USE OF CONNECTOR
BAFFIN SECTIONAL SET
BX8
B
B

PARTS LIST - SQUARE TABLE
ITEM DESCRIPTION THUMBNAIL QUANTITY
1Tile 1
2Table frame 1
3Table leg 4
EXPLODED PARTS
2
1
4x
3
19
BAFFIN SECTIONAL SET

STEP-BY-STEP GUIDE
3X4 2X1
STEP 1
Screw the table legs 3on the table frame 2, aligning the
holes.
STEP 2
Turn the table frame to upright position and carefully put the
tile 1on the table frame.
1X1
3
3
3
3
2
1
