Canvas SUMMERHILL YD-DSC2 User manual

ASSEMBLY INSTRUCTIONS
HAVING TROUBLE?
TOLL-FREE:
1-888 -670 -6684
IMPORTANT: Please read this manual carefully
before beginning assembly of this product.
Keep this manual for future reference.
SUMMERHILL
DAYBED
PRODUCT NO.
088-0606-2
MODEL NO. YD-DSC2

We believe in the power of décor and its
ability to make up the fabric of your home.
That’s why collections draw
inspiration from Canadians and the way
they live.
From on-trend furniture pieces to holiday
décor and all your outdoor living essentials,
makes it easy to refresh your space
your unique style and the way you
live every day.
We would love to hear from you and welcome
your thoughtful feedback. Visit our website
at canadiantire.ca to tell us about your
experience, and share your photos with us
using #mycanvasstyle.
Show us how you bring products
to life. We can’t wait to see!
CANVAS™
CANVAS™
CANVAS™

SUMMERHILL DAYBED3
Parts List 4
Step-by-step Guide
6
7
Caring for Your Item 9
Warranty
TABLE OF CONTENTS
TOOLS REQUIRED
Please read and understand this entire manual before attempting to assemble,
operate, or install the product.
Any assembly or maintenance of the product must be carried out by adults only.
Some parts may contain sharp edges. Wear protective gloves if necessary.
To prevent damage, place all parts on a level surface during assembly. Add a
layer of protective surface if needed.
Due to the nature of steel, surface oxidation (rusting) will occur if this protective
coating is scratched. This is a natural process. To minimize this condition, it is
recommended that care be taken when assembling and handling the product in
order to prevent the paint from being scratched.
WARNING! TO REDUCE THE RISK OF SERIOUS INJURY,
READ THE FOLLOWING SAFETY INSTRUCTIONS BEFORE
ASSEMBLING AND USING THE PRODUCT.
2 people
Hex key
Hardware List
9
Maximum weight limit: 500 lb (226.8 kg).

SUMMERHILL DAYBED 4
PARTS LIST
ITEM DESCRIPTION THUMBNAIL QUANTITY
1
Daybed base
1
2Daybed back
1
3Seat cushion 1
4Back cushion 3

SUMMERHILL DAYBED5
EXPLODED PARTS
1
2
3
4 4 4

SUMMERHILL DAYBED 6
HARDWARE LIST
ITEM DESCRIPTION THUMBNAIL QUANTITY
AM6x40 mm bolt 8
BWasher 8
CHex key 1

SUMMERHILL DAYBED7
STEP-BY-STEP GUIDE
2x 1
Bx 8
1x 1
Ax 8
STEP 1
Place the daybed back 2onto a non-abrasive surface, such
as a carpet.
Cx 1
Fasten the daybed base 1to daybed back 2with bolts
Aand washers B. Tighten all the bolts using hex key C.
1
A
1
1
B
1
1
1
1
2
1

SUMMERHILL DAYBED 8
STEP 2
Turn over the daybed. Place seat cushions
3and back cushion
4onto the daybed.
B C
4x 3 3x 1
3
4
44

WARRANTY INFORMATION
CARING FOR YOUR ITEM
1 3
4 5
OFF SEASON:
5-YEAR LIMITED WARRANTY*
SUMMERHILL DAYBED9
088-0606-2
CLEANING:
2
and a one (1) year warranty
