Canvas Blaire User manual

BLAIRE OFFICE CHAIR
Product No. 068-7859-2
IMPORTANT: Please read this manual carefully before beginning assembly of this product.
Keep this manual for future reference.
ASSEMBLY INSTRUCTIONS

Table of Contents
Table of Contents
Important Safety Instructions
Parts List
Assembly
Technical Specications
Warranty
2
2
3
4
6
6
Warning! To reduce the risk of injury, read the following safety instructions
Use this product only one person at a time.
Do not use this chair unless all bolts, screws and knobs are securely tightened.
Check that all bolts, screws and knobs are tightened every three months or as needed.
Do not overturn back tilt knob when decreasing tension.
Dispose of packing material properly. Do not use plastic cover as head covering,
as it may cause suocation.
Do not use chair as a stepladder.
Use this chair for its intended purpose only.
2
TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS
before assembling.

Parts List
Casters (5)
Cylinder
Seat cushion
Seat plate
Base
Screws (5/16’’ x 20 mm) (4)
Hex wrench
PARTS LIST
3
Product No. 068-7859-2
1
2
3
4
5
8
12
Back cushion
6
Arms
7
Screws (M8 x 50 mm) (4)
10
9
11
Screws (M6 x 25 mm) (4)
Plastic caps (4)

Step 1
Requires 1, 2, 3,
Insert ve casters 1into base 2.
Push hard until you feel or hear the
caster 1 snap into place.
Insert cylinder 3 into base 2.
Step 2
Requires 4, 5, 8, 12,
Attach seat plate 4 to seat cushion 5 with
the arrow towards the front of the chair.
Insert four screws 8 into the seat plate 4.
Fully tighten all screws using hex wrench 12.
Step 3
Requires 1, 2, 3, 4, 5, 8,
Place the seat plate 4 on top of cylinder 3
and apply downward pressure.
Step 4
Requires 1, 2, 3, 4, 5, 6, 8, 9, 12,
Open the velcro on both sides of seat rst,
then place the back cushion 6 on the seat
cushion 5 and use two screws 9 to attach
the lower screw holes on seat cushion 5.
Step 5
Requires 1, 2, 3, 4, 5, 6, 8, 9, 12,
Push the back cushion 6 up to a vertical
position and attach the seat cushion 5
by using two screws 9 then cover the
velcro back.
Step 6
Requires 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12,
Attach arms 7 to seat cushion 5 and back
cushion 6 using four screws 10.
Tighten screws using hex wrench 12,
then cover the caps 11.
Assembly
Model No. 068-7568-8 4
ASSEMBLY
(3)
(2)
(1)
⑻
⑷
⑸
FRONT
( 3 )
( 4 )
⑼
⑼
⑹
⑸
⑼⑼
⑹
⑸
⑺
⑽
⑽

Now your chair is ready for use. Enjoy!
5
ASSEMBLY
ASSEMBLY

Technical Specications
Dimensions (H x W x D)
37 13/32-41 5/16 x 24 13/32 x 25 13/64’’
(95-105 x 62 x 64 cm)
6
WARRANTY
This CANVAS™ product carries a one (1) year warranty against defects in workmanship
and materials.Trileaf Distribution agrees to replace the defective product free of charge
within the stated warranty period,when returned by the original purchaser with proof of
purchase. This product is not guaranteed against wear nor breakage due to misuse and/
or abuse.
TECHNICAL SPECIFICATION
Made in China.
Imported by Trileaf Distribution Trifeuil, Toronto, Canada M4S 2B8
