Canvas Office Landscape Private Office Hutch Installation instructions

Z
© 2014 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
® Y, Zand Canvas Office Landscape are among the registered trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products.
Part no. 1b54fp rev G.
1
Y
Parts Included:
Tools Needed:
Canvas Office Landscape®Private Office Hutch Installation
and Disassembly for Recycling Instructions
Minix Housing (4) Connecting Bolt (4) Trim Cap
Hutch Cabinet
Thin Door (1 or 2) Bin Door (1 or 2)
Hardware Pack
D E F
A
B C
Power Driver Phillips Bit 13/64 Drill Bit
(.196 Dia)
Phillips
Screwdriver
Tape Rule
Safety Glass

Z
© 2014 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
® Y, Zand Canvas Office Landscape are among the registered trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products.
Part no. 1b54fp rev G.
2
1. Drill 2 holes at each end of Work Surface
Using the dimensions given.
2. Install Connecting Bolt (E) into each hole.
11.50
1.50
.196 Dia
(13/64 Dia Drill)
Work Surface
.38 1
EE

Z
© 2014 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
® Y, Zand Canvas Office Landscape are among the registered trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products.
Part no. 1b54fp rev G.
3
2
1. Insert 2 Minix Housings (D) into each End Panel on Hutch Cabinet (A).
2. Set Hutch Cabinet End Panels onto Connection Bolts in Work Surface.
3. Turn Housings a 1/4 turn to lock onto Connection Bolts.
4. Install Trim Caps (F) where visible.
Spreading Bolt
Housing
Housing
Spreading Bolt
A
D
D
FF

Z
© 2014 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
® Y, Zand Canvas Office Landscape are among the registered trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products.
Part no. 1b54fp rev G.
4
3
1. Insert of Thin Door (B) into back groove of Upper Channel. Lower bottom of door into
back groove of Lower Channel.
2. Insert top clips on back of Bin Door (C) into Front Groove of Upper Channel. Snap
bottom clips on back of Bin Door into Front Groove of Lower Channel.
3. Install Tackboard onto Hutch. See instructions for Tackboard (1B57CW) for details.
Upper Channel
Lower Channel
Tackboard
Front Groove
Back Groove
C
B

Z
© 2014 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
® Y, Zand Canvas Office Landscape are among the registered trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products.
Part no. 1b54fp rev G.
5
Disassembly and Recycling:
Materials Identication and Segregation:
Where possible, plastic components are marked with ASTM recycling codes. Use
these codes to identify material type for recycling. Non marked components should
be treated as mixed plastic. Ferrous metals can be identied using a small magnet
for recycling. Non-ferrous metals should be separated and recycled separately.
To disassemble product, reverse the above installation steps:
1. Remove screws from track.
2. Remove track from storage assembly.
Storage Cabinet
Screws
Track

Z
© 2014 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
® Y, Zand Canvas Office Landscape are among the registered trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products.
Part no. 1b54fp rev G.
6
1. Remove screws from door guide.
2. Remove door guides from door.
1. Metal Lock Plug Removal: Insert Universal key into Lock Plug, rotate to unlocked
position. Insert Plug Removal Key into lock. Gently wiggle with light outward pressure.
2. Black Plastic Plug Removal: With Hex Wrench, rotate plug to unlocked position.
Gently pull outward. Be careful not to catch plug on wood surface around lock hole.
3. On units with no lock plug installed, use a athead screwdriver to rotate the adaptor to
the unlock position.
Metal Lock
Plug
Plug Removal
Key
Hex Wrench
Plastic
Plug
Keyed Alike Lock Plug Installation
Door Guide
Bin Door
Screws

Z
© 2014 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
® Y, Zand Canvas Office Landscape are among the registered trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products.
Part no. 1b54fp rev G.
7
1. Pull hard to remove the panels.
Panel
