Canvas ALMA 064-4023-0 User manual

ASSEMBLY INSTRUCTIONS
HAVING TROUBLE?
TOLL-FREE:
1-888-670-6684
IMPORTANT: Please read this manual carefully
before beginning assembly of this product.
Keep this manual for future reference.
PRODUCT NO. 064-4023-0
ALMA 72” MEDIA FIREPLACE

We believe in the power of décor and its
ability to make up the fabric of your home.
That’s why CANVAS™ collections draw
inspiration from Canadians and the way
they live.
From on-trend furniture pieces to holiday
décor and all your outdoor living essentials,
CANVAS™ makes it easy to refresh your space
to re ect your unique style and the way you
live every day.
We would love to hear from you and welcome
your thoughtful feedback. Visit our website
at canadiantire.ca to tell us about your
experience, and share your photos with us
using #myCANVASstyle.
Show us how you bring CANVAS™ products
to life. We can’t wait to see!

3
TABLE OF CONTENTS
When using electrical appliances, basic precautions should always be followed
to reduce the risk of re, electric shock and injury to persons, including the
following:
• If the information in this manual is not followed exactly, an electric shock or re
may result causing property damage, personal injury or loss of life.
• This appliance is hot when in use. To avoid burns, do not let bare skin touch hot
surfaces. Keep combustible material, such as furniture, pillows, bedding, papers,
clothes and curtains, at least 3’ (1 m) from the front of the heater and keep them
away from the sides and rear.
• Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or
tripped over.
• Do not insert or allow foreign objects to enter any ventilation or exhaust
opening as this may cause an electric shock or re, or damage the appliance.
• This appliance has hot and arcing or sparking parts inside. Do not use it in areas
where gasoline, paint or ammable vapours or liquids are used or stored.
This replace should not be used as a drying rack for clothing.
Christmas stockings or decorations should not be hung on it or near it.
WARNING! TO REDUCE THE RISK OF SERIOUS INJURY,
READ THE FOLLOWING SAFETY INSTRUCTIONS BEFORE
ASSEMBLING AND USING THE PRODUCT.
ALMA 72” MEDIA FIREPLACE
Safety Information
Parts List
Exploded Parts
Hardware List
Before You Begin Assembly
Step-by-step Guide
Instructions for Use
Technical Data
Troubleshooting
Warranty Information
4
6
8
9
11
12
37
45
46
47
• Extreme caution is necessary when any heater is used near children or by
individuals with disabilities and whenever the e is left operating and
unattended.

ALMA 72” MEDIA FIREPLACE4
TOOLS REQUIRED
No. 2 Cross-head Screwdriver
Tip Shown Actual Size
2 people
NOTE: Do not overdrill.
Be aware of over-drilling.
SAFETY INFORMATION
IMPORTANT SAFETY INFORMATION
Use this appliance only as described in the manual. Any other use is not recommended
by the manufacturer and may cause re, electric shock or injury to persons. Read all
instructions before installing or using the replace.
1. Read all instructions before using
this heater.
2. Do not use this heater outdoors.
3. This heater is not intended for use in
bathrooms, laundry areas and similar
indoor locations. Never locate the heater
where it may fall into a bathtub or other
water container.
4. Do not run the power cord under
carpeting. Do not cover the power
cord with throw rugs, runners, or the
like. Arrange the power cord away from
tripped over.
5. To disconnect the heater, turn controls to
6. Connect to properly grounded outlets
only. Always plug heaters directly into
a wall outlet/receptacle. Never use with
an extension cord or reloadable power
tap (outlet/power strip).
7. To prevent a possible re, do not block
rebox air intakes or the exhaust in any
8. There is a thermostat limiter inside the
heater. When the inner temperature
overheats or abnormal heating occurs,
the thermostat protective device cuts
damaged or risk of re.
manner. Do not x on
soft surfaces, like a bed, where openings
may become blocked.

5
9. Use this heater only as described
in this manual. Any other use not
recommended by the manufacturer
may cause re, electrical shock,
or injury to persons.
10. If possible, always unplug this
appliance when not in use.
11. Do not operate any heater with
a damaged cord or plug or after
the heater malfunctions.
12. Do not operate any heater if it has
been dropped or damaged in any
manner. Disconnect power at service
panel and have heater inspected by a
reputable electrician before reusing.
13. Any repairs to this replace should
be carried out by a quali ed service
person.
15. This appliance, when installed,
must be electrically grounded in
accordance with local codes, with
the current CSA C22.1 Canadian
Electrical Code or follow the National
Electrical Code, ANSI/NFPA 70.
16. The heater must not be located
immediately below a wall outlet/
receptacle.
17. Do not slide insert on top of wood
to avoid scratching wood surface.
18. Do not place any objects on top of
insert and top air intake vents as this
will cause unit to overheat and can
cause a re.
14. Under no circumstances should this
replace be modi ed. Parts having
to be removed for servicing must
be replaced prior to operating this
replace again.
A 15 A, 120 V, 60 Hz circuit with a properly grounded outlet is required. Preferably,
e should be on a dedicated circuit as other appliances on the same
circuit may cause the circuit breaker to trip or the fuse to blow when the heater is in
operation. The unit comes standard with a 6’ (1.8 m) three-wire cord, exiting from
therear of the . Do not exceed the current rating of the current tap. Always
plug heaters directly into a wall outlet/receptacle. Never use with an extension cord
or relocatable power tap (outlet/power strip).
• This heater is for use on a 120 V outlet. The cord has a plug as shown below.
ALMA 72” MEDIA FIREPLACE

6
PARTS LIST
ITEM DESCRIPTION THUMBNAIL QUANTITY
1Top Panel 1
2Left Side Panel
Left Partition Panel
1
3Right Side Panel
Right Partition Panel
Bottom Panel
Centre Shelf
Drawer Face
Left Door
Right Door
Left Drawer Side
Middle Crossbar
Middle Stile
1
41
51
61
72
81
91
10 1
11 2
12 2
13 2
ALMA 72” MEDIA FIREPLACE

7
PARTS LIST
ITEM DESCRIPTION THUMBNAIL QUANTITY
14 Right Drawer Side
Drawer Back
Drawer Bottom
2
15
16
2
2
Side Back Panel17
19
20
Metal Support Rail
Metal Leg
Metal Support Leg
18
2
2
2
2
21 Drawer Bottom Support 2
ALMA 72” MEDIAFIREPLACE

1
2
3
4
6
7
8
9
10
11
11
12x2
13x2
14x2
15x2
16x2
17
17
18
18
19
19
20
20
21x2
7
5
8
EXPLODED PARTS
ALMA 72” MEDIA FIREPLACE

9
HARDWARE LIST
ITEM DESCRIPTION THUMBNAIL QUANTITY
A 30
B12
G
10
H9
I
4
J4
K
24
Hinge 4
M
N
L
24
4
C
12
D6
E6
F10
Wood Dowel
Handle
Larger Cam Bolt
Larger Cam Lock
Smaller Cam Bolt
Smaller Cam Lock
Screw Ø3.8x35 mm
Screw Ø4x40 mm
Screw Ø4x30 mm
Screw Ø3.5x10 mm
Screw Ø4x12 mm
Extension Slide
Extension Rail with Stopper
ALMA 72” MEDIA FIREPLACE

10
HARDWARE LIST
ITEM DESCRIPTION THUMBNAIL QUANTITY
8
S
U
V
W
X
Y
aa
Z
xx
yy
zz
4
8
2
2
8
16
16
1
2
1
8
2
8
26
Q
O
P
R
Screw Ø3.5x12 mm
Screw Ø3.5x12mm
Screw Ø4.7x12.5 mm
Screw Ø4x10mm
Bolt: M6x30mm
Screw Ø3x16 mm
Anti-Tip Restraint
Wall Anchor
Washer
Bracket
Bracket
Back Panel Connector
Hex Key
Cushioning Cushion
T2
Screw Ø4x20mm
Drawer Connector
ALMA 72” MEDIA FIREPLACE

11
BEFORE YOU BEGIN ASSEMBLY
?
MAKE SURE ALL PARTS ARE PRESENT
Compare all pieces to the parts and hardware lists, and
make sure you have all tools required for assembly.
REMOVE PACKAGING MATERIALS
Place packing materials back in the box. Do not dispose of
packaging materials until assembly is complete.
READ EACH STEP CAREFULLY
Make sure you understand each step. Or if you have any questions,
contact CANVAS™ customer service at 1-888-670-6684 (toll-free).
ASSEMBLE IN A CLEARED AREA
Place all parts from the box on the oor in front of you on a clean,
dry, level surface to protect the product as it is being built.
ALMA 72” MEDIA FIREPLACE

12
STEP-BY-STEP GUIDE
STEP 1
AX12 7X2
A
7
2X1
x2
A
2
B
BX2
Insert four Wood Dowels (A) into the designated holes of Centre Shelf (7).
Repeat for the other Centre Shelf (7).
Securely screw two Cam Bolts (B) and insert four Wood Dowels (A) into the designated
holes of Left Side Panel (2).
ALMA 72” MEDIA FIREPLACE

13
STEP-BY-STEP GUIDE
STEP 2
A
IJ
J
K
3
3X1 AX4 JX2 KX6
B
BX2
J
Securely screw two Cam Bolts (B) and insert four Wood Dowels (A) into the designated
holes of Right Side Panel (3).
Separate Extension Slide (I) from Extension Rail with Stopper (J) as shown,
then attach Extension Rail with Stopper (J) by using three Screws (K) per Rail.
Match those three holes well to assemble slide.
Press locker down to separate the Slide (I) from Rail (J).
ALMA 72” MEDIA FIREPLACE

14
STEP-BY-STEP GUIDE
STEP 3
11 X1 AX6 BX2 4X1
AB
A
4
11
Securely screw two Cam Bolts (B) and insert four Wood Dowels (A) into the designated holes of
Left Partition Panel (4). Insert two Wood Dowels (A) into the holes of Middle Stile (11).
ALMA 72” MEDIA FIREPLACE

15
STEP-BY-STEP GUIDE
STEP 4
A
A
11
J
K
5
IJ
JX2 KX6
B
11 X1 AX6 BX2 5X1
J
Match those three holes well to assemble slide.
Insert two Wood Dowels (A) into the holes of Middle Stile (11).
Securely screw two Cam Bolts (B) and insert four Wood Dowels (A)
into the designated holes of Right Partition Panel (5).
Separate Extension Slide (I) from Extension Rail with Stopper (J) as shown,
then attach Extension Rail with Stopper (J) by using three Screws (K) per Rail.
Press locker down to separate the Slide (I) from Rail (J).
ALMA 72” MEDIAFIREPLACE

11
11
4
H
H
5
16
STEP-BY-STEP GUIDE
STEP 5
5X1 11 X2 HX6 4X1
Attach Middle Stile (11) onto Left Partition Panel (4) by using three Screws (H).
Repeat for Right Partition Panel (5).
ALMA 72” MEDIA FIREPLACE

STEP-BY-STEP GUIDE
STEP 6
17
2
7
C
4
4X1 7X1 CX4 2X1
Attach Left Side Panel (2) and Left Partition Panel (4) to Centre
Shelf (7) by engaging four Cam Locks (C).
Unfinished edge
Unfinished edge
Finished edge
Finished edge
ALMA 72” MEDIA FIREPLACE

18
STEP-BY-STEP GUIDE
STEP 7
7
C
5
3
5X1 7X1 CX4 3X1
Attach Right Side Panel (3) and Right Partition Panel (5) to Centre
Shelf (7) by engaging four Cam Locks (C).
Unfinished edge
Finished edge
Finished edge
Unfinished edge
ALMA 72” MEDIA FIREPLACE

STEP-BY-STEP GUIDE
STEP 8
6X1 GX8
19
5
2
4
6
G
3
Align and attach assembly from Step 6 and assembly from Step 7 to Top of Bottom
Panel (6) by using eight Screws (G).
ALMA 72” MEDIA FIREPLACE
top of bottom panel

20
STEP-BY-STEP GUIDE
STEP 9
18 X2 20 X2 QX18
6
20
20
18
18
Q
Attach Metal Support Rail (18) to Bottom Panel (6) by using five Screws (Q). Repeat for the other
Metal Support Rail (18). Attach two Metal Support Legs (20) on Bottom Panel (6) by using four
Screws (Q) per Leg.
ALMA 72” MEDIA FIREPLACE
