Canvas 088-2278-0 User manual

ASSEMBLY INSTRUCTIONS
HAVING TROUBLE?
TOLL-FREE:
1-888-670-6684 Scan the QR
code for online
assembly
instruction video.
IMPORTANT: Please read this manual carefully
before beginning assembly of this product.
Keep this manual for future reference.
SKYLINE 10'x12' DOUBLE-
TIER GAZEBO
PRODUCT NO. 088-2278-0

We believe in the power of décor and its
ability to make up the fabric of your home.
That’s why CANVAS®collections draw
inspiration from Canadians and the way
they live.
From on-trend furniture pieces to holiday
décor and all your outdoor living essentials,
CANVAS®makes it easy to refresh your space
to reflect your unique style and the way you
live every day.
We would love to hear from you and welcome
your thoughtful feedback. Visit our website
at canadiantire.ca to tell us about your
experience, and share your photos with us
using #mycanvasstyle.
Show us how you bring CANVAS®products
to life. We can’t wait to see!

IMPORTANT
HOW TO USE OUR QR CODES
follow the steps below to scan our QR codes and access helpful assembly videos.
1
Open the
camera on
your smart
device and
point it at
the QR code
2
Wait for the
camera to
recognize
and scan
the QR code
3
Tap the
when it
appears on
screen
LINK
4
The video
will load
automatically
Scan the QR
code for online
assembly
instruction video.

SKYLINE 10'X12' DOUBLE-TIER GAZEBO4
Warnings 4
Required and Recommended Tools 5
Important Safety Information 6
Parts List 7
Hardware List 13
General Preparations 14
Step-By-Step Guide 15
Caring for Your Item 43
Warranty 44
TABLE OF CONTENTS
Caution! Always keep children under close supervision while they are playing
around this product. Never leave children unattended. Keep pets away while
setting up the gazebo.
Caution! Check municipal by-laws prior to installing the gazebo.
• This product is intended for domestic outdoor use only.
• The product should be placed and assembled on flat, horizontal ground.
• Consult with your local governing authority/local municipal codes regarding installation of
temporary structures before assembly.
• Ensure there is enough clearance around the product. Before assembling the gazebo, make
sure to leave a distance of not less than 6’ (1.8 m) from any structures or obstructions, such as
fences, garages, houses, overhanging branches, laundry lines, or electrical wires.
• Anchor the gazebo to the ground with stakes for added safety. Stakes are provided to secure
the gazebo to the ground. If you wish to secure the gazebo to a concrete or wood surface, use
anchors suited for these surfaces (anchors not included). Do not assemble the gazebo on sandy,
muddy or loose soil, as stakes do not have enough anchorage in these types of soil.
• If more than one gazebo is set up, keep a minimum distance of 10’ (3 m) between the gazebos.
• Any assembly or maintenance of the product must be carried out by adults only.
• Make sure there is sufficient manpower when assembling or moving the product.
• Some parts may contain sharp edges. Wear protective gloves if necessary.
• Check all nuts and bolts periodically for tightness. When required, tighten them.
• Repairing and replacing parts should be done by a qualified technician.
• This gazebo is intended for decorative and sunshade purposes only.
• The gazebo is not designed to withstand harsh weather, including high winds, rain and snow.
Always remove the gazebo in such heavy weather conditions, otherwise it might tip over and
cause damage to the product or injuries to bystanders.
• During snow days, remove the snow at the top when the snow is thicker than 4” (10 cm).
• After a period of time, usually in 2–3 months, tighten all the bolts.
• After some time outdoors, the gazebo roof may get dirty. Rinse the top of the gazebo using
water. Do not use harsh cleaning agents.
• Do not hang any weights on the roof frame.
• Do not climb onto the roof of the gazebo. Falling off the gazebo can result in serious injury.
• Use paint of similar colour for touch-ups. It is recommended to use outdoor paint.
WARNING! TO REDUCE THE RISK OF SERIOUS INJURY, READ
THE FOLLOWING SAFETY INFORMATION.

SKYLINE 10'X12' DOUBLE-TIER GAZEBO 5
TOOLS REQUIRED
RECOMMENDED TOOLS
15-Foot Tape
measure
4mm Allen
or Hex bit
Socket wrench with
10mm socket
Cordless drill or
driver with 4mm
Allen head bit
2
people
Driver bit extension
(4-inch recommended)
8-Foot Ladder
(Qty. 2 recommended)

6
• Proper placement of the gazebo is essential. Do not place the product
underneath electrical lines.
• Keep children under close supervision while they are playing around this product.
This product contains small parts which can be swallowed by children.
• Keep fingers away from places where they can be pinched or trapped.
• Do not attempt to assemble the gazebo if any part is missing.
• Do not light any fires inside or near the product!
• Stay calm if fire breaks out. Search for the nearest exit. Do not return tothe
gazebo until the fire department deems it safe.
IMPORTANT: Please read and understand this manual before any assembly.
Before beginning the assembly of product, make sure all parts are available.
Compare parts list with packaging contents. If any part is missing, or if you have
any questions, contact the service centre at 1-888-670-6684 (toll-free). Unpack
and place all the parts from the packaging box in an open area and position them
on the floor. Remove all packing materials and place them back into the box.
Do not dispose of the packing materials until assembly is complete. Read each
step carefully before beginning any assembly and make sure you understand
each step. If you are missing a part, please call our toll-free number for assistance:
1-888-670-6684.
If you have questions regarding your product, require warranty assistance, or
have damaged or missing parts, please call our customer service toll-free helpline.
Contact us for assistance; we’re here to help.
CAUTION!
CAUTION!
LET US HELP YOU! DO NOT RETURN YOUR PRODUCT TO THE STORE.
CALL US FIRST! 1-888-670-6684
Disassemble the gazebo in reverse order of the steps used to assemble.
Always disassemble the gazebo completely. A partially-disassembled gazebo is
not stable enough to resist wind and bad weather, and therefore can be damaged
and/or cause damage.
IMPORTANT: RETAIN FOR FUTURE REFERENCE, AND READ
CAREFULLY.
IMPORTANT SAFETY INSTRUCTIONS
SKYLINE 10'X12' DOUBLE-TIER GAZEBO

7
PARTS LIST
ITEM DESCRIPTION THUMBNAIL QUANTITY
8Short side rafter
branch assembly 2
9Corbel 8
10 Crossbeam support
bracket 4
12 Long side left
roof panel 2
11 Roof corner cap 4
13 Long side right
roof panel 2
1Post leg 4
2Long side
left beam 2
3Long side
right beam 2
4Short side
left beam 2
5Short side
right beam 2
6Corner rafter 4
7Long side rafter
branch assembly 2
SKYLINE 10'X12' DOUBLE-TIER GAZEBO

8
PARTS LIST
ITEM DESCRIPTION THUMBNAIL QUANTITY
21 Edge roof cap
(long & short side) 8
22 Main roof rafter hub 1
23 2nd tier rafter hub 1
25 Foot plate cover 4
24 2nd tier top cover 1
26 Foot plate 4
14 Left middle roof panel
(long & short side) 4
15 Right middle roof panel
(long & short side) 4
16 Left small roof panel
(long & short side) 4
17 Right small roof panel
(long & short side) 4
18 Short side center
roof panel 2
19 Long side center
roof edge cap 2
20 Short side center
roof edge cap 2
SKYLINE 10'X12' DOUBLE-TIER GAZEBO

9
PARTS LIST
ITEM DESCRIPTION THUMBNAIL QUANTITY
34 2nd tier corner cap 4
35 2nd tier long beam 2
36 2nd tier short beam 2
38 2nd tier long side
left roof panel 2
37 2nd tier short side
roof panel 2
39 2nd tier long side
right roof panel 2
27 Beam corner cover 4
28 Beam center cover 4
29 Netting & wall curtain
hook (installed) 8
30 Netting 1
31 2nd tier netting 2
32 Chandelier hook
(weight capacity 25lb) 1
33 2nd tier corner rafter 4
SKYLINE 10'X12' DOUBLE-TIER GAZEBO

10
PARTS LIST
ITEM DESCRIPTION THUMBNAIL QUANTITY
40
41
42
43
Magnet 4
Long fiberglass rod
Short fiberglass rod 2
2
SKYLINE 10'X12' DOUBLE-TIER GAZEBO
Tieback bracket 4

11
EXPLODED PARTS
1
2
3
4
5
9
10
27
28
25
26
43
6
8
22
7
30
31
40
SKYLINE 10'X12' DOUBLE-TIER GAZEBO

33
24
23
36
35
37
34
39
38
32
41
42
12
EXPLODED PARTS
11
16
18
14
12
13
15
17
19
21
20
SKYLINE 10'X12' DOUBLE-TIER GAZEBO

20
20
13
HARDWARE LIST
ITEM DESCRIPTION THUMBNAIL QUANTITY
HNut cap 20
I
J
Stake 8
K
Hex key
2
AM6x10 bolt 12
BM6x15 bolt 198
CM6x40 bolt
DM6x55 bolt 8
E10mm nut with M6 threads 28
FRoof bolt 8
GWasher 20
Wrench
2
SKYLINE 10'X12' DOUBLE-TIER GAZEBO

STEP-BY-STEP GUIDE
14
GENERAL PREPARATIONS
SKYLINE 10'X12' DOUBLE-TIER GAZEBO
• When choosing the location for your gazebo build, plan to have at least 6 feet
(approximately 1.8 meter) of clearance beyond the footprint of the gazebo to allow
for installing parts. This is in conjunction with the Important Safety Instructions.
• It is very important that you install the gazebo on a flat, level surface. A surface that
is not flat and level will make it difficult to square the frame, which will make
assembly more difficult.
• Save your cardboard! You can use the box as padding when assembling the gazebo
to prevent damage to parts during assembly.
• Lay out all parts before beginning assembly and compare the parts you have to the
parts list in this manual. If parts are missing, please call 1-888-670-6684 to have
replacement parts provided to you.
• The hardware pack is designed to make assembly easier. Section 1 has all the tools
and hardware needed for Steps 1-13. Section 2 has all the tools and hardware needed
to complete Steps 14-28. Section 3 contains spare parts should you lose pieces in
Sections 1 or 2.
• Completely read through this assembly manual before beginning assembly so you
can become familiar with the building process.
• To further assist you with building your gazebo, a full assembly video is available
online. We highly recommend viewing the assembly video prior to beginning
assembly. You can watch this video by:
visiting https://qr1.be/W5YW
scanning the QR code at the bottom of this page
• Throughout this manual there are assembly tips that provide best assembly
practices. In many cases these tips also have QR codes that will take you directly to a
video excerpt demonstrating the tip. Instructions on how to use QR codes can be
found on Page 3 of this manual.
Scan the QR
code for online
assembly
instruction video.

15SKYLINE 10'X12' DOUBLE-TIER GAZEBO
NOTE:
Install all bolts by hand loosely
threaded BEFORE fully tightening
any bolts. Once all bolts are installed
loosely, then securethe bolts before
moving on tothe next step.
STEP 1
26
25
B
1
X4
26 X4 BX8
25 X4 1X4
STEP-BY-STEP GUIDESTEP-BY-STEP GUIDE

16
STEP-BY-STEP GUIDESTEP-BY-STEP GUIDE
SKYLINE 10'X12' DOUBLE-TIER GAZEBO
STEP 2
2
3
B
3
A
2
3
X2
2
3X2
BX4
AX8
2X2
NOTE:
Install all bolts by hand loosely
threaded BEFORE fully tightening
any bolts. Once all bolts are installed
loosely, then securethe bolts before
moving on to the next step.
X2
NOTE:
The beam ends have a plastic insert
for easier assembly. This part is
critical for a complete assembly of
your gazebo. If any of your beams
are missing this plasticinsert please
contact us at 1-888-670-6684

17SKYLINE 10'X12' DOUBLE-TIER GAZEBO
STEP 3
5
X2
4
B
5A
4
5
4
NOTE:
Do not install bolts in the
two outer holes marked
with X’s.
AX4 BX4
5X2 4X2
NOTE:
Install all bolts by hand loosely
threaded BEFORE fully tightening
any bolts. Once all bolts are installed
loosely, then securethe bolts before
moving on to the next step.
X2
NOTE:
The beam ends have a plastic insert
for easier assembly. This part is
critical for a complete assembly of
your gazebo. If any of your beams
are missing this plastic insert please
contact us at 1-888-670-6684

18
STEP-BY-STEP GUIDESTEP-BY-STEP GUIDE
SKYLINE 10'X12' DOUBLE-TIER GAZEBO
STEP 4
3
2
4
28
5
2
4
28
28
BX4
3
5
TIP:
Sometimes holes aren't completely aligned.
You can use the hex keys provided to help
you alignbolt holes while threading in the
bolts by hand. For avideo of this method,
scan the QR code provided.
BX12 28 X4
NOTE:
Install all bolts by hand loosely
threaded BEFORE fully tightening
any bolts. Once all bolts are installed
loosely, then securethe bolts before
moving on tothe next step.
X4

19SKYLINE 10'X12' DOUBLE-TIER GAZEBO
STEP 5
X2
Ground
1B C
1
3
2
1
23
CX8 BX8
TIP:
Re-use the cardboard packaging
to prevent damage to parts
during this step. NOTE:
Install all bolts by hand loosely
threaded BEFORE fully tightening
any bolts. Once all bolts are installed
loosely, then securethe bolts before
moving on tothe next step.
X4

20
STEP-BY-STEP GUIDESTEP-BY-STEP GUIDE
SKYLINE 10'X12' DOUBLE-TIER GAZEBO
STEP 6
1
B
4
5
5
4
3
2
2
3
C
X2
NOTE:
Install all bolts by hand loosely
threaded BEFORE fully tightening
any bolts. Once all bolts are installed
loosely, then securethe bolts before
moving on tothe next step.
X2
CX4 BX4
